- Page 1 Operating and Installation Manual for Cooker Hoods LC38S953..
- Page 2 Preface Thank you for choosing Siemens cooking appliance. Before using your appliance for the first time, please read these instructions for use carefully. They contain important information concerning your personal safety as well as on use and care of the appliance.
-
Page 3: Table Of Contents
Table of Contents Key Information Packaging of New Cooker Hood Disposal of Used Cooker Hood Before You Begin Product Introduction Technical Parameters Product Standards Safety Precautions Operating Instruction Getting Familiar with Your New Cooker Hood Control Panel Operating Instruction Installation Instruction Safety Precautions Installation Position and Height Installation of Fasteners... -
Page 4: Key Information
Key Information Packaging of You will receive your new appliance in a protective shipping carton. All packaging materials are New Cooker Hood environment friendly and recyclable. Please contribute to a better environment friendly manner. Do not let children play with the appliance or the packaging material. -
Page 5: Product Introduction
Product Introduction Technical Parameters Product Model LC38S953.. Appearance Rated Voltage 220-240V～50Hz Input Power Motor Light 2×12 Self Cleaning Air Volume / m /min 14.5±1 Static Pressure / Pa ≥300(max.) Noise / dB (A) ≤69 Net Weight / kg Dimension Length / mm Width Height... - Page 6 Product Introduction Overheated fat or oil is highly inflammable. Only prepare food cooked in fat or oil when cooking can be fully supervised. Under no circumstances attempt to extinguish burning fat or oil with water. Choke the fire using a lid or fire blanket.
-
Page 7: Operating Instruction
Operating Instruction Getting Familiar with Your New Cooker Hood LC38S953.. LC65S953.. 1. Duct 2. Screen 3. Inner frame 4. Filter frame 5. Oil collector 6. Front panel 7. Lamp 8. Switch Control Panel This appliance uses advanced touch control. The surface is easy to clean up and it has a long life time. - Page 8 Operating Instruction Operation Explain Every time the power is reconnect ,the clock shows 88:88 and flash. Only after adjust the clock and press “ok/esc” , the flashing shops. All other function can use at all time. Set clock: press “ ”...
- Page 9 Operating Instruction If in the setting status, in 1 minute no press “+ -ok/esc” will exit alarm to “00:00” or press”ok/esc” keep in 3s in setting status, can cancel the alarm function. Self cleaning function: When the hood is used for a certain time, the self cleaning function icon on the display will flash.
- Page 10 Operating Instruction During the stop 55 minutes, the display shows “ ” During the fan running, press the “ ” till “ ” flash. If press “ok/esc”, it will no respond and can not enter the ventilation function. Press any key except “ ”, it will cancel ventilation functional.
-
Page 11: Installation Instruction
Installation Instruction Safety Precautions Read these instructions carefully and keep them in a safe place. Safety during use can only be ensured if the appliance is fitted correctly according to these installation instructions. The installer is responsible for ensuring that the appliance operates perfectly at the point of installation. -
Page 12: Installation Position And Height
Installation Instruction Installation Position Install the cooker hood in a dry place and avoid direct sunlight. and Height The cooker hood is intended to be mounted onto the kitchen wall. Always mount the cooker hood over the centre of the hob. Ensure that the minimum distance between - the cooker hood and a gas hob is maintained at 750mm - the cooker hood and an electric hob is maintained at... -
Page 13: Installation Of Fasteners
Installation Instruction Installation of Fasteners Determine the installation positions of the fasteners (fixing brackets and mounting rails) on the wall and follow steps indicated in photo below. If the adjustable cover is not needed, skip step 5. Draw a line on the wall from the ceiling to the lower edge of the hood at the centre of the location where the hood is going to be mounted. -
Page 14: Connection Of Exhausted Pipe
Installation Instruction Fixing Cooker Hood Hang the cooker hood on to the fixing brackets on the wall. Make sure the cooker hood does not shake or hook off. Keep the cooker hood horizontal. Install the accessory fixing screws in the notch as shown in the figure to prevent the cooker hood falling off from the mounting rails. -
Page 15: Connection Of Adjustable Cover
Installation Instruction If you need to connect the exhausted pipe to the common chimney duct, DO NOT deeply insert the exhausted pipe into the common chimney duct in case the resistance increased when exhausting. If you need to connect the exhausted pipe directly outside the wall, a shutter (purchase additionally) is recommended to be mounted at one end of the exhausted pipe to prevent the external wind from... -
Page 16: Test Run
Cleaning, Maintenance and Repair Test Run After installation, clean the surface of the cooker hood. Insert the electric plug of the cooker hood into the receptacle. Test run operation is performed according to the “Operating Instruction”. Pull off the electric plug before cleaning or maintaining Cleaning and Maintaining the cooker hood. -
Page 17: Trouble Shooting
Siemens cleaning is not operating. customer service centre. If one of the following malfunction occurs, please pull out the electric plug of the cooker hood at once and contact our customer service centre. -
Page 18: Note
Cleaning, Maintenance and Repair Changing the Fluorescent Steps to change the fluorescent lamp: Lamp 1. Switch off the extractor hood and pulling out the main plug or switching off the fuse on the installation side. Caution!!! When switched on, the fluorescent lamp becomes very hot. - Page 19 Customer Service Tips Considerable injuries may be caused by faulty repairs. Repairs to the appliance must only be carried out by a trained technician. If a repair is required, please call the after-sales service. When cleaning things around the cooker hood (such as ceiling, cabinet) which may touch the hood, please war protection glove or take other protection measures to prevent injuries.
- Page 20 Material Number: 9000597286 Version: 01 Revised Date: 2011.04 Guarantee: The guarantee conditions for this appliance are as defined by our representative in the country in which it is sold. Details regarding these conditions can be obtained from the dealer from whom the appliance was purchased.
