SERVICE MANUAL
• HCD-101 is the CD PLAYER,
TUNER and AMPLIFIER
sections in CMT-101.
Tuner section
Tuning range
2 band model
European model:
Other models:
3 band model
Intermediate frequency
Aerial terminals
Timer
Timer setting
Sleep timer
CD player section
System
Laser
MICROFILM
SPECIFICATIONS
FM : 87.5-108MHz
(50kHz step)
AM : 522–1,611kHz
FM : 87.5–108MHz
(50kHz step)
AM : 531–1,602kHz
(at 9kHz interval)
530–1,710kHz
(at 10kHz interval)
FM : 87.5–108MHz
(50kHz step)
MW : 522–1,611kHz
(at 9kHz interval)
LW : 144–288kHz
(at 3kHz interval)
FM : 10.7MHz
AM : 450kHz
FM : 75Ω unbalanced
AM : External aerial
terminal
Quartz lock system
One-minute step
10–minute step, max.
90minutes
Compact disc digital
audio system
Semiconductor laser
(λ=780nm)
HCD-101
Model Name Using Similar Mechanism
CD Mechanism Type
Optical Pick-Up Type
Laser output power
Less than 44.6µW*
* This output is the value measured at a distance of 200mm from
the objective lens surface on the optical pick-up block with 7mm
aperture.
Frequency response
5Hz–20kHz
Signal to noise ratio
More than 90dB
Harmonic distortion
Less than 0.05%
Amplifier section
European model:
DIN power output
15+15 W (4Ω at 1kHz, DIN
Continuous RMS power output
21+21 W (4Ω at 1kHz, 10%
THD)
Music power output
26+26 W
Other model
Rated RMS power output 16+16 W (4Ω at 1kHz, 1% THD,
AC240V/AC120V)
Reference RMS power output
22+22 W (4Ω at 1kHz, 10% THD,
AC240V/AC120V)
Inputs
VIDEO/PC IN jack : Stereo
phone jack, sensitivity 500mV,
impedance 47kΩ
COMPACT COMPONENT SYSTEM
AEP Model
UK Model
E Model
Tourist Model
NEW
CDM50
KSS-313A
— Continued on next page —

Advertisement

Table of Contents
loading

Summary of Contents for Sony HCD-101

  • Page 1 HCD-101 SERVICE MANUAL AEP Model UK Model E Model Tourist Model • HCD-101 is the CD PLAYER, TUNER and AMPLIFIER sections in CMT-101. Model Name Using Similar Mechanism CD Mechanism Type CDM50 Optical Pick-Up Type KSS-313A SPECIFICATIONS Tuner section Laser output power Less than 44.6µW*...
  • Page 2: Table Of Contents

    (within 3 times). LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE • Be careful not to apply force on the conductor when soldering or COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS unsoldering. APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
  • Page 3: General

    SECTION 1 This section is extracted from instruction manual. GENERAL 1 Remote control signal sensor 2 Power switch 3 CD insertion slot 4 Display window 5 6 (CD EJECT) button 6 PHONES terminal 7 BAND button 8 DBFB button 9 =0/)+ (Cue-up musics, or fast rewind / fast forward) button 0 VOL+/–...
  • Page 4: Disassembly

    SECTION 2 DISASSEMBLY 2-1. CASE 2 Remove the case upward in the direction of the arrow. 1 Two screws (Case 3 TP2) 1 Two screws (Case 3 TP2) 2-2. FRONT PANEL SECTION claw 3 Wire (Flat Type) (27 Core) 4 Connector (CN916) 2 Pull the front panel out.
  • Page 5: Pre Board

    2-3. PRE board 4 Two screws (BVTP 3 × 8) !™ PRE board 8 CDM50 !¡ Two Connectors 7 Connector (CN107) (CN420, CN422) 5 Two screws 9 Wire (Flat type) (21 Core) (BVTT 3 × 6) (CN421) 6 Wire (Flat type) (30 Core) 1 Four screws (BVTP 3 ×...
  • Page 6: Mechanism Deck

    2-5. MECHANISM DECK (CDM50) 3 Mechanism Deck (CDM50) 2 Bracket (CDM) 1 Two screw (BVTT 2.6 × 6) 1 Two screw (BVTT 2.6 × 6) 2-6. CHASSIS (T2) ASSY 2 Bracket 5 Tension coil spring 3 Four screws 1 Two screws (BVTT 3 ×...
  • Page 7: Bd Board

    2-7. BD board 4 Flexible board 5 BD board (CN101) 3 Flexible board (CN106) 1 Two screws (BVTT × 2) 2 Connectir (CN104) 2-8. ROLLER ARM BLOCK ASSY 3 Roller arm block assy 1 Spring (press) 1 Spring (press) 2 BELT (L) —...
  • Page 8: Chassis (Opt), Chucking Arm Assy

