WASHING MACHINE

SERVICE MANUAL

CAUTION
READ THIS MANUAL CAREFULLY TO DIAGNOSE
PROBLEMS CORRECTLY BEFORE SERVICING THE UNIT.
MODEL : 796.4044#9##
http://www.managemyhome.com

Advertisement

Table of Contents
loading

Related Manuals for Kenmore 796.4044*9 Series

Summary of Contents for Kenmore 796.4044*9 Series

  • Page 1: Washing Machine

    http://www.managemyhome.com WASHING MACHINE SERVICE MANUAL CAUTION READ THIS MANUAL CAREFULLY TO DIAGNOSE PROBLEMS CORRECTLY BEFORE SERVICING THE UNIT. MODEL : 796.4044#9##...
  • Page 2 P/No.: MFL30599145...

  • Page 3: Table Of Contents

    CONTENTS 1. SPECIFICATIONS ....................... 3 2. FEATURES & TECHNICAL EXPLANATION ............... 4 3. PARTS IDENTIFICATION ....................7 4. INSTALLATION AND TEST ....................8 5. OPERATION ........................11 5-1. CONTROL PANEL FEATURES ................. 11 5-2. CYCLE GUIDE ......................14 5-3. SPECIAL FUNCTIONS ....................15 5-4.

  • Page 4: Specifications

    1. SPECIFICATIONS COLOR WHITE, PATINA BEIGE POWER SUPPLY AC 120 V, 60 Hz PRODUCT WEIGHT 190.7 lbs (86.5kg) WASHING 280 W ELECTRIC POWER DRAIN MOTOR 50 W CONSUMPTION 1000W WASH HEATER REVOLUTION WASH 46 rpm SPIN SPEED 0-1150 rpm CYCLE WASH/RINSE TEMPERATURES SPIN SPEEDS RINSE, ADD STEAM...

  • Page 5: Features & Technical Explanation

    2. FEATURES & TECHNICAL EXPLANATION 2-1. FEATURES Ultra Capacity The Larger drum enables not just higher head drop and stronger centrifugal force, but also less tangling and wrinkling of the laundry. Heavier loads, such as king size comforters, blankets, and curtains, can be washed. Direct Drive System The advanced Brushless DC motor directly drives the drum without belt and pulley.

  • Page 6: Water Level Control

    2-2. NEURO FUZZY WASHING TIME OPTIMIZATION To get the best washing performance, optimal time is determined by the water temperature, the selected washing temperature, and the size of the load. water temperature washing time the best selected NEURO- washing washing rinsing time temperature FUZZY...

  • Page 7: Control Lock

    2-5. THE DOOR CAN NOT BE OPENED While program is operating. When a power failed and power plug is taken out in operation While Door Lock lights turn on. White the motor is in the process of intertial rotating, through the operation is paused. 2-6.

  • Page 8: Parts Identification

    3. PARTS IDENTIFICATION ACCESSORIES Tie strap (Option) Hot/Cold (1 each) Wrench to secure drain hose to standpipe, Hose inlet hose, or laundry tub Caps(4) Elbow Bracket Non-skid pads (for securing drain hose) (for covering shipping bolt holes)

  • Page 9: Installation And Test

    4. INSTALLATION & TEST Before servicing, ask the customer what the trouble is. Check the setup (power supply is 120V, remove the transit bolts, level the washer...) Check with the troubleshooting guide. Plan your service method by referring to the disassembly instructions. Service the unit.

  • Page 11: Test Operation

    TEST OPERATION Press the POWER button. Preparation for Press the washing. START/PAUSE button. • Connect the power plug to • Listen for a click to determine if the outlet. the door has locked. • Connect the inlet hose. Check the water heating Check the automatic Check the water supply.

  • Page 12: Operation

    5. OPERATION 5-1. CONTROL PANEL FEATURES 796.4044#9##...

  • Page 13: Status Indicator

    POWER BUTTON STATUS INDICATOR • Use this button to turn the • It shows elapsed time of the cycle the washer POWER ON/OFF. is operating. CYCLE SELECTOR KNOB START/PAUSE • Rotate the CYCLE SELECTOR KNOB to select the cycle • Use this button to designed for different types of fabric and soil levels.

  • Page 14: Option Button

    OPTION BUTTON • STAIN TREAT: Use this option for heavily soiled loads that need improved stain treatment. • 2 RINSE: Use this option to add an extra rinse to the selected cycle. • ADD STEAM: Use this option to remove stains on fabrics without the energy usage or potential damage to fabrics.

  • Page 15: Cycle Guide

    5-2. CYCLE GUIDE 796.4044#9## Normal...

