Sharp XL-505 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

IMPORTANT SERVICE NOTES (XL-505 ONLY) .............................................................................................................. 2
SPECIFICATIONS ............................................................................................................................................................. 2
NAMES OF PARTS ........................................................................................................................................................... 3
OPERATION MANUAL ...................................................................................................................................................... 5
QUICK GUIDE ................................................................................................................................................................... 6
DISASSEMBLY .................................................................................................................................................................. 7
REMOVING AND REINSTALLING THE MAIN PARTS ..................................................................................................... 8
ADJUSTMENT ................................................................................................................................................................... 9
BLOCK DIAGRAM ........................................................................................................................................................... 16
SCHEMATIC DIAGRAM / WIRING SIDE OF P.W.BOARD ............................................................................................. 20
VOLTAGE ........................................................................................................................................................................ 26
NOTES ON SCHEMATIC DIAGRAM .............................................................................................................................. 27
TYPE OF TRANSISTOR AND LED ................................................................................................................................. 27
WAVEFORMS OF CD CIRCUIT ...................................................................................................................................... 28
TROUBLESHOOTING (CD SECTION) ........................................................................................................................... 29
FUNCTION TABLE OF IC ................................................................................................................................................ 34
LCD SEGMENT ............................................................................................................................................................... 41
REPLACEMENT PARTS LIST/EXPLODED VIEW
SERVICE MANUAL
CONTENTS
SHARP CORPORATION
- 1 -
XL-505
XL-505C
CP-505B
XL-505 and CP-505B constitute XL-505.
XL-505C and CP-505B constitute XL-505C.
• In the interests of user-safety the set should be restored to its
original condition and only parts identical to those specified be
used.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
XL-505/505C,CP-505B
No. S1808XL505///
Page

Advertisement

Table of Contents
loading

Related Manuals for Sharp XL-505

Summary of Contents for Sharp XL-505

  • Page 1: Table Of Contents

    • In the interests of user-safety the set should be restored to its original condition and only parts identical to those specified be used. CONTENTS Page IMPORTANT SERVICE NOTES (XL-505 ONLY) ......................2 SPECIFICATIONS ................................2 NAMES OF PARTS ................................3 OPERATION MANUAL ..............................5 QUICK GUIDE ................................... 6 DISASSEMBLY ..................................

  • Page 2: Important Service Notes (Xl-505 Only)

    XL-505/505C,CP-505B FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER TO THE OPERATION MANUAL. IMPORTANT SERVICE NOTES (XL-505 ONLY) BEFORE RETURNING THE AUDIO PRODUCT (Fire & Shock Hazard) Before returning the audio product to the user, perform the following safety checks.

  • Page 3: Names Of Parts

    XL-505/505C,CP-505B NAMES OF PARTS XL-505/505C Front Panel 1. Function/Band/Track Number Indicator 2. Volume Indicator 3. Timer Indicator AM PM REC SLEEP 4. Record Indicator 5. Sleep Indicator 6. Repeat Indicator RANDOM MEMORY 7. Play Indicator 8. Extra Bass/Equalizer Indicator 9. Random Indicator 10 11 12 10.
  • Page 4 XL-505/505C,CP-505B CP-505B Speaker Section 1. Full-Range Speaker 2. Bass Reflex Duct 3. Speaker Wire XL-505/505C Remote Control 1. Remote Control Transmitter LED 2. On/Stand-by Button 3. (CD) Repeat/Random Button 4. (CD/TUNER) Memory/Set Button 5. (CD/TUNER) Clear Button STAND-BY 6. Timer/Set Button 7.

  • Page 5: Operation Manual

    XL-505/505C,CP-505B OPERATION MANUAL – 5 –...

  • Page 6: Quick Guide

    XL-505/505C,CP-505B Quick-Guide DESK TOP AUDIO SYSTEM Guía rápida XL-505 Turning the power on and off Remote control Preparation for use Conexión y desconexión de la Control remoto Preparación para su uso alimentación AM Loop Antenna FM Antenna Remote Sensor Antena de cuadro de AM...

  • Page 7: Disassembly

    XL-505/505C,CP-505B DISASSEMBLY XL-505/505C Caution on Disassembly Follow the below-mentioned notes when disassembling (A3)x1 the unit and reassembling it, to keep it safe and ensure Top Cabinet ø3x10mm (A1)x1 excellent performance: Cabinet ø3x12mm 1. Take cassette tape and compact disc out of the unit.

