HISTORY INFORMATION FOR THE FOLLOWING MANUAL:
SERVICE MANUAL
ORIGINAL MANUAL ISSUE DATE: 10/2012
Version
Date
1.0
10/2012
2.0
10/2012
3.0
11/2012
4.0
03/2014
5.0
07/2014
Subject
Original manual issue.
Added models KDL-84X9000(AF/AUS) and KD-84X9005(AEP).
Added pages of SEC1. DISASSEMBLY, APPENDIX-1 and APPENDIX-2.
Added models KD-84X9000(HK/WB) and XBR-84X905(LA6).
Added LCD PANEL KIT and pages of APPENDIX-3. Updated Parts List.
Corrected Parts List. (P.110)
AZ3SR
CHASSIS
Segment: FS-H
LCD Digital Color TV
9-888-517-05

Advertisement

Table of Contents
loading

Related Manuals for Sony KD-84X9000

Summary of Contents for Sony KD-84X9000

  • Page 1 Original manual issue. 10/2012 Added models KDL-84X9000(AF/AUS) and KD-84X9005(AEP). Added pages of SEC1. DISASSEMBLY, APPENDIX-1 and APPENDIX-2. 11/2012 Added models KD-84X9000(HK/WB) and XBR-84X905(LA6). 03/2014 Added LCD PANEL KIT and pages of APPENDIX-3. Updated Parts List. 07/2014 Corrected Parts List. (P.110)
  • Page 2 SERVICE MANUAL AZ3SR CHASSIS Segment: FS-H LCD Digital Color TV 9-888-517-05...

  • Page 3: Model List

    RM-SD016 CHINA XBR-84X900 Black RM-YD086 US/CND RM-YD084 KD-84X9000 Black RM-GD025 MEXICO AFRICA AUSTRALIA XBR-84X905 Black RM-YD085 INDIA CHILE MIDDLE EAST PERU SOUTH EAST ASIA VENEZUELA BRAZIL KD-84X9000 Black RM-GD025 HONG KONG KD-84X9000 Black RM-CD017 TAIWAN KD-84X9005 Black RM-ED051 XBR/KD-84X9000 Series(WW)

  • Page 4: Warnings And Cautions

    Components identified by shading and ! mark on the schematic diagrams, exploded views, and in the parts list are critical for safe operation. Replace these components with Sony parts whose part numbers appear as shown in this manual or in supplements published by Sony. Circuit adjustments that are critical for safe operation are identified in this manual.
  • Page 5 Les composants identifi es par une trame et par une marque ! sur les schemas de principe, les vues explosees et les listes de pieces sont d’une importance critique pour la securite du fonctionnement. Ne les remplacer que par des composants Sony dont le numero de piece est indique dans le present manuel ou dans des supplements publies par Sony. Les reglages de circuit dont l’importance est critique pour la securite du fonctionnement sont identifi es dans le present manuel.

  • Page 6: Use Caution When Handling The Lcd Panel

    Use care when handling the wires or connectors of the inverter circuit. Damaging the wires may cause a short. Protect the panel from ESD to avoid damaging the electronic circuit (C-MOS). 10) It is recommended not to exceed 1 hour of Power-On nor Burn-in period with LCD panel face down condition, in repair activity. XBR/KD-84X9000 Series(WW)

  • Page 7: Safety Check-Out

    6. Check the line cords for cracks and abrasion. Recommend the replacement of any such line cord to the customer. 7. Check the antenna terminals, metal trim, “metallized” knobs, screws, and all other exposed metal parts for AC leakage. Check leakage as described below. 8. For safety reasons, repairing the Power board and/or Inverter board is prohibited. XBR/KD-84X9000 Series(WW)
  • Page 8 Try both slots, if necessary, to locate the hot side on the line; the lamp should light at normal brilliance if the screw is at ground potential (see Figure B). XBR/KD-84X9000 Series(WW)

  • Page 9: Self Diagnosis Function

    Temp. sensor I2C NACK Software Error (Also the main board• fs memory or Wi-Fi module is a suspect) Not used Not used CV3 FPGA device(Calvados) initialization failure CV_ERR HDMI equalizer I2C NACK on CV3 board ON_OUT_ER VBO LOCK Error XBR/KD-84X9000 Series(WW)

  • Page 10: Self-Diagnostic Screen Display

    ---------- ---------- ---------- 00 102 MEPS_WDT ---------- ---------- ---------- 00 CPU Watch-dog timer 103 HOST_WDT ---------- ---------- ---------- 00 104 STBY_WDT ---------- ---------- ---------- 00 0081-00671-00088 Panel operation time by hour (MAX:65535) Boot count (MAX:65535) Total operation time by hour (MAX:65535) XBR/KD-84X9000 Series(WW)
  • Page 11 Press the Channel 7 => Channel 0 . Exiting the Self-diagnostic screen To exit the Self Diagnostic screen, turn off the power to the TV by pressing the POWER button on the remote or the POWER button on the TV. XBR/KD-84X9000 Series(WW)

  • Page 12: Sec 1. Disassembly

    SEC 1. DISASSEMBLY • There are clutch in the yellow frame[ ]. Therefore please be careful in the case of the disassembly or assembly of parts. XBR/KD-84X9000 Series(WW)
  • Page 13 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 HOTEL COVER HOTEL COVER HOTEL COVER HOTEL COVER XBR/KD-84X9000 Series(WW)
  • Page 14 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 SUPPORT COVER(L) R AND SUPPORT COVER(L) L <A> SUPPORT COVER(L) R SUPPORT COVER(L) R <A> <B> <B> SUPPORT COVER(L) L SUPPORT COVER(L) L XBR/KD-84X9000 Series(WW)

