❈ The design and specification may be different depending on the models. Vacuum Cleaner SU-8500 Series FOR HOUSEHOLD USE ONLY Operating Instructions MPORTANT AFETY NSTRUCTIONS ...3 ACUUM LEANER ISCRIPTION ...4 ACUUM LEANER SSEMBLY ...4 ARTON CONTENTS ...4 CCESSORIES TTACH HANDLE TO VACUUM... -
Page 2: Important Safety Instructions
• Use only as described in this manual. Use only manufacturer’s recommended attachments. • Do not use with damaged cord or plug. • If vacuum cleaner is not working as it should, or has been dropped, damaged, left outdoors or dropped into water, return it to a service center. -
Page 3: Vacuum Cleaner Description
Vacuum Cleaner Description Assembled Vacuum Cleaner Parts TOOL COVER POWERED HAND TOOL CARTRIDGE FILTER TANK LOUVERS/FILTER FRAME DIRT CUP DIRT CUP HANDLE HEIGHT ADJUSTMENT KNOB FURNITURE GUARD Front CAUTION: Do not plug in your vacuum cleaner until you are familiar with all instructions and operating procedures. -
Page 4: Vacuum Cleaner Assembly
Vacuum Cleaner Assembly Carton contents Empty carton. Find the parts shown above before disposing of packing materials. A. Handle section(with 4 screws) B. Cleaner body Attach Handle To Vacuum Stand the vacuum upright and slide the base of the handle firmly into the grooves at the top of the vacuum body. -
Page 5: Attach Vacuum Hose And Tools
Vacuum Cleaner Assembly Attach Vacuum Hose and Tools Wrap the cord around hooks for storage. The top hook rotates right or left for easy cord release. Slide the extend wand into the storage clip. Insert the crevice tool into the nook. -
Page 6: Operation
The brush rolls will automatically turn off when the handle is in the upright position. NOTE: Your SAMSUNG vacuum is equipped with a special internal switch that turns the Rotating Brush off whenever the unit is in the Upright position. -
Page 7: Powerfoot Height Adjustment
Powerfoot Height Adjustment The powerfoot on your SAMSUNG vacuum can be adjusted to clean several floor surfaces. NOTE : For optimal cleaning performance, adjust to the lowest practical setting. If your cleaner is difficult to push, adjust to the next higher setting. -
Page 8: Power Cord Arrangement
Use for upholstered furniture, draperies, mattresses, clothing, automobile interiors, and carpeted stairs. Power Cord Arrangement When you are done using your SAMSUNG vacuum, return it to the Upright position and store the Power Cord. Turn vacuum cleaner OFF(O). Unplug Power Cord by grasping the polarized plug (Not the cord) and disconnect from outlet. -
Page 9: Maintenance
Do not operate cleaner with damp or wet filters or without all filters in place. Cartridge Filter Tank HEPA Media Post-Motor Filter WARNING: To reduce the risk of injury from moving parts, turn off vacuum cleaner and disconnect Power Plug from electrical outlet. -
Page 10: Check Rotating Floor Brush And Drive Belt
Check Rotating Floor Brush and Drive Belt You should check your vacuum cleaner’s Rotating Floor Brush and Drive Belt regularly for wear or damage. You should also clean the brush and brush ends of strings, hair, and carpet fibers. These can wrap around the brush and hamper its ability to effectively clean your carpet. -
Page 11: Clearing Clogs
Clearing Clogs Low suction or poor pickup may be due to a clog in the vacuum cleaner. If you notice a change in the sound of the motor or a reduction in the spinning action, check for clogs. Unplug cleaner from electrical outlet. -
Page 12: Powered Hand Tool(Turbine Brush)
Powered hand tool(Turbine Brush) *Brushbar Replacement Remove the tool from the hose, and turn upside down. Slide the switch to unlock position and remove bottom plate. Unscrew the one screw and remove belt guard. Remove brushbar including end plates and discard. Inspect belt to ensure that it is in good condition. -
Page 13: Troubleshooting
• Broken belt. • Hose not inserted fully. BNORMAL SOUND • Strange sound like air rushes This Vacuum cleaner is approved the following. EMC Directive: 89/336/EEC, 92/31/EEC and 93/68/EEC Low Voltage Safety Directive: 73/23/EEC and 93/68/EEC Possible solution • Plug unit in firmly. - Page 14 DJ68-00237A REV(0.0)
