Network Camera

Operating Instructions

KX-HCM10
Model No.
PLEASE READ BEFORE USE AND SAVE.
Panasonic World Wide Web Address: http://www.panasonic.com
for customers in the USA or Puerto Rico

Advertisement

Table of Contents
loading

Related Manuals for Panasonic KX-HCM10

Summary of Contents for Panasonic KX-HCM10

  • Page 1: Network Camera

    Network Camera Operating Instructions KX-HCM10 Model No. PLEASE READ BEFORE USE AND SAVE. Panasonic World Wide Web Address: http://www.panasonic.com for customers in the USA or Puerto Rico...
  • Page 2 Introduction Thank you for purchasing the Panasonic Network Camera. When unpacking, check the following items. CD-ROM Operating Instructions Getting Started Note: Directory and file structure of this CD-ROM The directory structure of this CD-ROM and the main files position are as follows.
  • Page 3 Operating Instructions Trademarks • Netscape® and Netscape Navigator® are registered trademarks of Netscape Communications Corporation in the U.S. and other countries. • Adobe and Acrobat are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries. •...

  • Page 4: Table Of Contents

    Table of Contents 1 Installation... 6 1.1 Overview... 7 1.1.1 Features ...7 1.1.2 System Requirements...8 1.2 Included Accessories... 10 1.3 Part Names... 11 1.3.1 Front View ...11 1.3.2 Rear View...12 1.3.3 Bottom View ...12 1.4 Setup ... 13 1.4.1 Diagram of Connections...13 1.4.2 Preparation...14 1.4.3 Mounting ...15 1.4.4 Connecting the Network Camera to Network ...16...

  • Page 5: For Assistance : 1-800-272-7033]

    Operating Instructions 4.2 Troubleshooting ... 81 4.3 Important Safety Instruction ... 86 4.4 FCC and Other Information ... 87 Index... 89 [For assistance : 1-800-272-7033]...

  • Page 6: Installation

    Operating Instructions Section 1 Installation...

  • Page 7: Overview

    Operating Instructions 1.1 Overview 1.1.1 Features The main features of the Network Camera are described as follows. Ease of Use This network camera has its own built in web server. Once the camera is connected to your Ethernet network and the card is configured, JPEG images can be easily viewed on your standard Internet browser.

  • Page 8: System Requirements

    Anytime improvements or changes are made you'll be able to get the latest firmware at no charge from the Panasonic web site. Since the user interface is your web browser, it's fast and easy to do! See Page 65 for more detailed information.
  • Page 9 Operating Instructions Note To prevent the limitation from the performance of the CPU inside the Computer, it is recommended to use a computer of Pentium II(300MHz) or more. [For assistance : 1-800-272-7033]...

  • Page 10: Included Accessories

    1.2 Included Accessories For extra orders, call 1-800-332-5368. AC adaptor --- One Order No. PQLV10Y Screws --- Two Order No. PSHE5004Z Washers --- Two Order No. XWG35FY • If any items are missing or damaged, ask the dealer where you purchased the product.

  • Page 11: Part Names

    • When performing Update Firmware. • When you pushed CLEAR SETTING button. • The KX-HCM10 hardware is defective. Please refer to Section 4.2 Troubleshooting. CAUTION • Network Camera is intended for indoor use only. Prolonged exposure to direct sunlight or halogen light may damage the CMOS sensor.

  • Page 12: Rear View

    I/O Connector Ethernet port (RJ-45) Ethernet Indicator DC IN jack * Use category 5 cross cable when KX-HCM10 is directly connected to PC. CAUTION Use ONLY with Panasonic AC adaptor (Order No. PQLV10Y). 1.3.3 Bottom View Tripod Mounting Hole Operating Instructions...

  • Page 13: Setup

    Operating Instructions 1.4 Setup Please confirm the connection of your network into following figure and check the Connection No. 1 - 6. This Connection No. is used by explanation of Section 1.5 Network Camera Configuration. 1.4.1 Diagram of Connections Direct Connection to Personal Computer (without Ethernet Hub) Power source AC Adaptor Power...

  • Page 14: Preparation

    Cable Line Cable/xDSL Line Internet Information *1) Router or Panasonic Broadband Networking Gateway KX-HGW200 1.4.2 Preparation Before starting to install the Network Camera, make sure that you have everything: • A Windows computer with web browser software, Ethernet card and TCP/IP installed.

