Page 1 High Performance & Energy Saving ■ Long Piping(Length & Height) ■ Long Ambient Operation(In Low Temp.) EH035EAV/EH052EAV/EH070EAV ■ : Up to -10˚C(Heating), Up to -5˚C(Cooling) Eco-friendly Product ■ (Lead-Free, RoHS, WEEE) UH035EAV UH052EAV UH070EAV For more information, Please access to our service web site(http://itself.sec.samsung.co.kr)
Page 2: Table Of Contents
17. Wiring Diagram ..........................7-1 Indoor Unit ............................7-2 Outdoor Unit ............................ 18. Schematic Diagram ........................8-1 Indoor Unit ............................8-2 Outdoor Unit ............................ 19. Circuit Descriptions ........................9-1 PCB Circuit Descriptions ........................9-2 Refrigerating Cycle Diagram ......................Samsung Electronics...
Page 3 14-2 Low Refrigerant Pressure Distribution 14-2 ..................14-3 Pressure & Capacity mark 14-3 ......................14-4 Q & A for Non-trouble 14-4 ........................14-5 Cleaning/Filter Change 14-7 ......................... 14-6 Installation 14-8 ............................14-7 Installation Diagram of Indoor Unit and Outdoor Unit 14-9 ............Samsung Electronics...
Page 4: Precautions
Do not place a cloth or other materials over it. ● Remove the batteries if you don’t use the remote control for a long time. (If applicable) ● Use the remote control within 7 meters from the indoor unit. (If applicable) Samsung Electronics...
Page 5: Disposing Of The Unit
● Young children or infirm persons should be always supervised when they use the air conditioner. ● Max current is measured according to IEC standard for safety. ● Current is measured according to ISO standard for energy efficiency. Samsung Electronics...
Page 6: Product Specifications
– EH052/070EAV : Max.30m Long & 15m Height ■ Long Ambient Operation (In Low Temperature) It can arise the reliability and the capacity of the air conditioner, especially operated in low temperature. ■ Eco-friendly Product (Lead-Free, RoHS, WEEE) Samsung Electronics...
Page 7: Product Specifications
Refrigerant Control Unit Freezer Oil Capacity Refrigerant to Change(R410A) 1,000 (~15m chargeless, 15~20m 15g/m) Protection Device(OLP) None Cooling Test Condition Indoor Unit: DB27 WB19˚C Outdoor Unit: DB35˚C WB24˚C Heating Test Condition Indoor Unit: DB20˚C WB15˚C Outdoor Unit: DB7˚C WB6˚C Samsung Electronics...
Page 8 2 Row 36 Step Refrigerant Control Unit Freezer Oil Capacity Refrigerant to Change(R410A) 1,450(20g/m) 1,900(10g/m) Protection Device(OLP) None Cooling Test Condition Indoor Unit: DB27˚C WB19˚C Outdoor Unit: DB35˚C WB24˚C Heating Test Condition Indoor Unit: DB20˚C WB15˚C Outdoor Unit: DB7˚C WB6˚C Samsung Electronics...
Page 9: The Comparative Specifications Of Product
Item EH070EAV DH24BT(Basic) Indoor Unit Design Outdoor Unit Indoor Unit 31.0kg 34.0kg Net Weight Outdoor Unit 57.0kg 74.0kg Indoor Unit 1,100x199x600mm 1,100x199x600mm Outer Dimension (WxHtxD) Outdoor Unit 880x798x310mm 880x798x310mm Indoor Unit 42dB↓ 42dB↓ Noise Outdoor Unit 60dB↓ 59dB↓ Samsung Electronics...
Page 10: Accessory And Option Specifications
Q'TY Remark Wired remote controller DB97-01904G Owner's Manual DB98-25806A Installation Manual DB98-25807A DB62-03440H Insulation DB62-03439H Indoor Unit Insu Pipe Joint Out DB62-03439J DB72-00143D Insu Pipe Joint In DB72-00143E Ass'y Holder Drain Pipe DB90-02064A Ass'y Drain Hose Joint DB94-00758A Samsung Electronics...
Page 11 Product Specifications Wireless Remote Controller Accessories ■ Item Descriptions Code-No. Q'TY Remark Wireless remote controller DB93-00251G Battery DB47-90024A Remote control holder DB61-00204A STS 2S-2x10 tapped screw 6002-000581 Owner’s instructions DB98-05156A Installation manual DB98-05184A Samsung Electronics...
Page 12 Q'TY Remark Wired remote controller DB93-01766C Cable-tie DB65-10088B Cable clamp DB65-10074E M4x16 tapped screw 6002-000474 Indoor unit power drawing cable DB39-00221A Communication cable of the DB39-00933A wired remote controller Wire joint DB39-90020A Owner’s instructions DB98-15731A Installation manual DB98-15770A Samsung Electronics...
Page 13: Alignment And Adjustments
(Display is unrelated Main-Inverter Micom(After 1 minute of Main-Inverter with operation) detection) ● : On, ◑ : Flickering, X : OFF ◆ If you turn off the air conditioner when the LED is flickering, the LED is also turned off. Samsung Electronics...
Page 14: Led Display
◑ EEPROM error ◑ ◑ ◑ ◑ ◑ EEPROM option error ● : On, ◑ : Flickering, X: OFF ◆ If you turn off the air conditioner when the LED is flickering, the LED is also turned off. Samsung Electronics...
Page 15 Outdoor unit Capacity Setup Option Error Wired Liquid Crystal ↔ Indoor unit Comm. Error Master Wired Liquid Crystal ↔ Slave Liquid Crystal Comm. Error Wired Remote Control Error Wired Liquid Crystal COM1/COM2 Cross Error Error of setting option for wired remote controller COM2 Samsung Electronics...
Page 16: Outdoor Led Error Display And Check Method
● Power ON reset(1sec) ◎ ○ ○ Capacity miss match ○ ◎ ◎ Test Operation at Cooling Mode ◎ ◎ ◎ Test Operation at Heating Mode ● : LED ON, ○ : LED OFF, ◎ : LED BLINK Samsung Electronics...
Page 17: Setting Option Setup Method
Push the button to set the display panel to Every time you push the button, the display panel reads ➡ ➡ ➡ . . . repeatedly. ➡ ➡ ➡ ➡ ➡ ➡ ➡ Samsung Electronics...
Page 18 If all lamps of indoor unit are flickering, Plug out, plug in power plug again and press ON/OFF key to retry. If the unit is not working properly or all lamps are continuously flickering after setting the option code, see if the correct option code is set up for its model. Samsung Electronics...
Page 19: Option Items
Operating Instructions and Installation Alignment and Adjustments ■ OPTION ITEMS REMOCON SEG1 SEG2 SEG3 SEG4 SEG5 SEG6 SEG7 SEG8 SEG9 SEG10 SEG11 SEG12 MODEL EH035EAV EH052EAV EH070EAV Samsung Electronics...
Page 20: Disassembly And Reassembly
1) Disassemble the Cabinet Top Motor. & - Unscrew 8 screws Blower 2) Disassemble 2 Cover Blower Uppers. - After unscrewing 2 screws - Disassemble the Cover Blower Upper with pushing its hook. 3) Disassemble the Cover Control. - Unscrew 2 screws Samsung Electronics...
Page 21 Partition. - Unscrew a screw 6) Disassemble the band Motor for fixing the Motor. - Unscrew 2 screws 7) After disassembling the Motor and Blower for the set, disassemble the Blower by use of 3mm wrench. Samsung Electronics...
Page 22 1) Disassemble the Cabinet Top Evap. - Unscrew 11 screws 2) Disassemble the Bracket Outlet Sub that fixes the Drain Pan equipped on the front of the set. - Unscrew 6 screws 3) Disassemble the Drain Cushion from the set. Samsung Electronics...
Page 23 Inlet air temperature sensor, and EEV wire that connected to the inside of PCB. 3) Disassemble the Support Evap. LF that fixes the Evaporator. - Unscrew 2 screws 4) Disassemble the Support Evap RH. - Unscrew 2 screws Samsung Electronics...
Page 24 Capacitor from the Case. 4) In case of disassembling the Case Control, disassemble the Case Control from the set after unscrewing the screw connected to the direction of Blower. - Disassemble if after disassembling the Cabinet Top Motor 1-1). Samsung Electronics...
Page 25 5) In case of disassembling the Trans Power, unscrew the screw fixing on the Case. ✳ Disassemble if after disassembling the case PCB 4-4). Bracket Outlet 1) Disassemble the Bracket Outlet assembled on the Cabinet. - Unscrew 10 screws Samsung Electronics...