  • Page 15: Stand Assy

    DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 STAND ASSY 4 Screws (SCREW, +PSW M5X20) P/N: 3-452-815-01 STAND ASSY XBR/KD-84X9000 Series(WW)
  • Page 16 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 NECK A(L) R, NECK A(L) L AND BASE A NECK A(L) L NECK A(L) R <A> <B> <A> <B> BASE A 8 Screws (SCREW, ORNAMETAL M6X20) P/N: 4-436-624-01 XBR/KD-84X9000 Series(WW)
  • Page 17 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 SPEAKER BOX ASSY L AND BRACKET SP A SPEAKER BOX ASSY L BRACKET SP A (LT) 2 Screws (SCREW, -FWH M5X14) P/N: No Service 2 Screws (SCREW, +PSW M5X12) P/N: 2-580-607-01 BRACKET SP A (LB) XBR/KD-84X9000 Series(WW)
  • Page 18 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 SPEAKER BOX ASSY R AND BRACKET SP A SPEAKER BOX ASSY R BRACKET SP A (RT) 2 Screws (SCREW, -FWH M5X14) P/N: No Service 2 Screws (SCREW, +PSW M5X12) P/N: 2-580-607-01 BRACKET SP A (RB) XBR/KD-84X9000 Series(WW)
  • Page 19 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 COVER SCREW TOP AND COVER SCREW BOTTOM COVER SCREW TOP COVER SCREW BOTTOM(R) COVER SCREW BOTTOM(L) XBR/KD-84X9000 Series(WW)
  • Page 20 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 REAR COVER A(REA)-1 REAR COVER A(REA) 11 Screws (SCREW, +BVTP 4X12 TYPE2 IT-3) P/N: 2-580-639-01 15 Screws (SCREW, +FWH M4) P/N: 4-432-981-01 4 Screws (SCREW, ORNAMENTAL M6X12) P/N: 4-268-126-02 XBR/KD-84X9000 Series(WW)
  • Page 21 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 REAR COVER A(REA)-2 REAR COVER A(REA) REAR COVER A(REA) XBR/KD-84X9000 Series(WW)
  • Page 22 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 REAR COVER FRAME ASSY 17 Screws (SCREW, +FWH M4) P/N: 4-432-981-01 REAR COVER FRAME ASSY XBR/KD-84X9000 Series(WW)
  • Page 23 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 FRAME JOINT BTM (R) ASSY 1 Screw (SCREW, +PSW M4X8) P/N: 2-580-600-01 FRAME JOINT BTM (R) ASSY XBR/KD-84X9000 Series(WW)
  • Page 24 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 SHEET SP CON, SP3 BOARD AND FRAME JOINT BTM (R) SHEET SP CON SP BOARD 2 Screws (SCREW (+PSW) (M3X6)) P/N: 2-990-421-41 SP BOARD FRAME JOINT BTM (R) XBR/KD-84X9000 Series(WW)
  • Page 25 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 FRAME JOINT BTM (L) ASSY 1 Screw (SCREW, +PSW M4X8) P/N: 2-580-600-01 FRAME JOINT BTM (L) ASSY XBR/KD-84X9000 Series(WW)
  • Page 26 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 SHEET SP CON, SP3 BOARD AND FRAME JOINT BTM (L) SHEET SP CON SP BOARD 2 Screws (SCREW (+PSW) (M3X6)) P/N: 2-990-421-41 SP BOARD FRAME JOINT BTM (L) XBR/KD-84X9000 Series(WW)
  • Page 27 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 FRAME JOINT TOP FRAME JOINT TOP FRAME JOINT TOP FRAME JOINT TOP 8 Screws (SCREW, +PSW M4X8) P/N: 2-580-600-01 XBR/KD-84X9000 Series(WW)
  • Page 28 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 FRAME JOINT TOP (L) AND FRAME JOINT TOP (R) FRAME JOINT TOP (L) FRAME JOINT TOP (R) FRAME JOINT TOP (L) FRAME JOINT TOP (R) 4 Screws (SCREW, +PSW M4X8) P/N: 2-580-600-01 XBR/KD-84X9000 Series(WW)
  • Page 29 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 SIDE REAR COVER A(L) AND SIDE REAR COVER A(R) SIDE REAR COVER A(L) SIDE REAR COVER A(R) XBR/KD-84X9000 Series(WW)
  • Page 30 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 TOP REAR COVER A(L) AND TOP REAR COVER A(R) TOP REAR COVER A(L) TOP REAR COVER A(R) XBR/KD-84X9000 Series(WW)
  • Page 31 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 FRAME BTM CORNER(L) AND FRAME BTM CORNER(R) FRAME BTM CORNER(L) FRAME BTM CORNER(R) 4 Screws (SCREW, +PSW M4X8) P/N: 2-580-600-01 FRAME BTM CORNER(R) FRAME BTM CORNER(L) XBR/KD-84X9000 Series(WW)
  • Page 32 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 FRAME(L), FRAME(R), FRAME TOP CORNER AND FRAME(C) FRAME(L) FRAME(L) 8 Screws (SCREW, +PSW M4X8) P/N: 2-580-600-01 FRAME TOP CORNER FRAME TOP CORNER FRAME(C) XBR/KD-84X9000 Series(WW)
  • Page 33 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 UNDER COVER A (REA) UNDER COVER A (REA) 5 Screws (SCREW, +FWH M4) P/N: 4-432-981-01 UNDER COVER A (REA) XBR/KD-84X9000 Series(WW)
  • Page 34 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 BRACKET VESA (REA) BRACKET VESA (REA) 2 Screws (SCREW, +PSW M8X15) P/N: 4-433-509-01 BRACKET VESA (REA) 2 Screws (SCREW, +PSW M8X15) P/N: 4-433-509-01 XBR/KD-84X9000 Series(WW)
  • Page 35 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 HTL2 BOARD/RU3 BOARD 2 Screws (SCREW (+PSW) (M3X6)) P/N: 2-990-421-41 HTL2 BOARD / RU3 BOARD BRACKET, HTL2 BRACKET, HTL2 HTL2 BOARD / RU3 BOARD XBR/KD-84X9000 Series(WW)
  • Page 36 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 AC INLET AND HOLDER, AC INLET 7 Screws (SCREW (+PSW) (M3X6)) P/N: 2-990-421-41 1 Screw (SCREW, +PSW M4X8) P/N: 2-580-600-01 AC INLET AC INLET AC INLET HOLDER, AC INLET 2 Screws (SCREW (+PSW) (M3X6)) P/N: 2-990-421-41 HOLDER, AC INLET...
  • Page 37 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 SWITCH UNIT AND BRACKET SW (REA) SWITCH UNIT SWITCH UNIT BRACKET SW (REA) 2 Screws (SCREW (+PSW) (M3X6)) P/N: 2-990-421-41 XBR/KD-84X9000 Series(WW)
  • Page 38 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 HARNESS ASSY, CONNECTOR ASSY AND FFC CONNECTOR ASSY HARNESS ASSY (MAIN) HARNESS ASSY (G17) FLEXIBLE FLAT CABLE 51P FLEXIBLE FLAT CABLE 68P CORD, CONNECTION (HDMI CABLE) XBR/KD-84X9000 Series(WW)
  • Page 39 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 CONNECTOR ASSY AND FFC CONNECTOR ASSY 20P FFC WITH CONNECTOR FLEXIBLE FLAT CABLE 51P CONNECTOR ASSY 5P FLEXIBLE FLAT CABLE 41P FLEXIBLE FLAT CABLE 20P XBR/KD-84X9000 Series(WW)
  • Page 40 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 ANTENNA <A> ANTENNA 1 Screw (SCREW (+PSW) (M3X6)) P/N: 2-990-421-41 <A> <B> ANTENNA <B> 1 Screw (SCREW (+PSW) (M3X6)) P/N: 2-990-421-41 XBR/KD-84X9000 Series(WW)

