EN
1 )
Input voltage range: 85 ... 264 V AC / 47 ... 63 Hz / 1 Ph. / PE
2)
Mains cable 3 x 0.75 mm2 with safety plug and PE conductor
Cable length 2.5 m, cable type H05VV-F 3G0.75
connection line according to HD21.5, HD21.12 (VDE 0281-5, VDE 0281-12)
The line conforms to Regulation (EC) No. 1907/2006 (REACH) and EC Directive 2002/95/EC (RoHS) as well as the
EC Low Voltage Directive 2006/95/EC.
Two-pin plug with PE conductor
Rate voltage for plug:
Rated current for plug:
Manufacturing regulation CEE 7 standard sheet VII, VDE 0620
3)
IP 44 according to EN 60529
IP
International Protection
4
Protection against access to hazardous parts with a wire (Ø 1.0 mm).
Protection against access to hazardous parts with foreign objects Ø ≥ 1.0 mm.
4
Protection against splashing water.
4)
Type:
Rated voltage:
Capacitance:
Max. continuous current:
Diameter:
Height:
Weight:
Operating temperature:
5)
BEKO sensors
Digital BEKO sensors for pressure dew point and consumption with RS485 interface,
Series: DPM SD23, FLM SFxx
Digital BEKO sensors for dew point and consumption with SDI interface,
Series: DP 109, DP 110, FS 109, FS 211
Analogue BEKO sensors preconfigured for pressure, temperature, consumption, current clamp,
Series: DPM, PRM, FLM
Sensors with analog signals: 0/4 – 20 mA, 0 - 1/10/30 V, pulse, Pt100, Pt1000
CE conformity
1
EMC Directive
Low voltage directive
RoHS II Directive
2
EMC immunity; industrial applications
EMC emission, group 1, class B
Electrical equipment for measurement, control and
laboratory use
1) CE Mark applied according to Low Voltage Directive 2006/95/EC
2) The terms of Directive 2011/65/EU on the Restriction of the use of certain hazardous substances in electrical and
electronic devices are fulfilled.
METPOINT
BDL compact
®
250 V
16 A
Lithium manganese dioxide battery, Panasonic CR2032
3 V
225 mAh
0,2 mA
20 mm
3,2 mm
2,9 g
-30 ... +60 °C
2004/108/EC
2006/95/EC
2011/65/EU
EN 61326-1 & EN 61326-2-3
EN 61326-1
EN 61010-1
Installation and operating manual
11