Page 26 Disassembly and Reassembly ■ EH052EAV/EH070EAV Parts Procedure Remark Filter 1) Pull out the Filter as picture 1 or picture 2. 2) If it is necessary, after disassembling 8 indicating screws, detach the Bracket Filter. Samsung Electronics...
Page 27 Blower 1) After disassembling 13 indicating screws, & detach Ass’y Cabinet-Top Motor. Motor 2) After disassembling 3 indicating screws, detach Ass’y Case Blower Upper. – Press the pothook of the Case Blower and detach Ass’y Case Blower Upper. Samsung Electronics...
Page 28 Cover Control. 4) Detach the Motor Wire Connected to PCB and Capacitor. 5) After disassembling the indicating screws, detach the wire connected to the Partition. 6) After disassembling 2 indicating screws, detach the Ass’y Band Motor. Samsung Electronics...
Page 29 Blowers from the axis of the Motor by 3mm inner hexagon spanner. Drain Pan 1) After disassembling 15 indicating screws, detach Ass’y Cabinet-Top Evap. 2) After disassembling 6 indicating screws, detach the Bracket Outlet. 3) Detach the Drain Pan. 4-10 Samsung Electronics...
Page 30 1) After disassembling 2 indicating screws, detach Ass'y Cover Pipe. 2) Detach the Sensor from the Control Box.(including 2 Sensors) 3) After disassembling 2 indicating screws, detach Ass'y Support Evap LF. 4) After disassembling 2 indicating screws, detach Ass'y Support Evap RH. Samsung Electronics 4-11...
Page 31 3) If only the disassembly of Capacitor is required, detach it from the set. 4) If only the disassembly of Case Control is required, detach it from the set after disassembling 2 indicating screws. 4-12 Samsung Electronics...
Page 32 Disassembly and Reassembly Parts Procedure Remark 5) Detach the Transformer after disassembling 2 indicating screws. ✳ Work is possible after disassembling the Case PCB. Ass’y Bracket 1) After disassembling 16 indicating screws, Outlet detach Ass’y Bracket Outlet. Samsung Electronics 4-13...
Page 33: Outdoor Unit
Cabinet Side edges and a fixing screw on the Cabinet Front lower to detach the Cabinet Front. 3) Detach the Cabinet Front like the picture on the right side. 4) Loosen 1 screw fixed to assemble Plate Control Out with Cabinet-Side RH. 4-14 Samsung Electronics...
Page 34 Disassembly and Reassembly Parts Procedure Remark 5) Loosen 2 fixing screws on the rear side of Cabinet-Side RH. 6) Loosen 3 screws fixed to assemble Bracket Valve with Cabinet-Side RH. 7) Loosen 2 fixing screws of Cabinet-Side LF. Samsung Electronics 4-15...
Page 35 1) Detach the Motor Wire from the PCB of Ass'y Control Out. 2) Detach several connectors from the PCB of Ass'y Control Out. 3) Detach 2 Connect Wires from Reactor. 4) Loosen 1 screw fixed to assemble Ass'y Control Out with Partition. 4-16 Samsung Electronics...
Page 36 1) Loosen the Nut of Terminal Cover. 2) Detach the Terminal Cover and detach the Connect Comp Wire from Compressor. 3) Disassemble the Felt Comp Sound. 4) Loosen the 3 bolts at the bottom of Compressor like the picture on the right side. Samsung Electronics 4-17...
Page 37 1) Loosen 1 fixing screw of the Cover-Control and detach the Cover Control. 2) Loosen fixing screws and detach the Cabinet-Upper. 3) Loosen 1 screw fixed to assemble Control Box with Cabinet-Side RH. 4) Loosen 6 fixing screws and detach the Cabinet-Side RH. 4-18 Samsung Electronics...
Page 38 Operating Instructions and Installation Disassembly and Reassembly Parts Procedure Remark 5) Loosen 2 screws fixed on the Guide Condenser. 6) Loosen fixing screws of the Cabinet Front. Samsung Electronics 4-19...
Page 39 5) Loosen 2 fixing screws and detach the Bracket Motor. Ass’y Control Out 1) Detach several connectors from the Ass’y Control Out. 2) Detach several connectors from the PCB of Ass’y Control Out. 3) Pull up the Ass’y Control Out. 4-20 Samsung Electronics...
Page 40 4) Detach the Heat Exchanger. Compressor 1) Loosen the fixing nut and detach the Compressor Lead Wire. 2) Disassemble the Felt Comp Sound. 3) Loosen the 3 bolts at the bottom of Compressor like the picture on the right side. Samsung Electronics 4-21...
Page 41 1) Loosen 1 fixing screw of the Cover-Control and detach the Cover Control. 2) Loosen each 8 fixing screws and detach the Cabinet-Upper. 3) Loosen 1 screw fixed to assemble Control Box with Cabinet-Side RH. 4) Loosen fixing screws and detach the Cabinet-Side RH. 4-22 Samsung Electronics...
Page 42 Operating Instructions and Installation Disassembly and Reassembly Parts Procedure Remark 5) Loosen 2 screws fixed on the Guide Condenser. 6) Loosen fixing screws of the Cabinet Front. Samsung Electronics 4-23...
Page 43 2) Detach the Fan Propeller. 3) Loosen 4 fixing screws to detach the Motor. 4) Disconnect the wire between Ass’y Control Out and Motor. 5) Loosen 2 fixing bolts and detach the Bracket Motor. 4-24 Samsung Electronics...
Page 44 3) Pull up the Ass’y Control Out. Heat Exchanger 1) Release the refrigerant at first. 2) Loosen fixing screw on both sides. 3) Disassemble the pipes in both inlet and outlet with welding torch. 4) Detach the Heat Exchanger. Samsung Electronics 4-25...
Page 45 Procedure Remark Compressor 1) Loosen the fixing nut and detach the Compressor Lead Wire. 2) Disassemble the Felt Comp Sound. 3) Loosen the 3 bolts at the bottom of Compressor like the picture on the right side. 4-26 Samsung Electronics...
Page 46 MEMO Samsung Electronics 4-27...
Page 47: Exploded Views And Parts List
5. Exploded Views and Parts List 5-1 Indoor Unit ■ EH035EAV 23-5 23-6 23-4 23-1 23-7 23-8 23-3 23-2 Samsung Electronics...
Page 48 COVER CONTROL SGCC-M T0.5 23-4 DB61-40291A HOLDER WIRE PP BLACK 23-5 DB65-00105L TERMINAL BLOCK 6P 6P, POWER 23-6 DB65-00105M TERMINAL BLOCK 6P 6P, COMMUNICATION 23-7 DB26-10070G TRANS POWER 230V, 50HZ 23-8 2301-001370 CAPACITOR 450V 2.5µF DB32-00142A ASS’Y THERMISTOR ASS’Y Samsung Electronics...
Page 49 Exploded Views and Parts List ■ EH052EAV/EH070EAV 30-1 30-6 30-2 30-3 30-4 30-5 Samsung Electronics...
Page 50 TERMINAL BLOCK 6P 6P,POWER 30-5 DB65-00105M TERMINAL BLOCK 6P 6P,COMMUNICATION 30-6 DB26-10070G TRANS POWER 60Hz DB32-00142A ASS’Y THERMISTOR ASS’Y DB61-02349A CLIP BRUSH NYLON66,BLACK DB63-01299C FILTER MSWG1,T1,192,1005 DB61-02643A BRACKET FILTER SGCC-M DB90-02101A ASS’Y COVER CONTROL ASS’Y DB93-03213G ASS’Y PCB ASS’Y Samsung Electronics...
Page 51: Outdoor Unit
5-2 Outdoor Unit ■ UH035EAV 19-1 20-2 19-2 20-1 20-3 17-3 17-4 17-5 17-2 17-1 Samsung Electronics...
Page 52 FUJIKOKI, ø1.4 20-2 DB62-03964A VALVE EXPANSION COIL FUJIKOKI 20-3 DB62-02283A VALVE SERVICE R410A, SANHUA, 1/4” DB93-03453A ASS’Y CONTROL OUT ASS’Y DB61-01861A GUIDE SCREEN P.E.H 100% DB63-01479A FELT COMP BASE FELT DB32-00083K THERMISTOR OUT/DIS ASS’Y DB32-00081D THERMISTOR COND ASS’Y Samsung Electronics...
