4 DIAGNOSTICS
The Current Channel status fields are:
Field
Type
Status
Preview
Purchasable
Purchased
EPOCH
Num
Auth
Reason
Description
Indicates whether the channel is analog or digital:
OSD Description
DIGITAL Digital
Indicates the current status of channel acquisition.
OSD Description
Acquired Service has been acquired and is playing, but stream
components may not be locked yet if the service is digital. For
an analog service, there are no stream components to lock, so
this is the final status.
Acquiring Service is being reacquired.
Not Service has not been acquired due to a failure.
Acquired
OSD Description
Acquired Digital service has been acquired, and all relevant stream
and Locked components for the service are locked. If the service is
purchasable, the stream components will not be locked until the
service is purchased.
Acquired Service has been partially acquired, but is not playing. For the
Not Playing MPEG-2 services, this means that no components are selected.
Indicates whether the current program is in preview mode.
Indicates whether the current program can be purchased for viewing.
Indicates whether the current program has been purchased.
Number of authorization requests originating from set-top.
The current epoch authorization reason is displayed in the hexadecimal format
0xbb on the OSD.
