DIGITAL
VIDEO RECORDER
S S S S P P P P R R R R - - - - 7 7 7 7 1 1 1 1 1 1 1 1 6 6 6 6 / / / / 7 7 7 7 4 4 4 4 1 1 1 1 6 6 6 6
U U U U s s s s e e e e r r r r G G G G u u u u i i i i d d d d e e e e
Please read this manual thoroughly before
use, and keep it handy for future reference.
AB82-01373A REV.00
Advertisement
Table of Contents
Related Manuals for Samsung SPR-7416
Summary of Contents for Samsung SPR-7416
-
Page 1: Video Recorder
DIGITAL VIDEO RECORDER S S S S P P P P R R R R - - - - 7 7 7 7 1 1 1 1 1 1 1 1 6 6 6 6 / / / / 7 7 7 7 4 4 4 4 1 1 1 1 6 6 6 6 U U U U s s s s e e e e r r r r G G G G u u u u i i i i d d d d e e e e Please read this manual thoroughly before use, and keep it handy for future reference. - Page 2 This product has certification for domestic and industrial use. Also, it has taken CE for Europe, FCC for the U.S. Samsung Eco-mark The Samsung’s own Eco mark helps consumers to easily understand that Samsung develops eco- friendly products. This mark represents Samsung’s continuous effort to develop eco-friendly products. RoHS compliant Our product complies with “The Restriction Of the use of certain Hazardous Substances in electrical...
-
Page 4: Notice For Safety
Notice before installation [ Please check these out before using the system.] Avoid any place that has high moisture, dust or black dirt. Avoid any place that has direct sun light or heat. High temperature is not good for the product. - Page 5 Warning Locate the product in shade where proper Do not disassemble or repair the system by temperature remains and avoid place next yourself since the system has high voltage to hot object. Do not place the equipment part inside. or device in the place people visits a lot. •...
- Page 6 Notice Avoid places with strong magnetic or electrical Keep it under proper temperature and field, severe impact or places near a radio or humidity conditions. Maintain a low level of humidity and the Keep it away from magnetic sources, electric operation temperature of 0 °C to 33°C.
-
Page 7: Table Of Contents
Product Contents [ Check to make sure the box has everything below. ] Contact your dealer if there is any missed item. (Optional: Monitor- Recommended monitor is one that supports the resolution of at least 1024 768, 60Hz) SPR SMART SYSTEM Mouse Power Cable SPR Smart Viewer... -
Page 8: System Outline
6. Inatalling WebDVR 7. Installing PPP in Windows 2000 8. Setting Guest User, Password and Account Options. 9. SSC-2000 SYSTEM KEYBOARD 10. DVR Control by SSC-2000 Keyboard 11. External monitor 2 output quality control VI. Specification 1. Specification VII. Q&A 1. -
Page 9: Product Introduction
It also has a function to record continuously so you don’t have to worry about the frequent change of tapes. DVR, therefore, is a video recording surveillance system for the next generation and it is growing very rapidly. In addition to that, it has communication function which enables you to detect remoteness screen even from household and it contains a multi branch of up-to-date function. - Page 10 • This function enables to search images from remote areas through LAN • All of 16 DVRs can connect to one specific Remote at once and it detects, searches, and controls each DVR. Search Multiple Screen • Display images into 1, 4, 9, 16 split screen or into Panorama Search Multi-Camera •...
-
Page 11: Ii.multi Channel Video Surveillance
Multi channel Video Surveillance... -
Page 12: Mainscreen
Multi channel Video Surveillance Mainscreen Division Alarm/Sensor/Audio toggle button Camera/Sensor/Alarm/Audio Description Screen Division : Displays the selected camera image System Status : Display time/date, HDD usage. Screen Division : Select the live image under surveillance. Maximum 16 live image can be displayed (1, 4, 6, 9, 16 division, 4division rotation mode is possible.) State Screen : Display for the status of continuous recording, sensor, alarm, motion, audio or network... -
Page 13: Full Screen Display
• Screen division can be made in 4, 6, 9, 16, full screen and quad rotation. (Screen division type can be different depending on model.) • Any click on certain camera will give you full screen. SPR-7416 16ch full screen rotation SPR-7116... -
Page 14: State Screen
Multi channel Video Surveillance State screen • Display the status of event such as continuous recording, sensor, alarm, motion, audio or network connection. • State screen displays [ time of event - camera number - event type ] State screen Time of event Camera number Above Event... - Page 15 Multi channel Video Surveillance PAN/TILT Mode I - Speed Dome Feature Display current date and time PAN/TILT : controls camera in left and right / up and down / diagonally adjust it FOCUS : adjust focus of the camera lens. (not applied to AUTO FOCUS lens) IRIS : adjust IRIS Out of the camera ZOOM...