Page 53 Exploded Views and Parts List ■ UH052EAV 18-1 15-3 15-4 15-2 15-1 16-1 Samsung Electronics...
Page 54 DB63-10165D COVER-TERMINAL DB99-00711A ASS’Y-4WAY V/V ASS’Y 16-1 DB62-02285A VALVE SERVICE 1/2’’ DB99-00708A ASS’Y VALVE EEV ASS’Y DB93-03665D ASS’Y CONTROL-OUT ASS’Y 18-1 DB81-00534A REACTOR 5mH,20A DB63-01223B CLOTH-COMP SOUND FELT+EVAR DB61-00821B GUARD-SCREEN P.E.H DB32-00081D SENSOR TEMP-COND ASS’Y DB32-00083G THERMISTOR-OUT/DISCHARGE ASS’Y Samsung Electronics...
Page 55 Exploded Views and Parts List ■ UH070EAV 18-1 15-3 15-4 15-2 15-1 16-1 Samsung Electronics...
Page 56 DB99-00710B ASS’Y-4WAY V/V ASS’Y 16-1 DB62-02342A VALVE SERVICE 5/8’’ DB99-00709A ASS’Y VALVE EEV ASS’Y DB93-03665E ASS’Y CONTROL OUT ASS’Y 18-1 DB81-00534A REACTOR 5mH,20A DB63-01223B CLOTH-COMP SOUND FELT+EVAR DB61-00821A GUARD-SCREEN P.E.H DB32-00081D SENSOR TEMP-COND ASS’Y DB32-00083J THERMISTOR-OUT/DISCHARGE ASS’Y Samsung Electronics 5-10...
Page 57: Ass'y Control Out
5-3 Ass'y Control Out ■ UH035EAV : DB93-03453A 5-11 Samsung Electronics...
Page 58 M4xL10 TH+ ZPC(YEL) DB81-00547B INSULATOR MICA DB39-01198A C/W-DISP(5P) DB98-24813A ASS’Y-THERMAL GREASE DB39-00604W LEAD CONNECTOR-N SKYBLU DB39-00604X LEAD CONNECTOR-L 6009-001001 SCREW SPECIAL SCREW EARTH DB61-00206A HOLDER WIRE CLAMP SGCC-M, T0.5 6002-001149 SCREW TAPPING M4x10 2S PH+ DB65-10088D CABLE TIE NYLON66 Samsung Electronics 5-12...
Page 59 Ass'y Control Out(cont.) ■ UH052EAV : DB93-03665D UH070EAV : DB93-03665E 5-13 Samsung Electronics...
Page 60 PH,+,M3,L8 DB91-00306A ASS’Y-SCREW MACHINE PH,+,M3,L16 DB91-00307A ASS’Y-SCREW MACHINE PH,+,M4,L16 6002-000555 SCREW-TAPPING PH,+,M4,L25 6001-001054 SCREW-MACHINE TH,+,M4,L10 6009-001001 SCREW-SPECIAL TH,+,M4,L8 6002-000536 SCREW-TAPPING PH,+,M4,L10 DB98-24813A ASS’Y-THERMAL GREASE INV,RADIANT HEAT 0.002 0.002 DB61-00206A HOLDER-WIRE SGCC-M,T0.5 6002-001149 SCREW-TAPPING PH,+,M4,L10 DB65-10088D CABLE-TIE NY-66 Samsung Electronics 5-14...
Page 61: Electrical Parts List
C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 C504 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C505 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C506 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C801 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C802 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C806 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C807 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C808 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C815 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 Samsung Electronics...
Page 62 DIODE-SWITCHING RLS4148,75V,150mA,LL-34,TP D906 0401-000133 DIODE-SWITCHING RLS4148,75V,150mA,LL-34,TP D907 0401-000133 DIODE-SWITCHING RLS4148,75V,150mA,LL-34,TP D912 0401-000133 DIODE-SWITCHING RLS4148,75V,150mA,LL-34,TP D913 0401-000133 DIODE-SWITCHING RLS4148,75V,150mA,LL-34,TP D914 0401-000133 DIODE-SWITCHING RLS4148,75V,150mA,LL-34,TP D915 0401-000133 DIODE-SWITCHING RLS4148,75V,150mA,LL-34,TP D916 0401-000133 DIODE-SWITCHING RLS4148,75V,150mA,LL-34,TP D917 0401-000133 DIODE-SWITCHING RLS4148,75V,150mA,LL-34,TP D918 0401-000133 DIODE-SWITCHING RLS4148,75V,150mA,LL-34,TP Samsung Electronics...
Page 63 IC20 0801-000393 IC-CMOS LOGIC 74HC86,OR GATE,SOP,14P,150MIL,QUAD,ST, -,2.0/6.0V,0.26V,-40to+85C,180mW,4.2V,1uA IC51 1103-001175 IC-EEPROM 93LC56,128x16,SOP,8P,5x4mm,2.5/6.0V, -40to+85C LED11 0601-001373 ROUND,RED,3mm,630nm LED12 0601-001375 ROUND,GRN,3mm,570nm,3.8x5.3mm LED13 0601-001377 ROUND,YEL,3mm,585nm,3.8x5.3mm DB41-00364A PBA LOGIC BOARD miniDVM_slimduct_chi,-,FR-4 ,T-1.6,-,-, 220~240V,50/60Hz Q201 0501-000534 TR-SMALL SIGNAL 2SC2412K,NPN,200mW,SOT-23,TP,180-390 Q202 0501-000534 TR-SMALL SIGNAL 2SC2412K,NPN,200mW,SOT-23,TP,180-390 Samsung Electronics...
Page 64 R-CHIP 1Kohm,5%,1/8W,TP,2012 R401 2007-001067 R-CHIP 6.8Kohm,1%,1/8W,TP,2012 R402 2007-001067 R-CHIP 6.8Kohm,1%,1/8W,TP,2012 R403 2007-001067 R-CHIP 6.8Kohm,1%,1/8W,TP,2012 R404 2007-000766 R-CHIP 330ohm,5%,1/8W,TP,2012 R405 2007-000766 R-CHIP 330ohm,5%,1/8W,TP,2012 R406 2007-000766 R-CHIP 330ohm,5%,1/8W,TP,2012 R413 2007-000613 R-CHIP 24Kohm,1%,1/8W,TP,2012 R416 2007-000766 R-CHIP 330ohm,5%,1/8W,TP,2012 R440 2007-001071 R-CHIP 6.8Kohm,5%,1/8W,TP,2012 Samsung Electronics...
Page 65 3501-001248 RELAY-MINIATURE 12V,-,11.7mA,DPDT,4mS,4mS RY70 3501-001154 RELAY-MINIATURE 12Vdc,200mW,3000mA,1FormA,10mS,10mS RY71 3501-001154 RELAY-MINIATURE 12Vdc,200mW,3000mA,1FormA,10mS,10mS RY74 3501-001154 RELAY-MINIATURE 12Vdc,200mW,3000mA,1FormA,10mS,10mS SS71 3502-001026 DC 12V,12V,3A,1mS,- SW02 3406-001098 SWITCH-ROTARY 240V AC,25A,6P(10C),L14mm SW04 DB34-00009A SWITCH-DIGITAL PT65 103,ROTARY DIP,-,DC24V Max, 0.4VA,50mOhm Max,-,BULK, 10mmx10mm,straight,-,-,- SW05 3407-000121 SWITCH-DIP 24V,300mA,SLIDE,STANDARD Samsung Electronics...
Page 66 3407-000121 SWITCH-DIP 24V,300mA,SLIDE,STANDARD SW07 3407-000121 SWITCH-DIP 24V,300mA,SLIDE,STANDARD VA71 1405-000154 VARISTOR 460Vdc,2500A,17.5x7.5mm,TP VA75 1405-000154 VARISTOR 460Vdc,2500A,17.5x7.5mm,TP X301 2802-001179 RESONATOR-CERAMIC 4MHz,0.5%,BK,8x3x5.5mm X701 2301-001220 C-FILM,LEAD-PPF 100nF,10%,275V,BK,18x6x12,15 X702 2301-001220 C-FILM,LEAD-PPF 100nF,10%,275V,BK,18x6x12,15 DB62-03085A HEAT SINK -,A6063,25,15,15,-,-,SSEC DB68-02809A LABEL BAR CODE -,-,-,-,W170,L115,-,-,-,FOR PACKING CASE Samsung Electronics...
