Sony MDR-ZX780DC Reference Manual

Wireless Noise Canceling
Stereo Headset
Casque stéréo sans fil
réducteur de bruits
MDR-ZX780DC
©2016 Sony Corporation Printed in Malaysia
http://www.sony.net/
English
WARNING
To reduce the risk of electrical shock, do not open the
cabinet. Refer servicing to qualified personnel only.
IMPORTANT SAFETY
INSTRUCTIONS – SAVE
THESE INSTRUCTIONS.
DANGER – TO REDUCE THE
RISK OF FIRE OR ELECTRIC
SHOCK, CAREFULLY
FOLLOW THESE
INSTRUCTIONS.
For connection to a supply not in the U.S.A., use an attachment
plug adaptor of the proper configuration for the power outlet, if
needed.
To reduce the risk of fire or electric shock, do not expose
the AC adaptor to rain or moisture.
To reduce the risk of fire or electric shock, do not expose the AC
adaptor to dripping or splashing, and do not place objects filled
with liquids, such as vases, on the AC adaptor.
Do not install the appliance in a confined space, such as a
bookcase or built-in cabinet.
Do not expose the batteries (battery pack or batteries installed)
to excessive heat such as sunshine, fire or the like for a long
time.
As the main plug of USB AC adaptor is used to disconnect the
USB AC adaptor from the mains, connect it to an easily
accessible AC outlet. Should you notice an abnormality in it,
disconnect it from the AC outlet immediately.
The unit is not disconnected from the AC power source (mains)
as long as it is connected to the wall outlet, even if the unit
itself has been turned off.
Information
FOR UNITED STATES CUSTOMERS. NOT APPLICABLE IN
CANADA, INCLUDING IN THE PROVINCE OF QUEBEC.
POUR LES CONSOMMATEURS AUX ÉTATS-UNIS. NON
APPLICABLE AU CANADA, Y COMPRIS LA PROVINCE
DE QUÉBEC.
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
You are cautioned that any changes or modifications not
expressly approved in this manual could void your authority
to operate this equipment.
This equipment must not be co-located or operated in
conjunction with any other antenna or transmitter.
Note
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
ē Reorient or relocate the receiving antenna.
ē Increase the separation between the equipment and
receiver.
ē Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
ē Consult the dealer or an experienced radio/TV technician
for help.
This device complies with Industry Canada's licence-exempt
RSSs. Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including
interference that may cause undesired operation of the device.
This equipment complies with FCC/IC radiation exposure limits
set forth for an uncontrolled environment and meets the FCC
radio frequency (RF) Exposure Guidelines and RSS-102 of the IC
radio frequency (RF) Exposure rules. This equipment has very
low levels of RF energy that is deemed to comply without
testing of specific absorption rate (SAR).
CAN ICES-3B/NMB-3B
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings.
Install in accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
4-596-345-11(1)
Reference Guide
Guide de référence
9) Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when
unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
The BlUETOOTH word mark and logos are owned by the
Bluetooth SIG, Inc. and any use of such marks by Sony
Corporation is under license.
The N Mark is a trademark or registered trademark of NFC
Forum, Inc. in the United States and in other countries.
Microsoft, Windows and Windows Vista are registered
trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries.
Mac and Mac OS are trademarks of Apple Inc., registered in the
U.S. and other countries.
iPhone is a trademark of Apple Inc., registered in the U.S. and
other countries.
Qualcomm® is a trademark of Qualcomm Incorporated,
registered in the United States and other countries, used with
permission. Qualcomm aptX™ audio is a trademark of
Qualcomm Technologies International, ltd., registered in the
United States and other countries, used with permission.
Android and Google Play are trademarks of Google Inc.
Other trademarks and trade names are those of their respective
owners.
Precautions
On BLUETOOTH communications
ˎ BlUETOOTH wireless technology operates within a range of
about 10 m (30 feet). Maximum communication range may
vary depending on obstacles (human body, metal, wall, etc.)
or electromagnetic environment.
ˎ The antenna is built into the unit as illustrated in the dotted
line. The sensitivity of the BlUETOOTH communications will
improve by turning the direction of the built-in antenna to
the connected BlUETOOTH device. When obstacles are
between the antenna of the connected device and the
built-in antenna of this unit, noise or audio dropout may
occur, or communications may be disabled.
ˎ BlUETOOTH communications may be disabled, or noise or
audio dropout may occur under the following conditions.
ē There is a human body between the unit and the
BlUETOOTH device.
This situation may be improved by placing the BlUETOOTH
device facing the antenna of the unit.
ē There is an obstacle, such as metal or wall, between the
unit and the BlUETOOTH device.