  • Page 15: Mounting

    Operating Instructions 1.4.3 Mounting You can install the Network Camera in the following ways. Installing on the Stand Fix the Network Camera to the Stand. Installing on the wall Screw the two screws (accessories) into the wall. The distance of two screws should be 2.75"...

  • Page 16: Connecting The Network Camera To Network

    1.4.4 Connecting the Network Camera to Network Connect the category 5 straight cable to Ethernet port of the Network Camera and Ethernet Hub. Ethernet port Connect the category 5 straight cable to the LAN port of the computer and Network. To Network Note If you connect Network Camera to PC directly, you should use Category 5...
  • Page 17 • Use Only with Panasonic AC adaptor (Order No. PQLV10Y). After the power is connected the Network Camera will initialize. The power LED will come on and the pan - tilt motors will adjust themselves.

  • Page 18: Network Camera Configuration

    1.5 Network Camera Configuration In order to set up Network Camera Configuration, the following items are used in this Section. • Static : IP Address/Subnet Mask or DHCP (Dynamic Host Configuration Protocol) : Host Name • Port No. • Default Gateway •...
  • Page 19 Operating Instructions Setup Connection It is necessary to connect locally PC and Network Camera, as follows. Insert the Setup CD-ROM in the CD-ROM Drive of your computer. The following screen is displayed. (If the screen does not appear, please open "setup.exe" file in the CD-ROM.) After confirmation of connecting of the Network Camera to a network, turn on the power again.
  • Page 20 Note Ethernet defines a 48-bit addressing scheme. Each computer or device attached to an Ethernet network is assigned a unique 48-bit number known as its Ethernet address. To assign an address, Ethernet hardware manufacturers purchases blocks of Ethernet addresses and assign them in sequence as they manufacture Ethernet interface hardware.
  • Page 21 Operating Instructions turning on the power of the Network Camera. 4. During this process the Ethernet LED adjacent to the network connector should be flashing. Select your target Network Camera in Box (i) and click the The following Configuration screen is displayed. See the Page 23 for instructions about each data fields.
  • Page 22 Operating Instructions When you use Connection 2 or 3 in Section 1.4.1 (ii): Set to 80. [Default] (iii): Check the Static and set Static IP Address and Subnet Mask. (iv): If you use Gateway, you need to set it. (v) : If you use DNS (Domain Name System) Server, you need to set it. (vi) : You don't need to set this item.
  • Page 23 (Global IP Address or URL) (Port No.) vvv.xxx.yyy.zzz:80 vvv.xxx.yyy.zzz:81 Internet (Local IP Address) 192.168.0.254 Router or Panasonic Broadband Networking Gateway KX-HGW200 (vii) is Max. bandwidth Usage setting. It can restrict the transmit bandwidth. Port No.** iii Static* • IP Address •...
  • Page 24 iv Default Gateway* DNS Server* vi DDNS • Your E-mail Address**** • Personal (Camera) URL • Purchase Link vii MAX Band Usage *: Must be composed of four numeral characters (0 to 255) and divided with 3 dots, such as 192.168.0.253. (Can not use "0.0.0.0" and "255.255.255.255") **: Numeral characters only (1 - 65535) ***: Can not use [Space], ["], ['], [#], [&], [%], [=], [+], [?], [<], [>], [:] (only...

  • Page 25: Setup The Computer

    Operating Instructions Note • The Network Camera is automatically reset after setting up the Network Configuration. • When the following message is displayed, the IP address seems to be overlapped. Verify the IP Address to the network administrator, and enter the correct IP address.
  • Page 26 If your network using proxy server, it is recommended to change the setting of the web browser not to use the proxy server for the communication with the IP address of the Network Camera. In some corporate environments the use of a proxy server with a firewall may prevent you for connecting directly to the Network Camera.

  • Page 27: Confirmation Of The Network Setup

    Operating Instructions LAN Settings... Click the dialogue box appears. In this box, confirm if the Use a proxy server check box is checked or not. Confirm if the check box is checked or not. If the check box is not checked, web browser setting for a proxy server is not necessary and click If the check box is checked, click Settings dialogue box appears.
  • Page 28 On the computer, start up your web browser. Enter "http://IP Address (or URL):Port No." in the address field of your web browser and press need to input Port No.. • If the Top Page of the Network Camera appears as below, the setup is completed.
  • Page 29 Operating Instructions Important Information: The KX-HCM10 Network Camera is designed to work with 10 Mbps networks, cable modems or DSL Internet connections. If the Network Camera is used with a 56K Internet dial-up connection the available bandwidth may not be adequate to allow motion video to work properly. In this case, we suggest using regularly refreshed JPEG image captures (No.2 on Top...

