E62: Heating timeout

E62
Thermal Limiter 2 open (Domestic GAS only and international electrical only)
Checks to perform:
Check if any foreign material restricting the passage of
air in Vent. (See Fig. 1)
Check if Resistance between the terminals of heating
coil is 11 Ω ± 10%. (See Fig. 2)
Check Thermal limiter 2 (Inlet Thermal Limiter) for
continuity. Continuity is there?
Replace the Electronic Control board and check for any
further alarms.
Y
E
S
Y
E
S
Y
E
S
WARNING
Check that all the connectors are correctly inserted
Clean the ventilation and repeat the Diagnostic Cycle to
NO
check for any further alarms.
Replace the Heater and repeat the Diagnostic Cycle to
NO
check for any further alarms.
Replace the Thermal Limiter 2 and repeat the Diagnostic
NO
Cycle to check for any further alarms.
130
E62