  • Page 41: Wireless Lan Card

    DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 WIRELESS LAN CARD WIRELESS LAN CARD 2 Screws (SCREW (+PSW) (M3X6)) P/N: 2-990-421-41 WIRELESS LAN CARD WIRELSS LAN CARD XBR/KD-84X9000 Series(WW)
  • Page 42 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 FRAME, BOTTOM (REA) HOLDER, RF 2 Screws (SCREW, +BVTP 4X12 TYPE2 IT-3) P/N: 2-580-639-01 6 Screws (SCREW, +PSW M4X10) P/N: 4-159-298-01 HOLDER, RF XBR/KD-84X9000 Series(WW)
  • Page 43 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 G16 BOARD AND F BOARD G16 BOARD G16 BOARD 6 Screws (SCREW (+PSW) (M3X6)) P/N: 2-990-421-41 F BOARD F BOARD 4 Screws (SCREW (+PSW) (M3X6)) P/N: 2-990-421-41 XBR/KD-84X9000 Series(WW)
  • Page 44 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 SPACER (B) Note: Do NOT mount G16 and F board to Panel without Spacers. XBR/KD-84X9000 Series(WW)
  • Page 45 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 G17 BOARD G17 BOARD G17 BOARD 5 Screws (SCREW (+PSW) (M3X6)) P/N: 2-990-421-41 1 Screw (SCREW, +PSW M4X8) P/N: 2-580-600-01 G17 BOARD G17 BOARD 5 Screws (SCREW (+PSW) (M3X6)) P/N: 2-990-421-41 1 Screw (SCREW, +PSW M4X8) P/N: 2-580-600-01...
  • Page 46 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 SPACER (B) Note: Do NOT mount G17 board to Panel without Spacers. XBR/KD-84X9000 Series(WW)
  • Page 47 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 BRACKET (TOP), F AND BRACKET (BOTTOM), F 4 Screws (SCREW (+PSW) (M3X6)) P/N: 2-990-421-41 BRACKET (TOP), F BRACKET (BOTTOM), F XBR/KD-84X9000 Series(WW)
  • Page 48 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 BRACKET, G BRACKET G 4 Screws (SCREW (+PSW) (M3X6)) P/N: 2-990-421-41 BRACKET G XBR/KD-84X9000 Series(WW)
  • Page 49 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 SHEET, INSULATION (F) AND SHEET, INSULATION (G17) SHEET, INSULATION (F) SHEET, INSULATION (G17) XBR/KD-84X9000 Series(WW)
  • Page 50 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 BRACKET, UNDER ASSY BRACKET, UNDER ASSY XBR/KD-84X9000 Series(WW)
  • Page 51 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 BRACKET, SIDE BRACKET, SIDE BRACKET, SIDE XBR/KD-84X9000 Series(WW)
  • Page 52 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 BAPS BOARD 6 Screws (SCREW (+PSW) (M3X6)) P/N: 2-990-421-41 BAPS BOARD XBR/KD-84X9000 Series(WW)
  • Page 53 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 SHIELD (CV) AND CV3 BOARD 7 Screws (SCREW (+PSW) (M3X6)) P/N: 2-990-421-41 SHIELD (CV) CV3 BOARD CV3 BOARD XBR/KD-84X9000 Series(WW)
  • Page 54 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 SHEET, RADIATION (CV) INFORMATION CV3 BOARD XBR/KD-84X9000 Series(WW)
  • Page 55 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 BRACKET, WIFI AND BRACKET, MAIN 11 Screws (SCREW (+PSW) (M3X6)) P/N: 2-990-421-41 BRACKET, MAIN BRACKET, WIFI XBR/KD-84X9000 Series(WW)
  • Page 56 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 SHEET, THERMAL (Atreyu) AND SHEET THERMAL (WiFi) INFORMATION BRACKET, MAIN XBR/KD-84X9000 Series(WW)
  • Page 57 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 P3L BOARD, SHIELD (P3L) AND HEATSINK (PHOTO) 7 Screws (SCREW (+PSW) (M3X6)) P/N: 2-990-421-41 1 Screw (SCREW, DAMPER M3) P/N: 4-444-146-01 HEATSINK (PHOTO) SHIELD (P3L) P3L BOARD 4 Screws (SCREW (+PSW) (M3X6)) P/N: 2-990-421-41 XBR/KD-84X9000 Series(WW)
  • Page 58 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 SHEET RADIATION (FPGA), (PPL), (PPL, HS1) INFORMATION SHIELD (P3L) P3L BOARD P3L BOARD SHIELD (P3L) SHIELD (P3L) P3L BOARD XBR/KD-84X9000 Series(WW)
  • Page 59 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 HEATSINK (ON) AND ON3 BOARD 8 Screws (SCREW, DAMPER M3) P/N: 4-444-146-01 HEATSINK (ON) ON3 BOARD ON3 BOARD ON3 BOARD 8 Screws (SCREW (+PSW) (M3X6)) P/N: 2-990-421-41 XBR/KD-84X9000 Series(WW)
  • Page 60 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 SHEET, RADIATION (ON) INFORMATION ON3 BOARD ON3 BOARD XBR/KD-84X9000 Series(WW)
  • Page 61 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 BRACKET PANEL-1 <A> BRACKET PANEL BRACKET PANEL <A> <B> <B> BRACKET PANEL BRACKET PANEL XBR/KD-84X9000 Series(WW)
  • Page 62 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 BRACKET PANEL-2 BRACKET PANEL <A> <B> <C> <D> <A> BRACKET PANEL <B> BRACKET PANEL <C> BRACKET PANEL <D> XBR/KD-84X9000 Series(WW)
  • Page 63 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 BRACKET PANEL BRACKET PANEL-3 BRACKET PANEL <A> <A> <B> BRACKET PANEL BRACKET PANEL <B> XBR/KD-84X9000 Series(WW)
  • Page 64 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 NOTICE WHEN INSTALL THE PANEL BRACKET Confirm that panel bracket does not fall out by pulling it to arrow mark direction. XBR/KD-84X9000 Series(WW)
  • Page 65 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 LABEL, PANEL AND SHEET AL S2 LABEL, PANEL LABEL, PANEL SHEET AL S2 LABEL, PANEL XBR/KD-84X9000 Series(WW)

