- Page 1 Vacuum cleaner User manual SS80N80**** / SS75N80**** • Before operating this unit, please read the instructions carefully. • For indoor use only Stick_VS8000-V2_EN_00803R-00_SA.indd 1 2018-03-08 오후 4:26:04...
-
Page 2: Table Of Contents
Contents PREPARATION MAINTENANCE Safety information Maintaining the vacuum cleaner When to empty the dustbin INSTALLATION Emptying the dustbin without causing dust clouds Name of the parts Emptying and Cleaning the dustbin Accessories Cleaning the sponge filter Installing the wall mount Cleaning the outlet filter Cleaning the accessories Installing the wall mount... -
Page 3: Preparation
PREPARATION Safety information • Before operating the appliance, please read this manual thoroughly and retain it for your reference. • Because the following operating instructions cover various models, the characteristics of your vacuum cleaner may differ slightly from those described in this manual. Caution/Warning symbols used WARNING Indicates that a danger of death or serious injury exists. - Page 4 General • Read all instructions carefully. Before switching the vacuum on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate on the bottom of the battery charger. • WARNING : Do not use the vacuum cleaner on a wet rug or floor. •...
- Page 5 • Do not use to suction up water. • Do not immerse in water for cleaning. • Please contact Samsung or a Samsung service center for a replacement if one is needed. Battery charger • Do not modify the polarized plug to fit a non-polarized outlet or extension cord.
- Page 6 • Do not attempt to open the battery charger. Repairs should be only carried out by a qualified Samsung service center. • Do not expose the battery charger to high temperatures or allow moisture or humidity of any kind to come into contact with the battery charger.
-
Page 7: Installation
Installation • If you have a problem with installing the wall mount (battery charger), contact a Samsung service center. • Do not install the wall mount (battery charger) near water, in an area with excessive moisture, or near window, etc. - Page 8 • Do not use a damaged power plug, power cord, or loose power outlet. – Otherwise, electric shock or fire may occur. • If the power cord is damaged, have a Samsung authorized service center replace the power cord with a new power cord.
- Page 9 – Otherwise, an explosion or fire may occur. • If the vacuum makes a strange sound or emits a smell or smoke, turn off the vacuum immediately, and then contact a Samsung service center. – Otherwise, electric shock or fire may occur.
- Page 10 • When you need to store the vacuum cleaner for a short time during cleaning, lay the vacuum on the floor. – Otherwise, the vacuum cleaner may fall and could cause an injury or severe product damage. • When you charge the vacuum cleaner by directly connecting it to the battery charger (without using the wall mount), the vacuum cleaner must lie in a stable place (that is flat, has no moisture, is out of reach of children, and that is configured so that the vacuum will not fall).
- Page 11 • When using the vacuum cleaner, be careful hurt yourself on the moving parts. – Be careful not to suction body parts into a brush of the vacuum cleaner (Hair, etc.) – When using the Flex Handle, be careful not to catch your fingers or hands in the movement fold of the handle.
- Page 12 – If water gets into the product and an error occurs, turn off the product and contact a Samsung service center. • After unplugging the product, clean the battery charger.
-
Page 13: Name Of The Parts
INSTALLATION Name of the parts 01 Pipe 07 Turbo mode button 02 Dustbin 08 Battery level indicator 03 Power indicator 09 Battery release button 04 Power( ) button 10 Flex Handle button 05 Outlet filter 11 Battery release lock button 06 Handle 12 Dustbin release button English... -
Page 14: Accessories
Accessories Accessories may differ depending on the models. Pipe Soft Action Brush Turbo Action Brush Mini Motorized Tool Combination Tool Extension Crevice Tool Flexible Tool Battery Wall mount (Screws / Screw anchors) User manual 14 English Stick_VS8000-V2_EN_00803R-00_SA.indd 14 2018-03-08 오후 4:26:11... -
Page 15: Installing The Wall Mount
Installing the wall mount CAUTION • The wall mount's mounting screws must be affixed to a hard wall or underlying wall stud. – If you install the wall mount on a plaster board wall, you must screw the supporting screws into an underlying stud. Installing the wall mount 01 Remove the rubber cap from the Groove for fixing... -
Page 16: Operation
OPERATION Using the vacuum cleaner CAUTION • Before ejecting the battery, the product must be turned off. (If the battery is forcibly ejected while the vacuum is operating, the vacuum can malfunction.) • Be careful not to drop the battery. If you do, you can injure yourself or damage the battery. -
Page 17: Using The Handle
Ejecting the battery Grip the handle, and then press the battery release button . While pressing the battery release lock button , eject the battery Re-inserting the battery Push the battery in as shown in the illustration until you hear a click. Click Using the handle Power( ) on/off... -
Page 18: Storing The Vacuum Cleaner
Using the Flex Handle • Press the Flex Handle button to release the Flex Handle. The Flex Handle will now move up and down as you clean. • The movement of the Flex Handle will protect your wrist or arm as it helps you to maneuver the vacuum and clean more comfortably. -
Page 19: Using The Accessories
Using the accessories Combination Tool Soft Action Brush Use to remove dust from curtains, furniture, sofas, etc. Use the Soft Action Brush to clean small Extension Crevice Tool dust particles off a floor (wood and linoleum). Turbo Action Brush Use to remove dust in grooves of window frames, chinks, corners, etc. -
Page 20: Maintenance
MAINTENANCE Maintaining the vacuum cleaner CAUTION Emptying and Cleaning the dustbin • Before cleaning the vacuum cleaner, turn it off. • When the dustbin or sponge filter is filled with dust, the vacuum cleaner may stop. You should empty and clean the dustbin before it becomes completely full. -
Page 21: Cleaning The Sponge Filter
Cleaning the sponge filter Open the filter holder. After cleaning the dustbin, dry it in the shade. NOTE • If the lever is not pushed in Remove the all the way, suction force may filter. decrease. If dust is extremely tangled, pull the lever repeatedly. -
Page 22: Cleaning The Outlet Filter
Cleaning the accessories Make sure the filter is dry. Soft Action Brush Place in the filter holder. Close the filter holder. Click Cleaning the outlet filter NOTE To maintain the best performance of the • When foreign matter remains on outlet filter, replace it once a year. - Page 23 Turbo Action Brush Mini Motorized Tool Extension Crevice Tool / Pipe Click • When the rotating brush is disassembled, the Turbo Action Brush's EzClean function automatically removes tangled foreign matter or hair. • If the foreign matter is not removed, use a scissors to remove it.
-
Page 24: Appendix
When the battery a Samsung service center, check no longer charges or runs down for the genuine Samsung logo on quickly, replace the exhausted the battery ( ) and the battery name (VCA-SBT80). -
Page 25: Operation
If the etc. in your home. If it happens liquid gets on your skin, wash repeatedly, contact a Samsung the affected area quickly with service center. water. If the liquid gets into your • Please charge the battery fully:... -
Page 26: Maintenance
• When the battery level is low, contact a Samsung service recharge it. If the level of the center. battery remains low for a long CAUTION period of time, it can cause the •... -
Page 27: Troubleshooting
Before calling for service, review the problems and solutions below. If none of the suggested solutions resolve your problem, please visit our website at www.samsung.com or call Samsung Customer Care. Note that you will be charged for any service calls in which no defects were found. - Page 28 If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Country Customer Care Center Web Site 1300 362 603 (Other) AUSTRALIA www.samsung.com/au/support 1300 425 299 (HHP) www.samsung.com/hk/support (Chinese) HONG KONG 3698 4698 www.samsung.com/hk_en/support (English)