  • Page 16: Special Functions

    5-3. SPECIAL FUNCTIONS STAIN TREAT Use this option for heavily soiled loads that need improved stain treatment. When STAIN TREAT is selected, the water temperature for the selected cycle will begin as warm water to help prevent the setting of certain types of stains. Then as the cycle progresses, the water will be heated to higher temperatures to help remove stains that require treatment at higher temperatures.

  • Page 17: Explanation Of Each Process

    5-4. EXPLANATION OF EACH PROCESS Process Explanation Stay • Electrical power is supplied • Washer is ready to work and the micom is in the active mode. Water • After loading laundry and selecting a course and a cycle, water is supply supplied and drum rotates.
  • Page 18 Process Explanation Intermittent • To reach the correct set speed, the motor rotates clockwise and spin counterclockwise directions after spin process starts. • If the water level frequency is lower than 23.0 kHz, a washer senses suds and starts suds removal process. Rinse •...

  • Page 19: Program Chart

    6. PROGRAM CHART...

  • Page 20: Test Mode

    7. TEST MODE 7-1. SAFETY CAUTION There's built-in AC 110V and DC power in output terminal of PWB assembly in common. Be careful electric shock when disconnecting parts while trouble shooting. (Wear Electro Static Discharge gloves when working.) After cutting off the power when changing PWB assembly, disconnect or assemble. Be careful static when handling PWB assembly, and use Electro Static Discharge plastic pack when delivering or keeping it.

  • Page 21: Troubleshooting

    8. TROUBLESHOOTING 8-1. SAFETY CAUTION There’s built-in AC 120V and DC power in output terminal of PWB assembly in common. Be careful electric shock when disconnecting parts while trouble shooting. (Wear Electro Static Discharge gloves when working.) After cutting off the power when changing PWB assembly, disconnect or assemble. Be careful static when handling PWB assembly, and use Electro Static Discharge plastic pack when delivering or keeping it.
  • Page 22 ERROR SYMPTOM CAUSE • The connector (3-pin, male, white) in the MOTOR HARNESS is not connected to the connector (3-pin, female, white) of STATOR ASSEMBLY. • The electric contact between the connectors LOCKED (3-pin, male, white) in the MOTOR HARNESS MOTOR and 4-pin, female, white connector in the MAIN PWB ASSEMBLY is bad or unstable.

  • Page 23: Troubleshooting Summary

    8-3. TROUBLESHOOTING SUMMARY...

  • Page 25: Troubleshooting With Error

    8-4. TROUBLESHOOTING WITH ERROR INLET VALVE ERROR Replace the Is the voltage at the inlet INLET VALVE valve coil 120VAC with the ASSEMBLY. valve energized? displayed? Check the AIR When you press both CHAMBER WASH/RINSE button and and the tube DELAY STRAT button (clogged).
  • Page 26 DRAIN ERROR Measure the resistance of Replace the the drain pump motor. Is DRAIN PUMP the resistance between 10Ω ASSEMBLY. and 20Ω ? displayed? (Refer to 9-4 Pump motor assembly.) Reconnect or Check the connectors at the Replace the Check the voltage between repair main PCB and the drain MAIN PWB...
  • Page 27 HEATING ERROR Reconnect or Is the connector connected to repair thermistor disconnected or the connector. disassembled? displayed? Reconnect or Check the connectors at the repair main PCB, the heater and the the connector. thermistor. Are the connectors loose or disconnected? Steam generator thermistor Steam generator heater Wash thermistor...
  • Page 28 - part of motor LOCKED MOTOR ERROR displayed? Check the connectors at the Reconnect Motor main PCB and the main the connector. motor. Are the connectors (connector / loose or disconnected? wire / motor ) Replace Check the resistance of the Main PCB connectors RD3 the STATOR.

  • Page 29: Door Open Error

    DOOR OPEN ERROR Replace gasket Is the spring in the door displayed? or hinge. latch hook on the door Remove foreign strong and tight? objects. Reconnect or Check the connectors at the repair main PCB and the door the connector switch.

  • Page 30: Unbalance Error

    UNBALANCE ERROR OVER FLOW ERROR displayed? displayed? While a cycle is running, Check the AIR Put laundry Does the laundry lean press the WASH/RINSE and CHAMBER evenly toward one side, not evenly DELAY START buttons and the tube In the DRUM put in the DRUM assembly? together to display the water (clogged).
  • Page 31 PRESSURE SENSOR ERROR displayed? Reconnect or Check the connectors at the repair main PCB and the pressure the connector switch. Are the connectors loose or disconnected? Replace the Measure the resistance pressure between pins 1 and 3 of the switch pressure switch.

