Philips Consumer Lifestyle
Service Manual
PRODUCT INFORMATION
The new Satin Ice combinates a new ceramic epilating
system with a contour following skin cooler and a
massaging system.
Safety
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
- Power Source
- Voltage
- Motor
- Power Consumption
- Number of Discs
- Number of catching points
- RPM
speed I
speed II
- Pulling actions/second
speed I
speed II
Published by Philips Consumer Lifestyle
10/01
: AC (mains)
: 100 V - 240 V
(50 - 60 Hz)
: DC - Motor 14 V
: 7,5 W
: 13
: 24
: 2200
: 2700
: 880
: 1080
Printed in the Netherlands
DISASSEMBLY- AND RE-ASSEMBLY ADVISE
- No specific issues.
REPAIR INSTRUCTION
- This is a replacement appliance.
For this Epilator only the parts shown in the exploded view
will be supplied.
Hints for repairs:
- No specific issues.
OPTIONAL (accessories)
- No specific issues.
PACKAGING
F-box dimensions
- Width
: 192 mm
- Depth
: 114 mm
- Height
: 235 mm
- Weight F-box
: 0.639 kg
ATTENTION:
- By ordering pos. 2 and pos. 6 see remarks in the partslist
due incompatible between old and new parts.
© Copyright reserved
Satinelle - ICE
HP6481/00
Subject to modification
Advertisement
Related Manuals for Philips Satinelle ICE HP6481/00
Summary of Contents for Philips Satinelle ICE HP6481/00
- Page 1 - By ordering pos. 2 and pos. 6 see remarks in the partslist speed II : 1080 due incompatible between old and new parts. Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification 10/01...
-
Page 2: Parts List & Exploded View
PARTS LIST & EXPLODED VIEW HP6481/00 Service code Description 4203 035 53990 Massage Attachment HP6481 4203 035 91701 Repair Kit (For products with production date till 744) 4203 035 54170 Epilation Head new (From 744 onwards) 4203 035 86400 Cooling Glove + Cooling Pad 4203 035 51810 Adapter WEU 4203 035 51900... - Page 3 Instruction for exchanging the Gearwheel 3 HP6481/00 Remove the small gearing cover with a small screwdriver. Here you see the opened gearing. As you can see, the small edge from the release knob is hampering you by removing the damaged gearwheel. Cut this small edge with a very sharp knife, so that the damaged gearwheel becomes free.
- Page 4 Instruction for exchanging the Gearwheel 3 HP6481/00 Cutted edge. Now you are able to exchange the damaged gearwheel.
-
Page 5: Instruction Sheet
INSTRUCTION SHEET HP6481/00 For Repair Kit 4203 035 91701 Only for products with production date till 0744. 1. Exchanging gearwheel 3 and small cover on old epilation body. - Open the small gearing cover. - Remove small cover and gear wheel 3. - Exchange the 2 parts with below 12 NC’s.