  • Page 30: Using Network Camera Web Screen

    Operating Instructions Section 2 Using Network Camera Web screen...

  • Page 31: Table Of Contents For Section 2

    Operating Instructions 2.1 Table of Contents for Section 2 Setup Items to the beginning • Network Configuration (Essential) • Setup Time Seeing the Flow of Web screen Using Top Page & Top View Image Using the Operation Bar Using the Buffer Memory Using the Multi-Camera •...

  • Page 32: Flow Of Network Camera Web Screen

    2.2 Flow of Network Camera Web screen About the Top Page and Top View Image Page Enter "http://IP Address (or URL) : Port No." in the address field of your web browser and press Enter . When Port No. is set as 80 (default), you don't need to input Port No..
  • Page 33 Operating Instructions About the Setup Page Enter "http://IP Address ( or URL) : Port No./config.html" in the address field of your web browser and press Enter . When Port No. is set as 80 (default), you don't need to input Port No.. Information: (*a) It is possible to display the following (*a).

  • Page 34: Using The Top Page And Top View Image Page

    2.3 Using the Top Page and Top View Image Page 2.3.1 Using the Top Page In Top Page, you can select to link Motion JPEG/JPEG - Regularly Refresh, Single Camera/Multi-Camera, and Help. Motion JPEG • JPEG – Regularly • Refresh Single Camera •...

  • Page 35: Using Top View Image Page

    Operating Instructions 2.3.2 Using Top View Image Page Single Camera Screen When you select Single camera from Top Page, the screen below appears. Operation bar The Network Camera Image screen does not appear. When Internet Explorer is used for a browser, it is necessary to download ActiveX program.
  • Page 36 About operation Item (1) Pan & Tilt (2) Pan Scan (3) Brightness (a) [STD] (b) [–], [+] (4) End & Locked display (5) Resolution (6) Image quality (a) Favor clarity (b) Standard (c) Favor motion Operating Instructions Description Click the arrow button to perform the Pan/Tilt operation.
  • Page 37 Operating Instructions Operation range of Pan & Tilt : Note • When an image does not come out or irregular, please push the Refresh or Reload button of your browser. [For assistance : 1-800-272-7033] Item (7) Image size (8) Buffering Image (a) Start Capture (b) Viewer (9) Multi-Camera...
  • Page 38 Buffering Image Explanation A display of Buffering Image of operation bar is changed according to Image Transfer mode setting. Please refer to Page 50 about Image Transfer mode. Case-1 "Non transfer" condition in "Image Transfer" menu. [Start Capture] button Current image will be captured in internal memory when click the "Start Capture" button.
  • Page 39 Operating Instructions CAUTION Buffered images will clear when following operation. • Turning off the power, Restarting, Update Firmware, Reset to Factory Default. • "Image Transfer" or "Name/Time" menu page is saved. • Push the "Start Capture" button. Multi-Camera When you select Multi-Camera by Top Page, the next screen appears. Note •...
  • Page 40 • When you see the image of two or more cameras in Multi-Camera, it is recommended to use Ethernet Switching Hub. If Ethernet Switching Hub is not used, renewal of an image may become slow. If the image of Multi-Camera does not displayed. Make sure the IP address of each camera setting and connection.

  • Page 41: About The Network Camera Setup Page

    Operating Instructions 2.4 About the Network Camera Setup Page Enter "http://IP Address (or URL):Port No./config.html" in the address field of your web browser and press don't need to input Port No.. The Setup Page screen below appears. (10) (11) (12) (13) (14) (15)