ē A device using 2.4 GHz frequency, such as a Wi-Fi device,
cordless telephone, or microwave oven, is in use near this
unit.
ˎ Because BlUETOOTH devices and Wi-Fi (IEEE802.11b/g/n) use
the same frequency (2.4 GHz), microwave interference may
occur resulting in noise or audio dropout or communications
being disabled if this unit is used near a Wi-Fi device. In such
a case, perform the following.
ē Use this unit at least 10 m (30 feet) away from the Wi-Fi
device.
ē If this unit is used within 10 m (30 feet) of a Wi-Fi device,
turn off the Wi-Fi device.
ē Install this unit and the BlUETOOTH device as near to each
other as possible.
ˎ Microwaves emitting from a BlUETOOTH device may affect
the operation of electronic medical devices. Turn off this unit
and other BlUETOOTH devices in the following locations, as it
may cause an accident:
ē where inflammable gas is present, in a hospital, or a petrol
station
ē near automatic doors or a fire alarm
ˎ Do not use the unit on an airplane. Radio waves may affect
instruments, causing an accident due to malfunction.
ˎ This unit supports security capabilities that comply with the
BlUETOOTH standard to provide a secure connection when
the BlUETOOTH wireless technology is used, but security may
not be enough depending on the setting. Be careful when
communicating using BlUETOOTH wireless technology.
ˎ We do not take any responsibility for the leakage of
information during BlUETOOTH communications.
ˎ Connection with all BlUETOOTH devices cannot be
guaranteed.
ē A device featuring BlUETOOTH function is required to
US
conform to the BlUETOOTH standard specified by
Bluetooth SIG, Inc. and be authenticated.
ē Even if the connected device conforms to the above
FR
mentioned BlUETOOTH standard, some devices may not
be connected or work correctly, depending on the features
or specifications of the device.
ē While talking on the phone hands free, noise may occur,
depending on the device or communication environment.
ˎ Depending on the device to be connected, it may require
some time to start communications.
On charging the unit
ˎ This unit can be charged using USB only. Personal computer
with USB port, or supplied USB charger is required for
charging.
ˎ This unit cannot be turned on, nor can the BlUETOOTH and
noise canceling functions be used, during charging.
ˎ You can use the unit by connecting the supplied headphone
cable, even while charging the unit.
ˎ If you do not use the unit for a long time, the rechargeable
battery may not be able to keep sufficient charge. The
battery will be able to keep a charge properly after
repeatedly discharging and charging several times.
ˎ If you store the unit for a long time, charge the battery once
every half year to prevent over-discharge.
ˎ If the length of time you can use the unit became extremely
short, the rechargeable battery should be replaced with a
new one. Please contact your nearest Sony dealer for a
battery replacement.
Note on static electricity
ˎ Static electricity accumulated in the body may cause mild
tingling in your ears. To minimize the effect, wear clothes
made from natural materials.
If the unit does not operate properly
ˎ Reset the unit.
Push the RESET button with a pointed object, such as a pin,
until you feel a click. The unit will be reset. Pairing
information is not deleted.
ˎ If the problem persists even after the resetting operation
above, initialize the unit as follows.
Turn off the unit by pressing the POWER button for more than
2 seconds. Then, press and hold the POWER button and the
/ button together for more than 7 seconds. The
indicator (blue) flashes 4 times, and the unit is reset to the
factory settings. All pairing information is deleted.
ˎ After the unit is initialized, it may not connect to your iPhone
or computer. In this case, delete the pairing information of
the unit from the iPhone or computer, and then pair them
again.
What is noise canceling?
ˎ The noise canceling circuit actually senses outside noise with
built-in microphones and sends an equal-but-opposite
canceling signal to the unit.
ē The noise canceling effect may not be pronounced in a
very quiet environment, or some noise may be heard.
ē The noise canceling effect may vary depending on how you
wear the unit.
ē The noise canceling function works for noise in the low
frequency band primarily. Although noise is reduced, it is
not canceled completely.
ē When you use the unit in a train or a car, noise may occur
depending on street conditions.
ē Mobile phones may cause interference and noise. Should
this occur, locate the unit further away from the mobile
phone.
ē Do not cover the microphones of the headset (MIC) with
your hands. The noise canceling function may not work
properly.
MIC
Others
ˎ Do not place this unit in a place exposed to humidity, dust,
soot or steam, subject to direct sunlight, or in a car waiting at
a traffic signal. It may cause a malfunction.
ˎ Using the BlUETOOTH device may not function on mobile
phones, depending on radio wave conditions and location
where the equipment is being used.
ˎ If you experience discomfort after using the BlUETOOTH
device, stop using the BlUETOOTH device immediately.
Should any problem persist, consult your nearest Sony dealer.
