BOSCH
ENGINE
MANUAL
VER. 8.03
PERFORMANCE LINE CX - 2020
EN

Advertisement

Table of Contents
loading

Related Manuals for Bosch Performance CX 2020

Summary of Contents for Bosch Performance CX 2020

  • Page 1 BOSCH ENGINE MANUAL VER. 8.03 PERFORMANCE LINE CX - 2020...

  • Page 2: Table Of Contents

    INDICE Attention ................pag. 3 Unplug the connectors ............pag. 3 Activation of the Speed Ulocker ........pag. 9 Data view on the display ............ pag. 9 Menu 0,5 ................pag. 10 Intuvia ................pag. 11 Nyon ................... pag. 13 Kiox ..................

  • Page 3: Attention

    INSTALLATION Connection AT TENTION It is forbidden by law to activate EPLUS speed unlocker in public places such as streets, squares and cycling paths. So it is only possible to activate EPLUS speed unlocker in private places such as circuits and private properties. The maker denies responsibility due to any damage to pedal assisted bicycles where Eplus is set up.
  • Page 4 Once the cover has been removed, locate the two connectors on the display (black 4-wire connector: yellow-green-black-red) and the speed sensor (gray 2-wire connec- tor: black-red). With a long pliers carefully remove the two plugs paying attention not to pinch them ruining plugs or wires.
  • Page 5 Slide the thermoshrinking sheath (enclosed) in the two disconnected wires, pushing it over the plug. Insert plugs (output cables from the chip) in their respective two sockets (cables disconnected from the engine) respecting the correct wire color: DISPLAY PLUG > YELLOW-YELLOW / GREEN-GREEN / BLACK-BLACK / RED-RED AND SPEED SENSOR PLUG >...
  • Page 6 PEED SENSOR HMI (DISPLAY) PLUG PLUG SPEED SENSOR HMI (DISPLAY) SOCKET SOCKET TO THE DISPLAY (HMI) PLUG: TO THE SPEED RED => RED SENSOR PLUG: BLACK => BLACK GREEN => GREEN BLACK => BLACK YELLOW => YELLOW RED => WHITE (SEE PHOTO 5) (SEE PHOTO 5) 6.
  • Page 7 Carefully cover the two plugs with shrink wrap and with a hair dryer or a lighter heat uniformly the sheath (turning it from right to left) until you have the sheath that takes the shape of the plugs. Be careful not to burn wires or plugs. 7.
  • Page 8 Now connect the two plugs remaining on the chip to the engine, respecting the correct posi- tion of the colors (display RED WIRE and speed sensor WHITE WIRE get to the RIGHT), push the connectors firmly to the end; CAUTION: WRONG CONNECTION LEADS TO SHORTCIRCUIT, DAMAGES NOT COVERED BY WARRANTY! Possibly arrange the cables with electrician clamps paying attention that there are no wires in correspondence with holes where cover’s screws are.

  • Page 9: Activation Of The Speed Ulocker

    RACING MODE ACTIVATION OF THE SPEED UNLOCK The engine unlock at 25 km / h is activated by pressing the Walk button on the on-board computer. The activation button can be changed (see pag. 9). The display will show the value 2.2 if the unlock has been activated and 1.1 if it is deactivated.

  • Page 10: Menu 0,5

    MENU 0.5 For changes to the factory settings The SPEED UNLOCKER chip, factory mode, is set to be switched on / off using the WALK button and calibrated for 27.5 “wheels (2170 mm in circumference) and to be used with Purion/Nyon Display.

  • Page 11: Intuvia

     [0.5] > For INTUVIAvisualization of total km done; for PURION/NYON the partial and total km will be visible asusual on the display; • parameter [1.5] > Display Type (only Bosch) 2.2 Intuvia; parameter [2.5] > Choice of wheel circumference size: • wheel circumference (default value > 21.7 equivalent to 2170 mm or 27.5” standard wheel) the value must be as close as possible to the real circumference in order to have a...
  • Page 12 INTUVIA • parameter [4.5] > Automatic calibration of wheel circumference: If the bike is stopped, the message 55.6 will appear on the display for a few seconds, at the end of calibration 50.1 appears. If the bike is moving or the magnet on the spokes is positioned above the sensor, calibration is NOT STARTED and 99.9 appears on the display;...

  • Page 13: Nyon

    1,2,3,4,5,6 (large number on display). • parameter  [0.5] > - • parameter [1.5] > Display Type (only Bosch) 3.2 Nyon, parameter [2.5] > Choice of wheel circumference size: • wheel circumference (default value > 21.7 equivalent to 2170 mm or 27.5” standard wheel) the value must be as close as possible to the real circumference in order to have a correct reading of the speed.
  • Page 14 NYON • parameter [4.5] > Automatic calibration of wheel circumference: If the bike is stopped, the message 55.6 will appear on the display for a few seconds, at the end of calibration 50.1 appears. If the bike is moving or the magnet on the spokes is positioned above the sensor, calibration is NOT STARTED and 99.9 appears on the display;...

  • Page 15: Kiox

    Premere 4/5 volte il tasto [-] sul manubrio finché comparirà il numero 0.5 sul display • parameter  [0.5] > - parameter [1.5] > Display Type (only Bosch) 2.2 Kiox; • parameter [2.5] > Choice of wheel circumference size: • wheel circumference (default value > 21.7 equivalent to 2170 mm or 27.5” standard wheel) the value must be as close as possible to the real circumference in order to have a...
  • Page 16 KIOX • parameter [4.5] > Automatic calibration of wheel circumference: If the bike is stopped, the message 55.6 will appear on the display for a few seconds, at the end of calibration 50.1 appears. If the bike is moving or the magnet on the spokes is positioned above the sensor, calibration is NOT STARTED and 99.9 appears on the display;...

  • Page 17: Purion

    3. Move the [+ -] keys on the handlebar and enter the menu to be modified choosing between 1,2,3,4,5,6 (large number on display). • parameter  [0.5] > - • parameter [1.5] > Display Type (only Bosch) 1.1 Purion • parameter [2.5] > Choice of wheel circumference size: • wheel circumference (default value > 21.7 equivalent to 2170 mm or 27.5” standard wheel) the value must be as close as possible to the real circumference in order to have a...
  • Page 18 PURION • parameter [4.5] > Automatic calibration of wheel circumference: If the bike is stopped, the message 55.6 will appear on the display for a few seconds, at the end of calibration 50.1 appears. If the bike is moving or the magnet on the spokes is positioned above the sensor, calibration is NOT STARTED and 99.9 appears on the display;...
  • Page 19 After that, keeping the “+” and “-” buttons pressed, press the e bike start button. A scrolling message will appear on the display indicating the firmware version. If the display has a version prior to 1.4.0, connect the Purion display to the PC and update the firmware version with the Bosch diagnosis. 19. INSTALLATION...

  • Page 20: App Eplus

    APP E PLUS Only for Advanced version It is necessary to download our application Eplus smart controller, available for: Android / iOs Android http://goo.gl/DehnLE http://goo.gl/i3uwvL We recommend reading the manual of our Eplus smart controller application, back to the manual section: https://www.eplus.bike/en/guides/ 20.
  • Page 21 12 months warranty. We are responsible for manufacturing defects and not for installation defects. Do not expose to moisture and sources of heat.