  • Page 42: Using The Functions

    Item Top View Image Image Transfer Camera Setup Multi-Camera (10) Digital Output Control Digital output setting (Open or Short to GND) (11) LED Control (12) Restart (13) Update Firmware (14) Reset to Factory Default (15) Help 2.4.1 Using the Functions Go to Top Page Top Page screen allows you to select the Top Page items.
  • Page 43 Operating Instructions Network Click the The next screen appears. Enter each parameter in the proper data field. • To reset the current settings, click Then it returns to Setup Page, without saving setting value. When you have finished, click • The setting will be saved.
  • Page 44 Instructions for the data fields Network Configuration from Setup Program Port No.** Static* • IP Address • Subnet Mask DHCP*** • Host name Default Gateway* DNS Server* DDNS • Your E-mail Address**** • Personal (Camera) URL • Purchase Link MAX Band Usage *: Must be composed of four numeral characters (0 to 255) and divided with 3 dots, such as 192.168.0.253.(Can not use "0.0.0.0"...
  • Page 45 Operating Instructions **: Numeral characters only (1 - 65535) ***: Can not use [Space], ["], ['], [#], [&], [%], [=], [+], [?], [<], [>], [:] (only ASCII character codes 33-126) ****: Can not use [Space], ["], ['], [#], [&], [%], [=], [+], [?], [<], [>], [:] (only ASCII character codes 33-126) and need the [@] and domain name of e-mail, such as [text] + [@] + [text] + [.] + [text].
  • Page 46 Time setting Please click one of the time setting buttons("AM/PM" or "24H") at first. After that, the other setting items are displayed. Time is used at trigger condition and time stamp of buffered images. *: Can not use [Space], ["], ['], [#], [&], [%], [=], [+], [?], [<], [>], [:] (only ASCII character codes 33-126) Security: Administrator Security: Administrator screen allows you to set the Administrator security...
  • Page 47 Operating Instructions Instructions for the data fields Authentication It is possible to select the three security levels. Enable None : Since an Authentication Page is not displayed, all users can access all pages. Administrator only: Setup Page for Administrator only. Administrator and General User: Setup Page for administrator and Viewer Page for General User.

  • Page 48: Top View Image

    When you have finished, click • The setting will be saved. Instructions for the data fields General User Register the General User up to 20 user IDs. Authentication (1) User ID List • • Delete Please select the desired ID from User List, then click the Delete button.
  • Page 49 Operating Instructions Select the each parameter. • To reset the current settings, click Then it returns to Setup Page, without saving setting value. When you have finished, click • The setting will be saved. Instructions for the data fields Image Resolution Select the following Image Resolution item.

  • Page 50: Image Transfer

    Image Transfer Image Transfer screen allows you to set the Image Transfer parameters. • It is possible to transfer the images to computer or Server, with mail or FTP function. • It is possible to set up the various trigger by setting up Timer or External Alarm. Note Since the Image Transfer mode uses the cameras internal clock, please make sure the cameras clock setting have been configured.
  • Page 51 Operating Instructions • To reset the current settings, click Then it returns to Setup Page, without saving setting value. • To clear the buffered image, click When you have finished, click • The setting will be saved. CAUTION • When you click the cleared.
  • Page 52 Operating Instructions (a.) (b.) (c.) (d.) (e.) (f.) (g.) (h.) (i.) (j.) (k.) (l.)
  • Page 53 Operating Instructions Instructions for the data fields It is possible to buffer or transfer by alarm trigger. Alarm event is generated by Digital Input Terminal. (Please refer to Section 3.1 I/O Connector). Active Time of Trigger is set up. Always : Always active the alarm trigger. Operational between : Operational between start and stop time, please select the desired time.
  • Page 54 ***: Numeral characters only (1-65535) Over write setting It is possible to select from [Over Write to Fix Upload File Name] or [Add time stamp to Upload File Name]. Mail : Please setting the following items. Server Address* or Host Name**. From (Reply)***: Enter the e-mail address of [from].
  • Page 55 Operating Instructions Select the each parameter. • To reset the current settings, click Then it returns to Setup Page, without saving setting value. • To clear the buffered image, click When you have finished, click • The setting will be saved. CAUTION •...
  • Page 56 Setting Example (a.) (b.) (c.) (d.) (e.) (f.) It is setup Active time of trigger between 9:00 am to 6:00 PM on Monday to Friday. When alarm is generated in the setting time, the images are transmitted to server with FTP protocol and is transmitted to specific user by mail. Trigger is generated when door sensor is changed Rising edge(GND to Open High).
  • Page 57 After the alarm detection, 20 images are buffered by 1 image per second. Setting of FTP server : IP Address --- 192.168.0.200 Login ID --- Panasonic Password --- ******* Upload File name --- KXHCM10 File name is added at time stamp mode.
  • Page 58 (b.) (c.) (d.) (e.) (f.) (g.) (h.) (i.) (j.) It is possible to buffer or transfer by time trigger only. Active Time of Trigger is set up. Always : Always active. Operational between : Operational between start to stop time, please select the desired time.
  • Page 59 Operating Instructions Secondary Time is only active outside of the time period established for Primary Time. Please check Enable, when you use. It can select the Buffering Image Resolution and Quality. Same as Image setting of [Alarm]. The Image buffer of Primary and Secondary can be set up. Same as Image setting of [Trigger setting Alarm].

