- Page 1 Indoor Unit Operation & Installation Manual AC092MDERA AC122MDERA AC162MDERA AC182MDERA AC242MDERA AC282MDERA AC302MDERA AC382MDERA AC482MDERA No. 0150538640 • Please read this manual carefully before using. • Keep this operation manual for future reference. Original instructions...
-
Page 2: Table Of Contents
User Manual Contents Parts and Functions................................1 Safety ....................................2 Maintenance ..................................5 Fault Checkup ...................................6 Installation Procedures ..............................7 Electrical Wiring ................................14 Test Run & Fault Code ..............................18 Move and scrap the air conditioning ..........................19 • The indoor unit, suspended to ceiling or standing on floor, renders considerable operating ease and flexibility. •... -
Page 3: Parts And Functions
Parts and Functions Indoor unit Operating Control Panel Wi-Fi Indicator Lamp Human Sensor Operation Control Panel Display Indicator Lamp Cover Plate Emergency Switch Front Panel Remote Receiver Inlet Grill (Filter inside) Note: For the wired control type unit, the unit state should be checked by the wired controller, instead of the remote receiver. -
Page 4: Safety
Safety • If the air conditioner is transferred to a new user, this manual shall be transferred to the user, together with the conditioner. • Before installation, be sure to read Safety Considerations in this manual for proper installation. • The safety considerations stated below is divided into " WARNING"... - Page 5 Safety Items with this warning sign concerning the product's safety and the personal security must be performed strictly. Items with this forbidding sign refer to absolutely forbidden behaviors. If not, they may cause machine damage or endanger operator's personal safety. Clean the filter regularly.
- Page 6 Safety Notices during Operation • It cannot be used for the preservation of food, living creature, precise instrument and artworks, etc, otherwise damage may occur. • Use the fuse with proper capacity. Metal wires and copper wires, etc., may cause fire or other faults. •...
-
Page 7: Maintenance
Maintenance • Only when the air cleaner is switched off and disconnected to the power supply can it be cleaned, or electric shock and injury may appear. Daily Maintenance: Cleaning the air outlet port and the shell: Attention • Don't use gasoline, benzene, diluents, polishing powder or liquid insecticide to clean them. •... -
Page 8: Fault Checkup
Fault Checkup Please check the following when consigning repair service: Symptoms Reasons Water flow sound can be heard when starting operation, during operation or immediately after stopping operation. When it starts to work for 2-3 minutes, Water flow sound the sound may become louder, which is the flowing sound of refrigerant or the draining sound of condensed water. -
Page 9: Installation Procedures
Installation Procedures This manual does not cover all user cases; please contact Haier marketing centers in local places to propose new requirements and clear new doubts and problems. Standard installation tools are recommended according to installation requirements. For information about standard model series accessories, see packing list; other necessary parts to be installed shall be prepared by users as required by installation service network stations. - Page 10 Installation Procedures Open the intake grill (1) Push the embeding switch according to the direction of the arrowhead.(Refer to Figure 2) (2)Turn into the intake grill according to the direction of the arrowhead.(Refer to Figure 3) Figure 3 Figure 2 Remove the Side cover (1) Remove the screw.
- Page 11 Installation Procedures 3. Floor Type Installation When the unit is installed on the floor,Installing CAUTION: drain pipe leading-out direction shown with figure below. them as below: Drain Pipe Correct Wrong Wrong Attention to distance from the unit to household usables or obstacles (as shown with figure).
- Page 12 Installation Procedures (2) Location of ceiling supension bolts Model AC092MDERA AC122MDERA AC162MDERA AC182MDERA AC242MDERA AC282MDERA 1204 AC302MDERA AC382MDERA 1530 AC482MDERA For half-concealed installation Supension-bolt pitch should be as shown below (3) Installing Hanger Bolt Use M10 hanger bolt (prepared on the site) featuring 60mm hole depth, clearance fixed according to size proposed in the air conditioner external view;...
- Page 13 Installation Procedures (5) Air Conditioner Installation Diagram ① Hanger Chain Hook ② Installing Status of Mounting Rack Hanger Bolt Ceiling (Ceiling) ≤40mm Bolt Sleeve Mounting Rack Unit (Wall) Flat Spacer Hexagon Bolt Double Nut Leveling is forbidden after air conditioner is installed; please make adjustment according to diagram indication.
- Page 14 Installation Procedures Attention • For normal drainage, the water drainage piping should be connected according to the installation manual. Heat insulation should be performed to avoid condensation. Improper pipe connection may cause water going into the machine. Requirements: • Heat insulating treatment should be made for the water drainpipes of the indoor units. •...
- Page 15 Installation Procedures Tubing Permissible Length & Height Difference Please refer to the attached manual of outdoor units. Tubing Permissible Length & Height Difference Model AC092MDERA AC122~182MDERA AC242~482MDER Gas pipe Ø9.52 Ø12.7 Ø15.88 Tubing Size (mm) Liquid pipe Ø6.35 Ø6.35 Ø9.52...
-
Page 16: Electrical Wiring
Electrical Wiring WARNING • Electrical construction should be made with specific mains circuit by the qualified personnel according to the installation instruction. Electric shock and fire may be caused if the capacity of power supply is not sufficient. • During arranging the wiring layout, specified cables should be used as the mains line, which accords with the local regulations on wiring. - Page 17 Electrical Wiring Signal Wiring Drawing (This machine) (AC machine) (AC machine) (DC machine) Outdoor units are of parallel connection via three lines with polarity. The main unit, central control and all indoor units are of parallel connection via two lines without polarity. There are three connecting ways between line control and indoor units: A.One line control controls multiple units, i.e.
- Page 18 Electrical Wiring The wiring for the power line of indoor unit, the wiring between indoor and outdoor units as well as the wiring between indoor units: Items Cross Sectional Rated current of residual Rated Area of Signal Line Cross Circuit Breaker(A) Length Current of Section...
- Page 19 Electrical Wiring (B) Definition and description of SW03 Set the address with wired controller or automatism (default) Manner of set SW03_1 address Set the address with dip switch Address of centralized Address of indoor unit controller 0# (Default) 0# (Default) Set the Communication SW03_2...
-
Page 20: Test Run & Fault Code
Test Run & Fault Code Before Test Run • Before switching it on, test the supply terminal tier (L, N terminals) and grounding points with 500V megaohm meter and check if the resistance is above 1MΩ. It can't be operated if it is below 1MΩ. •... -
Page 21: Move And Scrap The Air Conditioning
Move and scrap the air conditioning • When moving, to disassemble and re-install the air conditioning, please contact your dealer for technical support. • In the composition material of air conditioning, the content of lead, mercury, hexavalent chromium, polybrominated biphenyls and polybrominated diphenyl ethers are not more than 0.1% (mass fraction) and cadmium is not more than 0.01% (mass fraction). - Page 24 Qingdao Haier Air Conditioner Electric Co.,Ltd. Haier Industrial Park,Qianwangang Road,Eco-Tech Development Zone,Qingdao 266555, Shandong,P.R.C.
