Summary of Contents for Sony DSR-500WS
- Page 1 NTSC Digital Camcorder DSR-500WS *Optional items are included.
- Page 2 Furthermore, the built-in digital output of the i.LINK™ interface for backup and simple field editing is introduced with the DSR-500WS. The DSR-500WS can be used for a wide variety of field acquisition applications including video journalist, event photographer, news gathering for broadcasting and more.
- Page 3 True Digital Camcorder The DSR-500WS is a “True Digital Camcorder”. The signal is maintained in the digital domain. This allows for higher image quality, free of artifacts and the loss of resolution typical of multiple A/D and D/A conversion. This is a major advantage for the user.
- Page 4 Compact and Lightweight BP-L40 Lithium-ion Battery The Sony BP-L40 is a compact Lithium-ion battery for professional use, which is designed to match the body height of the DSR-500WS. It has a high charge capability in a small and light package, providing continuous camcorder operation for up to approximately 70 minutes.
- Page 5 DSR-500WS with a lens, VF and microphone attached. The case is easy to carry, using the robust shoulder belt; a single person can transport all the required equipment.
- Page 6 Composite Input Board must be installed. Dual Zebra The DSR-500WS has two simultaneous types of zebra patterns - ‘ZEBRA 1’ and ‘ZEBRA 2’. ‘ZEBRA 1’ can be set within a range of 70 IRE to 90 IRE, in 1 IRE steps.
- Page 7 The camera can be instantly set to a standard or auto position simply by pressing the EZ Mode button. The DSR-500WS has a choice of two EZ Modes - STANDARD or CUSTOM. When set to CUSTOM EZ Mode, the camera setting is changed in accordance with the user selected menu setting.
-
Page 8: Other Features
Edit Search The DSR-500WS incorporates an Edit Search function. Its control button is located on the side panel to allow easy access while shooting. Freeze Mix Function With conventional cameras, when the camera operator needs to shoot a subject in the same framework as that of a previously recorded subject, it is very difficult to perfectly re-position the subject. - Page 9 RM-VJ1 Remote Control Unit The Sony RM-VJ1 Remote Control Unit is an exclusive accessory for the DSR-300/500WS, which directly connects to the camcorder via a CCA-7-7A cable. This compact, mobile and...
- Page 10 Anton Bauer light 26-pin DV out ONL Y CCZ-A cable i.LINK 6-pin DSR-70 26-pin DVW-250 or BVW-50 (For simultaneous recording with DSR-500WS) DSR-500WSL Carrying Cases LC-DS300SFT (Soft Carrying Case) NP-1B BP-90A LCR-1 LC-DS500 (Hard Carrying Case) (Rain Cover) Battery Chargers...
- Page 11 UHF Synthesized Tuner Index Picture Board (Wireless microphone receiver) DXF-51 DXF-701WS 1.5” Viewfinder 5” B/W Viewfinder (When it is attached to the DSR-500WS, an attachment kit (Service parts No. A-8274-968-A) is required.) BP-L90A NP-1B NiCd Rechargeable Battery Rechargeable Li-ion Battery Pack BC-L100...
- Page 12 24 dB+DRR: Hyper Gain (30 dB+DPR): * The specifications of “Video/Audio performance” were measured by playing back material on the DSR-85 (via analog component out) that had been recorded on the DSR-500WS. * 0 dBu = 0.775 Vrms DSBK-501 Mass:...