Page 67 C-CER,CHIP 1.2nF,5%,25V,SL,TP,1608 C406 2203-002041 C-CER,CHIP 0.47nF,10%,50V,X7R,1608 C407 2203-002041 C-CER,CHIP 0.47nF,10%,50V,X7R,1608 C408 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 C409 2401-002300 C-AL 47uF,20%,50V,GP,TP,6.3x11,5 C410 2401-002300 C-AL 47uF,20%,50V,GP,TP,6.3x11,5 C411 2401-002300 C-AL 47uF,20%,50V,GP,TP,6.3x11,5 C412 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 C413 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 C414 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 Samsung Electronics...
Page 68 C802 2203-000609 C-CER,CHIP 22nF,10%,50V,X7R,TP,2012 C803 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C900 2203-006104 C-CER,CHIP 1000nF,10%,50V,X7R,3225 C901 2201-000322 C-CERAMIC,DISC 2.2NF,10%,2KV,Y5P,TP,13x5mm,10 C902 2401-000480 C-AL 10uF,20%,50V,GP,TP,5x11,5 C905 2401-002598 C-AL 220uF,20%,50V,GP,TP,10x16,5 C906 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 C907 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 CN01 3711-005654 HEADER-BOARD TO CABLE 1WALL,7P,1R,3.96mm,ANGLE,SN,WHT Samsung Electronics...
Page 69 IC81 DB98-20678A ASS’Y-PHOTOCOUPLER KFR-35(25)GW/GPI,TLP351 DB95-00599A ASS’Y-IPM KFR-35GW/GPI,INVERTER LED1 DB98-16601A ASS’Y-LED RED -,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-, LED2 DB98-16600A ASS’Y-LED GREEN -,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-, LED3 DB98-16602A ASS’Y-LED YEL -,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-,-, DB41-00412A PCB MAIN-OUTDOOR INV BAC-INV,FR4,2,-,1.6T,140x160,-,1,-,BLDC-INV PT02 DB26-00049A TRANS PULSE PT_50,MH080FXEA4,10,65.5,8~14,EI2218,FERRITE, AC90-275V,-25˚C~+105˚C,BULK,GND 2P Q801 0504-000127 TR-DIGITAL FJV3102RMTF,NPN,200mW,10K/10K,SOT-23,TP Samsung Electronics...
Page 70 4.7Kohm,5%,1/10W,TP,1608 R418 2006-001013 R-CEMENT 0.02ohm,5%,7W,CA,BK,35x9.5x9.5mm R419 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R420 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R421 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R422 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R423 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R424 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R425 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R426 2007-008261 R-CHIP 150Kohm,1%,1/2W,TP,5025 Samsung Electronics 6-10...
Page 71 5.1Kohm,5%,1/8W,TP,2012 R543 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608 R554 2007-000077 R-CHIP 470ohm,5%,1/10W,TP,1608 R601 2007-000468 R-CHIP 1Kohm,5%,1/8W,TP,2012 R602 2007-000766 R-CHIP 330ohm,5%,1/8W,TP,2012 R603 2007-000766 R-CHIP 330ohm,5%,1/8W,TP,2012 R604 2007-000468 R-CHIP 1Kohm,5%,1/8W,TP,2012 R805 2007-000300 R-CHIP 10Kohm,5%,1/8W,TP,2012 R806 2007-000950 R-CHIP 47ohm,5%,1/4W,TP,3216 R807 2007-000553 R-CHIP 20ohm,5%,1/4W,TP,3216 6-11 Samsung Electronics...
Page 72 SH12BPB,#1015 16 AWG,AWG,3,290/280/270, red/blue/yellow,16,MG620877,-,-,250V,-,29 WIRE-PCB DB39-01194B CONNECT WIRE AS12(09)BPB,#1007 26 AWG,-,7P,150,WHT,-, SMH200-07 WHT,YBH200-07WHT,BK,230V/50Hz WIRE-REACTOR DB39-00998F CBF LEAD WIRE -,AS12(09)BPBX,-,200,260,-,600V,AWG#16, WHIT & YEL,-,-,CORE TR29G5A XTAL01 2802-001179 RESONATOR-CERAMIC 4MHz,0.5%,BK,8x3x5.5mm ZD200 0403-000282 DIODE-ZENER MMBZ5232B,5%,225mW,SOT-23,TP ZD201 0403-000282 DIODE-ZENER MMBZ5232B,5%,225mW,SOT-23,TP ZD23 0403-000282 DIODE-ZENER MMBZ5232B,5%,225mW,SOT-23,TP Samsung Electronics 6-12...
Page 73 10nF,+80-20%,50V,Y5V,2012 C202 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 C203 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 C204 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 C205 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 C301 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 C302 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C303 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C304 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C305 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 6-13 Samsung Electronics...
Page 74 10nF,+80-20%,50V,Y5V,2012 C428 2401-001552 C-AL 47uF,20%,35V,GP,TP,6.3x11,2.5 C429 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C430 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C501 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C502 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C503 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C504 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C505 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 C506 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 Samsung Electronics 6-14...
Page 75 100nF,+80-20%,25V,Y5V,1608 C721 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C722 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 C801 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 C802 2203-005261 C-CER,CHIP 1000nF,10%,25V,X7R,3216 C803 2306-000123 C-FILM,LEAD-PPF 100nF,5%,630V,BK,26x16.5x8.5,2 C805 2401-000832 C-AL 220uF,20%,25V,GP,TP,8x11.5,5 C900 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 C901 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 C902 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 6-15 Samsung Electronics...
Page 76 IC31 0604-001003 PHOTO-COUPLER TR,50-150%,200mW,DIP-4,ST IC41 1201-000166 IC-OP AMP LM358,SOP,ST,8P,150MIL,DUAL,100V/MV,PLASTIC, 32V,500mW,0TO+70C,70DB,0.6V/US,5NA,- IC42 1202-000104 IC-VOLTAGE COMP. 393,SOP,8P,150MIL,DUAL,36V,CMO IC50 DB09-00461A IC MICOM MB90F823,-,80 P,5 V,24 MHz,STM-0580-OA,24,16, QFP,QFP,14x20 mm,16,-40~85 IC51 0506-000175 TR-ARRAY 2003,NPN,7,1W,SOP-16,ST,1000 IC52 0506-000175 TR-ARRAY 2003,NPN,7,1W,SOP-16,ST,1000 IC53 0506-000175 TR-ARRAY 2003,NPN,7,1W,SOP-16,ST,1000 Samsung Electronics 6-16...
Page 77 Q906 0504-000001 TR-DIGITAL DTA114EKA,PNP,200mW,10K/10K,SOT-23,TP Q907 0504-000001 TR-DIGITAL DTA114EKA,PNP,200mW,10K/10K,SOT-23,TP R001 2006-001080 R-CEMENT(S) 200ohm,5%,5W,CB,BK,13x9x25.5mm R101 2003-000855 R-METAL OXIDE(S) 47Kohm,5%,3W,AA,TP,6x16mm R102 2007-001074 R-CHIP 6.8ohm,5%,1/8W,TP,2012 R103 2007-000468 R-CHIP 1Kohm,5%,1/8W,TP,2012 R104 2007-000686 R-CHIP 3.3Kohm,5%,1/8W,TP,2012 R105 2007-001222 R-CHIP 9.09Kohm,1%,1/8W,TP,2012 R106 2007-000263 R-CHIP 1.82Kohm,1%,1/8W,TP,2012 6-17 Samsung Electronics...
Page 78 100ohm,5%,1/8W,TP,2012 R404 2007-000290 R-CHIP 100ohm,5%,1/8W,TP,2012 R405 2007-000290 R-CHIP 100ohm,5%,1/8W,TP,2012 R406 2007-000290 R-CHIP 100ohm,5%,1/8W,TP,2012 R407 2007-000872 R-CHIP 4.7Kohm,5%,1/8W,TP,2012 R408 2007-000781 R-CHIP 33ohm,5%,1/8W,TP,2012 R409 2007-000781 R-CHIP 33ohm,5%,1/8W,TP,2012 R410 2007-000781 R-CHIP 33ohm,5%,1/8W,TP,2012 R412 2007-000928 R-CHIP 470ohm,1%,1/8W,TP,2012 R413 2007-008261 R-CHIP 150Kohm,1%,1/2W,TP,5025 Samsung Electronics 6-18...