  • Page 60: Camera Setup

    Then it returns to Setup Page, without saving setting value. • To clear the buffered image, click When you have finished, click • The setting will be saved. CAUTION • When you click the are cleared. • Buffered images are erased by power stop, restart, Update Firmware and etc.
  • Page 61 Operating Instructions Select the each parameter in the proper data field. • To reset the current settings, click Then it returns to Setup Page, without saving setting value. When you have finished, click • The setting will be saved. Instructions for the data fields White Balance [For assistance : 1-800-272-7033] Save...
  • Page 62 Power Line Frequency Pan/Tilt Control Brightness Control Multi-Camera Multi-Camera screen allows you to set the Multi-Camera parameters. • It is possible to set the IP Address and Camera Name of Multi-Camera. • When using Multi-Camera, setup is required. Multi-Camera Click the The next screen appears.
  • Page 63 Operating Instructions Note Please do not overlap the IP Address setting. Instructions for the data fields Enable • • IP Address (or Enter the desired Network Camera's IP Address or Host Name. URL)* or Host Name*** Camera Name** • It is used only for the display of Multi-Camera. *: Must be composed of four numeral characters (0 to 255) and delimited with 3 dots, such as 192.168.0.253.

  • Page 64: Led Control

    When you click the (0V). When you have finished , click The setting will be saved. Information • It is shown in Section 3.1 I/O Connector. LED Control LED Control screen allows you to set the LED Control parameters. • It is possible to set LED ON or OFF.

  • Page 65: Update Firmware

    • It is possible to upgrade the Firmware Version. Before beginning Update Firmware, it is necessary to get the proper firmware from Panasonic Support Website (http://www.kmelink.net/ipproducts/us/download/ index.html) and please store to your computer's Hard Disk or Floppy Disk. Note When you use the DHCP function, please change your Internet Connection from DHCP to Static in Network Page.
  • Page 66 When you need to restart, Click Restarting message appears. Please wait up to 1 minute and then the screen below appears. Browse... Click • The Choosing file dialogue box appears. Enter a desired Firmware file (including the path information) to the "File name"...

  • Page 67: Reset To Factory Default

    Operating Instructions Next message is displayed between Update Firmware. Update Firmware operation takes about 80 seconds. And next, the screen of Restart is displayed and a Network Camera begins Restart automatically. Restart operation takes up to 1 minute. Then Top Page is displayed. CAUTION •...
  • Page 68 When you need to reset to Factory Default, click the The Reset to Factory Default button allows you to initialize all the parameters of the Network Camera to the factory default, including the ID, Password, IP Address and Subnet Mask. •...

  • Page 69: Useful Information

    Operating Instructions Section 3 Useful Information [For assistance : 1-800-272-7033]...

  • Page 70: I/O Connector

    3.1 I/O Connector By attaching external devices, such as a sensor, in I/O connector, images can be transmitted at the time of alarm generating. Explanation of I/O Connector Function DC Power Output • DC8V - 12V • Maximum of 50mA load drive is possible. Digital Input •...
  • Page 71 Operating Instructions Circuit Diagram Example KX-HCM10 DC8V-12V CAUTION The above circuit involves low voltage/low current circuits as well as high voltage/high current circuits. It is dangerous to wire this yourself. Please ask a qualified electrician to do the wiring for you. He will understand what type of wires, switches, and relays to use.

  • Page 72: Reset The Camera To The Factory Default Settings

    3.2 Reset the Camera to the Factory Default settings The Network Camera has an CLEAR SETTING button which is located on back panel. To Reset the Camera to the Factory Default Settings If any of the user settings or password were forgotten the Network Camera can be easily reset to the factory default settings.