  • Page 32: Troubleshooting Else

    8-5. TROUBLE SHOOTING ELSE CAUTION 1. Be careful of electric shock if disconnecting parts while troubleshooting. 2. First of all, check the connection of each electrical terminal with the wiring diagram. 3. If you replace the MAIN PWB ASSEMBLY, reinsert the connectors correctly. NO POWER Replace the Is LED on while the power...
  • Page 33 BUTTON DOESN’T WORK Reconnect or Check the connectors at the Repair main PCB and the line filter. the connector Are the connectors loose or disconnected? Check the connectors Replace the between the main PCB and main PCB. the display PCB. Are the connectors loose or disconnected? Replace the main PCB.
  • Page 34 VIBRATION & NOISE IN SPIN Put an unbalance part (rubber) inside of drum and start QC test mode and run in high spin. Remove the Have all the transit bolts (Refer to section 7-2.) transit bolts and base packing been When the machine is and Base removed?
  • Page 35 DETERGENT DOES NOT FLOW IN Refer to Is water supplied? NO WATER SUPPLY Are receptacles correctly connected to the Check the wiring. terminals of the INLET VALVE ASSEMBLY? Put the detergent in the correct place. Has detergent been put in the correct compartment of the dispenser? Is the detergent caked or hardened? Clean the dispenser.
  • Page 36 LIQUID DETERGENT/SOFTENER/BLEACH DOES NOT FLOW IN Refer to Is water supplied? NO WATER SUPPLY Check the wiring on the Are the plugs correctly connected to the terminals of dispenser. the INLET VALVE ASSEMBLY? Put it in the correct Is liquid detergent/softener/bleach put in the correct compartment.

  • Page 37: Component Testing Information

    9. COMPONENT TESTING INFORMATION When Resistance (Ohm) checking the Component, be sure to turn the power off, WARNING and do voltage discharge sufficiently. 9-1. FILTER ASSEMBLY (LINE FILTER) Circuit Circuit in the MAIN PWB / Circuit diagram diagram MAIN PWB ASSEMBLY FUSE Test...

  • Page 38: Door Look Switch Assembly

    9-2. DOOR LOCK SWITCH ASSEMBLY Circuit Circuit in the MAIN PWB / Circuit diagram diagram MAIN PWB MICOM Relay Relay Common terminal of Valve Door switch The Door Lock Switch Assembly consists of a Heating PTC, a Bimetal, a Function Protection PTC, and a Solenoid.
  • Page 39 Test points Result Test Points Result Remarks (2) to (4) 700-1500 Ω At 77 °F °C (3) to (4) 60-90 Ω At 77 °F °C (4) to (5) Infinity (2) to (4) 120 Vac Voltage Input...

  • Page 40: Stator Assembly

    9-3. STATOR ASSEMBLY Circuit Circuit in the MAIN PWB / Circuit diagram diagram MAIN PWB NA1NA MICOM Function The DD motor can be driven from stopped to maximum speed in infinite steps in either direction. There are 36 poles on the stator; 12 permanent magnets spaced around the rotor.
  • Page 41 The hall sensor determines the speed and direction of the motor. It also can read that the load is off balance when the drum speed fluctuates. Test point - Voltage Testing Hall Sensor at Stator Result (Hall Sensor) (2) (4) (1) (3) (5) If measuring voltage from the Main PCB Assembly to the Hall Sensor, use the following steps:...
  • Page 42 7. To measure output signal voltage from the hall sensor, carefully move test leads to terminals 1 to 4, blue and gray. Slowly rotate motor rotor by hand. You should read a pulsing 10 Vdc. If 10 Vdc is measured from 1 to 4, move lead on blue wire to red wire, terminal 2.

  • Page 43: Pump Motor Assembly

    9-4. PUMP MOTOR ASSEMBLY Circuit Circuit in the MAIN PWB Circuit diagram diagram MAIN PWB 1 2 3 1 2 3 1 2 3 4 1 2 3 3 2 1 MICOM 3 2 1 CONNECTOR Pump Driving circuit DRAIN CIRCULATION PUMP PUMP...

  • Page 44: Inlet Valve Assembly

    9-5. INLET VALVE ASSEMBLY Circuit Circuit in the MAIN PWB diagram MICOM CONNECTOR Inlet valve driving circuit INLET VALVE Circuit diagram MIAN PWB COMMON GY YL (BK) MAIN BLEACH VALVE WASH VALVE WASH INLET VALVE * Each circuits of loads in wiring diagram are all same. Depending on the cycle and water temperature, the controller will energize the hot or Function cold water valve solenoids to meet the selected water temperature.

  • Page 45: Heater Assembly

    9-6. HEATER ASSEMBLY Circuit Circuit in the MAIN PWB Circuit diagram diagram MAIN PWB (X71) (X135) (X134) X100 MICOM Heater Tab Relay STEAM Heater driving circuit WASH GENERATOR HEATER HEATER * Each circuits of loads in wiring diagram are all same. Function 1.