Page 79 5.1Kohm,5%,1/10W,TP,1608 R512 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608 R513 2007-000076 R-CHIP 330ohm,5%,1/10W,TP,1608 R514 2007-000614 R-CHIP 24Kohm,1%,1/10W,TP,1608 R515 2007-000455 R-CHIP 18Kohm,1%,1/10W,TP,1608 R516 2007-000455 R-CHIP 18Kohm,1%,1/10W,TP,1608 R517 2007-000455 R-CHIP 18Kohm,1%,1/10W,TP,1608 R518 2007-000076 R-CHIP 330ohm,5%,1/10W,TP,1608 R519 2007-000076 R-CHIP 330ohm,5%,1/10W,TP,1608 R520 2007-000076 R-CHIP 330ohm,5%,1/10W,TP,1608 6-19 Samsung Electronics...
Page 80 47ohm,5%,1/4W,TP,3216 R807 2007-000553 R-CHIP 20ohm,5%,1/4W,TP,3216 R808 2007-000931 R-CHIP 470ohm,5%,1/8W,TP,2012 R900 2007-001318 R-CHIP 1Kohm,5%,1/4W,TP,3216 R901 2007-001318 R-CHIP 1Kohm,5%,1/4W,TP,3216 R902 2007-001318 R-CHIP 1Kohm,5%,1/4W,TP,3216 R903 2007-001318 R-CHIP 1Kohm,5%,1/4W,TP,3216 R904 2007-001318 R-CHIP 1Kohm,5%,1/4W,TP,3216 R905 2007-001318 R-CHIP 1Kohm,5%,1/4W,TP,3216 R906 2007-001318 R-CHIP 1Kohm,5%,1/4W,TP,3216 Samsung Electronics 6-20...
Page 81 DC12V,3A 250V AC,-,-,10mS,10mS RY04 3501-001238 RELAY-POWER DC12V,3A 250V AC,-,-,10mS,10mS RY05 3501-001238 RELAY-POWER DC12V,3A 250V AC,-,-,10mS,10mS RY31 3501-001248 RELAY-MINIATURE 12V,-,11.7mA,DPDT,4mS,4mS XTAL01 2802-001179 RESONATOR-CERAMIC 4MHz,0.5%,BK,8x3x5.5mm XTAL51 2802-001179 RESONATOR-CERAMIC 4MHz,0.5%,BK,8x3x5.5mm ZD21 0403-000282 DIODE-ZENER MMBZ5232B,5%,225mW,SOT-23,TP ZD22 0403-000282 DIODE-ZENER MMBZ5232B,5%,225mW,SOT-23,TP ZD72 0403-000282 DIODE-ZENER MMBZ5232B,5%,225mW,SOT-23,TP 6-21 Samsung Electronics...
Page 82 10nF,+80-20%,50V,Y5V,2012 C204 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 C205 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 C301 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 C302 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C303 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C304 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C305 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C306 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C307 2201-000154 C-CERAMIC,DISC 10nF,+80-20%,2kV,Y5P,TP,20x5mm,7.5 Samsung Electronics 6-22...
Page 83 10nF,+80-20%,50V,Y5V,2012 C428 2401-001552 C-AL 47uF,20%,35V,GP,TP,6.3x11,2.5 C429 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C430 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C501 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C502 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C503 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C504 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C505 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 C506 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 6-23 Samsung Electronics...
Page 84 47uF,20%,35V,GP,TP,6.3x11,2.5 C715 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 C721 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 C722 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 C801 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 C802 2203-005261 C-CER,CHIP 1000nF,10%,25V,X7R,3216 C803 2306-000123 C-FILM,LEAD-PPF 100nF,5%,630V,BK,26x16.5x8.5,2 C805 2401-000832 C-AL 220uF,20%,25V,GP,TP,8x11.5,5 C900 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 C901 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 Samsung Electronics 6-24...
Page 85 393,SOP,8P,150MIL,DUAL,36V,CMO IC30 0801-000393 IC-CMOS LOGIC 74HC86,OR GATE,SOP,14P,150MIL,QUAD,ST,-, 2.0/6.0V,0.26V,-40to+85C,180mW,4.2V,1uA, IC31 0604-001003 PHOTO-COUPLER TR,50-150%,200mW,DIP-4,ST IC41 1201-000166 IC-OP AMP LM358,SOP,ST,8P,150MIL,DUAL,100V/MV,PLASTIC, 32V,500MW,0TO+70C,70DB,0.6V/US,5NA,- IC42 1202-000104 IC-VOLTAGE COMP. 393,SOP,8P,150MIL,DUAL,36V,CMO IC50 DB09-00461A IC MICOM MB90F823,-,80 P,5 V,24 MHz,STM-0580-OA,24,16, QFP,QFP,14x20 mm,16,-40~85 IC51 0506-000175 TR-ARRAY 2003,NPN,7,1W,SOP-16,ST,1000 6-25 Samsung Electronics...
Page 86 Q904 0504-000001 TR-DIGITAL DTA114EKA,PNP,200mW,10K/10K,SOT-23,TP Q905 0504-000001 TR-DIGITAL DTA114EKA,PNP,200mW,10K/10K,SOT-23,TP Q906 0504-000001 TR-DIGITAL DTA114EKA,PNP,200mW,10K/10K,SOT-23,TP Q907 0504-000001 TR-DIGITAL DTA114EKA,PNP,200mW,10K/10K,SOT-23,TP R001 2006-001080 R-CEMENT(S) 200ohm,5%,5W,CB,BK,13x9x25.5mm R101 2003-000855 R-METAL OXIDE(S) 47Kohm,5%,3W,AA,TP,6x16mm R102 2007-001074 R-CHIP 6.8ohm,5%,1/8W,TP,2012 R103 2007-000468 R-CHIP 1Kohm,5%,1/8W,TP,2012 R104 2007-000686 R-CHIP 3.3Kohm,5%,1/8W,TP,2012 Samsung Electronics 6-26...
Page 87 100ohm,5%,1/8W,TP,2012 R402 2007-000290 R-CHIP 100ohm,5%,1/8W,TP,2012 R403 2007-000290 R-CHIP 100ohm,5%,1/8W,TP,2012 R404 2007-000290 R-CHIP 100ohm,5%,1/8W,TP,2012 R405 2007-000290 R-CHIP 100ohm,5%,1/8W,TP,2012 R406 2007-000290 R-CHIP 100ohm,5%,1/8W,TP,2012 R407 2007-000872 R-CHIP 4.7Kohm,5%,1/8W,TP,2012 R408 2007-000781 R-CHIP 33ohm,5%,1/8W,TP,2012 R409 2007-000781 R-CHIP 33ohm,5%,1/8W,TP,2012 R410 2007-000781 R-CHIP 33ohm,5%,1/8W,TP,2012 6-27 Samsung Electronics...
Page 88 10Kohm,5%,1/10W,TP,1608 R510 2007-000109 R-CHIP 1Mohm,5%,1/10W,TP,1608 R511 2007-000965 R-CHIP 5.1Kohm,5%,1/10W,TP,1608 R512 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608 R513 2007-000076 R-CHIP 330ohm,5%,1/10W,TP,1608 R514 2007-000614 R-CHIP 24Kohm,1%,1/10W,TP,1608 R515 2007-000455 R-CHIP 18Kohm,1%,1/10W,TP,1608 R516 2007-000455 R-CHIP 18Kohm,1%,1/10W,TP,1608 R517 2007-000455 R-CHIP 18Kohm,1%,1/10W,TP,1608 R518 2007-000076 R-CHIP 330ohm,5%,1/10W,TP,1608 Samsung Electronics 6-28...
Page 89 330ohm,5%,1/10W,TP,1608 R805 2007-000300 R-CHIP 10Kohm,5%,1/8W,TP,2012 R806 2007-000950 R-CHIP 47ohm,5%,1/4W,TP,3216 R807 2007-000553 R-CHIP 20ohm,5%,1/4W,TP,3216 R808 2007-000931 R-CHIP 470ohm,5%,1/8W,TP,2012 R900 2007-001318 R-CHIP 1Kohm,5%,1/4W,TP,3216 R901 2007-001318 R-CHIP 1Kohm,5%,1/4W,TP,3216 R902 2007-001318 R-CHIP 1Kohm,5%,1/4W,TP,3216 R903 2007-001318 R-CHIP 1Kohm,5%,1/4W,TP,3216 R904 2007-001318 R-CHIP 1Kohm,5%,1/4W,TP,3216 6-29 Samsung Electronics...
