D-Link DWC-1000 User Manual page 247

Section 7 - VPN Settings
A Manual policy does not use IKE and instead relies on manual keying to exchange authentication
parameters between the two IPSec hosts. The incoming and outgoing security parameter index
(SPI) values must be mirrored on the remote tunnel endpoint. As well the encryption and integrity
algorithms and keys must match on the remote IPSec host exactly in order for the tunnel to establish
successfully. Note that using Auto policies with IKE are preferred as in some IPSec implementations the
SPI (security parameter index) values require conversion at each endpoint.
The DWC-1000 supports VPN roll-over feature. This means that policies configured on the primary
Option port will rollover to the secondary port in case of a link failure. This feature can be used only if
your WAN is configured in Auto-Rollover mode.
Note: Once you have created an IPSec policy, you may right-click the policy and select Export to save
as a file. You can then upload this to another controller or keep as a backup. To upload a saved policy,
refer to "Easy VPN Setup" on page 254.
D-Link DWC-1000 User Manual 247