  • Page 8: Removing And Reinstalling The Main Parts

    XL-505/505C,CP-505B REMOVING AND REINSTALLING THE MAIN PARTS CD MECHANISM SECTION ( A1 ) x2 Perform steps 1 and 9 of the disassembly method to remove Mechanism Cover the CD mechanism. ( A2 ) x2 How to remove the pickup (See Fig. 8) ø2.6 x6mm...

  • Page 9: Adjustment

    XL-505/505C,CP-505B ADJUSTMENT TUNER SECTION MECHANISM SECTION fL: Low-range frequency • Driving Force Check fH: High-renge frequency Torque Meter Specified Value • FM RF Play: TW-2412 Over 80 g Signal generator: 1 kHz, 75 kHz dev., FM modulated Test Stage Frequency...
  • Page 10 XL-505/505C,CP-505B CD SECTION 1. This CD unit need adjustment as follow. CD Test Mode Adjustment Part Value/Adjusting Method Instrument Connection Step 1 VR803 (Focus Offset) DC + 40 mV (FEI>RFO) FEI (R826) and VRO (1-Pin of TP801) Step 4 VR802 (Tracking Error Balance) *1 (See Fig.

  • Page 11: Test Mode

    XL-505/505C,CP-505B TEST MODE The Test Mode for this microcomputer has two variations, namely "regular Test Mode" for adjustment and measurement and "self- diagnosis Test Mode" for self-judgment in final inspection of products. 1. Entering the Test Mode To enter the each Test Mode, press the POWER key, holding down the following two keys in the regular standby mode (power off state).
  • Page 12 XL-505/505C,CP-505B 2. Step 2 Mode When the PLAY key is pressed in the mode above, the laser lighting is turned on. In this state the laser is only turned on, and other operations are not performed. When the following operation key is pressed in this state, the following operation is performed.
  • Page 13 XL-505/505C,CP-505B 5. Step 5 Mode The tracking servo is turned on, groove is traced, mute is set to off, and playback is started. Even when the outermost periphery of disc is reached in playback mode, it does not stop. The LCD display indicates playback lapse time as in case of regular CD playback.
  • Page 14 XL-505/505C,CP-505B Test Mode operation specification 3. Preset frequencies for various destinations (random preset memory) BAND (CH) 87.5MHz FM 108.0MHz 98.0MHz 90.0MHz FM 106.0MHz 530 kHz AM 1720 kHz 990 kHz 600 kHz AM 1400 kHz • The unit used in the table above is Hz. K represents 1,000 times, and M represents 1,000,000 times.
  • Page 15 XL-505/505C,CP-505B 6. LCD Test Mode (TEST 6) When the LCD Test Mode is set, all the LCD segments light. 7. Key input diagnosis Test Mode (TEST A) When the Test Mode is set, the following display appears. In this Test Mode checking as to whether all the main unit keys can be detected is performed. Accordingly, when this mode is set, checking is performed so as to examine whether the POWER key was pressed last after all the following keys were pressed.

  • Page 16: Block Diagram

    XL-505/505C,CP-505B LCD701 COM3 COM0 VLC3 OSC2 IC701 OSC1 X701 IX0189AW 8MHz SYSTEM MICROCOMPUTER X702 MMOD 32.768KHz VREF BUS3 KEY1 SW702-SW707 PU-IN SW710-SW714 POWER SW718 LID-SW BIAS B-CAN CAM SW LED704-LED712 34 35 36 37 38 39 40 41 45 46 47 48...
  • Page 17 XL-505/505C,CP-505B SW701 CD EJECT M 12V D GND M GND CD+6.2V A GND R-CH L-CH P MUTE A 12V P CONT CD+B R-MUTE FM ST B-CAN BIAS µ-CON5V CD +5V Q861 REGULATOR Q906 SWTCHING TAPE MOTOR DRIVER SWTCHING PU IN...
  • Page 18 XL-505/505C,CP-505B SWITCHING R-MUTE Q351 FM MUTE LEVEL VR351 T302 AM ANT. X351 AM OSC OUT AM OSC. ANTENNA T306 CNP301 AM LOOP CF351 AM IF T351 CF352 VOLTAGE REGULATOR ZD351 AUDIO +12V A-GND RF AMP. Q305 CF302 FM RF FM OSC...
  • Page 19 XL-505/505C,CP-505B R-MUTE R-CH X-BASS/GRAPHIC EQUALIZER TAPE TAPE L TAPE R 17 32 TUN R TUNER TUN L RVref CD R Vref LVref CD L IC401 LTEST LC75394E RTEST AUDIO PROCESSOR FUNCTION CONTROL AUDIO +12V VOL CONTROL AVSS LVROUT G-EQ CONTROL...