-
Page 16: Pan/Tilt Mode-Ii
Multi channel Video Surveillance PAN/TILT Mode II - RX Receiver(Already Setup) Description Indicates current date and time PAN/TILT : controls camera in left and right / up and down / diagonally adjust it FOCUS : adjust focus of the camera lens. (not applied to AUTO FOCUS lens) ZOOM : adjust Zoom In/ Zoom Out of the camera LIGHT... -
Page 17: Environment Setup
Environment Setup... -
Page 18: Hardware
Environment Setup Hardware Press set up button for system setup Screen which inputs password will be appeared. The screen will not be appeared if password is not created. Hardware [Camera] Description Select Camera : To decided which camera to use When Camera Button is pressed: Camera in use When Camera Button is not pressed: Camera not in use camera not in use’... - Page 19 Environment Setup Hardware [Sensor] Function • Record camera image when the external sensor signal is triggered. • Beep when the external sensor detects any signal. • Activate external control output on receipt of sensor signal. Description Select Sensor : The number of external sensors and input terminal should be correspondent to each other. NC/NO : Configure Sensor Each time when the button is clicked it will change to [NC]<->[NO] and vice versa.
- Page 20 Environment Setup Hardware [Alarm] Function • It indicates whether alarm will be used or not and setup sensor and time of output produced. • Output of alarm will be either ON/OFF when any sensor or moving(motion) object is captured. It can control light, siren, speaker, and other external equipment. Description Select Alarm : This button is to choose output of alarm terminal you wish to setup.
- Page 21 Hardware [External monitor] Description • The external monitor function is to transmit the image displayed on DVR monitor by using a general analogue monitor(TV, general monitor). • You can print the images as sequentially converting the images from the camera from 1 to 16 according to the designed time(sec.) or as the split screen system.
-
Page 22: System
Then, the language that you select is applied to the sysem. DVR ADDRESS : DVR address shall be entered to control DVR by keyboard by interlocking DVR and SCC-2000 key board. It is available to enter 0 ~ 255 for DVR address. - Page 23 Environment Setup System [Backup setup] Description Backup schedule setup • This backup media will show reserved list of backup data which will record data, assigned time for backup, and etc. • According to assigned backup schedule, it will backup in order. Calendar •...
- Page 24 Environment Setup Media list : Choose backup data to record backup media It can be added up to 8 from media list and if fail to record on initially setup media, it will automatically back up to next media. Selection should be made as following: HDD, CD-RW, removable drive, Network drive except floppy disk, etc.
- Page 25 Environment Setup Remote drive Select drive : Input IP address and password and select [Select Drive]. In order to connect to Remote backup server for remote backup, remote IP address and registered password from Remote Backup server program is needed. (If password is not registered,select [Select drive] button after IP address from remote site is inputted.) Drive path...
- Page 26 Environment Setup System [S/W Update] Description When [S/W Update] is selected, Intelli Upgrade window will be executed to let you choose new package for program version. This function is to upgrade to a new version that’s stored in hard disk or joint network folder. Description Select Package directory Click [OK] after selecting hard disk or joint network folder which is store in a new version...
- Page 27 Environment Setup System [Other] Description Enable/Disable HDD Warning : This function is to detect the possibility of HDD drive error in advance and info it to the user. A buzzer sounds in the system when the bad sector and overheating generate in HDD disc.
- Page 28 The available control port is COM1. in case of using SSC-2000 keyboard, it is requested to set the communication transmission speed of DVR and keyboard as the same speed. Display setup : It sets up status bar appeared from surveillance screen or area When button is pressed: Appropriate status bar or area appears from detection mode When button is not pressed: Appropriate status bar or area don’t appear from...