Page 90 DC12V,3A 250V AC,-,-,10mS,10mS RY04 3501-001238 RELAY-POWER DC12V,3A 250V AC,-,-,10mS,10mS RY05 3501-001238 RELAY-POWER DC12V,3A 250V AC,-,-,10mS,10mS RY31 3501-001248 RELAY-MINIATURE 12V,-,11.7mA,DPDT,4mS,4mS XTAL01 2802-001179 RESONATOR-CERAMIC 4MHz,0.5%,BK,8x3x5.5mm XTAL51 2802-001179 RESONATOR-CERAMIC 4MHz,0.5%,BK,8x3x5.5mm ZD21 0403-000282 DIODE-ZENER MMBZ5232B,5%,225mW,SOT-23,TP ZD22 0403-000282 DIODE-ZENER MMBZ5232B,5%,225mW,SOT-23,TP ZD72 0403-000282 DIODE-ZENER MMBZ5232B,5%,225mW,SOT-23,TP Samsung Electronics 6-30...
Page 91 0406-001109 DIODE-TVS SAC5.0,7.6/-/-V,500W,DO-15 CD32 0406-001109 DIODE-TVS SAC5.0,7.6/-/-V,500W,DO-15 CN01 3711-000024 HEADER-BOARD TO CABLE BOX,3P,1R,2.5mm,STRAIGHT,SN,WHT CN03 3711-003873 HEADER-BOARD TO CABLE BOX,7P,1R,2mm,STRAIGHT,SN,NTR CN30 DB98-24921A ASS’Y-HOOK WHT UH035EAV,SMAW250A-06 WHT CN50 DB98-22299A ASS’Y-HOOK WHT INVERTER,SMAW250A-04 WHT CN51 DB98-22298A ASS’Y-HOOK RED INVERTER,SMAW250A-O4 RED 6-31 Samsung Electronics...
Page 92 47Kohm,5%,1/4W,TP,3216 R314 2007-000944 R-CHIP 47Kohm,5%,1/4W,TP,3216 R315 2007-000300 R-CHIP 10Kohm,5%,1/8W,TP,2012 R414 2007-000455 R-CHIP 18Kohm,1%,1/10W,TP,1608 R499 2007-000455 R-CHIP 18Kohm,1%,1/10W,TP,1608 R500 2007-000455 R-CHIP 18Kohm,1%,1/10W,TP,1608 R501 2007-000455 R-CHIP 18Kohm,1%,1/10W,TP,1608 R502 2007-000614 R-CHIP 24Kohm,1%,1/10W,TP,1608 R503 2007-000614 R-CHIP 24Kohm,1%,1/10W,TP,1608 R504 2007-000455 R-CHIP 18Kohm,1%,1/10W,TP,1608 Samsung Electronics 6-32...
Page 93 2007-001177 R-CHIP 8.2Kohm,5%,1/8W,TP,2012 R911 2007-000964 R-CHIP 5.1Kohm,5%,1/8W,TP,2012 R912 2007-000964 R-CHIP 5.1Kohm,5%,1/8W,TP,2012 R913 2007-000964 R-CHIP 5.1Kohm,5%,1/8W,TP,2012 RY31 3501-001248 RELAY-MINIATURE 12V,-,11.7mA,DPDT,4mS,4mS WIRE-COMM 485 DB39-01017F CONNECT WIRE-COMM KH035EAV,UL1015,AWG #22,2,180,RED/BLUE,22, 179974-1,-,TP,230V/50Hz,3.96mm,180,AWG WIRE-EARTH DB39-00514F CBF LEAD WIRE-EARTH -,KFR-35(25)GW/GPI,-,200,-,-,-,GRN/YEL,-,-,- XTAL51 2802-001179 RESONATOR-CERAMIC 4MHz,0.5%,BK,8x3x5.5mm 6-33 Samsung Electronics...
Page 94 Specification Q'TY SA/SNA Remark D901 0401-000005 DIODE-SWITCHING 1N4148,75V,150mA,DO-35,TP D902 0401-000005 DIODE-SWITCHING 1N4148,75V,150mA,DO-35,TP LED91 0601-000402 ROUND,YEL,3mm,585nm,- LED92 0601-000552 ROUND,GRN,3mm,570nm LED93 0601-001373 ROUND,RED,3mm,630nm 3404-000165 SWITCH-TACT 12V,50mA,160gf,6x6mm,SPST 3404-000165 SWITCH-TACT 12V,50mA,160gf,6x6mm,SPST CN953 3711-004068 HEADER-BOARD TO CABLE BOX,5P,1R,2mm,ANGLE,SN,WHT DB41-00447A PCB DISPLAY AS24BPB,FR-1,1,00,1.6T,45,Q,15,-,- Samsung Electronics 6-34...
Page 95 560V,2500A,17.5x7.5mm,TP VA09 1405-000154 VARISTOR 560V,2500A,17.5x7.5mm,TP C/W POWER DB39-00998C WIRE-POWER UL1015 AWG #16 L/W AC_L DB39-00961T WIRE-AC_L UL1015 AWG #16, BRN L/W AC_N DB39-00961U WIRE-AC_N UL1015 AWG #16, SKYBLU L/W EARTH DB39-00514F WIRE_EARTH UL1015 AWG #16, GRN/YEL 280mm 6-35 Samsung Electronics...
Page 96 -,AS24(18)BPB,2,180,-,-,-,BRN,-,-,- 3712-001139 CONNECTOR-TERMINAL TAB,MALE,-,6.35x0.8mm DB41-00433A PCB SUB-EMI BOARD AS18BPB,FR-4,2,1.0,1.6T,-,-,-,-,- R002 2001-001150 R-CARBON(S) 470Kohm,5%,1/2W,AA,TP,2.4x6.4mm R003 2001-001150 R-CARBON(S) 470Kohm,5%,1/2W,AA,TP,2.4x6.4mm VA01 1405-000154 VARISTOR 460Vdc,2500A,17.5x7.5mm,TP VA02 1405-000154 VARISTOR 460Vdc,2500A,17.5x7.5mm,TP VA03 1405-000154 VARISTOR 460Vdc,2500A,17.5x7.5mm,TP VA04 1405-000154 VARISTOR 460Vdc,2500A,17.5x7.5mm,TP VA05 1405-000154 VARISTOR 460Vdc,2500A,17.5x7.5mm,TP Samsung Electronics 6-36...
Page 97 -,UH070EAV,-,200,-,-,-,BRN,-,-,- 3712-001139 CONNECTOR-TERMINAL TAB,MALE,-,6.35x0.8mm DB41-00433A PCB SUB-EMI BOARD AS18BPB,FR-4,2,1.0,1.6T,-,-,-,-,- R002 2001-001150 R-CARBON(S) 470Kohm,5%,1/2W,AA,TP,2.4x6.4mm R003 2001-001150 R-CARBON(S) 470Kohm,5%,1/2W,AA,TP,2.4x6.4mm VA01 1405-000154 VARISTOR 460Vdc,2500A,17.5x7.5mm,TP VA02 1405-000154 VARISTOR 460Vdc,2500A,17.5x7.5mm,TP VA03 1405-000154 VARISTOR 460Vdc,2500A,17.5x7.5mm,TP VA04 1405-000154 VARISTOR 460Vdc,2500A,17.5x7.5mm,TP VA05 1405-000154 VARISTOR 460Vdc,2500A,17.5x7.5mm,TP 6-37 Samsung Electronics...
Page 98: Wiring Diagram
7. Wiring Diagram 7-1 Indoor Unit This Document can not be used without Samsung’s authorization. Samsung Electronics...
Page 99: Outdoor Unit
7-2 Outdoor Unit ■ UH035EAV This Document can not be used without Samsung’s authorization. Samsung Electronics...
Page 100 Wiring Diagram ■ UH052EAV This Document can not be used without Samsung’s authorization. Samsung Electronics...
Page 101 Wiring Diagram ■ UH070EAV This Document can not be used without Samsung’s authorization. Samsung Electronics...
Page 102: Schematic Diagram
8. Schematic Diagram 8-1 Indoor Unit This Document can not be used without Samsung’s authorization. Samsung Electronics...
Page 103: Outdoor Unit
8-2 Outdoor Unit 8-2-1 UH035EAV ■ Inverter This Document can not be used without Samsung’s authorization. Samsung Electronics...
Page 104 Schematic Diagram ■ Main This Document can not be used without Samsung’s authorization. Samsung Electronics...
Page 105 Schematic Diagram 8-2-2 UH052EAV/UH070EAV This Document can not be used without Samsung’s authorization. Samsung Electronics...
Page 106 MEMO Samsung Electronics...
