Siemens SIMATIC 277 IWLAN Getting Started

Hmi device mobile panel
Hide thumbs
Table of Contents
  • Table of Contents

  • 1 Welcome

  • 2 Configuring the WLAN
    • What Is a WLAN
    • Configuring the Access Point
    • Configuring a Mobile Panel for WLAN Use
    • Setting up a Configuring PC for WLAN Use

  • 3 Creating the Project
    • Creating the "MOB_277_IWLAN" Project
    • Configuring the Wireless Network Quality Display
    • Configuration of Multiple Wireless Networks
    • Transferring and Testing a Project

  • 4 Planning a Wireless Network
    • Interference Factors in a Wireless Network
    • Methods for Planning the Wireless Network

Advertisement

Available languages
  • EN

Available languages

  • ENGLISH, page 68

Quick Links

Download this manual
SIMATIC HMI
HMI Device
Mobile Panel 277 IWLAN
Getting Started
The following supplement is part of this documentation:
No.
Designation
1
Product Information
04/2008
A5E01004533-01
Drawing number
A5E02615843-01
Edition
08/2009

Advertisement

Table of Contents
loading

Related Manuals for Siemens SIMATIC 277 IWLAN

Summary of Contents for Siemens SIMATIC 277 IWLAN

  • Page 1 SIMATIC HMI HMI Device Mobile Panel 277 IWLAN Getting Started The following supplement is part of this documentation: Designation Drawing number Edition Product Information A5E02615843-01 08/2009 04/2008 A5E01004533-01...
  • Page 2 Safety Guidelines This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert symbol, notices referring only to property damage have no safety alert symbol.
  • Page 3 Trademarks All names identified by ® are registered trademarks of the Siemens AG. The remaining trademarks in this publica- tion may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.

  • Page 5: Table Of Contents

    Inhaltsverzeichnis ..........2 Welcome .

  • Page 6: Welcome

    1 Welcome...
  • Page 7 Welcome Welcome to the Getting Started for the Mobile Panel 277 IWLAN. Taking the Mobile Panel 277 IWLAN as an example, we will show you how to set up and configure a WLAN wireless network. Wireless operator-control and monitoring devices are primarily used in applications where inaccessible process stations have to be reached quickly: cranes, high-bay warehouses, telpher lines and even physically separated subnets.
  • Page 8 1 Welcome If you do not have the access point shown, you can also use a standard WLAN router. In this event, the configuration may deviate from the configuration illus- trated in this Getting Started. Requirements The access point is intended for Web Based Management. The following WLAN configuration settings are used by way of an example in this Getting Started: •...
  • Page 9 HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...

  • Page 10: Configuring The Wlan

    2 Configuring the WLAN...

  • Page 11: What Is A Wlan

    2.1 What is a WLAN? Data is transmitted and received by radio waves in WLAN instead of via cables. Mobile HMI devices such as the Mobile Panel 277 IWLAN conduct wireless communication with the PLC via the access point, which makes them very fle- xible to use, e.g.
  • Page 12 SIEMENS access points are designed for industrial use. Security SIEMENS access points support all the current measures to secure your WLAN. Take the following steps to avoid unauthorized access to the WLAN: 1. Select a secure encryption process. All SIEMENS access points support WPA2 with AES and TKIP, which is currently regarded as the most secure encryption process.