  • Page 66: Harness Assy

    DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 HARNESS ASSY HARNESS ASSY (LS-L1) HARNESS ASSY (LS-S) HARNESS ASSY (LS-L2) XBR/KD-84X9000 Series(WW)
  • Page 67 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 LD BOARD AND SHEET, INSULATION (LD) LD BOARD 6 Screws (SCREW (+PSW) (M3X6)) P/N: 2-990-421-41 LD BOARD INSULATION (LD) XBR/KD-84X9000 Series(WW)

  • Page 68: Remove Screws

    DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 REMOVE SCREWS 4 Screws (SCREW, POSITIONING M4X6) P/N: 4-433-510-01 XBR/KD-84X9000 Series(WW)
  • Page 69 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 BRACKET BOTTOM ASSY, HL BOARD, TAPE PWB HL (S) AND TAPE PWB HL (L) BRACKET BOTTOM ASSY HL BOARD BRACKET BOTTOM ASSY TAPE PWB HL (L) TAPE PWB HL (S) HL BOARD XBR/KD-84X9000 Series(WW)
  • Page 70 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 SHEET AL C2, SHEET AL C AND PROTECT TAB C SHEET AL C2 XBR/KD-84X9000 Series(WW)
  • Page 71 DISASSEMBLY 1-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 FRONT PANEL A, SHEET AL S3, PROTECT TAB S, SHEET AL S AND LCD PANEL LCD PANEL FRONT PANEL A SHEET AL S3 XBR/KD-84X9000 Series(WW)

  • Page 72: Sec 2. Adjustment

    001 OP Category Category number WYVERN 000 VERS name S2_NOISE_TH Item number <MAIN> <EXT> DM1.301W00AA RF:01.05 WF1.003W00AA WF:2.0.0.99 DF1.001W00AA WF:0B YM1.010W00AA CAM:X.XXX DB2.105W00AA FD:XXXX Item name Data (DM1.301W00AA) DD1.016W00AA WP0.521W00AA <PEM> MID:1C117081 PM1.012W00LU PID:04020000 PB1.000W00LU PNL:LTY320AB01 PL1.011J46LUX POP:X.XXX PD1.011J46LUX XBR/KD-84X9000 Series(WW)
  • Page 73 <3>/<6> Test reset <8> + <Mute> + <0> Read data <9> + <0> Execute <10 or 0> Write data <Mute> + <0> Change module <Jump> / <Option> 5) After entering service mode, then turn off the power switch. XBR/KD-84X9000 Series(WW)
  • Page 74 Press “0 / 10” on remote to select item. d. Press number key “1”~”9” directly. “*” stamp move. e. Press “12 / enter / select” to decide and advance next step. Press “return”, when returning on the previous page. DIGITAL(DIG_SRV_MODE) SERVICE TEST_PATTERN *1 Video 2 Audio XBR/KD-84X9000 Series(WW)

