Summary of Contents for Siemens HB33RB.50
- Page 1 [en] Instruction manual HB33LB.50, HB33RB.50 Built-in oven...
-
Page 3: Table Of Contents
Type of heating and temperature ..........10 Rapid heating ................... 10 Additional information on products, accessories, replacement Setting the time-setting options..........10 parts and services can be found at www.siemens-home.com Timer ....................10 and in the online shop www.siemens-eshop.com Cooking time ..................11 End time .................... -
Page 4: Important Safety Information
: Important safety information Read these instructions carefully. Only then A draught is created when the appliance ■ will you be able to operate your appliance door is opened. Greaseproof paper may safely and correctly. Retain the instruction come into contact with the heating manual and installation instructions for element and catch fire. -
Page 5: Causes Of Damage
Risk of electric shock! Causes of damage Incorrect repairs are dangerous. Repairs Caution! ■ may only be carried out by one of our Accessories, foil, greaseproof paper or ovenware on the ■ trained after-sales engineers. If the cooking compartment floor: do not place accessories on the cooking compartment floor. -
Page 6: Your New Oven
Your new oven Control panel Here you will learn about your new oven. The control panel and the individual operating controls are explained. You will find Here, you will see an overview of the control panel. All of the information on the cooking compartment and the accessories. symbols never appear in the display at the same time. -
Page 7: Temperature Selector
Temperature selector Cooking compartment The temperature selector is used to set the temperature or grill The oven light is located in the cooking compartment. A cooling setting. fan protects the oven from overheating. Oven light Setting Meaning During operation, the oven light in the cooking compartment is Off position The oven does not heat up. - Page 8 Optional accessories HZ number Wire rack HZ334000 For ovenware, cake dishes, joints, grilled items and frozen meals. Enamel baking tray HZ331003 For cakes and biscuits. Push the baking tray into the oven with the sloping edge facing towards the oven door. universal pan HZ332003 For moist cakes, baked items, frozen meals and large joints.
-
Page 9: After-Sales Service Products
Optional accessories HZ number Self-cleaning oven ceiling and side walls Appliances with one oven light and a folding HZ329020 You can retrofit the ceiling and side walls so that the cooking grill element compartment automatically cleans itself during operation. Appliances with two oven lights and a folding HZ329022 You can retrofit the ceiling and side walls so that the cooking grill element... -
Page 10: Setting The Oven
Setting the oven There are various ways in which you can set your oven. Here Switching off the oven we will explain how you can select the desired type of heating Turn the function selector to the off position. and temperature or grill setting. You can select the oven cooking time and end time for your dish. -
Page 11: Cooking Time
Cooking time End time The cooking time for your dish can be set on the oven. When You can change the time at which you wish your dish to be the cooking time has elapsed, the oven switches itself off ready. -
Page 12: Clock
Checking the time settings Changing the clock If several time-setting options are set, the relevant symbols are No other time-setting option should have been set. illuminated on the display. The time-setting options symbol is in Press the button four times. the foreground and preceded by the arrow. -
Page 13: Care And Cleaning
Care and cleaning With good care and cleaning, your oven will remain clean and Cleaning the self-cleaning surfaces in the cooking fully-functioning for a long time to come. Here we will explain compartment how to maintain and clean your oven correctly. The back wall in the cooking compartment is coated with a highly porous ceramic layer. -
Page 14: Folding Down The Grill Element
Unscrew the retaining carriers on the right and left and Refitting the rails remove them (fig. C). Lift out the panel upwards at an angle. First insert the rail into the rear socket, press it to the back slightly (figure A), &... -
Page 15: Troubleshooting
Troubleshooting Malfunctions often have simple explanations. Refer to the table Risk of electric shock! before calling the after-sales service as you may be able to Incorrect repairs are dangerous. Repairs may only be carried remedy the fault yourself. out by one of our trained after-sales engineers. Malfunction table Replacing the bulb in the oven ceiling light If a dish does not turn out as well as you had hoped, refer to... -
Page 16: Energy And Environment Tips
Energy and environment tips Here you can find tips on how to save energy when baking and For longer cooking times, you can switch the oven off ■ roasting and how to dispose of your appliance properly. 10 minutes before the end of the cooking time and use the residual heat to finish cooking. - Page 17 Cakes in tins Level Type of Temperature Cooking time heating in °C in minutes Sponge cake, simple Ring tin/round tin 160-180 50-60 3 loaf tins 140-160 60-80 Sponge cake, delicate Ring tin/round tin 150-170 65-75 Flan base, sponge Flan tin 160-180 20-30 Delicate fruit flan, sponge...
-
Page 18: Baking Tips
Small baked items Accessories Level Type of Temperature Cooking time heating in °C in minutes Viennese whirls (preheat) Baking tray 140-150 30-40 Baking tray 140-150 30-40 Universal pan + baking tray 140-150 30-45 2 baking trays + universal pan 5+3+1 130-140 40-55 Macaroons... -
Page 19: Meat, Poultry, Fish
The fruit juice overflows. Next time, use the deeper universal pan, if you have one. Small baked items made out of yeast There should be a gap of approx. 2 cm around each item. This gives enough space for dough stick to one another when bak- the baked items to expand well and turn brown on all sides. - Page 20 Meat Weight Accessories and Level Type of Temperature Cooking time ovenware heating in °C, grill set- in minutes ting Pork Joint without rind (e.g. neck) 1.0 kg Uncovered 190-210 1.5 kg 180-200 2.0 kg 170-190 Joint with rind (e.g. shoulder) 1.0 kg Uncovered 190-210...
-
Page 21: Tips For Roasting And Grilling
Poultry Weight Accessories and Level Type of Temperature Cooking time ovenware heating in °C, grill set- in minutes ting Duck, whole 2.0 kg Wire rack 190-210 100-110 Duck breast 300 g each Wire rack 240-260 30-40 Goose, whole 3.5-4.0 kg Wire rack 170-190 120-140... -
Page 22: Convenience Products
Dish Accessories and ovenware Level Type of Temperature Cooking time heating in °C in minutes Gratin Potato gratin, raw ingredients, 1 ovenproof dish 160-180 60-80 max. 4 cm deep 2 ovenproof dishes 150-170 60-80 Toast 4 slices, with topping Wire rack 160-170 10-15 12 slices, with topping... -
Page 23: Special Dishes
Special dishes Preheat the cooking compartment as indicated. Place the cups or jars on the cooking compartment floor and At low temperatures, 3D hot air is equally useful for incubate as indicated. producing creamy yoghurt as it is for proving light yeast dough. First, remove accessories, hook-in racks or telescopic shelves Proving dough from the cooking compartment. -
Page 24: Acrylamide In Foodstuffs
After 25 to 35 minutes of residual heat, remove the preserving Preserving jars from the cooking compartment. If they are allowed to cool Fruit for longer in the cooking compartment, germs could multiply, After approx. 40 to 50 minutes, small bubbles begin to form at promoting acidification of the preserved fruit. -
Page 25: Test Dishes
Test dishes These tables have been produced for test institutes to facilitate the inspection and testing of the various appliances. In accordance with EN 50304/EN 60350 (2009) and IEC 60350. Baking Baking on 2 levels: Always insert the universal pan above the baking tray. Baking on 3 levels: Insert the universal pan in the middle. - Page 28 Siemens-Electrogeräte GmbH Carl-Wery-Straße 34 81739 München Germany *9000776276* 9000776276 45 920323...