-
Page 29: Recording/Display
Environment Setup Storage Structure re-allocation Click [Modify storage structure] and exit the system in the surveillance. Then the system will reboot and you can re-allocate the storage structure. Once you reboot the system below window will appear and select the drive to allocate again. - Page 30 Only 1 channel can record voice when using sound card installed on main board. Voice recording is supported up to 8 channel when using Samsung Electronics Co., Ltd. made exclusive audio board. If sound card and exclusive audio board are installed simultaneously, then we recommend you to record voice using audio board.
- Page 31 Environment Setup (Interworked) Audio Output : Through detection of motion, an external sensor’s detection, or user’s right-clicking the mouse, the audio data along with the video data of an external monitor can be outputted. By interworking with the connected external sensor, the audio data of the corresponding channel can be outputted based on generation of sensor signals.
- Page 32 Environment Setup Input Sensor No. : Select whether to use the sensor inerworking the camera. : The sensor interworks with the corresponding camera. : The sensor does not interwork with the corresponding camera. If a signal is generated is inputted in the sensor interworking with the camera, camera images will be recorded according to the frame rates setting.
- Page 33 All camera images except the camera image selected in the 6 Division mode will be converted. [Notice] • SPR-7416 support 6-division mode. Recording Period : Select the period to store the video data. Then, the data will be kept during the period set here and will be automatically detected after the period expires.
-
Page 34: Schedule
Environment Setup Input Motion No. : Select whether to use interworking Motion feature. Full Screen : Zooms in the camera image to the full-screen size when a sensor is inputted into a sensor interworking with the camera or motion. Select Time (S) : Set the time to convert the full-screen image to the previous image in seconds. -
Page 35: Motion Detection
Environment Setup Record mode (C/M/S/P) : This function is to set recording type with day and time for selected camera. After choosing day and time from selected camera, selecting more than 1 record mode will change selected time within selected time. If you erase all the record type from [Record Mode], selected setup time will change to no record mode. -
Page 36: Motion Detection
Environment Setup Rotate : You may choose specific Month/Day/Year as holiday If you select [None], one day will be assigned and for that specific day only. Holiday list : This function is to show designated holiday and its repeated date or period in a list Any additional holidays will be stored in the list in an alphabetical order. - Page 37 (Proper setup is required depending on situation) Enable / Disale Auto Gain The brightness control for external monitor output is automatically controlled by the DVR system (The Auto gain function can only be selectable on the SPR-7116 model.) Motion Detection Area Select the camera number and draw detection area using left click dragging.
-
Page 38: Network
If any new signal is detected while connection, image transfer time starts again. Password : Input required password to connect from SPR Smart Viewer p.c. (4 digit number is possible.) [Password] : Input password required to access to DVR from SPR Smart Viewer. [Confirm] : Input once again to confirm. -
Page 39: Password Setup
[OK] button. When SPR Smart View Restart Window appears, select [OK] button to restart the system. [Notice] When you try to connect to DVR from SPR Smart Viewer(Remote), SPR Smart View(DVR) checks the site code and password together. Network Port Setting : Network ports used for View-Viewer commnunication must be the same on the both sided. -
Page 40: On-Screen Keyboard Display
Environment Setup On-screen Keyboard On-screen Keyboard Display Functions : It enables to enter letters using on-screen keyboard when there is no separate keyboard os it diffcult to use keyboard. Description Active On-Screen Keybaord : Select on-screen keyboard to enter letters, and you can run on-screen keyboard. Input : Click he parts to enter the letters among the setting items by a mouse and immediately, press the letters(keyboard). -
Page 41: Run Search Program
Search Screen Run Search Program Click on search button to execute from surveillance screen. Password screen will appear for securing purpose Click [OK] if the password was not initially entered Search Screen Search Window Camera Record Time indication and Button Storage Expansion for graph Scroll for... -
Page 42: Camera Selection
Search Screen Camera Selection Camera Selection Screen Description Camera Scroll button : This function is to scroll search button from up and down. Camera : Choose the camera number you wish to search When you double click on camera number, button and the colored graph of appropriate camera number will be changed. - Page 43 : Select [OK] button after adjusting bookmark information. Recording during playback : Image search speed will increase if DVR does not record while searching. In order to set it as recording during playback, click this button again. (This will be disabled in monitoring mode.)