    2-9. CHASSIS (OPT) ASSY, CHUCKING ARM ASSY 7 Chucking arm assy 6 Move the Chucking arm assy to the position shown in the 5 Spring (CH) illustration and move it up. 6 Move the Chucking arm assy to the position shown in the illustration and move it up.
  • Page 9: Test Mode

    SECTION 3 TEST MODE There are two methods to enter the TEST mode. 5. Watch operation check (Can be operated only while the main power is off.) • How to Enter the Test Mode - 1 Press [FUNCTION] and [BAND] at the same time. → Watch Remove the AC power cord from wall outlet, and press [EJECT 6].
  • Page 10 5) Pressing [TUNING–] and [VOL+] at the same time : ** Other troubles • Aging mode “TW*SW*” The machine enters the aging mode by inserting a CD disc TW : Numbers of times that the machine could not read and performing the above button TOC.
  • Page 11: Electrical Adjustment

    SECTION 4 ELECTRICAL ADJUSTMENTS 5. Check the oscilloscope waveform (S-curve) is symmetrical CD SECTION between A and B. And confirm that peak to peak level is within Note: 2.4 ± 0.7 Vp-p. 1. CD Block is basically constructed to operate without adjustment. Therefore, check each item in order given.
  • Page 12 Traverse waveform symmetry amplitude: 300 ± 100 mVp-p • × 100 = less than ± 7% specified value: 2 (A+B) • A+B = 300 ± 100 mVp-p Focus/Tracking Gain Adjustment This gain has a margin, so even if it is slightly off. There is no problem.
  • Page 13 — 13 —...
  • Page 14: Diagrams

    SECTION 5 DIAGRAMS 5-1. CIRCUIT BOARDS LOCATION TRANS board POWER IC board RELAY board PRE board POWER board BD board SP TM board POSISTOR board RDS board FUNCTION board HP board MOTOR board SENSOR board EJECT board SWITCH board PANEL board VOL SEL board —...
  • Page 15: Block Diagram

    HCD-101 5-2. BLOCK DIAGRAM R-CH J660 TB401 IC401 TUNER UNIT INPUT SELECT PHONES J402 ST-L IC423 EFFECT IC424 IC801 IC404(1/2) ANTENNA SWITCH VOL LOUDNESS POWER AMP CN410 ST-R R-CH BUFFER L IN L OUT IC430 BUFFER Q424 DBFB R-CH TM801...
  • Page 26: Ic Pin Function

    HCD-101 5-13. IC PIN FUNCTION 5-14. IC BLOCK DIAGRAMS • IC701 µPD780206GF-023-3BA Pin No. Pin Name Description Pin No. Pin Name Description D+5V — Power supply (+5V) PLAY LED CD PLAY LED output IC 102 BA6397FP AUB OUT AU_BUS output...
  • Page 27 IC104 PCM1710U-B IC410 BU2092 LRCIN ML/DSD CONTROL CIRCUIT INPUT DATA MC/DM2 DIGITAL MODE INTERFACE 12-BIT SHIFT REGISTER FILTER CONTROL CLOCK BCKIN MD/DM1 12-BIT STORAGE REGISTER TIMING CLKO MUTE CONTROL OUTPUT BUFFER (OPEN DRAIN) MODE CKSL NOISE SHAPER DGND DGND 5-LEVEL DAC 5-LEVEL DAC RIGHT LEFT...
  • Page 28 IC101 CXA1782BQ – LEVELS 24 SENS – MIRR RF IV AMP1 DFCT 23 C. OUT – 22 XRST RF IV AMP2 21 DATA FE BIAS • IIL DATA RESISTOR • INPUT SHIFT RESISTOR • ADDRESS DECODER 20 XLT • OUTPUT DECODER 19 CLK –...
  • Page 29: Exploded Views

    Remarks 4-994-808-01 PANEL (ALUMINUM), FRONT (SP,MY,HK,JE) 1-667-385-11 SWITCH BOARD 4-994-808-11 PANEL (ALUMINUM), FRONT (AEP,G,UK) 4-930-336-61 FOOT (FELT) 4-942-636-21 EMBLEM (No.3.5), SONY 4-958-107-01 SCREW (BV/RING S TIGHT) 4-994-813-01 FILTER (RM) 3-363-099-51 SCREW (CASE 3 TP2) 1-667-387-11 HP BOARD 4-951-620-01 SCREW (2.6X8), +BVTP...
  • Page 30: Chassis Section

    6-2. CHASSIS SECTION not supplied not supplied #1 #1 not supplied T901 SP, MY MODEL MODEL EXCEPT UK MODEL not supplied MODEL Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 1-668-138-11 POSISTOR BOARD * 63 1-667-386-11 SP TM BOARD * 52 1-667-384-11 TRANS BOARD 4-985-672-01 SCREW (+PTPWHM2.6), FLOATING...
  • Page 31: Mechanism Deck Section-1 (Cdm50)

