A.5.2 Mezzanine PCI-X PMC Site 2 Connector and Pinout (J22)

Figure A-13 Mezzanine PCI-X PMC Site Connector (J22)

Table A-12 Mezzanine PCI-X PMC Site Connector Pinout (J22)

PMC Connector (J22)
Left Side
Pin Name
1 VCC_12.0 2
3 JTAG_TMS_2 4
5 JTAG_TDI 6
7 GND 8
9 N/C 10
11 BMODE2# 12
13 PCIB_RESET# 14
15 VCC_3.3 16
17 N/C 18
19 AD[30] 20
21 GND 22
23 AD[24] 24
25 PMC_IDSEL 26
27 VCC_3.3 28
29 AD[18] 30
31 AD16] 32
N/C indicates No Connection
Right Side
Pin Name Pin
JTAG_TRST# 33
JTAG_TDO 35
GND 37
N/C 39
N/C 41
VCC_3.3 43
BMODE3# 45
BMODE4# 47
GND 49
AD[29] 51
AD[26] 53
VCC_3.3 55
AD[23] 57
AD[20] 59
GND 61
CBE[2]# 63
PMC Connector (J22)
Left Side Right Side
Name Pin
GND 34 N/C
TRDY# 36 VCC_3.3
GND 38 STOP#
PERR# 40 GND
VCC_3.3 42 SERR#
CBE[1]# 44 GND
AD[14] 46 AD[13]
M66EN 48 AD[10]
AD[8] 50 VCC_3.3
AD[7] 52 N/C
VCC_3.3 54 N/C
N/C 56 GND
N/C 58 N/C
GND 60 N/C
ACK64# 62 VCC_3.3
GND 64 N/C
Appendix A: Connector Pinouts 71
Name
