  • Page 1 ADS 525X Quick Start Guide (en-US)

  • Page 2: Safety Precautions

    | 2 | Quick Start Guide| ADS 525X Safety Precautions • To reduce risk of injury, charge only Bosch Automotive Service Solutions, Inc. supplied rechargeable batter- ies for the ADS 625 product with the supplied charger. BEFORE OPERATING THIS TOOL, ALL OPERATORS SHOULD...

  • Page 3: General Information

    ADS 525X| Quick Start Guide | 3 | en-US General Information Introduction TOP VIEW 10:22 Connected Main Menu Diagnostics QuickScan Generic OBDII Repair-Source Diagnostic Information Wiring Diagrams Saved Reports Web Browser Coverage Guide Video Tutorials What’s New Settings Apps Shortcut BOTTOM VIEW 1.

  • Page 4: Battery Charging

    | 4 | Quick Start Guide| ADS 525X Setup Battery Charging. Connect the handset to AC power and fully charge the battery. Handset USB Power Block and Charging Cord When the handset is turned on, the level of battery charge is indicated in the upper right corner of the screen.
  • Page 5 ADS 525X| Quick Start Guide | 5 | en-US Press the power button to Battery Life Tips turn on the handset. The Handset is an Android based touch screen tablet. The battery life icon shows charge level. The scan tool...
  • Page 6 If you are not sure that you are authorized by your employer to accept this Agreement, take this package to a principal in your firm before proceeding. This Agreement is a legally binding document setting forth the menner by which you may use the Bosch Automotive Service Solutions Inc. (”Bosch”) software that is Valued embedded on the Bosch device and any assoociated media, printed materials and electronic documentation (collectively “Software Product”) Carefully read the terms and conditions of this Agreement before using this...

  • Page 7: Setup Printer

    ADS 525X| Quick Start Guide | 7 | en-US 10. Connect the VCI to the rt0008 vehicle. Step 6 of 7 - Activate Warranty Activate Warranty rt00001 ValuedCustomer@gmail.com 123-555-1234 5678 Shop Lane Address 2 (optional) Detroit Michigan 48260 E0VTOW0000000000GR Confirm Info Enter contact information.
  • Page 8 | 8 | Quick Start Guide| ADS 525X c. If VCI Connection Manager icon shows “No connection,” select the VCI Connection Manager icon. rt0011 10:22 Connected Main Menu Diagnostics QuickScan Generic OBDII Repair-Source Diagnostic Information Wiring Diagrams Saved Reports...
  • Page 9 ADS 525X| Quick Start Guide | 9 | en-US ss02876 Power port (used when necessary) DLC/OBDII cable port Power Indicates the VCI has received power. PC Connection Indicates the VCI is communicating with the PC. Vehicle Connection Indicates the VCI is communicating with vehicle.

  • Page 10: Diagnostics Button

    | 1 0 | Quick Start Guide| ADS 525X Main Menu Coverage Guide button Access vehicle coverage button. rt0012 10:22 Connected 10. Video Tutorials button Main Menu Access video tutorial files on scan tool QuickScan Diagnostics use. Generic OBDII Repair-Source 11.

  • Page 11: Selecting Vehicle

    ADS 525X| Quick Start Guide | 11 | en-US Selecting Vehicle Allows the user to enter a new vehicle or view Recent Vehicles previously selected. Select the “Select Vehicle” button then enter a vehicle one of four ways: rt0013 10:22...
  • Page 12 | 1 2 | Quick Start Guide| ADS 525X AutoID® • Automatically selects the vehicle using rt0014 OBD II Mode 9. 10:22 Connected • Identifies vehicles to quickly set up year, Select Vehicle Main Menu Choose vehicle selection method: make, model, and engine.

  • Page 13: Diagnostic Functions

    ADS 525X| Quick Start Guide | 13 | en-US Diagnostic Functions Enhanced Vehicle Scan Access to scan all available controllers After selecting a vehicle the user will be on the selected vehicle for Modes 1-7. able to begin using diagnostic functions on the vehicle.

  • Page 14: Software Updates

    | 1 4 | Quick Start Guide| ADS 525X Features Software Updates OBDII/DLC Cable Software Updates: Periodically, updates will become available and the user The OBDII/DLC cable has a LED lamp to will be notified through a message locate vehicle DLC and voltmeter that on the screen.
  • Page 15 ADS 525X| Quick Start Guide | 15 | en-US AutoDetect® How to Power Off ADS 525X The new user interface utilizes graphic a. Press and release the power “badges” to illustrate when critical button. information is found. AutoDetect® automatically detects vehicle-specific...
  • Page 16 Bosch Automotive Service Solutions, Inc. 655 Eisenhower Drive Owatonna, MN 55060 USA Phone: 1-855-267-2483 Option 1 www.boschdiagnostics.com 1699502643 Rev B...