  • Page 75: Save Changing Data

    Press “0” or “enter” on remote. Green “WRITE” changes to red “WRITE”. It indicate writing is processing. c. After a while, red “WRITE” changes to green “SERVICE”. Writing process is done at this point. 2) TV reboot is necessary for applying data change. CHASSIS WRITE WYVERN S2_NOISE_TH XBR/KD-84X9000 Series(WW)
  • Page 76 Press “mute” ＋”0” on remote to save the data. “SERVICE” comment is changed to “WRITE”, indicating writing process. d. After a while, “WRITE” comment returns to “SERVICE”, which means writing process is done. SERVICE SERVICE R_DRV R_BKG SERVICE SERVICE G_DRV G_BKG SERVICE SERVICE B_DRV B_BKG XBR/KD-84X9000 Series(WW)

  • Page 77: Set To Shipping Condition

    After a while, red “EXE-RST” changes to green “SERVICE”. And all LED lights. Writing process is done at this point. TIMER Standby POWER <Another way> You can set to shipping condition w/o entering Service Mode. -> “Cursor Up” on remote + “Power Key” on Front panel. XBR/KD-84X9000 Series(WW)

  • Page 78: Sec 3. Trouble Shooting

    VOB FFC(ON3 to TCON) ● FFC(P3L to CV3) ● ● ● ● ▲ ▲ ▲ LCD Panel Shisar Panel Soft- Power Power P3L board TEMP CV3 board (Backlight) ware LOCK Problem panelID Audio board Local : doubtful part : Few possibility XBR/KD-84X9000 Series(WW)

  • Page 79: Troubleshooting

    Sound OK ? No Picture / No Sound Skype malfunction (Except China model) Is the HDD Rec Do the buttons function OK? on the TV & Remote HDD Rec malfunction TV/ Commander (AEP only) Commander work button malfunction properly? XBR/KD-84X9000 Series(WW)
  • Page 80 Long AC off Power protection or (> 15 min.). CPU abnormal stop Check STBY_+3.3V Replace the harness at 10 pin of CN6001 between G* board and G* board on the BAPS board BAPS board Symptom improvement BAPS board Harness XBR/KD-84X9000 Series(WW)
  • Page 81 1) 2 times blinking (Main Power Error) 2 times blinking Check REG+12V at 12V NG Replace pins 3/5 of Between G* Board to G* Board CN6001 on BAPS Board Harness the BAPS Board Symptom 12V OK improvement BAPS Board Harness XBR/KD-84X9000 Series(WW)
  • Page 82 Check +3.3V_MAIN F6003,IC6003,etc at JL6005 on (BAPS Board) the BAPS Board Check +5.0V_MAIN F6002,IC6002,etc FE/BE Communication at JL6004 on (BAPS Board) BAPS board Other BAPS Board’s parts (Audio, Tuner, HDMI Eq...) AUDIO Check Speaker Impedance Speaker at SP Connector XBR/KD-84X9000 Series(WW)
  • Page 83 LD board and LS FFC Change ON3 Board ON3 board the light source connection (inside the panel module). Check the FFC connection ON3-LD FFC Light source between ON3 board and connection (Inside Panel module) LD board. XBR/KD-84X9000 Series(WW)
  • Page 84 ON3 board P3L* board Symptom Symptom improvement improvement Replace Harness ON3 - P3L Change ON3 board Between ON3 and P3L harness ON3 board Symptom improvement Replace Harness CV3 - P3L BAPS board Between CV3 and P3L harness XBR/KD-84X9000 Series(WW)
  • Page 85 6 times blinking Check Under 2.65V BACKLIGHT_MON at pins 18/20 of BAPS board CN6001 on BAPS board Over 2.65V Check the harness between G* board G*-BAPS harness and BAPS board. Symptom improvement Change G* board G* board LD board XBR/KD-84X9000 Series(WW)
  • Page 86 Change P3L board P3L board Change BAPS Board, Panel Symptom and Aging a few hours improvement Change CV3 board CV3 board BAPS Board If the symptom improved by changing BAPS board the WiFi module Symptom improvement WiFi module XBR/KD-84X9000 Series(WW)
  • Page 87 ON3 Change P3L board P3L board between B*and CV3 board ON3 and P3L and P3L Symptom Symptom improvement improvement Change G* board G* board Change CV3 board CV3 board Symptom improvement Change ON3 board ON3 board BAPS board XBR/KD-84X9000 Series(WW)
  • Page 88 TROUBLE SHOOTING 9) 12 times blinking 12 times blinking Symptom improvement Replace Harness Harness between ON3 between ON3 and TCON and TCON Symptom improvement Change ON3 board ON3 board Panel (TCON board) XBR/KD-84X9000 Series(WW)
  • Page 89 B*-P3L FFC and Harness Symptom Symptom improvement improvement BAPS board Harness FFC or Harness ON3 board Panel Change P3L board Change BAPS board Change G* board (TCON, LD) Symptom Symptom Symptom improvement improvement improvement P3L board BAPS board G* Board XBR/KD-84X9000 Series(WW)
  • Page 90 “Audio System” Change to Check the “Speakers setting” “TV Speaker” “TV Speakers” “Minimum” Check the Increase the “Maximum Volume” level “>Minimum” Symptom improvement Check the Speaker Replace BAPS Board Harness the BAPS Board Symptom improvement Speaker Harness Speaker XBR/KD-84X9000 Series(WW)
  • Page 91 TROUBLE SHOOTING 3-7. TV COMMANDER BUTTONS MALFUNCTION 1) TV button malfunction Button malfunction on the TV Symptom improvement Replace the Harness between BAPS to Switch Unit change Switch Unit Switch Unit Symptom improvement Harness BAPS Board XBR/KD-84X9000 Series(WW)
  • Page 92 (ex. bezel) near sensor’s window Check the Harness between the BAPS Board Sensor is broken and the HLR Board Symptom improvement Exchange the Harness Harness Symptom improvement Exchange the HL Board HL Board BAPS Board XBR/KD-84X9000 Series(WW)
  • Page 93 Check the Ethernet Cable Ethernet Cable Cable Connection BAPS Board Auto Connection result Wired Set-up Check Local router DHCP server Local Access IP address setting Manual Check IP address and Local router setting Connection result Proxy setting Internet Access XBR/KD-84X9000 Series(WW)
  • Page 94 USB Dongle Network is selected? Network is selected? Is the radio field Is the radio field Strength too weak Antenna harness/Access Point Strength too weak Access Point or even No signal? or even No signal? BAPS Board BAPS Board XBR/KD-84X9000 Series(WW)
  • Page 95 Insert other Skype unit -Unplug other USB device Connect to other Able to run Skype App? BAPS board -AC OFF/ON USB port USB dongle Spec. USB overload. BAPS board Skype unit Network connected? Do network setup Next page XBR/KD-84X9000 Series(WW)
  • Page 96 Move unit away Auto-Focus work? Call Skype sound test Video/Audio quality? No video? from speaker No video Network speed Enough network speed? Far end setting/system Skype unit far end system issue Manual Focus work? Skype unit Check Auto-Focus area XBR/KD-84X9000 Series(WW)
  • Page 97 Is the drive size larger Only 32GB~2TB in between the than 32GB and is supported USB port and HDD? Smaller than 2TB?? USB Hub is not supported All the setups and restrictions listed in Check the iManual iManual are cleared? BAPS board XBR/KD-84X9000 Series(WW)

