Asus ZenWiFi CT8 Quick Start Manual

Quick
Start Guide
ZenWiFi
Wireless AC3000 Tri Band Gigabit Router
Model: CT8
Before Setup
Preparing to set up an AiMesh Wi-Fi system
Find two ZenWiFi CT8, and power both on.
1
Use a network cable to connect your modem to the WAN port of either ZenWiFi CT8. This
2
ZenWiFi CT8 will be the AiMesh router, and the other ZenWiFi CT8 will be the AiMesh node.
The LED turns solid blue to indicate that ZenWiFi CT8 is ready for setup.
3
ASUS Router App
Download free ASUS Router APP to set up
and manage your router(s).
AiMesh Setup Steps
01
Prepare
Place your AiMesh router and node within 1-3 meters of each
other during the setup process.
02 AiMesh node
Load factory defaults. Keep your router powered on and stand-
by for AiMesh system settings.
03 Enabling Bluetooth
Enable Bluetooth on your phone.

Troubleshooting

If your AiMesh router cannot find any AiMesh node nearby or
synchronization fails, please check the following and try again.
Move your AiMesh node closer to the AiMesh router ideally. Ensure that it is
a
within 1-3 meters.
Your AiMesh node is powered on.
b
04 Launching ASUS Router APP
Launch ASUS Router APP, and then follow the on-screen in-
structions to finish the AiMesh setup.
Hardware Explanations
Plug the adapter into the DCIN port, and press the Power On/Off.
1
The power LED will light up when your hardware is ready.
2
Button and Port Explanations
DC-IN port Power On/Off LAN ports 1-3
USB 3.0/2.0 port WAN port
Specifications:
DC Power adapter DC Output: +19V with max 1.75A current
Operating Temperature
0~40 o C Storage
Operating Humidity 50~90% Storage
AiMesh node
AiMesh Setup Steps
within
1-3 meters
AiMesh node
WAN port
Connect your modem to this port
with a network cable.
LAN ports 1-3
Connect your PC to a LAN port with
a network cable.
0~70 o C
20~90%
AiMesh router
AiMesh router