  • Page 13: Configuring The Access Point

    2.2 Configuring the Access Point Configuration during Commissioning with the Primary Setup Tool The Primary Setup Tool is used to configure the access point. The WLAN is set up when you commission an access point. The Primary Setup Tool is supplied in the access point package.
  • Page 14 2 Configuring the WLAN Selecting the interface 1. Start “Primary Setup Tool”: HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 15 2. Configure Primary Setup Tool in such a way that the LAN connection is used to connect to the access point: HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 16 2 Configuring the WLAN Configuring the interface 1. Configure the access point's Ethernet interface: HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 17 Uploading the configuration to the module 1. Upload the interface configuration to the module (access point): HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 18 2 Configuring the WLAN 2. Close the Primary Setup Tool: The access point is configured for commissioning. Further configuration is per- formed via the Web Based Management. Save the configuration data Configuring WLAN Settings for the Access Point with Web for the access point.
  • Page 19 Logging on to the Web Based Management 1. Open the Web Based Management in the browser and log on to it using the default access data for the Web Based Management (password: “admin”): HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 20 2 Configuring the WLAN Configuring the access point base parameters 1. Enter an IP address and subnet mask: The addresses are identical to the IP address and subnet mask allocated by you for the access point in the Primary Setup Tool. HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 21 2. Enter a descriptive name for the access point: HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 22 2 Configuring the WLAN 3. Select the code for the country where you are operating the WLAN: You may not select a country other than the one where you are using the WLAN. HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 23 4. Enter the SSID of the WLAN and select the transmission process: The SSID consists of up to 32 characters. The character “%” is not permitted. In order to ensure optimum compatibility with partner devices in other countries, only use the letters “A”...
  • Page 24 2 Configuring the WLAN 5. Select the channel on which this access point transmits: HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 25 6. Check the settings in the summary and close the wizard: HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 26 2 Configuring the WLAN Configuring the access point security parameters 1. Start the security settings wizard and change the administrator password for the access point from “admin” to “PGg%L”: The new password is valid from the next time you log in. HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 27 2. Configure the access point in such a way that the configuration settings cannot be changed via WLAN: 3. Apply the settings on the “Security Settings for SNMP Protocol” page by pressing “Next”. HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 28 2 Configuring the WLAN 4. Configure the access point in such a way that multiple access points within a radio cell are unable to communicate with one another: HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 29 5. Select the WLAN encryption process: Select an encryption process which is supported by all the HMI devices connected. HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 30 2 Configuring the WLAN 6. Enter the network code “Klh65Rff”: HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 31 7. Check the settings in the summary: HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 32 2 Configuring the WLAN 8. Close the wizard: HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 33 2 Configuring the WLAN 9. Restart the access point: The “Status” page shows you which wizard you have already “Completed” or “Not completed”. The settings become effective after restarting. You save the access point The access point transmits and receives with a specific transmission process on configuration in the Web a selected channel.

  • Page 34: Configuring A Mobile Panel For Wlan Use

    2 Configuring the WLAN 2.3 Configuring a Mobile Panel for WLAN Use You can assign one or more Mobile Panels to an access point. The configuration of the Mobile Panels has the following objectives: • To enable the access point and Mobile Panel to recognize each other. •...
  • Page 35 2. Enter an IP address and subnet mask using the screen keyboard: HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 36 2 Configuring the WLAN 3. Connect to the network: The WPA code corresponds to the network code which you entered when you configured the access point. HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 37 4. Set the same country code as that of the access point: The HMI device is connected to the access point via WLAN and can exchange data with it. HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...

  • Page 38: Setting Up A Configuring Pc For Wlan Use

    2 Configuring the WLAN 2.4 Setting up a Configuring PC for WLAN Use In order to configure a Mobile Panel on a wireless basis and transfer the project later on, first of all set the WLAN on the configuring PC. 1.
  • Page 39 3. Open the overview of the available wireless networks: HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 40 2 Configuring the WLAN 4. Enter the network code “KIH65Rff” to gain access to the wireless network: HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 41 The connection is established with the AP_transport_WLAN: HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...

  • Page 42: Creating The Project

    3 Creating the Project...
  • Page 43 In order to test the WLAN functionality, create a project which displays the qua- lity of the wireless network and the strength of the signal on the Mobile Panel. Then transmit the project on a wireless basis from the configuring PC to the Mobile Panel.