  • Page 20: Schematic Diagram / Wiring Side Of P.w.board

    XL-505/505C,CP-505B R320 VD301-1 R319 KV1236Z2 100K (0V) R358 C330 C343 4.7V C332 C333 C331 8.2K R364 8.2P R363 0.022 0.022 T302 0.047 3.3K L353 3.3K (UJ) AM ANT. TP302 C364 10/16 VR351 R361 Q351 10K(B) TRACKING KRC104 M FM MUTE...
  • Page 21 XL-505/505C,CP-505B FM SIGNAL AM SIGNAL PLAYBACK SIGNAL RECORD SIGNAL CD SIGNAL C645 330P R412 5.6K BOTTOM MECHA C412 R414 22/16 3.3K 33 34 C406 C434 R480 1/50 0.0033 100K TAPE R R420 C438 C404 RVref 1/50 100P TUN R C436...
  • Page 22 XL-505/505C,CP-505B DISPLAY PWB-A3 CD LI LCD701 LED PWB-A4 FUNCTION SW707 99 98 97 96 95 94 93 92 91 90 89 88 87 86 85 84 83 82 81 80 79 78 77 76 STOP R708 /CLEAR BAND 5.6K SW714...
  • Page 23 XL-505/505C,CP-505B CD LID SWITCH PWB-A7 SW701 CD SERVO PWB-A2 CD EJECT M 12V M 12V D GND D GND R787 R788 R793 R794 CNS603 CD STB R781 1K BUS3 M GND R780 1K BUS2 CD+6.2V R779 1K BUS1 A GND...
  • Page 24 XL-505/505C,CP-505B DISPLAY PWB-A3 Q701 Q702 R70B R70G Q703 R70C R753 LCD701 D722 ZD701 SW718 R70L ON/STAND-BY SW707 FUNCTION IC701 R732 C702 SW706 BAND C701 R726 X702 21 20 P24 6 - G X701 FW702 R725 R724 TO CD LID SWITCH PWB...
  • Page 25 XL-505/505C,CP-505B MAIN PWB-A1 CNP301 1 2 3 L-CH SO601 R-CH C311 C304 C330 C318 C317 IC301 C316 4 5 6 7 8 9 R305 C614 R301 C305 C307 C306 C607 C331 C613 D305 VD301-1 R319 C608 C332 T306 C333 1 2 3 4 5 6 7 8 9 10...

  • Page 26: Voltage

    XL-505/505C,CP-505B VOLTAGE IC101 IC303 IC401 IC801 IC701 IC802 NO. VOLTAGE NO. VOLTAGE NO. VOLTAGE NO. VOLTAGE NO. VOLTAGE NO. VOLTAGE NO. VOLTAGE NO. VOLTAGE 2.1V 4.7V 2.5V 2.4V 4.2V 2.5V 4.7V 2.1V 2.3V 2.1V 4.7V 2.5V 2.1V 2.6V – 0.3V(8V) 2.1V...

  • Page 27: Notes On Schematic Diagram

    XL-505/505C,CP-505B NOTES ON SCHEMATIC DIAGRAM • The indicated voltage in each section is the one measured • Resistor: by Digital Multimeter between such a section and the chas- To differentiate the units of resistors, such symbol as K and sis with no signal given.

  • Page 28: Waveforms Of Cd Circuit

    XL-505/505C,CP-505B WAVEFORMS OF CD CIRCUIT STOP PLAY NO DISC FOCUS SEARCH DMEO FKIC DMFC FCSI DMPC FOCUS SEARCH STOP PLAY FKIC FCSI FMSO STOP PLAY TKIC FMFB STOP PLAY REVIEW TKIC SBAD FMFB STOP PLAY TCD-782 TUO-02 PLAYBACK TS2O RFRP R-CH –...

  • Page 29: Troubleshooting (Cd Section)