Page 107: Circuit Descriptions
Wired Remote Controller Power(12V) 485 Communication Part(F1/F2) 485 Communication Part(F3/F4) Temperature Sensor Part - Room Temperature - Eva. In Temperature Micom download Display Part Option & Address Set S/W Floating S/W This Document can not be used without Samsung’s authorization. Samsung Electronics...
Page 108 Circuit Descriptions Circuit Descriptions 9-1-2 Outdoor Unit(UH035EAV) ■ Inverter BLDC FAN INVERTER SMPS MICOM COMMUNICATION This Document can not be used without Samsung’s authorization. Samsung Electronics...
Page 109 Circuit Descriptions Circuit Descriptions ■ Main TEMPERATURE SENSOR & EEV 485 COMMUNICATION This Document can not be used without Samsung’s authorization. Samsung Electronics...
Page 110 Circuit Descriptions Circuit Descriptions 9-1-3 Outdoor Unit(UH052EAV/UH070EAV) TEMPERATURE SENSOR & EEV SMPS INVERTER This Document can not be used without Samsung’s authorization. Samsung Electronics...
Page 111: Refrigerating Cycle Diagram
9-2 Refrigerating Cycle Diagram ■ EH035EAV/UH035EAV Samsung Electronics...
Page 112 Circuit Descriptions ■ EH052EAV/UH052EAV, EH070EAV/UH070EAV Samsung Electronics...
Page 113: Pcb Diagram
External control OUT(ERROR, COMP. Status) : SMW250-04(RED) Display : SMW200-09(WHT) External Option SUB PCB Connector : SMW250-05(YEL) HALL-IC(RPM Feedback : SMW250-03(BLU) Electric Heater : SMW250-02(RED) COM1(F1/F2) : YW396-02AV(RED) Floating Switch : SMW250-02(BLK) COM2(F3/F4) :YW396-02AV(BLU) MICOM Download : SMW200-10(WHT) Trans-out : SMW250-03(RED) 10-1 Samsung Electronics...
Page 114: Outdoor Pcb
10-2 Outdoor PCB 10-2-1 UH035EAV ■ Inverter Power N Power Relay Power L Comp. Connector Wire BLDC Fan : YAW396-07V (WHT) Reactor Connector Wire Main PCB Connector : SMW200-07(WHT) Samsung Electronics 10-2...
Page 115 PCB Diagram ■ Main PCB Inverter PCB Connector : SMW200-07(WHT) Display PCB Connector : SMW200-07(WHT) OLP/Cond. Temperature Sensor : SMAW250A-04(WHT) Outdoor/Discharge Temperature Sensor : SMAW250A-04(RED) EEV Connector : SMAW250A-06(WHT) DC5V Connector : SMW250-03(WHT) Communication 10-3 Samsung Electronics...
Page 116 PCB Diagram 10-2-2 UH052EAV/UH070EAV The red number connecter is not used. Power N COND/OLP Temperature Sensor Power L DIS/OUT Temperature Sensor BLDC FAN EEV Connector AC FAN Comp. Connector Wire Communication 485 Reactor Connector Wire Samsung Electronics 10-4...
Page 117: Operating Instructions
11. Operating Instructions 11-1 Name of Each Part 11-1-1 Indoor Unit The figures are shwon in this instruction may differ from yours depending on the model. ■ EH035EAV outlet Inlet ■ EH052EAV/EH070EAV outlet Inlet 11-1 Samsung Electronics...
Page 118 Operating Instructions 11-1-2 Outdoor Unit ■ UH035EAV Air Inlet(Rear) Air Outlet Connection Valve (inside) ■ UH052EAV Air Inlet(Rear) Air Outlet Connection Valve ■ UH070EAV Air Inlet(Rear) Air Outlet Connection Valve Samsung Electronics 11-2...
Page 119: Main Function
3. To adjust the temperature, press the buttons one or more times until the required temperature is displayed. Possible temperatures are between 18˚C and 30˚C inclusive. 11-3 Samsung Electronics...
Page 120 Possible temperatures are between 16˚C and 30˚C inclusive. 4. Select the fan speed by pressing the button one or more times until the intended value is displayed : Automatic(rotated : ➔ ➔ Medium High Samsung Electronics 11-4...
Page 121 2. To select the FAN mode, press the button until is displayed at the top of the wireless remote controller. 3. Select the fan speed by pressing the button one or more times until the intended value is displayed: Medium High 11-5 Samsung Electronics...
Page 122: Wired Remote Controller
3. To adjust the temperature, press the buttons one or more times until the required temperature is displayed. Possible temperatures are between 18˚C and 30˚C inclusive. Samsung Electronics 11-6...
Page 123 Possible temperatures are between 16˚C and 30˚C inclusive. 4. Select the fan speed by pressing the button one or more times until the intended value is displayed : Automatic(rotated : ➔ ➔ Medium High 11-7 Samsung Electronics...
Page 124 2. To select the FAN mode, press the button until is displayed at the top of the wired remote controller. 3. Select the fan speed by pressing the button one or more times until the intended value is displayed: Medium High Samsung Electronics 11-8...
Page 125: Wireless Remote Control-Buttons And Display
Air flow direction Swing button On Timer setting On Timer button Off Timer setting Off Timer button Battery discharge indicator On/Off & Timer Set/ Cancel button Note : • After cleaning the air filter, press the button. 11-9 Samsung Electronics...
Page 126: Wired Remote Controller-Buttons And Display
You must not press it. • After cleaning the air filter, press the button. Then the wired remote controller will display the Filter Sign indicator when the time to clean the air filter. Samsung Electronics 11-10...
Page 127: Troubleshooting
The compressor operates in a reverse cycle to remove Indoor fan and outdoor fan stop operation intermittently exterior ice in a HEAT mode, and indoor fan and outdoor in a HEAT mode. fan do not operate intermittently for within 20% of the total heater operation 12-1 Samsung Electronics...
Page 128: Fault Diagnosis By Symptom
Replace fuse 20[A]/250[V]:✳✳035/052✳✳ 30[A]/250[V]:✳✳070✳✳ Check the input/output voltage of SMPS on the INV PCB. PCB should be replaced DC_Link voltage(C101):DC300[V] IC16, IC19 Input:DC12[V] output:DC5[V] ◆ Check the setting temperature Samsung Electronics 12-2...
Page 129 Replace the PCB. Separate the BLDC FAN Wire Is the number 1, 3 of the Is the +, - of C102 Short? BLDC FAN Wire Short? Replace the PCB Replace the BLDC FAN Normal Operation : UH035EAV Exit 12-3 Samsung Electronics...
Page 130 Pull out the power cord and during the operation? (Square-Wave) execute the following step after 30 seconds. Disassemble the BLDC FAN Wire. Is the short between Exchange the PCB. the BLDC FAN Wires? Exchange the BLDC FAN MOTOR. Exchange the PCB. Samsung Electronics 12-4...
Page 131 Pull out the power cord and exchange the PCB from the case after 30 seconds. Is the assembly of Micom and Exchange the PCB. peripheral circuit part good? Check again after assembly of PCB. 12-5 Samsung Electronics...
Page 132 4-WAY valve coil error of 4-WAY valve coil. Dose the voltage of AC 220V Exchange apply to the connector of 4-WAY the outdoor PCB. valve coil during the operation? Go to the next page 4-WAY valve main body error Samsung Electronics 12-6...
Page 133 Connect the connector. correctly? Check the resistance value Outdoor fan error of outdoor fan. Dose the voltage of DC300V apply to the connector of outdoor Check the motor wire. fan during the operation of outdoor unit? Outdoor PCB error 12-7 Samsung Electronics...
Page 134: Outdoor Temperature Sensor Error
Exchange the sensor. (Refer to the R/T TABLE) Is the resistance value of sensor connection pull_up 18K? Exchange the PCB. Exchange the PCB. Normal operation Exit 400.0 350.0 300.0 250.0 200.0 150.0 100.0 50.0 Samsung Electronics 12-8...
Page 135 Exchange the sensor. (Refer to the R/T TABLE) Is the resistance value of sensor connection pull_up 24K? Exchange the PCB. Exchange the PCB. Normal operation Exit 600.0 500.0 400.0 300.0 200.0 100.0 12-9 Samsung Electronics...
Page 136 Exchange the sensor. (Refer to the R/T TABLE) Is the resistance value of sensor connection pull_up 18.2K? Exchange the PCB. Exchange the PCB. Normal operation Exit 400.0 350.0 300.0 250.0 200.0 150.0 100.0 50.0 Samsung Electronics 12-10...