  • Page 44: Creating The "Mob_277_Iwlan" Project

    3 Creating the Project 3.1 Creating the “MOB_277_IWLAN” project 1. Start WinCC flexible: The WinCC flexible project wizard opens. The project wizard provides support when creating a project by guiding users step-by-step through the configura- tion settings. HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 45 2. Create a new project. HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 46 3 Creating the Project 3. Select the plant configuration: HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 47 4. Select the HMI device and use the default PLC: HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 48 3 Creating the Project 5. Disable all the template settings: 6. Click on “Next” to apply the standard settings provided on the “Screen Navigation” page. 7. Click on “Next” to apply the standard settings provided on the “Libraries” page. HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 49 8. Then enter information on the project: HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...

  • Page 50: Configuring The Wireless Network Quality Display

    3 Creating the Project 3.2 Configuring the Wireless Network Quality Display The project wizard has created the project according to the information specified and opened it in WinCC flexible. Configure the display for wireless network quality in the template so that it appears in every screen.
  • Page 51 2. Insert the display object for wireless network quality: HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 52 3 Creating the Project 3. Arrange the display object for wireless network quality using the cursor keys, as shown in the figure: HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...

  • Page 53: Configuration Of Multiple Wireless Networks

    3.3 Configuration of multiple wireless networks There are usually several access points in the plant to be operated and therefore several wireless networks. In WinCC flexible, you can store up to three SSIDs for wireless networks in the device settings: When the “Allow other SSIDs”...

  • Page 54: Transferring And Testing A Project

    3 Creating the Project 3.4 Transferring and Testing a Project 1. Save the project: HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 55 2. Transfer the project to the Mobile Panel. 3. Move around the room carrying the Mobile Panel and note of how the displays change. HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...

  • Page 56: Planning A Wireless Network

    4 Planning a Wireless Network...

  • Page 57: Interference Factors In A Wireless Network

    4.1 Interference factors in a wireless network Even if all the security functions on the access point have been correctly configured, special factors may disrupt the data exchange with WLAN. Therefore, allow for factors which may cause interference in planning your wireless network.
  • Page 58 4 Planning a Wireless Network • Interference Radio waves may have an intensifying or quenching effect on one another. This is the case, for example, if a receiver is located in the vicinity of both a receiver and its reflection. Remedies Apply the following measures to reduce the interference factors described above:...