  • Page 73: The Initial Value Of A Factory And Notes Of A Setting Item

    Operating Instructions 3.3 The initial value of a factory and notes of a setting item [For assistance : 1-800-272-7033]...
  • Page 74 Operating Instructions...
  • Page 75 Operating Instructions [For assistance : 1-800-272-7033]...
  • Page 76 Operating Instructions...
  • Page 77 Operating Instructions [For assistance : 1-800-272-7033]...

  • Page 78: Appendix

    Operating Instructions Section 4 Appendix...

  • Page 79: Specification

    Operating Instructions 4.1 Specification Camera Specification Item Pan & Tilt Angle Sensor Type Number of Pixels Illumination White Balance Adjustment Focus Caliber Ratio(F No.) Horizontal Angle Exposure Other Specification Item Video Compression Video Resolution Image Buffer Magnification Frame rate(*1) Supported Protocols TCP , UDP , IP , HTTP , FTP , SMTP , DHCP , DNS, DDNS Message Operation Message Method [For assistance : 1-800-272-7033]...
  • Page 80 Item Trigger Interface Sensor I/O Connector (*2) LED Display Dimension(HWD) Weight Power Environmental Frame rate changes with the environment of a network and the performance of computer. A sensor must be attached to the Network Camera in order to perform alarm function.

  • Page 81: Troubleshooting

    Operating Instructions 4.2 Troubleshooting Problem While setting with CD- ROM, could not succeed with Network configuration setting. The Network Camera Web screen does not appear. [For assistance : 1-800-272-7033] Cause and Remedy Please power supply is returned on. Please do not use to over the Router. When you change the IP address of Network Camera, enter the new IP address in the URL of the browser.
  • Page 82 When you change the IP address of Network Camera, enter the new IP address in the URL of the browser. The Panasonic KX-HCM10 IP Camera can provide a motion JPEG image to a maximum of 10 simultaneous network connections. If an 11th user tries to connect, a blue screen is displayed.
  • Page 83 Operating Instructions Problem You do not remember the password to use the Network Camera administration web screen. The Ethernet network does not work and the Ethernet indicator on the Network Camera is off. Pan & Tilt does not move. Image is out of focus. The color of image is not good.
  • Page 84 If you can access the camera and the screen is Update Firmware page, you should do Update Firmware procedure. • If you can not access the camera, the KX-HCM10 hardware is defective. Please call our customer call center. • The number of the renewal frames of an image of a camera changes from the following contents.
  • Page 85 Operating Instructions Problem Update Firmware is not carry out a normal end. If you cannot solve your problem [For assistance : 1-800-272-7033] Cause and Remedy When it becomes impossible to access a camera by the reason of power supply OFF, network troubles, and others at the time of Update Firmware, it connects in the following procedure.

  • Page 86: Important Safety Instruction

    4.3 Important Safety Instruction When using this unit, basic safety precautions should always be followed to reduce the risk of fire, electric shock, or personal injury. Read and understand all instructions. Unplug this unit from AC outlets before cleaning. Do not use liquid or aerosol cleaners.

  • Page 87: Fcc And Other Information

    Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this device. No responsibility will be taken by our company with respect to consequences resulting from the use and/or the damage of the KX-HCM10 Network Camera. [For assistance : 1-800-272-7033]...
  • Page 88 Operating Instructions...

  • Page 89: Index

    Operating Instructions Section 5 Index...
  • Page 90 Numerics 10 Base-T Ethernet 80 AC adaptor 10, 12, 17, 80 Administrator 41, 46, 47 Alarm trigger 53 Authentication 47, 48 Brightness 36, 62 Buffering Image 37, 38, 40 CLEAR SETTING button 12, 72 CMOS sensor 11 DC IN jack 12 DDNS(Dynamic Domain Name System) 24, 44 Default Gateway 24, 44...
  • Page 91 Operating Instructions Stand 10, 15 Static 23, 44 Status 35 Subnet Mask 23, 44, 68 TCP/IP 8 Tilt 7, 36, 37, 83 Time 41, 45, 46, 80 Time of Trigger 53, 58, 80 Top Page 32, 34, 37, 41 Top View Image Page 32, 35 Tripod 15 URL(Uniform Resource Locator) 81 Web Browser 26, 82...
  • Page 92 Symptom Send the unit to an authorized servicenter, prepaid and adequately insured. Do not send your unit to the Panasonic Consumer Electronics Company listed below or to executive or regional sales offices. These locations do not repair consumer products. Copyright: This manual is copyrighted by Kyushu Matsushita Electric Co., Ltd.