    XL-505/505C,CP-505B TROUBLESHOOTING (CD SECTION) When the CD does not function When the CD section does not operate When the objective lens of the optical pickup is dirty,this section may not operate.Clean the objective lens,and check the playback operation.When this section does not operate even after the above step is taken,check the following items.
  • Page 30 XL-505/505C,CP-505B • LCD indication error. Is +5V applied to the pin 8 (VDD) of IC701? Is +5.6V applied to the Check the pattern between emitter of Q704? Q704 and CNS603. Check the pattern between Q704 and IC704. Is +5V applied to the pin 38 (SYS STOP) of IC701? Check the PWB pattern between the collector of Q702 and Q701.
  • Page 31 XL-505/505C,CP-505B • Focus servo sawtooth wave is not ouput. Check the pattern between pin 20 of IC801 and Q861. Is +5V applied to the pin 20 (VCC) of IC801? Is the following waveform Check R823 and R833 of Is sawtooth wave output to the pin 16 (FSO) of IC801? shown below obtained? pins 43 and 44 of IC802.
  • Page 32 XL-505/505C,CP-505B • HF error. Is output (tracking error signal) obtained at the pin 35 (TSO) of Check IC801 and the periphery of CNW802. If OK, the optical IC801 when the CD test mode "STEP4" is set? pickup is faulty. Is tracking output obtained at the pin 30 (TS20) of IC801 when Check the peripheral parts of IC801.
  • Page 33 XL-505/505C,CP-505B • Sled motor operation failure. Is slide feed signal output between the pin 26 (FUSO), 27 Check the pattern between pin 27 of IC801 and pin 36 of IC802. Check the connection of peripheral parts of IC801. (FMSM) of IC801 and the pin 15 of IC804 when FF/REW is If OK, IC801 is faulty.

  • Page 34: Function Table Of Ic

    XL-505/505C,CP-505B FUNCTION TABLE OF IC IC701 RH-iX0189AWZZ:System Microcomputer (IX0189AW) (1/2) Terminal Name Input/Output Pin No. Function COM3-COM0 Output LCD COMMON output terminal VLC3-VLC1 — LCD power terminal — Microcomputer power supply +5V. OSC2 Output Main clock oscillator connection terminal f=8MHz...
  • Page 35 XL-505/505C,CP-505B IC701 RH-iX0189AWZZ:System Microcomputer (IX0189AW) (2/2) Pin No. Terminal Name Input/Output Function SEG47 P62/A2 Output Tape circuit record/playback selection output H:Record Mode L:Playback Mode SEG46 P63/A3 Output Record bias oscillation frequency selection control output SEG45 P64/A4 Output Record bias oscillation circuit control output...
  • Page 36 XL-505/505C,CP-505B IC802 VHiTC9284BF-1:Servo/Signal Control (TC9284BF) (1/2) Function Port Name Input/Output Pin No. GNDA — Analog grand terminal fo DA vonverter (R channel) Output R channel data forward output terminal. Output R channel data reverse output terminal. — Analog power supply terminal for DA converter.
  • Page 37 XL-505/505C,CP-505B IC802 VHiTC9284BF-1:Servo/Signal Control (TC9284BF) (2/2) Function Port Name Input/Output Pin No. FCSI Output Focus actuator driving signal output terminal in the focus search mode. COMMAND FCSI OUTPUT OPERATION FORST Lens gets for away from disc FOSET Lens gets near disc...
  • Page 38 XL-505/505C,CP-505B IC802 VHiTC9284BF-1:Servo/Signal Control (TC9284BF) 64 63 62 61 60 59 58 57 56 55 54 53 52 51 50 49 48 47 46 45 44 43 42 41 TESTX DMPC PLL circuit Data slicer DMFC AD converter Focus/ GNDD...
  • Page 39 XL-505/505C,CP-505B IC801 VHiTA2065F/-1:Servo Amp. (TA2065F) Pin No. Input/Output Function Terminal Name Output RF amp (RF AMP) output terminal. Input RF ripple signal generating circuit input terminal. Output VR amp output terminal. 2VRO Output 2VR amp output terminal. RFRP Output RF ripple signal output terminal.
  • Page 40 XL-505/505C,CP-505B IC801 VHiTA2065F/-1:Servo Amp. (TA2065F) 180k DMEO 68µF DMEN 2.8k DMEP 680k 3 STATE 25µA 1.5k OSCI RFRP BOTTOM FSOSC PEAK COSC 100k 33PF Figure 40-1 BLOCK DIAGRAM OF IC IC601 VHiLA4600//-1:Power Amp. (LA4600) Standby Standby switch ch1 input Pre-...

  • Page 41: Lcd Segment

    XL-505/505C,CP-505B LCD701 RV-LX0027AWZZ : LCD COMMON SEGMENT Figure 41 LCD – 41 –...
  • Page 42 XL-505/505C,CP-505B — M E M O — – 42 –...