  • Page 46: Thermistor Assembly

    9-7. THERMISTOR ASSEMBLY Circuit Circuit in the MAIN PWB / Circuit diagram diagram MAIN PWB MICOM WASH STEAM THERMISTOR GENERATOR THERMISTOR The thermistor (temperature sensor) is used to monitor water temperature in the tub. Function Test points (1) (2) (1) (2) Wash Thermistor Steam generator Thermistor...
  • Page 47 Result Wash Thermistor Test Points Result Remarks (tolerance ±5%) (1) to (2) At 86°F (30°C) 39.5 kΩ 26.1 kΩ At 104°F (40°C) 12.1 kΩ At 140°F (60°C) 8.5 kΩ At 158°F (70°C) At 203°F (95°C) 3.8 kΩ At 221°F (105°C) 2.8 kΩ...
  • Page 48 2) Operation mechanism of Steam generator Function After supplying some amount of water through inlet valve and water level sensor, Heater operates and steam generates. Generated steam is sprayed by nozzle. If the water in the steam generator is reduced by spraying steam, water level sensor decide to supply water or not.

  • Page 49: Disassembly Instructions

    10. DISASSEMBLY INSTRUCTIONS Be sure to unplug the machine before disassembling and repairing the parts. CONTROL PANEL ASSEMBLY Unscrew 2 screws on the back of the top plate. Pull the top plate backward and upward as shown. Disconnect the Display PWB assembly connector from trans cable.
  • Page 50 MAIN PWB ASSEMBLY Disconnect the POWER connector and SENSOR SWITCH ASSEMBLY. Remove the Protective cover. Disconnect the connectors. Unscrew 1 screw on the back. Remove the Main PWB.

  • Page 51: Noise Filter

    DISPENSER ASSEMBLY Disassemble the top plate assembly. Pull out the drawer. Push out the DISPENSER ASSEMBLY after unscrewing 2 screws. Unscrew the Clamp nut at the lower part of the dispenser. Disassemble the 4 connectors from the valves. Wire Color Blue Housing (YL-BK) White Housing (BK-WH) Blue Housing (BK-GY)
  • Page 52 CABINET COVER Unscrew the 5 screws from upper of the canbinet cover. Unscrew the screw from filter cover. Put a flat ( -) screwdriver or putty knife into the hinge slots at the bottom of the cover and pry it out. Unscrew the screw from the lower side of the cabinet cover.
  • Page 53 Open the door. Disassemble the clamp assembly. Tilt the cabinet cover. Disconnect the door switch connector. NOTE: When assembling the CABINET COVER, connect the door switch connector. Lift and separate the cabinet cover. Disassemble the clamp assembly. Disassemble the gasket.
  • Page 54 DOOR ① ① Open the door. ② ② Unscrew the 7 screws from the HINGE COVER. ③ ③ Put a flat ( - ) screwdriver into the openng of the hinge, and pull out the hinge cover. ④ ④ Unscrew a screw from the lower side of door. ⑤...
  • Page 55 PUMP Disassemble the cabinet cover. CIRCULATION Separate the pump hose, the bellows and the HOSE circulation hose assembly from the pump PUMP HOSE assembly. BELLOWS Disassemble the pump assembly in arrow direction. HEATER Disassemble the cabinet cover. Separate 2 connectors from the heater. Loosen the nut and pull out the heater.
  • Page 56 WHEN FOREIGN OBJECT IS STUCK BETWEEN DRUM AND TUB Disassemble the cabinet cover. Separate the heater from the tub. Remove any foreign objects (wire, coin, etc.) by inserting a long bar in the opening.
  • Page 57 MOTOR/DAMPER Disassemble the back cover. Remove the bolt. Pull out the Rotor. Unscrew the 2 screws from the tub bracket. Remove the 6 bolts on the stator. Unplug the 2 connectors from the stator. Disassemble the damper hinges from the tub and base.

  • Page 58: Exploded View

    11. EXPLODED VIEW 11-1. CABINET & CONTROL PANEL ASSEMBLY “The following parts are not illustrated" Description Loc No. *Owner’s Manual G001 *Energy Label G002 M400 *Tech Sheet G003 M410 Printed materials *Service Manual G004 *Quick Start Guides G006 *Installation Sheet G007 F215 A485...

  • Page 59: Drum And Tub Assembly

    11-2. DRUM & TUB ASSEMBLY K123 K351 K350 K360 K143 K610 F140 K611 K115 K411 K410 K141 F466 K110 K117 K111 K140 K571 F310 K142 F315 F465 K572 K190 F463 F464 K513 K570 K122 K195 K130 K125 K320 K530 K121 K510 K512 K560...

  • Page 60: Dispenser Assembly

    11-3. DISPENSER ASSEMBLY F323 F322 F462 F321 Inlet Valve Filter SVC F180 F300 COLD (BLUE) HOT (ORANGE) F170 F160 F227 F226 F327 F225 F430 F220 F441 F120 A275 F130 A276 F432...
