- Page 1 Operating Instructions LVC-DV110HM/HP LVC-DV111HM/HP Before installing and using the camera, please read these instructions thorough- ly and retain them for later reference. P/NO: 3834RS0072G...
-
Page 2: Regulatory Notices
Regulatory Notices For U.S.A CAUTION RISK OF ELECTRIC SHOCK This equipment has been tested and found DO NOT OPEN to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC CAUTION TO REDUCE THE RISK OF Rules. -
Page 3: Safety Precautions
1 Safety Precautions Do not attempt to Avoid exposing the disassemble the camera camera to direct sunlight To prevent electric shock, do not Do not aim the camera at bright remove screws or covers. There are no objects. Never point it toward direct user serviceable parts inside. - Page 4 2 What's in the box Video Cable M4 Tapping Screws Camera Body (2EA) (Pan Lock Screw) Optional Adapter (AC 24V, 300mA)
-
Page 5: Front View
3 Construction Front View LG logo 4-pin Dip Switch Tilt Base Zoom Lever Tilting Lock Screw Focus Lever Side View Dome Cover Lens Tilting Lock Screw Dome Cover Separatory Spring... -
Page 6: Rear View
4 Construction Rear View Dome Cover Separatory Spring Video Out AC Power In Pan Base Base Fixing Hole... -
Page 7: Installation
5 Installation Video Cable Connection RED Cable BLACK Cable WHITE Cable BLACK Cable 1. RED : Connect the RED Cable to 1(AC). 2. BLACK : Connect the BLACK Cable to 2(AC). 3. WHITE : Connect the WHITE Cable to 3(V). 4. -
Page 8: Camera Installation
6 Installation Camera Installation 1. Aim the LG logo of the Dome Camera to face the place that you wish to watch. 2. Tighten the M4 Tapping Screws to fix the Dome Camera on the ceiling, then adjust the Pan (Left / Right) by moving the Pan Base. - Page 9 7 Installation NOTE When you disassemble the Dome Cover, lift the Dome Cover • Separatory Spring on the opposite side of LG Logo and turn the Dome Cover clockwise simultaneously. Dome Cover Separatory Spring When you install the camera, handle with care. The camera •...
-
Page 10: Camera Connection
8 Installation Camera Connection Connect the Power Adapter (AC24V, 300mA; optional) to the Power Input Jack of the camera as shown below. Power Adapter Input Jack Jack Adapter Rear Panel Monitor... - Page 11 9 Setup 4-pin Dip Switch Setting This camera has the 4-pin Dip Switch inside of the camera for setting. 1. ALC / ELC : ELC (Electronic IRIS), ALC (Auto IRIS) The default setting is ALC. 2. Y/ DC IRIS : When you use Video Lens or DC IRIS Lens The default setting is DC.
-
Page 12: Backlight Compensation Setting
10 Setup Backlight Compensation Setting Backlight compensation eliminates strong background light which makes the camera picture dark such as a spotlight. You can select the mode for adjusting the iris lens. There are two mode as follows. 1. BLC : Set the BLC to ON. The lens iris is manually fixed at the value that you have set regardless of an object. - Page 13 11 Setup Line Lock Phase Adjustment Volume This function is that V SYNC sig- nal of the VIDEO signal can move based on the power sig- nal. Use this function when screen conversion of the cam- eras can't become softly. (When screen conversion is working, it prevents the screen from becoming jump with vertical...
-
Page 14: Troubleshooting
12 Troubleshooting Check the following guide for the possible cause of a problem before contacting service. The picture is poor. • Does the Dome Cover have lots of dust on the surface? Use a dry cloth to clean the camera when it is dirty. Smear may be caused to the screen of night than daytime. - Page 15 13 Dimension ø100 91mm 10mm 31mm ø121.5...
-
Page 16: Specifications
-10°C ~ 50°C (Humidity : 0%RH ~ 60RH) Storage Temp. -20°C ~ 60°C (Humidity : 0%RH ~ 85RH) Weight 273g Dimensions ø121.5(Diameter)x91(H), Dome Size=ø100 LVC-DV110HM/HP : f=4.0 ~ 9.0mm LVC-DV111HM/HP : f=2.6 ~ 6.0mm Design and specifications are subject to change without notice.