    6-3. MECHANISM DECK SECTION-1 (CDM50) not supplied M103 S002 not supplied Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 3-387-776-01 BELT (L) 3-906-921-01 SPRING, TENSION 3-578-242-11 WASHER 3-906-924-01 SPRING, TENSION 3-384-894-01 GEAR (R1) * 122 1-653-378-51 SENSOR BOARD 3-384-895-01 GEAR (R2) 3-907-588-11 SPRING (FL2) 3-384-900-01 SPRING (PRESS)
  • Page 32: Mechanism Deck Section-2 (Cdm50)

    6-4. MECHANISM DECK SECTION-2 (CDM50) M101 M102 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks A-3252-586-A SHAFT (SL) ASSY 3-384-912-11 GEAR (K2) ! 152 8-848-283-11 OPTICAL PICK-UP KSS-313A 3-570-615-02 POLY-WASHER (DIA.1.2) 3-384-922-01 GEAR (SL FEED) 3-384-913-11 SPRING (THRUST RETAINER) 3-384-920-01 RETAINER (SL FEED) * 165 1-653-379-51 MOTOR BOARD...
  • Page 33: Electrical Parts List

    SECTION 7 ELECTRICAL PARTS LIST NOTE: • Due to standardization, replacements in the • RESISTORS When indicating parts by reference number, parts list may be different from the parts All resistors are in ohms. please include the board name. specified in the diagrams or the components METAL: metal-film resistor used on the set.
  • Page 34 EJECT FUNCTION Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks < TRANSISTOR > R156 1-216-085-00 METAL CHIP 1/10W R157 1-216-069-00 METAL CHIP 6.8K 1/10W 8-729-032-35 PHOTO TRANSISTOR CPT-230S-C-TU R158 1-216-001-00 METAL CHIP 1/10W 8-729-032-35 PHOTO TRANSISTOR CPT-230S-C-TU R171 1-216-049-91 METAL GLAZE 1/10W...
  • Page 35 FUNCTION Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks C407 1-162-282-31 CERAMIC 100PF < TRANSISTOR > (AEP,G,UK) C408 1-162-282-31 CERAMIC 100PF Q401 8-729-422-57 TRANSISTOR UN4111 (AEP,G,UK) Q404 8-729-620-05 TRANSISTOR 2SC2603-EF C426 1-164-159-11 CERAMIC 0.1uF C430 1-164-159-11 CERAMIC 0.1uF <...
  • Page 36 MOTOR PANEL Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 1-667-387-11 HP BOARD C727 1-163-251-11 CERAMIC CHIP 100PF C728 1-165-319-11 CERAMIC CHIP 0.1uF ********* C729 1-165-319-11 CERAMIC CHIP 0.1uF < CAPACITOR > C730 1-165-319-11 CERAMIC CHIP 0.1uF C731 1-165-319-11 CERAMIC CHIP...
  • Page 37 PANEL POSISTOR POWER Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R723 1-216-025-91 METAL GLAZE 1/10W 1-668-138-11 POSISTOR BOARD R724 1-216-017-91 METAL GLAZE 1/10W *************** R725 1-216-017-91 METAL GLAZE 1/10W R726 1-216-025-91 METAL GLAZE 1/10W < CAPACITOR > R727 1-216-085-00 METAL CHIP 1/10W...
  • Page 38 POWER POWER IC Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks C962 1-162-306-11 CERAMIC 0.01uF < RESISTOR > C963 1-162-306-11 CERAMIC 0.01uF C965 1-126-233-11 ELECT 22uF R801 1-249-417-11 CARBON 1/4W F C966 1-164-159-11 CERAMIC 0.1uF R802 1-247-870-11 CARBON 1/4W C967...
  • Page 39 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks A-4403-527-A PRE BOARD, COMPLETE < CONNECTOR > ******************** CN420 1-770-383-11 CONNECTOR, BOARD TO BOARD 14P < CAPACITOR > * CN421 1-568-864-11 SOCKET, CONNECTOR 21P CN422 1-770-381-11 CONNECTOR, BOARD TO BOARD 10P C409 1-126-233-11 ELECT 22uF...
  • Page 40 RELAY Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R484 1-247-807-31 CARBON 1/4W < COIL > R485 1-247-807-31 CARBON 1/4W R486 1-249-437-11 CARBON 1/4W L601 1-410-977-11 INDUCTOR 100uH R487 1-249-437-11 CARBON 1/4W R488 1-249-432-11 CARBON 1/4W <...
  • Page 41 SENSOR SP TM SWITCH TRANS VOLSEL Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 1-653-378-51 SENSOR BOARD < RESISTOR > ************* R750 1-249-427-11 CARBON 6.8K 1/4W F < DIODE > R751 1-249-429-11 CARBON 1/4W R752 1-247-858-11 CARBON 1/4W D801 8-719-045-75 DIODE CL-200IR-X-TU...
  • Page 42 HCD-101 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks MISCELLANEOUS ************** HARDWARE LIST ************** ************** 1-782-805-11 WIRE (FLAT TYPE) (5 CORE) 1-782-781-11 WIRE (FLAT TYPE) (27 CORE) 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S 1-782-780-11 WIRE (FLAT TYPE) (21 CORE)
