Summary of Contents for Bosch DMExRMSxx

  • Page 1 DME Series Instruction Manual EN Integrated Fixed Dome...
  • Page 2: Important Safeguards

    Important Safeguards 1. Read, Follow, and Retain Instructions - All safety 10. Power Sources - Operate the unit only from the type and operating instructions should be read and of power source indicated on the label. If unsure of followed before operating the unit. Retain instructions the type of power supply to use, contact your dealer for future reference.
  • Page 3: Safety Precautions

    Safety Precautions For Indoor Product 1. Water and Moisture - Do not use this unit near water - for example, in a wet basement, in an unprotected outdoor installation or in any area classified as a wet location. CAUTION: TO REDUCE THE RISK OF 2.
  • Page 4: Precauciones De Seguridad

    Sicherheitshinweise Sécurité ATTENTION : POUR ÉVITER TOUT RISQUE D'ÉLECTROCUTION, VORSICHT: UM EINEN ELEKTRISCHEN SCHLAG ZU N'ESSAYEZ PAS DE RETIRER LE CAPOT (OU LE PANNEAU VERMEIDEN, IST DIE ABDECKUNG (ODER RÜCKSEITE) NICHT ARRIÈRE). CET APPAREIL NE CONTIENT AUCUN COMPOSANT ZU ENTFERNEN. ES BEFINDEN SICH KEINE TEILE IN DIESEM SUSCEPTIBLE D'ÊTRE RÉPARÉ...
  • Page 5 Sicurezza ATTENZIONE: PER RIDURRE IL RISCHIO DI SCOSSE ELETTRICHE NON RIMUOVERE LA COPERTURA (O IL PANNELLO POSTERIORE). L'UNITÀ NON CONTIENE COMPONENTI INTERNI RIPARABILI DALL'UTENTE. PER QUALSIASI INTERVENTO, RIVOLGERSI A PERSONALE TECNICO QUALIFICATO. Questo simbolo indica la presenza di "tensione pericolosa" non isolata all'interno del contenitore del prodotto.
  • Page 6: Table Of Contents

    CONTENTS UNPACKING ............6 MODEL NUMBERS .
  • Page 7: Unpacking

    1. NOTE: a W at the end of a number indicates a Wall-mounted version (e.g. DME6PMS38W). SERVICE If the unit ever needs repair service, the customer should contact the nearest Bosch Security Systems Service Center for return authorization and shipping instructions.
  • Page 8 Set-up Lead. Clamps swing out to secure unit. Mounting Clamps (3). Fold in to install unit. T-Connector. Power Leads. Connect video out lead here. Rotate T-Connector (make power connections first.) for clear access. Note clamp in extended position. CEILING Figure 1 Ceiling Mount Power & Video Connections 2.
  • Page 9: Pendant Model (Dmexpx Series)

    Pendant Model (DMExPx Series) The pendant mount version of the DME Series can be wall or conduit/pipe mounted. 4.2.1 Conduit/Pipe Mounting 1. When pendant mounting a vertical conduit, route power/video cables through your mounted conduit. Then, route these cables through the removable pendant cap. 2.
  • Page 10: Camera Adjustments

    Wall Arm Secure wall arm to wall with appropriate anchors using Pendant Cap four #6 or four 4 mm screws Supplied with (not included). Dome Unit Electrical Box Mounting Option: Hole pattern in mounting plate matches a North Conduit Nut American double-outlet electrical box.
  • Page 11: Remote Video Setup

    Remote Video Setup A second coaxial cable is included to allow the installer to set up the video at the camera site using a small spare monitor. Refer to the following steps for this procedure. 1. After the power and video connections are made to the camera and the dome is mounted correctly, connect the setup coax cable with BNC located next to the camera/lens module to the remote monitor.
  • Page 12: Camera & Lens Settings

    CAMERA AND LENS SETTINGS Line Lock / Phase / Backlight Compensation Settings As received, the unit will be set such that the line lock is on, the backlight compensation is off, and the white balance is on. See Detail for Camera Module Adjustmens and Connections Figure 7 Camera Assembly on/off...
  • Page 13: Spare Parts/Accessories

    SPARE PARTS/ ACCESSORIES Spare Parts Description Part No. Dome/Trim Ring 315 3741 001 Inner Liner 315 3741 002 Pendant Cap 315 3741 003 Mounting Clamps/Screws (3 sets) 315 3741 004 Lens - 3–8 mm DC Iris LEN 3.08.0AI-T Lens - 5–50 mm DC Iris LTC 3374/20 Accessories Description...
  • Page 16 +1 800 289 0096 Fax: +31 (0) 40 27 86668 Fax: +65 6319 3499 security.sales@us.bosch.com emea.securitysystems@bosch.com apr.securitysystems@bosch.com http://www.boschsecurity.us http://www.boschsecurity.com http://www.boschsecurity.com © 2005 Bosch Security Systems GmbH F01U010413_01 05-25 | Updated July 14, 2005 | Data subject to change without notice.
