LG OLED88ZXPUA Service Manual
  1. Manuals
  2. Brands
  3. LG Manuals
  4. OLED TV
  5. OLED88ZXPUA
  6. Service manual

LG OLED88ZXPUA Service Manual

Chassis : eax1z
Hide thumbs

Advertisement

Quick Links

Download this manual
OLED TV
SERVICE MANUAL
CHASSIS : EAX1Z
MODEL : OLED88ZXPUA
CAUTION
BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
P/NO : MFL71717001 (2003-REV00)
Any reproduction, duplication, distribution (including by way of email, facsimile or other electronic means),
publication, modification, copying or transmission of this Service Manual is STRICTLY PROHIBITED unless you
have obtained the prior written consent of the LG Electronics entity from which you received this Service Manual.
The material covered by this prohibition includes, without limitation, any text, graphics or logos in this Service
Manual.
Copyright © 2020 LG Electronics Inc. All rights reserved. Only training and service purposes.