  • Page 59: Methods For Planning The Wireless Network

    • SINEMA E (SIMATIC Network Manager Engineering) is Windows software You can find additional infor- mation at the following from SIEMENS for planning, simulating and configuring a WLAN. This tool address: can be used to resolve possible interference during the planning phase. By http://www.automation.sieme...
  • Page 60 Ethernet. 4. Step: Adapt the plan Vary the arrangement of the access points until the required WLAN range is covered to optimum effect. See also (http://www.automation.SIEMENS.com/net/html_00/produkte/sinema.htm) HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 61 HMI Device Mobile Panel 277 IWLAN Getting Started, 04/2008, A5E01004533-01...
  • Page 62 Aussagen in der Betriebsanleitung, in den Release Notes und in der Online-Hilfe in der Verbindlichkeit übergeordnet. Beachten Sie insbesondere Zulassungen und Zertifikate. Hinweis Für das Bediengerät gelten nur die Zulassungen, die auf der Geräterückseite angegeben sind. © Siemens Ⓟ2009 A5E02615843-01, 08/2009...
  • Page 63 Sicherheitshinweise für Mobile Panel 277 IWLAN und Mobile Panel 277F IWLAN Powermanagement ACHTUNG Meldungen im Energiesparmodus unsichtbar Im Energiesparmodus wird das Display des Bediengeräts je nach Einstellung abgedunkelt ("Power Save 1") oder ausgeschaltet ("Power Save 2"). Wenn Meldungen auftreten, während der Energiesparmodus aktiv ist, dann bleibt die Anzeige abgedunkelt oder ausgeschaltet.
  • Page 64 Umständen garantiert werden. Störungen, die von außen auf das Funknetz wirken, können z. B. zu einer Überlastung des Bediengeräts führen. Die "Storm Threshold"-Funktion beim Siemens Access Point SCALANCE muss aktiviert sein. Diese Aktivierung ist für einen stabilen Anlagenbetrieb auch bei hoher Netzlast notwendig. Für Broadcast-Telegramme ist Folgendes einzustellen: ●...
  • Page 65 Beachten Sie das Funktionshandbuch "Fehlersicherer Betrieb des Mobile Panel 277F IWLAN" und die darin enthaltenen Sicherheitshinweise, sowie weitere Informationen im Internet unter: Gesamtdokumentation zum Mobile Panel 277 IWLAN und Mobile Panel 277F IWLAN (http://support.automation.siemens.com/WW/view/de/26268960) Das Funktionshandbuch "Fehlersicherer Betrieb des Mobile Panel 277F IWLAN" liegt in den Sprachen deutsch, englisch und japanisch vor.
  • Page 66 Die folgende Übersicht informiert Sie über die möglichen Zulassungen. Für das Bediengerät gelten nur die Zulassungen, die auf der Geräterückseite angegeben sind. CE-Zulassung Das Bediengerät stimmt in der von Siemens I IA in Verkehr gebrachten Ausführung mit den Vorschriften der folgenden europäischen Richtlinie überein: 99/5/EG Richtlinie des europäischen Parlaments und des Rates zur Angleichung der Rechtsvorschriften der Mitgliedstaaten über...
  • Page 67 EG-Konformitätserklärung Die EG-Konformitätserklärung wird gemäß den obengenannten EG- Richtlinien für die zuständigen Behörden zur Verfügung gehalten bei: Siemens Aktiengesellschaft Bereich Automatisierungstechnik I IA AS RD ST Postfach 1963 92209 Amberg Deutschland Diese Erklärung bescheinigt die Übereinstimmung mit den genannten Richtlinien, ist jedoch keine Zusicherung von Eigenschaften.
  • Page 68 IEEE802.11b or g operation of this product in the USA is firmware-limited to channels 1 through 11. ______________________________________________________________________________________________________________ Notice Changes or modifications made to this equipment not expressly approved by SIEMENS may void the FCC authorization to operate this equipment. ______________________________________________________________________________________________________________ This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 69 Lettland ✓ Türkei ✓ Liechtenstein ✓ Ukraine Litauen ✓ Ungarn ✓ Luxemburg ✓ Vereinigte Staaten ✓ von Amerika Malaysia Zypern ✓ Siemens AG Industry Sector Postfach 48 48 90026 NÜRNBERG Mobile Panel 277 IWLAN, Mobile Panel 277F IWLAN A5E02615843-01, 08/2009...