  • Page 98: Sec 4. Diagrams

    SEC 4. DIAGRAMS 4-1. BLOCK DIAGRAM 4-1-1. KD-84X9000(CH) XBR/KD-84X9000 Series(WW)
  • Page 99 DIAGRAMS 4-1-2. XBR-84X900(U/C) XBR/KD-84X9000 Series(WW)
  • Page 100 DIAGRAMS 4-1-3. KD-84X9005(AEP) XBR/KD-84X9000 Series(WW)
  • Page 101 DIAGRAMS 4-1-4. KD-84X9000(AF/AUS/HK/TW) AND XBR-84X905(LA6) XBR/KD-84X9000 Series(WW)

  • Page 102: Connector Diagram

    DIAGRAMS 4-2. CONNECTOR DIAGRAM (1/4) XBR/KD-84X9000 Series(WW)
  • Page 103 DIAGRAMS 4-2. CONNECTOR DIAGRAM (2/4) XBR/KD-84X9000 Series(WW)
  • Page 104 DIAGRAMS 4-2. CONNECTOR DIAGRAM (3/4) XBR/KD-84X9000 Series(WW)
  • Page 105 DIAGRAMS 4-2. CONNECTOR DIAGRAM (4/4) XBR/KD-84X9000 Series(WW)

  • Page 106: Circuit Boards Location

    DIAGRAMS 4-3. CIRCUIT BOARDS LOCATION LD Board HTL2 Board (CH) RU3 Board (U/C) P3L Board Board Board CV3 Board ON3 Board Switch Unit BAPS Board G16 Board Board SP3 Board SP3 Board Wireless LAN Card HL Board XBR/KD-84X9000 Series(WW)

  • Page 107: Sec 5. Exploded Views

    • The construction parts of an assembled part are indicated with a collation number in the remark colum. • Items marked " * " are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items XBR/KD-84X9000 Series(WW)

