Haier HLF103Q Service Manual

Haier HLF103Q Service Manual

Front load dryer
Hide thumbs Also See for HLF103Q:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Front Load Dryer
Service
1. Specification list
1. Specification list
2. Dimensional drawing
2. Dimensional drawing
3. Circuit diagram
3. Circuit diagram
4. Names of parts
4. Names of parts
5. Usage of the operation knobs
5. Usage of the operation knobs
6. Products brief and new features
6. Products brief and new features
7. Key point in installation
7. Key point in installation
8. Analysis of the common breakdowns
8. Analysis of the common breakdowns
Features
Electrionic Control
Front Door Design
10 Drying Cycles
5 Drying Levels
4 Temperatures Setting
Manual
adjustment and disassembly
adjustment and disassembly
End Of Drying Signal
Wrinkle Care Program
Delay Start Program
Drying Rack
Model: HLF103Q
WD-8888-95
1
1
1
1
2
2
2
2
3
3
5
5
7
7
11
11

Advertisement

Table of Contents
loading

Related Manuals for Haier HLF103Q

Summary of Contents for Haier HLF103Q

  • Page 1 Front Load Dryer Model: HLF103Q Service Manual 1. Specification list 1. Specification list 2. Dimensional drawing 2. Dimensional drawing 3. Circuit diagram 3. Circuit diagram 4. Names of parts 4. Names of parts 5. Usage of the operation knobs 5. Usage of the operation knobs 6.

  • Page 2: Specification List

    1 Specification list Model HLF103Q Rated voltage rated frequency 120V/240V 60Hz 10kg(weight of standard dry cloth Rated dry capacity Rated power consumption in drying 4800W Rated input consumption of motor 379W Weight(kg) About 58kg Dimension L 686mm W 718mm H 1080mm...

  • Page 3: Circuit Diagram

    3 Circuit diagram circuit diagram 4 Names of parts back baffle control plate control panel fasten button thread-protected board I front plate thread-protected board II cabinet nameplate whisk leaf barrel roll front door lint filter adjustable foot shutter lock body exhaust duct...

  • Page 4: Usage Of The Operation Knobs

    5 usage of the operation knobs WARNING: to reduce the risk of fire, electric shock or injury to persons, read the IMPORTANT SAFETY INSTRUCTIONS before operating this dryer. Understanding the Control Panel Super Capacity Super Capacity High High High High High High High...
  • Page 5 Wrinkle Saver Button: (6) This convenient feature lets you delay the start of the dry cycle between 3 to 24 hours. Press the "Wrinkle Saver" to choose the number of hours you want to delay the start of the cycle. If no delay, the wrinkle saver indicator is off and remaining time indicator is on.
  • Page 6 6 Product Brief and New Features roduct briefs 1) Program control As the control center of the appliance, the program controller directs the appliance to meet the demand of the user like the brain of human body. This part has acquired the UL certification, with long operation life and reliable performance.

  • Page 7: End Of Cycle Signal

    6) Lint filter It is a kind of wearing part, made of filter screen frame and screen cloth by one-time plastic injection. When taking off the lint filter, please do not squeeze the screen cloth by force to avoid damaging the cloth.

  • Page 8: Tools And Materials Required

    7 Key points in installation, adjustment and disassembly Select a suitable location for the dryer on a hard even surface away from direct sunlight or heat source e.g. Radiators, baseboard heaters, cooking appliances etc . Any floor unevenness should be corrected with leveling legs located on the bottom of the dryer.

  • Page 9: Location Of Your Dryer

    After installation is completed, the following method must be used to determine if the exhaust system is acceptable: 1. Connect an inclined or digital manometer between the dryer and the point the exhaust connects to the dryer. 2. Set the dryer timer and temperature to air fluff (cool down) and start the dryer. 3.

  • Page 10: Installation In Mobile Home

    Installation in mobile home Dryer must be exhausted outside (outdoors, not beneath the mobile home) using metal ducting that will not support combustion. Metal ducting must be 4 inches (10.16 cm) in diameter with no obstructions. Rigid metal duct is preferred. If dryer is exhausted through the floor and area beneath the mobile home is enclosed, the exhaust system must terminate outside the enclosure with the termination securely fastened to the mobile home structure.

  • Page 11: Wire Cord Connections

    Danger : Improper connection of the equipment grounding conductor can result in a risk of electrical shock. Check with a licensed electrician if you are in doubt as to whether the appliance is properly grounded. The dryer MUST be connected to a grounded metal, permanent wiring system, or an equipment grounding conductor must be run with the circuit conductors and connected to the equipment-grounding terminal or lead on the appliance.
  • Page 12 analysis of the common breakdowns Trouble-shooting charts If you replace the thermal limiter or program controller without checking the other components carefully, the thermal limiter or program controller may be damaged again. Therefore, please first check if the other components working normally before replacing the thermal limiter or program controller in maintenance.
  • Page 13 8.2 the tub rotates but does not dry Switch on the power, push down the start button Set timed drying (above 15 min) Observe wether the heater is aglow from the back of the machine Check the ventilation condition ( while the power switches on ) No ventilating Measure the resistance Measure wether there is the voltage between...
  • Page 14 8.4 too much noise in drying the noise includes the harsh , the metallic bang and the big collision sound during drying , These are normal sounds such as vent-like sound and a grating ect. Switch on the power, push down the start button Search the root of the noise Check if these come from the vibration Fasten the support bracket or...
