Summary of Contents for Sony TA-F3A
- Page 2 SAFE OPERATION. REPLACE THESE COMPONENTS (60 Hz: 7 kHz = 4:1) Less than 0.1% at 1W output WITH SONY PARTS WHOSE PART NUMBERS APPEAR A8 SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. ATTENTION AU COMPOSANT AVANT RAPPORT...
- Page 4 1-2. CIRCUIT DESCRIPTION Muting Circuit (See Fig. 1-3 and Fig. 1-4) This muting circuit prevents the loud “pop” (due PROTECTION CIRCUIT to initial current flow) or click noises produced just after turning the POWER switch to on or off. Two kinds of protection circuit are employed in These transients might damage a delicate high- this power amplifier.