  • Page 70 Observe the approvals and certificates. Note The HMI device itself is certified as shown on the rear panel labels. © Siemens Ⓟ2009 A5E02615843-01, 08/2009...
  • Page 71 Safety notes on the Mobile Panel 277 IWLAN and Mobile Panel 277F IWLAN Power management NOTICE Alarms not visible in power-save mode Depending on the setting, the display of the HMI device will either be dimmed ("Power Save 1") or turned off ("Power Save 2").
  • Page 72 The "Storm Threshold" function in the Siemens Access Point SCALANCE must be selected. This option has to be selected to ensure stable plant operation when the load on the network is high. The following settings have to be made for broadcast message frames: ●...
  • Page 73 Internet at: Complete documentation on the Mobile Panel 277 IWLAN and Mobile Panel 277F IWLAN (http://support.automation.siemens.com/WW/view/en/26268960) The function manual "Fail-safe operation of the Mobile Panel 277F IWLAN" is available in German, English and Japanese.
  • Page 74 The following overview shows the approvals that may be available. The HMI device itself is certified as shown on the rear panel labels. CE approval The HMI device in the version put into circulation by Siemens I IA conforms to the regulations of the following European directive: 99/5/EC Directive of the European Parliament and of the Council relating to Radio Equipment and Telecommunications Terminal Equipment and the Mutual Recognition of their Conformity.
  • Page 75 EC Declaration of Conformity The EC Declaration of Conformity is available for the responsible authorities according to the above-mentioned EC Directive at the following address: Siemens AG Industry Sector I IA AS RD ST PO Box 1963 92209 Amberg Germany This declaration certifies compliance with the directives named above, but does not guarantee any specific properties.
  • Page 76 IEEE802.11b or g operation of this product in the USA is firmware-limited to channels 1 through 11. ______________________________________________________________________________________________________________ Notice Changes or modifications made to this equipment not expressly approved by SIEMENS may void the FCC authorization to operate this equipment. ______________________________________________________________________________________________________________ This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 77 Latvia ✓ Turkey ✓ Liechtenstein ✓ Ukraine Lithuania ✓ Hungary ✓ Luxembourg ✓ United States of ✓ America Malaysia Cyprus ✓ Siemens AG Industry Sector Postfach 48 48 90026 NÜRNBERG Mobile Panel 277 IWLAN, Mobile Panel 277F IWLAN A5E02615843-01, 08/2009...
  • Page 78 à elles que vous devez vous reporter. Veuillez tenir compte des autorisations et des certificats. Remarque Les homologations valables pour le pupitre sont uniquement celles indiquées au dos de l'appareil. © Siemens Ⓟ2009 A5E02615843-01, 08/2009...
  • Page 79 Consignes de sécurité pour le Mobile Panel 277 IWLAN et le Mobile Panel 277F IWLAN Gestion de l'alimentation IMPORTANT Alarmes invisibles en mode d'économie d'énergie En mode d'économie d'énergie, l'écran du pupitre opérateur est sombre ("Power Save 1") ou éteint ("Power Save 2") selon le paramétrage.
  • Page 80 La fonction "Storm Threshold" doit être activée pour le point d'accès Siemens SCALANCE. Cette activation est nécessaire pour que le fonctionnement de l'installation soit stable même quand la charge du réseau est élevée. Pour les télégrammes Broadcast, il faut effectuer le paramétrage suivant :...