-
Page 44: Search Tool
Search Screen Search Screen Search Tool Brightness : Adjust brightness of the image. Contrast : Adjust contrast of the image. Smooth & Sharpness : Make the rough image smooth and vague image clear. Noise Reduction : Reduce noise in the image. Turning image : Turn the image in the angle of 90, 180 or 270. -
Page 45: Data Backup
Search Screen Data Backup Backup : copy restored data onto media on a selected time or AVI format. Image Backup Image Backup : This is used to backup one still image in BMP or JPEG format. This image can be viewed with other image viewer. - Page 46 Search Screen [ How to use Watermark Checker ] : You can check the authentication of the image restored in BMP or JPG. Watermark Check Program If you execute ‘WMChecker.exe’ which is copied to the media drive with the backup image, following ‘WaterMark’...
- Page 47 Search Screen Time backup (Large Media) : This is a backup using HDD, CD-RW, mobile driver, network driver or copy using IP address. Backup by time This streaming data is our own data type. So this image cannot be read using other program than SPR Smart Viewer program.
-
Page 48: Avi Backup
Search Screen [ Backup onto CD-R / CD-RW ] CD-R/RW backup • Select [Select media] from “backup media“ window. • From “Select backup media“ window, select [OK] button after selecting CD-RW drive which you will backup. • You need to format CD in order to backup CD-R/CD-RW from SPR Smart View program. •... - Page 49 Search Screen Select Compressor : You can select available compression codec under AVI backup. [Tip] • In order to format CD, DNE should have Direct-CD installed. • When other advanced compression codecs then the basic Mpeg compression codec provided on Window were installed, AVI files are saved into smaller sizes, the compression quality is advanced and the time for backup is reduced.
-
Page 50: Print Search Screen
Search Screen AVI Real Time Backup File and Caption information : Using media player provided from Window, caption information of Date and time, days, camera number and etc can be indicated. Other real time player shows image only. [Note] We recommend minimum of v6.4 for Media Player and if caption information cannot be checked, then choose ‘Caption’... -
Page 51: Motion Search
Search Screen [Tip] Print Setup 1. Click Start Setup Print from Windows 2. Double click on ’Add Printer’ when Print Menu appears 3. Click [Next] when Add Pinter Wizard executes 4. Check to see if [Local Printer] is selected and then Click [Next] if Printer is connected to system. - Page 52 Search Screen Designation of a Part to Search : Designate the part to search on the screen. To search the changed image in a specific area of the selected camera, it is required to designate the part of the image to search. Time Selection : Select the starting time and Ending Time to search a specific area of the selected camera.
-
Page 53: Appendix
Appendix... -
Page 54: Formatting A Cd Using Direct Cd
Appendix Formatting a CD using Direct CD [Formatting CD using Direct CD] When you try to backup on an unformatted CD or in case where the message of backup failure has shown, format the CD as follows. Below contents is based on Direct CD v5.1. If some other message comes up, please refer to Direct CD manual. - Page 55 Appendix If Direct CD format utility windows come up, click this button ( Do not click [eject] button.) Select the type, time, and camera for backup and click [OK] button. “WRITE“ LED of CD-R/RW will be turned on till CD writing is done. Do not press button in CD-R/RW Once the backup is done, click “Eject”...
-
Page 56: Formatting A Cd Using Incd
Appendix Formatting a CD using InCD [Formatting CD using InCD] • When trying to back up date in an unformatted CD or receiving an error message after trying to backup up, format the CD by the following procedure. • insert a black CD, and click on “Format CDR/CDRW” from “Data Backup” window. Then, the following screen will appear. -
Page 57: Serial Cable Connection (Input)
Appendix • After the CD is completely formatted, the following window will appear. (Click on the “Confirm” button to complete formatting.) • After the CD is completely formatted, continue backup by the same method as those of the hard disk or movable drives (DVD-RAM, ZIP, MOD, ORB, etc.) •... -
Page 58: Pan/Tilt Drive Connection
Appendix PAN/TILT Drive connection [I/O Board] EXTERNAL MONITOR RS-422 connection (from RX-Receiver) RS-232 Connection (from Com1 port) [Notice] • Be cautious about (+),(-) of the signal line. Wrong connection of the signal line might cause damage. • Please contact our distributor if you use other brand’s RX Receiver. •... - Page 59 Appendix Install WebDVR Insert the SPR Smart View CD into the CD-ROM and duble-click on the folder where the SPR Smart View program is saved. When the following window appears, double-click on Disk1 folder. Select “Setup” (If CD-R/RW drive is set as “auto“ Direct CD program will run automatically.) Click on “Next”...