ˎ listening with this unit at high volume may affect your
hearing. For traffic safety, do not use this unit while driving or
cycling.
ˎ Do not use the unit in places where it would be dangerous if
you are unable to hear ambient sound, such as at railroad
crossings, train station platforms, and construction sites.
ˎ Do not put weight or pressure on this unit as it may cause the
unit to deform during long storage.
ˎ Do not subject the unit to excessive shock.
ˎ Clean the unit with a soft dry cloth.
ˎ Do not expose the unit to water. The unit is not waterproof.
Remember to follow the precautions below.
ē Be careful not to drop the unit into a sink or other container
filled with water.
ē Do not use the unit in humid locations or bad weather,
such as in the rain or snow.
ē Do not get the unit wet.
If you touch the unit with wet hands, or put the unit in a
damp article of clothing, the unit may get wet and this may
cause a malfunction of the unit.
ˎ The earpads may deteriorate due to longterm storage or use.
ˎ If you have any questions or problems concerning this unit
that are not covered in this manual, please consult your
nearest Sony dealer.

Specifications

General
Communication system: BlUETOOTH Specification version 3.0
Output: BlUETOOTH Specification Power Class 2
Maximum communication range: line of sight approx. 10 m
(30 ft) 1)
Frequency band: 2.4 GHz band (2.4000 GHz - 2.4835 GHz)
Modulation method: FHSS
Compatible BLUETOOTH profiles :
2)
A2DP (Advanced Audio Distribution Profile)
AVRCP (Audio Video Remote Control Profile)
HFP (Hands-free Profile)
HSP (Headset Profile)
Supported Codec 3) : SBC , AAC , aptX
4) 5)
Supported content protection method: SCMS-T
Transmission range (A2DP): 20 Hz - 20,000 Hz (Sampling
frequency 44.1 kHz)
Included items:
Wireless noise canceling stereo headset (1)
Micro-USB cable (approx. 50 cm (19 3/4 in.)) (1)
Headphone cable (approx. 1.2 m (47 1/4 in.)) (1)
Carrying pouch (1)
Carrying case (1)
USB charger (1)
Reference Guide (this sheet) (1)
Operating Instructions (1)
Other documents (1 set)
The actual range will vary depending on factors such as
1)
obstacles between devices, magnetic fields around a
microwave oven, static electricity, reception sensitivity,
antenna's performance, operating system, software
application, etc.
2) BlUETOOTH standard profiles indicate the purpose of
BlUETOOTH communications between devices.
3) Codec: Audio signal compression and conversion format
4) Subband Codec
Advanced Audio Coding
5)
Wireless noise canceling stereo
headset
Power source:
DC 3.7 V: Built-in lithium-ion rechargeable battery
DC 5 V: When charged using USB
Mass: Approx. 245 g (8.64 oz)
Operating temperature: 0 °C to 40 °C (32 °F to 104 °F)
Usage hours:
When connecting via the BlUETOOTH device
Music playback time:
Max. 13 hours (NC ON), Max. 19 hours (NC OFF)
Communication time:
Max. 10 hours (NC ON), Max. 12 hours (NC OFF)
Standby time:
Max. 26 hours (NC ON), Max. 150 hours (NC OFF)
When connecting via the headphone cable
Max. 24 hours (NC ON)
Note: Usage hours may be shorter depending on the
Codec and the conditions of use.
Charging time:
Approx. 2.5 hours
Note: Charging hours may be different depending on the
conditions of use.
Charging temperature: 5 °C to 35 °C (41 °F to 95 °F)
Receiver
Type: Closed, Dynamic
Driver units: 40 mm
Frequency response: 8 Hz - 22,000 Hz (when using the
headphone cable)
Maximum input: 100 mW (when using the headphone cable)
Impedance:
NC ON: 23 Ω (1 kHz) (when using the headphone cable)
NC OFF: 50 Ω (1 kHz) (when using the headphone cable)
Sensitivity:
NC ON: 98 dB/mW (when using the headphone cable)
NC OFF: 100 dB/mW (when using the headphone cable)
Microphone
Type: Electret condenser
Directivity: Omni directional
Effective frequency range: 100 Hz - 10,000 Hz
System requirements for battery
charge using USB
Personal Computer with pre-installed with any of the following
operating systems and USB port:
Operating Systems
(when using Windows)
® ®
Windows 8.1 / Windows 8.1 Pro
® ®
Windows 8 / Windows 8 Pro
®
Windows 7
Home Basic / Home Premium / Professional / Ultimate
®
Windows Vista (Service Pack 2 or later)
Home Basic / Home Premium / Business / Ultimate
(when using Mac)
Mac OS X (version.10.3 or later)
Design and specifications are subject to change without notice.