  • Page 108: Exploded Views

    EXPLODED VIEWS 5-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 5-1-1. CHASSIS-1 REF. No. PART No. DESCRIPTION MARK A-1906-640-A SP BOX R, SERVICE 4-443-444-01 BRACKET SP A (RT) 4-436-031-01 BRACKET SP A (RB) 4-441-834-01 REAR COVER A(REA) A-1906-639-A SP BOX L, SERVICE 4-443-446-01 BRACKET SP A (LT)
  • Page 109 EXPLODED VIEWS 5-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 5-1-2. CHASSIS-2 REF. No. PART No. DESCRIPTION MARK A-1901-705-A SP3 MOUNT 4-441-836-01 SIDE REAR COVER A(R) 4-441-838-01 TOP REAR COVER A(R) 4-441-837-01 TOP REAR COVER A(L) 4-441-835-01 SIDE REAR COVER A(L) 4-432-992-01 FRAME TOP CORNER 4-432-996-01...
  • Page 110 EXPLODED VIEWS 5-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 5-1-3. CHASSIS-3 REF. No. PART No. DESCRIPTION MARK 1-489-984-12 SWITCH UNIT U/C/LA1/AF/AUS AEP/LA6//HK/WB 1-489-985-12 SWITCH UNIT 1-842-104-31 AC INLET 4-432-978-01 FRAME, BOTTOM (REA) 4-448-793-01 UNDER COVER A (REA) 1-458-355-21 WIRELESS LAN CARD 1-754-823-11 ANTENNA 1-754-820-11 ANTENNA...
  • Page 111 EXPLODED VIEWS 5-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 5-1-4. CHASSIS-4 REF. No. PART No. DESCRIPTION MARK 4-433-035-01 SHEET, INSULATION (F) 4-433-034-01 SHEET, INSULATION (G17) A-1902-158-A P3L COMPLE A-1902-159-A CV3 COMPLE CH/AEP/AF/AUS/ LA6/HK A-1904-170-A CV3 COMPLE U/C/LA1/WB A-1905-682-A BAPS-CH-HTL COMPLE SERVICE A-1905-679-A BAPS-UC-HTL COMPLE SERVICE...
  • Page 112 EXPLODED VIEWS 5-1. KD-84X9000/KD-84X9005/XBR-84X900/XBR-84X905 5-1-5. CHASSIS-5 REF. No. PART No. DESCRIPTION MARK 4-433-933-01 FRONT PANEL A 4-440-337-01 PROTECT TAB C 4-439-883-01 LABEL, PANEL 4-440-336-01 SHEET AL C 4-441-537-01 SHEET AL C2 A-1902-157-A ON3 COMPLE Refer APPENDIX-1 4-441-393-01 PROTECT TAB S...
  • Page 113 4-447-335-01 SHEET, AL (P3L, TOP) Refer to APPENDIX-3 4-433-027-01 SHEET, RADIATION (CV) 4-433-029-01 SHEET, RADIATION (FPGA) 4-434-324-01 SHEET, RADIATION (ON) 4-433-028-01 SHEET, RADIATION (PPL) 4-433-031-01 SHEET, RADIATION (PPL, HS1) 4-433-032-01 SHEET, RADIATION (PPL, HS2) 4-300-810-01 SHEET, THERMAL (ATREYU) XBR/KD-84X9000 Series(WW)
  • Page 114 4-440-334-01 COVER SCREW BOTTOM (L) 4-440-335-01 COVER SCREW BOTTOM (R) 4-441-915-21 TAPE, MASK for FRONT PANEL A, Refer to APPENDIX-3 4-442-735-01 ADHESIVE (15) for BRACKET PANEL, Refer to APPENDIX-3 4-442-735-11 ADHESIVE (15) for BRACKET PANEL, Refer to APPENDIX-3 XBR/KD-84X9000 Series(WW)
  • Page 115 3-674-673-01 STOPPER (A) 1-835-200-11 POWER-SUPPLY CORD * 4-440-748-01 TRAY (REA) 1-835-281-11 POWER-SUPPLY CORD SET 1-846-268-11 POWER-SUPPLY CORD 4-435-229-01 NECK A (S) (for Short Stand) 1-846-383-11 POWER-SUPPLY CORD SET 4-435-233-01 SUPPORT COVER (S) (for Short Stand) 1-828-109-12 POWER-SUPPLY CORD XBR/KD-84X9000 Series(WW)
  • Page 116 English 2012JL08-Data Sony Corporation Made in Japan Home Entertainment &Sound 9-888-517-05 © 2012. 10 Business Group XBR/KD-84X9000 Series(WW)
  • Page 117 Please remove IC2504 and IC2505 from the original board and exchange these IC’s on the board to be replaced, since the IC’s have adjustment data for LCD Panel. At first, please make sure that ON3 board needs to be replaced surely before exchanging IC’s, after the confirmation, please exchange them accordingly. <ON3 Board B-side> IC2504 IC2505 XBR/KD-84X9000 Series(WW)

  • Page 118: Packing Instruction

    APPENDIX-2 PACKING INSTRUCTION TRAY(REA), TAPE, FILAMENT AND CUSHION, STAND(REA) TRAY(REA) CUSHION, STAND(REA) TRAY(REA) TAPE,FILAMENT (#880) 48X55M TRAY(REA) CUSHION, STAND(REA) XBR/KD-84X9000 Series(WW)
  • Page 119 APPENDIX-2 PACKING INSTRUCTION SHEET, PROTECTION AND BAG, POLYETHLEN Note: The long Stand must be attached when re-packing. BAG, POLYETHLEN < for U/C, LA > < for AEP, GA, CH > < for AEP, GA, CH > XBR/KD-84X9000 Series(WW)
  • Page 120 APPENDIX-2 PACKING INSTRUCTION BAG, PROTECTION AND TAPE, PP < for AEP, GA, CH > XBR/KD-84X9000 Series(WW)
  • Page 121 APPENDIX-2 PACKING INSTRUCTION SUPPORT COVER(S), ACCESSORY ASSY AND TAPE, PP SUPPORT COVER(S) ACCESSORY ASSY XBR/KD-84X9000 Series(WW)
  • Page 122 APPENDIX-2 PACKING INSTRUCTION CUSHION, LOWER(REA) LOWER, SHEET AND CUSHION, LOWER(REA) CUSHION, LOWER(REA) LOWER, SHEET LOWER, SHEET XBR/KD-84X9000 Series(WW)
  • Page 123 APPENDIX-2 PACKING INSTRUCTION TAPE, PP TAPE, PP TAPE, PP TAPE, PP < for U/C, LA > < for AEP, GA, CH > XBR/KD-84X9000 Series(WW)
  • Page 124 APPENDIX-2 PACKING INSTRUCTION LOWER, BOX AND CUSHION, LOWER(REA) LOWER, BOX CUSHION, LOWER(REA) XBR/KD-84X9000 Series(WW)
  • Page 125 APPENDIX-2 PACKING INSTRUCTION POWER-SUPPLY CORD ASSY POWER-SUPPLY CORD ASSY XBR/KD-84X9000 Series(WW)
  • Page 126 APPENDIX-2 PACKING INSTRUCTION 3D GLASSES AND PATE, PP (for excluding CH) 3D GLASSES XBR/KD-84X9000 Series(WW)
  • Page 127 APPENDIX-2 PACKING INSTRUCTION 3D GLASSES AND TAPE ,PP (for CH) 3D GLASSES XBR/KD-84X9000 Series(WW)