Page 137 4) Is the resistance value of sensor connection pull_up correct? 2. Troubleshooting procedure Remove the Fan lock. Isn't the Fan locked? Is the connector connected correctly? Connect the connector. Is the color of Fan wire matched correctly? Exchange the Fan. Exchange the PCB. Normal operation Exit 12-11 Samsung Electronics...
Page 138 N, L correct after power supply? Is the capacitor(C101, C102, C103) Connect the connector. for DC-Link assembled in accordance the specification? Are R113, R114, R115 470kohm? Exchange the PCB. Is R116 14.3kohm? Exchange the Fan. Exchange the PCB. Normal operation Exit Samsung Electronics 12-12...
Page 139 Is the position of temperature sensor Correct the sensor position or and the sensing value normal? exchange the sensor. Is the connection cable for Correct the cable connection. the compressor and power terminal normal? Exchange the PCB. 12-13 Samsung Electronics...
Page 140: Communication Error
Correct the wrong wiring. communication cable wiring error? Is the connection of Correct the connection of communication cable normal? communication cable. Is it the outdoor Exchange the indoor/outdoor unit PCB. 2 Micom(Inverter + Main) model? Exchange the outdoor unit PCB. Samsung Electronics 12-14...
Page 141 Exchange the compressor. compressor (u↔v, v↔w, w↔u) normal? Is the compressor body and Exchange the compressor. interphase resistance insulated? Is the connection cable for the Correct the cable connection. compressor and power terminal normal? Exchange the PCB. 12-15 Samsung Electronics...
Page 142 Exchange the compressor. compressor (u↔v, v↔w, w↔u) normal? Is the compressor body and Exchange the compressor. interphase resistance insulated? Is the connection cable for the Correct the cable connection. compressor and power terminal normal? Exchange the PCB. Samsung Electronics 12-16...
Page 143 Is the resistance for the Exchange the PCB. detection of DC Link voltage normal? Is the resistance value of Exchange the PCB. DC Link discharge normal? Is the reactor insulation damaged? Exchange the PCB. Exchange the reactor. 12-17 Samsung Electronics...
Page 144 1. AC Line Zero Cross Signal OUT – Check the assembly condition of peripheral part of IC21, ZD201, ZD200(✳✳035✳✳) / ZD21, ZD22(✳✳052/070✳✳) and D201 on the PCB. 2. Capacity miss match – Check again the indoor unit option code. Samsung Electronics 12-18...
Page 145: Pcb Inspection Method
2) The fan motor of the indoor unit doesn't run. Fan Motor Connector(CN72) is faulty 3) The power voltage between terminal #3 and #5 • ASS'Y Main PCB is faulty of the connector(CN72) is 0V. • Connection is faulty 12-19 Samsung Electronics...
Page 146 • Outdoor PCB Error (✳✳035✳✳) 2) Is CN01 3, 5 within 1V~5V? • BLDC Motor Error 3) Is the voltage of CN01 6 changed? 4) Is the resistance of BLDC Motor 1, 3 opened after power off? Samsung Electronics 12-20...
Page 147: Main Part Inspection Method
∞, 0Ω . . . Open or Short Stepping Motor Measure the resistance between the red wire and each terminal wire with a tester. Normal About 300Ω at the normal temperature (20˚C ~ 30˚C) Abnormal ∞, 0Ω . . . Open or Short 12-21 Samsung Electronics...
Page 148: Block Diagram
Drain Pump, Ventilator Indoor FAN(SSR Control) Address, Option Setting Switch Display MAIN PCB External Control Signal / External Status Output 485 Communication Sensor(Room, Eva.-in temp) Floating Switch Wired Remocon Micom Program Comm. Beween Wired DC12V Power Download Remocon unites Samsung Electronics 13-1...
Page 149: Outdoor Unit
• LED CONTROL SIGNAL • AC FAN CONTROL SIGNAL • EEV CONTROL SIGNAL • 4-WAY VALVE • 4-WAY CONTROL SIGNAL • EEV • LED CONTROL SIGNAL • INDOOR COMMUNICATION SIGNAL INDOOR UNIT SMPS AC INPUT PFC CIRCUIT 13-2 Samsung Electronics...
Page 150 Block Diagram 13-2-1 UH035EAV ■ Inverter PCB IGBT DIODE OUTDOOR FAN POWER RELAY DC_LINK CAP SMPS Samsung Electronics 13-3...
Page 151 Block Diagram ■ Main PCB DISPLAY CONTROL INV PCB CONNECTOR INDOOR COMMUNICATION CIRCUIT EEV CONNECTOR THERMISTOR CONNECTOR 13-4 Samsung Electronics...
Page 152 Block Diagram 13-2-2 UH052EAV OUTDOOR FAN IGBT DIODE DC_LINK CAP SMPS Samsung Electronics 13-5...
Page 153 Block Diagram 13-2-3 UH070EAV OUTDOOR FAN IGBT DIODE DC_LINK CAP SMPS 13-6 Samsung Electronics...
Page 154: Reference Sheet
380~415V,50Hz,3Φ Unit Buint-in 127V, 50Hz Ceiling - 220~240V,50/60Hz,1Φ Console - 380V,60Hz,3Φ Inverter 1Φ Split Inverter 3Φ Universal Outdoor Unit(DPM) Refrigerant Product Type(ll) Version Plant R-22 Indoor None Normal R407C Outdoor SSEC R410A Indoor Universal (DPM) Outdoor Inverter Samsung Electronics 14-1...
Page 155: Low Refrigerant Pressure Distribution
Low Pressure at Heating mode 27/19 24/18 21/15 20/15 32/23 27/15 Outdoor Temperature(˚C) Outdoor Temperature(˚C) ■ ✳✳070✳✳ Low Pressure at Cooling mode Low Pressure at Heating mode 27/19 24/18 21/15 20/15 32/23 27/15 Outdoor Temperature(˚C) Outdoor Temperature(˚C) 14-2 Samsung Electronics...
Page 156: Pressure & Capacity Mark
0.001341 0.10197 0.73756 4.1868 14.286 0.0056146 0.42693 3.088 1.163 0.27778 3.9683 0.0015596 0.11859 0.85778 0.29307 0.06999 0.252 3.9302x10 0.029885 0.21616 745.7 178.11 641.19 2,544.4 76.04 9.8067 2.3423 8.4322 33.462 0.013151 7.233 1.3558 0.32383 1.1658 4.6262 0.0018182 0.13826 Samsung Electronics 14-3...
Page 157: Q & A For Non-Trouble
It occurs when the drain pump is plugged out or it is out of order. Check the power of the drain pump and the position of the drain hose, and when the pump is faulty, contact the drain pump manufacturer. Samsung Electronics do not manufacture drain pumps.
Page 158 Also, the remote controller may not work under intensive light from a 3-wave length lamp or a neon sign due to the EMI. In this case, take the remote controller closer to the receiver. Samsung Electronics 14-5...
Page 159 There is a cost table. But, our service engineer needs to visit to total up the cost correctly. When you move in, make sure to contact Samsung Electronics Service Center or Authorized Service Agent in advance to streamline the process.
Page 160: Cleaning/Filter Change
5. When you have finished, insert the filter into the unit. 6. Clean the outdoor unit with a vacuum cleaner or a brush once a month. Note : • After cleaning the air conditioner, press the Filter Reset button. Wireless Remote Controller Wired Remote Controller Samsung Electronics 14-7...
Page 161: Installation
Electric and earth work shall meet the "Electric Facility Technology Standard" and the "Internal Wire Regulation" of the Electric Business Laws. ■ Inspection & Trial Run Upon completion of the tests, you shall make a trial run while you explain the main functions of the air conditioner to finish the installation. 14-8 Samsung Electronics...
Page 162: Installation Diagram Of Indoor Unit And Outdoor Unit
183kgf . cm with a torque wrench. 7) Check for gas leakage. - At this time, especially check for gas leakage from the 3-Way valve’s stem nuts, and from the service port cap. Samsung Electronics...
Page 163 • Make sure you do not bend the connection pipes in the middle and store together with the cables. • Move the indoor and outdoor units to a new location. • Remove the mounting plate for the indoor unit and move it to a new location. 14-10 Samsung Electronics...
Page 164 MEMO Samsung Electronics 14-10...
Page 165 MEMO 14-11 Samsung Electronics...
Page 166 © Samsung Electronics Co., Ltd. Apr. 2006. This Service Manual is a property of Samsung Electronics Co., Ltd. Printed in Korea. Any unauthorized use of Manual can be punished under applicable International and/or domestic law. Code No. DB98-25888A(1)