  • Page 81 Internet : Documentation complète du Mobile Panel 277 IWLAN et Mobile Panel 277F IWLAN (http://support.automation.siemens.com/WW/view/fr/26268960) La description fonctionnelle du fonctionnement de sécurité du Mobile Panel 277F IWLAN existe en allemand, en anglais et en japonais.
  • Page 82 Les homologations valables pour le pupitre sont uniquement celles indiquées au dos de l'appareil. Homologation CE Le pupitre opérateur dans la version mise en circulation par Siemens I IA est conforme aux normes de la directive européenne suivante : 99/5/EG Directive du Parlement et du Conseil Européen pour l'harmonisation des directives sur les installations radioélectriques et...
  • Page 83 Déclaration de conformité CE La déclaration de conformité CE est tenue à la disposition des autorités compétentes, conformément aux directives CE susmentionnées, par : Siemens Aktiengesellschaft Industry Sector I IA AS RD ST Postfach 1963 92209 Amberg Allemagne Cette déclaration atteste la conformité aux directives mentionnées, mais ne tient pas lieu de garantie de propriétés.
  • Page 84 IEEE802.11b or g operation of this product in the USA is firmware-limited to channels 1 through 11. ______________________________________________________________________________________________________________ Notice Changes or modifications made to this equipment not expressly approved by SIEMENS may void the FCC authorization to operate this equipment. ______________________________________________________________________________________________________________ This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 85 ✓ tchèque Lettonie ✓ Turquie ✓ Liechtenstein ✓ Ukraine Lithuanie ✓ Hongrie ✓ Luxembourg ✓ Etats-Unis ✓ d'Amérique Malaisie Chypre ✓ Siemens AG Industry Sector Postfach 48 48 90026 NÜRNBERG Mobile Panel 277 IWLAN, Mobile Panel 277F IWLAN A5E02615843-01, 08/2009...
  • Page 86 Release Notes e nella Guida in linea. In particolare è importante tener conto delle omologazioni e dei certificati. Nota Per un dato pannello operatore sono valide solo le omologazioni indicate sul retro dell'apparecchiatura. © Siemens Ⓟ2009 A5E02615843-01, 08/2009...
  • Page 87 Avvertenze di sicurezza per il Mobile Panel 277 IWLAN e il Mobile Panel 277F IWLAN Power Management ATTENZIONE Segnalazioni non visualizzate nella modalità a risparmio energetico Nella modalità a risparmio energetico il display del pannello operatore viene oscurato ("Power Save 1") o disattivato ("Power Save 2") a seconda dell'impostazione.
  • Page 88 I disturbi esterni che hanno effetto sulla rete radiofonica possono ad es. determinare un sovraccarico del pannello operatore. La funzione "Storm Threshold" nell'Access Point SCALANCE di Siemens deve essere attivata. Questa attivazione è necessaria affinché l'impianto funzioni in modo stabile anche in caso di un elevato carico della rete. Per i telegrammi broadcast devono essere effettuate le seguenti impostazioni: ●...
  • Page 89 Internet: Documentazione sul Mobile Panel 277 IWLAN e il Mobile Panel 277F IWLAN (http://support.automation.siemens.com/WW/view/it/26268960) Il manuale di guida alle funzioni "Fail-safe operation of the Mobile Panel 277F IWLAN" è disponibile in tedesco, inglese e giapponese.
  • Page 90 Omologazione CE Il pannello operatore, nella versione commercializzata da Siemens I IA, è conforme alle prescrizioni stabilite dalle seguenti direttive europee: 99/5/CE Direttiva del Parlamento europeo e del Consiglio riguardante le apparecchiature radio e le apparecchiature terminali di telecomunicazione e il reciproco riconoscimento della loro conformità.
