INSTALLATION INSTRUCTIONS
– VRF System Air Conditioner –
for Refrigerant R410A
■ R410A Models
Model No.
Indoor Units
Type Indoor Units Type
U1 4-Way Cassette
Type Indoor Units Type
U1 4-Way Cassette
* Panel (optional parts)
ENGLISH
Read through the Installation Instructions before you proceed with the installation.
In particular, you will need to read under the "IMPORTANT!" section at the top of the page.
FRANÇAIS
Lisez les instructions d'installation avant de commencer l'installation.
En particulier, vous devez lire la section "IMPORTANT!" en haut de la plage.
ESPAÑOL
Lea las Instrucciones de instalación antes de proceder con la instalación del equipo.
En concreto, deberá leer detenidamente la sección "¡IMPORTANTE!" situada al principio de la página.
DEUTSCH
Lesen Sie die Einbauanleitung, bevor Sie mit der Installation beginnen.
Insbesondere die Hinweise im Abschnitt "WICHTIG!" oben auf der Seite müssen unbedingt gelesen werden.
ITALIANO
Leggere le Istruzioni di installazione prima di procedere con l'installazione.
Prestare particolare attenzione alla sezione "IMPORTANTE!" all'inizio della pagina.
NEDERLANDS
Lees de installatie-instructies zorgvuldig door voor u begint met de installatie.
U moet vooral het gedeelte waar "BELANGRIJK!" boven staat heel goed lezen.
PORTUGUÊS
Leia cuidadosamente as instruções de instalação antes de prosseguir com a instalação.
Em particular, é necessário ler as informações na secção "IMPORTANTE!" na parte superior da página.
ΕΛΛΗΝΙΚΆ
Διαβάστε τις Οδηγίες εγκατάστασης πριν συνεχίσετε με την εγκατάσταση.
Συγκεκριμένα, θα χρειαστεί να διαβάσετε την ενότητα «ΣΗΜΑΝΤΙΚΟ!» στο πάνω μέρος της σελίδας.
БЪЛГАРСКИ
Прочетете инструкциите за инсталиране преди да продължите с инсталирането.
В частност, ще трябва да прочетете раздела „ВАЖНО!" в горната част на страницата.
РУССКИЙ
Перед выполнением установки прочтите инструкцию по установке.
В частности, вам следует прочесть раздел «ВАЖНО!» вверху страницы.
УКРАЇНСЬКА
Перш ніж продовжити встановлення, прочитайте вказівки зі встановлення.
Зокрема, обов'язково прочитайте розділ «ВАЖЛИВО!» вгорі сторінки.
B.INDONESIA
Bacalah seluruh Petunjuk Pemasangan sebelum Anda melakukan pemasangan.
Secara khusus, Anda perlu membaca bagian " PENTING! " di bagian atas halaman.
AMP Air Conditioning
22
28
S-22MU1E5A
S-28MU1E5A
S-36MU1E5A
(CZ-KPU21)*
(CZ-KPU21)*
(CZ-KPU21)*
Rated Capacity
106
140
S-106MU1E5A
S-140MU1E5A
S-160MU1E5A
(CZ-KPU21)*
(CZ-KPU21)*
(CZ-KPU21)*
Rated Capacity
36
45
56
S-45MU1E5A
S-56MU1E5A
(CZ-KPU21)*
(CZ-KPU21)*
160
www.ampair.co.uk | sales@ampair.co.uk
60
73
S-60MU1E5A
S-73MU1E5A
S-90MU1E5A
(CZ-KPU21)*
(CZ-KPU21)*
(CZ-KPU21)*
F616390
90
