Sony KDL-52XBR4 Service Manual

Lcd digital color television
Hide thumbs Also See for KDL-52XBR4:
Table of Contents

Advertisement

Quick Links

See also: Operating Instructions , Instruction Manual
HISTORY INFORMATION FOR THE FOLLOWING MANUAL:
SERVICE MANUAL
MODEL NAME
KDL-52XBR4
KDL-52XBR5
ORIGINAL MANUAL ISSUE DATE: 8/2007
:UPDATED ITEM
REVISION DATE
8/2007
8/2007
9/2007
10/2007
11/2007
1/2008
9-883-761-06
REMOTE COMMANDER
RM-YD017
RM-YD017
SUBJECT
No revisions or updates are applicable at this time.
Removed CN202 from AU Board Schematic and PWB (no fan in these models).
Replaced pages 26 to 32.
Updated Self Check illustration. Replaced page 11.
Added PNs for LCD Panels and FB1 Boards for S/N 8,100,001 to 8,499,999 and
8,600,001 on up. Replaced page 78 & 80.
Updated schematic diagrams to correct connector pins #s that were up side down.
Replaced pages 26, 33, 36, 39, 41, 57, 68 & 71.
Corrected P/N for FB1 Board on Exploded View. Replaced page 78.
Added SN Ranges for FB1 Boards on Electrical Parts List. Replaced page 98.
Added PNs for Balancer Boards for LCD panel. Replaced page 80.
DESTINATION
US/CND
US/CND
LCD DIGITAL COLOR TELEVISION
FIX2
CHASSIS