  • Page 91 Dichiarazione di conformità CE La dichiarazione di conformità CE è a disposizione delle autorità competenti al seguente indirizzo come stabilito dalle direttive CE sopra indicate: Siemens Aktiengesellschaft Bereich Automatisierungstechnik I IA AS RD ST Postfach 1963 92209 Amberg Germania Questa dichiarazione certifica la conformità alle direttive indicate ma non costituisce una garanzia rispetto alle caratteristiche.
  • Page 92 IEEE802.11b or g operation of this product in the USA is firmware-limited to channels 1 through 11. ______________________________________________________________________________________________________________ Notice Changes or modifications made to this equipment not expressly approved by SIEMENS may void the FCC authorization to operate this equipment. ______________________________________________________________________________________________________________ This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 93 ✓ Lettonia ✓ Turchia ✓ Liechtenstein ✓ Ucraina Lituania ✓ Ungheria ✓ Lussemburgo ✓ Stati Uniti ✓ d'America Malesia Cipro ✓ Siemens AG Industry Sector Postfach 48 48 90026 NÜRNBERG Mobile Panel 277 IWLAN, Mobile Panel 277F IWLAN A5E02615843-01, 08/2009...
  • Page 94 Release Notes y en la Ayuda en pantalla. Observe especialmente las homologaciones y certificados. Nota Para el panel de operador son aplicables únicamente las homologaciones indicadas en el lado posterior del equipo. © Siemens Ⓟ2009 A5E02615843-01, 08/2009...
  • Page 95 Consignas de seguridad para el Mobile Panel 277 IWLAN y Mobile Panel 277F IWLAN Opciones de energía ATENCIÓN Mensajes no visibles en el modo de ahorro de energía En el modo de ahorro de energía, la pantalla del panel de operador se oscurece ("Power Save 1") o se apaga ("Power Save 2") según cómo esté...
  • Page 96 La función "Storm Threshold" tiene que estar activada en el Siemens Access Point SCALANCE. Esta activación es necesaria para el funcionamiento estable de la instalación, incluso a una carga de red elevada. Ajuste lo siguiente para los telegramas broadcast: ●...
  • Page 97 Internet: Consignas de seguridad para el Mobile Panel 277 IWLAN y Mobile Panel 277F IWLAN (http://support.automation.siemens.com/WW/view/es/26268960) El manual de funciones "Fail-safe operation of the Mobile Panel 277F IWLAN" está disponible en alemán, inglés y japonés. Transferencia automática ADVERTENCIA No utilizar la transferencia automática...
  • Page 98 Para el panel de operador son aplicables únicamente las homologaciones indicadas en el lado posterior del equipo. Homologación CE El modelo del panel de operador comercializado por la Siemens I IA cumple con las prescripciones de la siguiente directiva europea: 99/5/CE Directiva del Parlamento Europeo y del Consejo sobre la aproximación de las legislaciones de los Estados miembros sobre...
  • Page 99 Declaración de conformidad CE Según exigen las directivas CE arriba mencionadas, la declaración de conformidad CE está a disposición de las autoridades competentes en: Siemens Aktiengesellschaft Industry Automation Division I IA AS RD ST Postfach 1963 92209 Amberg Alemania Esta declaración certifica el cumplimiento de las directivas mencionadas pero no garantiza las características.
  • Page 100 IEEE802.11b or g operation of this product in the USA is firmware-limited to channels 1 through 11. ______________________________________________________________________________________________________________ Notice Changes or modifications made to this equipment not expressly approved by SIEMENS may void the FCC authorization to operate this equipment. ______________________________________________________________________________________________________________ This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 101 Letonia ✓ Turquía ✓ Liechtenstein ✓ Ucrania Lituania ✓ Hungría ✓ Luxemburgo ✓ Estados Unidos de ✓ América Malasia Chipre ✓ Siemens AG Industry Sector Postfach 48 48 90026 NÜRNBERG Mobile Panel 277 IWLAN, Mobile Panel 277F IWLAN A5E02615843-01, 08/2009...