-
Page 60: Installing Ppp In Windows 2000
Appendix The program will be installed. After “Installation is completed sucessfully” message is displayed, check in “Restart your computer” field and click on “Finish” button. If “Restart your computer” field is not checked, the WebDVR program may not be completely installed. The computer will be rebooted, and the WebDVR program will be completely installed before the user starts to run the program. - Page 61 Appendix Select the modem installed in the system, and click on “Next”. Select “Internet Protocol (TCP/IP)” from networking components list, and click on “Properties”. Click on “Next”. Make a setting as shown below, and click on “OK” Select one of allowed users as a guest, and click on “Next”.
-
Page 62: Setting Guest User, Password And
Appendix Click on “Finish”. Then, change the guest user as well as the password and the account. (For more information about setting the account, see “Changing Guest User’s Password” in “Appendix”. ) Setting Guest user, Password, and Account Options Setting Account Passwords and Options Select Control Panel, and double-click on “User and Password”. - Page 63 Appendix Select to view Properties of the guest user. (Select a guest and right-click on it. Then, Propertices window will appear as shown below.) If “Account is locked out “ field is checked, uncheck this field. Click on “OK”. Select a guest user, and right-click on it. Select set password from the pull-down menu. Type in “1234”...
-
Page 64: Ssc-2000 System Keyboard
: This function is to force to stop the alarm output when an alarm sounds in DVR. Joystick Controller (UP/DOWN/LEFT/RIGHT/AF) : This function is used to move the action of Pan/Tilt connected to SAMSUNG Dome Camera or Receiver unit up/down/left/right and control the action of Auto Focus. In addition, this is used to control the action of Zoom by turning it clockwise or counterclockwise. -
Page 65: Dvr Control By Ssc-2000 Keyboard
[Emergency Rec] button again and enter the password from the password input screen and then select [OK] button. Alarm release This function is to force to stop the alarm output, when an alarm sounds in DVR. Environment Setting If you select [ ] button to set the system, the password input screen shall be displayed for the system security.If you enter the password from the password input screen and select [OK] button, the... - Page 66 SPR Smart View screen. If you select the selected camera button again, the screen shall return to the previous screen. If you select [ ] button, the screen shall be changed over to DVR control screen. 0 0 1 SPR-7116...
-
Page 67: External Monitor 2 Output Quality Control
This is because the power of the signal can drop over a long distance. To overcome this problem you can use the control switch on the back panel of the DVR <SPR-7116 Model>... -
Page 68: Specification
The distance between the DVR and external monitor should be measured then you can change the control switch on the back of the DVR accordingly. There are 4 level settings for the difference distances between DVR and Monitor so you can select which gives the best picture. - Page 69 Display Speed • 1, 4, 6, 9, 16 split screen, full screen SPR-7416 : 480 Frames/sec, 16Ch Monitors Real time, 480 Frames/sec Recording Real time • 1, 4, 9, 16 split screen, full screen SPR-7116 : 480 Frames/sec, 16Ch Monitors Real time, 120 Frame/sec Recording Alarm Output •...
- Page 70 Q&A...
- Page 71 Q&A The system is not powered on and LED status indicator is not operated. Check if the power is connected properly. Check the voltage of power supply. If the power is not on after checking the two items above, then inspect or replace the power supply.
- Page 72 Warranty Guide This product has passed thorough quality control and test, and if this get broken during normal use we provide 12 months warranty service. Warranty Guide Check this warranty sheet first. Please contact the distributor after checking out any defect in the product. The standard for repairing, replacement or reimbursement follows Customer Warranty Content Any defect under normal use within the warranty service period we give you free repair service...
