- Page 1 DISCRETE SEMICONDUCTORS DATA SHEET book, halfpage CR6927 Triple video driver hybrid amplifier Product specification Supersedes data of 1997 Oct 02 File under Discrete Semiconductors, SC05 M3D156 1998 Feb 12...
- Page 2 Philips Semiconductors Triple video driver hybrid amplifier FEATURES Transition times (10 to 90%) with 45 V (p-p) swing and C = 10 pF: rise time (typ.) 2.5 ns fall time (typ.) 2.1 ns Low power consumption: 11 W with 25 MHz square wave...
- Page 3 Philips Semiconductors Triple video driver hybrid amplifier CHARACTERISTICS = 85 V; T = 25 C; C = 10 pF; output swing = 45 V (p-p) with 42.5 V DC offset (see Fig 7); unless otherwise specified. SYMBOL PARAMETER supply current...
- Page 4 Philips Semiconductors Triple video driver hybrid amplifier handbook, halfpage (ns) = 85 V; T = 25 C; C = 10 pF; (R1 + R2) = 330 ; output swing = 45 V (p-p) with 42 V DC offset. Fig.4 Rise time as a function of load capacitance;...
-
Page 5: Type Description
Test equipment (see Fig.7) EQUIPMENT Pulse generator Le Croy; Model 9210 with unit 9212 Philips; Model PM5785B (125 MHz) with internal DC offset Power supply Philips; Model PE1541, 80 V FET probe Philips; Model PM8943, attenuation 100 : 1 Sampling oscilloscope Tektronix;... -
Page 6: Package Outline
Philips Semiconductors Triple video driver hybrid amplifier PACKAGE OUTLINE Ceramic single-ended flat package; heatsink mounted; 2 mounting holes; 12 in-line tin (Sn) plated leads DIMENSIONS (mm are the original dimensions) UNIT 0.51 36.2 18.2 0.25 0.38 35.8 17.8 OUTLINE VERSION... -
Page 7: Life Support Applications
Philips customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Philips for any damages resulting from such improper use or sale. - Page 8 Switzerland: Allmendstrasse 140, CH-8027 ZÜRICH, Tel. +41 1 488 2686, Fax. +41 1 488 3263 Taiwan: Philips Semiconductors, 6F, No. 96, Chien Kuo N. Rd., Sec. 1, TAIPEI, Taiwan Tel. +886 2 2134 2865, Fax. +886 2 2134 2874 Thailand: PHILIPS ELECTRONICS (THAILAND) Ltd., 209/2 Sanpavuth-Bangna Road Prakanong, BANGKOK 10260, Tel.