  • Page 43: Parts Guide

    “HOW TO ORDER REPLACEMENT PARTS” To have your order filled promptly and correctly, please furnish the For U.S.A. only following information. Contact your nearest SHARP Parts Distributor to order. 1. MODEL NUMBER 2. REF. No. 3. PART NO. 4. DESCRIPTION For location of SHARP Parts Distributor, Please call Toll-Free;...
  • Page 44 XL-505/C,CP-505B PRICE PRICE PART CODE DESCRIPTION PARTS CODE DESCRIPTION RANK RANK FILTERS XL-505/505C BF301 RFILR0008AWZZ AE Band Pass Filter INTEGRATED CIRCUITS CF302 92LFILTF1768AT AE FM IF CF351 RFILF0003AWZZ AK FM IF IC101 VHIBA3126N/-1 AF Head Selector,BA3126N CF352 RFILA0009AWZZ AE AM IF...
  • Page 45 XL-505/C,CP-505B PRICE PRICE DESCRIPTION PARTS CODE DESCRIPTION PART CODE RANK RANK AA 0.047 µF,50V AB 10 µF,16V,Electrolytic C331 VCKZPA1HF473Z C713 RC-GZA106AF1C AA 0.022 µF,25V C332,333 VCTYMN1EF223Z C714 VCKYMN1HB471K J AA 470 pF,50V AB 100 µF,10V,Electrolytic C334 VCCUMN1HJ180J AA 18 pF (UJ),50V...
  • Page 46 XL-505/C,CP-505B PRICE PRICE PART CODE DESCRIPTION PARTS CODE DESCRIPTION RANK RANK R113,114 VRD-MN2BD332J AA 3.3 kohms,1/8W R608 VRD-ST2EE102J AA 1 kohm,1/4W R115,116 VRD-MN2BD153J AA 15 kohms,1/8W R615,616 VRD-MN2BD682J AA 6.8 kohms,1/8W R117,118 VRD-MN2BD223J AA 22 kohms,1/8W R617 VRD-MN2BD333J AA 33 kohms,1/8W...
  • Page 47 XL-505/C,CP-505B PRICE PRICE DESCRIPTION PARTS CODE DESCRIPTION PART CODE RANK RANK CD MECHANISM PARTS R845 VRD-MN2BD225J AA 2.2 Mohms,1/8W R846 VRD-MN2BD333J AA 33 kohms,1/8W R852 VRD-MN2BD102J AA 1 kohm,1/8W NGERH0011AWZZ J AC Gear,Middle R866 VRD-ST2EE820J AA 82 ohms,1/4W NGERH0012AWZZ J...
  • Page 48 XL-505/C,CP-505B PRICE PRICE PART CODE DESCRIPTION PARTS CODE DESCRIPTION RANK RANK LX-EZ0005AWFD AA Screw,ø2.6×10mm XJBSD30P08000 AA Screw,ø3×8mm XEBSF30P08000 AA Screw,ø3×8mm XJBSD30P06000 AA Screw,ø3×6mm,For Power IC ACCESSORIES/PACKING PARTS QACCD0006AW00 J AP AC Power Supply Cord QANTL0004AWZZ AG AM/FM Loop Antenna SPAKA0144AWZZ AL Packing Add.Left/Right [C Only]...
  • Page 49 XL-505/505C,CP-505B XL-505/505C 306-2 306-1 306-3 M802 M801 305x2 SW801 PWB-B Figure 6 CD MECHANISM EXPLODED VIEW – 49 – – 6 –...
  • Page 50 XL-505/505C,CP-505B XL-505/505C 607x2 223-3 607x3 223-1 610x3 223-2 MECHANISM Silicon PWB-A7 Grease 602x6 607x2 PWB-A1 PWB-A2 230x4 PWB-A3 201-1 TAPE MECHANISM PWB-A4 602x4 PWB-A5 201-2 LCD701 (249-1,249-2,249-3, PWB-A6 249-4,249-5,249-6, 230x2 249-7,249-8) 201-3 603x3 607x2 201-4 605x2 201-4 207-1 607x2 207-2 80 mm NOTE: The parts of cassette mechanism which are supplied are only the unit and consumable parts.
  • Page 51 XL-505/505C,CP-505B CP-505B SP1,2 704x4 SP1,2 Woofer Black Figure 8 SPEAKER EXPLODED VIEW – 51 – – 8 –...

  • Page 52: Packing Of The Set (Xl-505 Only)

    XL-505/505C,CP-505B PACKING OF THE SET (XL-505 ONLY) Setting position of switches and knobs Tape Mechanism STOP AC Power Supply Cord SSAKH0014AWZZ Polyethylene Bag, Unit 92LBAG1658B SPAKA0144AWZZ Polyethylene Bag, Packing Add., Left/Right AC Power Supply Cord 92L411-0019 XL-505 Polyethylene Bag, Speaker...