  • Page 102 - 6AV6 645-0DE01-0AX0 - 6AV6 645-0FD01-0AX0 - 6AV6 645-0FE01-0AX0 ● Mobile Panel 277F IWLAN 注文番号: - 6AV6 645-0DB01-0AX0 - 6AV6 645-0DC01-0AX0 - 6AV6 645-0GB01-0AX0 - 6AV6 645-0GC01-0AX0 この製品情報には、重要な情報が含まれています。 この注意事項は、HMI デバイスの操作説明書を補足し、操作説明書、 リリースノート、オンラインヘルプの記述より優先されます。 承認と認定書を確認してください。 注記 HMI デバイス自体の認証は、背面パネルのラベルに表示されています。 © Siemens Ⓟ2009 A5E02615843-01, 08/2009...
  • Page 103 Mobile Panel 277 IWLAN および Mobile Panel 277F IWLAN の安全に 関する注意事項 電源管理 通知 省電力モードでアラームが表示されない 設定によって、HMI デバイスの表示が暗くなるか("省電力 1")オフになります("省電力 2")。 省電力モードの間にアラーム がある場合は表示が暗いままかオフになったままになります。 この状態で、アラームを確認するのは難しいか不可能で す。 注記 外部電源を使用して HMI デバイスを操作している場合、入力が行われずに 2 分が経過すると、デバイスは「省電力 1」の 省電力モードに切り替わります。 表示が暗くなります。 注記 外部 USB キーボードを HMI デバイスに接続した場合、"省電力 2"の省電力モードの外部 USB キーボードはアクティブのま まです。...
  • Page 104 アクセスポイント - ワイヤレス通信 注記 より広い WLAN エリアをカバーするために、複数のアクセスポイントとの通信を障害なく行うことはできません。 PROFINET IO、HTTP、Sm@rtAccess、Sm@rtService、OPC などのワイヤレス Ethernet ベースの通信の場合、エンドユ ーザーが自分のデータネットワークのセキュリティに責任を負います。 どんな環境でも、HMI デバイスの安全な操作を完 全に保証することはできません。 たとえば、無線ネットワークの外からの干渉によって、HMI 装置の過負荷が引き起こさ れることがあります。 Siemens アクセスポイント SCALANCE の｢ストームしきい値｣機能を選択する必要があります。 このオプションを選択す れば、ネットワークの負荷が高い場合でも、安定したプラント操業を保証できます。 ブロードキャスト メッセージ フレー ムを作るには、以下の設定を行ないます： ● アドレスしきい値: 255 ● ワイヤレス: 255. PROFINET IO 注記 使用しているアプリケーションの安全性を高めるには、CPU アプリケーションでライフサインビットを要求します。...
  • Page 105 Mobile Panel 277F IWLAN に関する安全注意事項 警告 機能マニュアル『Mobile Panel 277F IWLAN のフェールセーフ操作』をお読みください 機能マニュアル『Mobile Panel 277F IWLAN のフェイルセーフ操作』および次の Web サイトにある警告と追加情報を熟 読してください。 Mobile Panel 277 IWLAN および Mobile Panel 277F IWLAN に関する総合的なマニュアル (http://support.automation.siemens.com/WW/view/en/26268960) 機能マニュアル『Mobile Panel 277F IWLAN のフェイルセーフ操作』はドイツ語版、英語版、日本語版で提供されていま す。 自動転送 警告 自動転送は使用しないでください HMI デバイスでは自動転送(コントロールパネル、オプション｢リモートコントロール｣)は使用しないでください。...
  • Page 106 規格と承認 この節には、無線システムに関する Mobile Panel 277 IWLAN および Mobile Panel 277F IWLAN HMI デバイスの規格と各国 における承認に関する重要な情報が記載されています。 注意 以下に、使用できる承認の概要を示します。 HMI デバイス自体の認証は、背面パネルのラベルに表示されています。 CE 承認 Siemens I IA が提供するバージョンの HMI デバイスは、以下の欧州指令の規制に準拠します。 99/5/EC 無線装置と通信端末装置および適合性の相互承認に関する欧州議会および欧州理事会指令。 ガイドラインの基本要件との互換性は、以下の規格に準拠することによって証明されています。 EN 60950 情報テクノロジ装置の安全性 EN 301489-1 無線装置とサービスの電磁互換性 EN 301489-17 ブロードバンドデータ伝送システムとローカル高性能無線ネットワークの装置のための固有の要件 (HIPERLAN) EN 300328 電磁両立性および周波数問題(ERM) - 広帯域伝送システム...
  • Page 107 EC 適合性宣言 EC 適合性宣言は、上記の EC 指令に従う下記の住所にある担当機関から入手できます。 Siemens AG Industry Sector I IA AS RD ST PO Box 1963 92209 Amberg Germany この宣言は、上記の指令に準拠していることを認定するものであり、特定の特性を保証するものではありません。 EC 適合性宣言をダウンロードするには、次のアドレスにアクセスしてください。 Mobile Panel 277 IWLAN および Mobile Panel 277F IWLAN に関する総合的なマニュアル (http://support.automation.siemens.com/WW/view/en/26268960) 入力タイプ「認定書」のコメントをフィルタします。 UL 承認 Underwriters Laboratories Inc.
  • Page 108 IEEE802.11b or g operation of this product in the USA is firmware-limited to channels 1 through 11. ______________________________________________________________________________________________________________ Notice Changes or modifications made to this equipment not expressly approved by SIEMENS may void the FCC authorization to operate this equipment. ______________________________________________________________________________________________________________ This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 109 クウェート チェコ共和国 ✓ ラトビア ✓ トルコ ✓ リヒテンシュタ ✓ ウクライナ イン リトアニア ✓ ハンガリー ✓ ルクセンブルグ ✓ アメリカ合衆国 ✓ マレーシア キプロス ✓ Siemens AG Industry Sector Postfach 48 48 90026 NÜRNBERG Mobile Panel 277 IWLAN、Mobile Panel 277F IWLAN A5E02615843-01, 08/2009...