  • Page 128: Remote Commander

    APPENDIX-2 PACKING INSTRUCTION REMOTE COMMANDER REMOTE COMMANDER XBR/KD-84X9000 Series(WW)
  • Page 129 APPENDIX-2 PACKING INSTRUCTION CUSHION, SIDE(REA) CUSHIN, SIDE(REA) CUSHIN, SIDE(REA) XBR/KD-84X9000 Series(WW)
  • Page 130 APPENDIX-2 PACKING INSTRUCTION TAPE, PP TAPE, PP TAPE, PP TAPE, PP TAPE, PP XBR/KD-84X9000 Series(WW)
  • Page 131 APPENDIX-2 PACKING INSTRUCTION CUSHION, UPPER(REA) AND TAPE, PP CUSHIN, UPPER(REA) XBR/KD-84X9000 Series(WW)
  • Page 132 APPENDIX-2 PACKING INSTRUCTION TAPE, PP AND CARTON, INDIVIDUAL(REA 84) CARTON, INDIVIDUAL(REA 84) CARTON, INDIVIDUAL(REA 84) XBR/KD-84X9000 Series(WW)
  • Page 133 APPENDIX-2 PACKING INSTRUCTION LID(REA), TAPE, FILAMENT AND STOPPER (A) LID(REA) TAPE,FILAMENT (#880) 48X55M STOPPER (A) XBR/KD-84X9000 Series(WW)
  • Page 134 APPENDIX-3 SUPPORTING INFORMATION FOR ASSEMBLEY TAPE, MASK Please exchange TAPE, MASK when replace LCD Panel. TAPE, MASK XBR/KD-84X9000 Series(WW)
  • Page 135 APPENDIX-3 SUPPORTING INFORMATION FOR ASSEMBLEY PROTECT TAB S, SHEET AL S XBR/KD-84X9000 Series(WW)
  • Page 136 APPENDIX-3 SUPPORTING INFORMATION FOR ASSEMBLEY SHEET AL S3, SHEET AL C (SHEET AL S3) (SHEET AL C) SHEET AL S3 XBR/KD-84X9000 Series(WW)
  • Page 137 APPENDIX-3 SUPPORTING INFORMATION FOR ASSEMBLEY PROTECT TAB C XBR/KD-84X9000 Series(WW)
  • Page 138 APPENDIX-3 SUPPORTING INFORMATION FOR ASSEMBLEY Remove Screws from original Panel and put back to new Panel SCREWS ON PANEL Remove Screws from new Panel and put back to original Panel XBR/KD-84X9000 Series(WW)
  • Page 139 APPENDIX-3 SUPPORTING INFORMATION FOR ASSEMBLEY LABEL, PANEL XBR/KD-84X9000 Series(WW)
  • Page 140 APPENDIX-3 SUPPORTING INFORMATION FOR ASSEMBLEY SHEET AL C2, SHEET AL S2 (SHEET AL C2) (SHEET AL S2) XBR/KD-84X9000 Series(WW)
  • Page 141 APPENDIX-3 SUPPORTING INFORMATION FOR ASSEMBLEY BRACKET PANEL INFORMATION BRACKET PANEL is not stocked, please stick ADHESIVE (15) on BRACKET PANEL. 4-442-735-01 (270 mm) : for shorter BRACKET PANEL (x6), 4-442-735-11 (890 mm) : for longer BRACKET PANEL (x2) XBR/KD-84X9000 Series(WW)
  • Page 142 APPENDIX-3 SUPPORTING INFORMATION FOR ASSEMBLEY BRACKET PANEL XBR/KD-84X9000 Series(WW)
  • Page 143 APPENDIX-3 SUPPORTING INFORMATION FOR ASSEMBLEY BRACKET PANEL XBR/KD-84X9000 Series(WW)
  • Page 144 APPENDIX-3 SUPPORTING INFORMATION FOR ASSEMBLEY BRACKET PANEL XBR/KD-84X9000 Series(WW)
  • Page 145 APPENDIX-3 SUPPORTING INFORMATION FOR ASSEMBLEY BRACKET PANEL XBR/KD-84X9000 Series(WW)
  • Page 146 Stick SHEET, AL on the edge of P3L board at first, then stick on the back chassis to avoid creating gap between SHEET, AL and P3L board. Stick SHEET, AL with pushing to the underneath of P3L board. XBR/KD-84X9000 Series(WW)
  • Page 147 Stick the rest on the shield case. Stick starting from the center of the second and third hole of FFC. Align with the edge of shield Align with the edge of case. shield case. Hole of FFC XBR/KD-84X9000 Series(WW)
  • Page 148 SHEET AL (P3L) and two FFCs. Edge of P3L board Stick the rest on the heat sink. Stick starting from the edge of metal bracket to edge of P3L board. <Note> Stick SHEET, AL (P3L) first, and next stick SHEET, AL (CV). XBR/KD-84X9000 Series(WW)
  • Page 149 Bump Center between screw hole and the Screw hole Bump corner of bump. Center of the Corner of bumps bump Stick the rest to Align to the back chassis with edge of hole. avoiding gap. XBR/KD-84X9000 Series(WW)
  • Page 150 APPENDIX-3 SUPPORTING INFORMATION FOR ASSEMBLEY SHEET AL CV XBR/KD-84X9000 Series(WW)

This manual is also suitable for:

Kd-84x9005Xbr-84x900Xbr-84x905Az3sr

Table of Contents
