Tools needed for assembly: Phillips screwdriver • Adjustable wrench
WARNING
Do not use this unit on a wood deck or on combustible
surfaces such as dry grass, leaves, mulch, etc. Do not
use this unit near heat sensitive or combustible structures
such as vinyl or wood siding.
CAUTION
Some parts may contain sharp edges – especially as
noted in manual. Wear protective gloves if necessary.
WARNING
NEVER LEAVE FIRE UNATTENDED!
Do not allow small children near flame. Hot embers can
fly out of ring in breezy conditions. Adequate fire
extinguishing material should be readily available.
Trentino Fireplace
MODEL 02505755 • Assembly Instructions
FOR OUTDOOR USE ONLY!
TM
CAUTION
THIS UNIT IS HEAVY!
DO NOT assembly without a helper.
CAUTION
Read and follow all safety statements, warnings,
assembly instructions and use & care directions before
attempting to assemble.
WARNING
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill you. It gives off carbon
monoxide, which has no odor. NEVER burn charcoal
inside homes, vehicles or tents.
02505755 / 42804025 (01-28-04)
Advertisement
Related Manuals for Char-Broil Trentino 02505755
Summary of Contents for Char-Broil Trentino 02505755
- Page 1 Trentino Fireplace MODEL 02505755 • Assembly Instructions FOR OUTDOOR USE ONLY! Tools needed for assembly: Phillips screwdriver • Adjustable wrench WARNING CAUTION Do not use this unit on a wood deck or on combustible THIS UNIT IS HEAVY! surfaces such as dry grass, leaves, mulch, etc. Do not use this unit near heat sensitive or combustible structures DO NOT assembly without a helper.
- Page 2 STOP! Call Our Help Line Missing a part? No need to go back to the store! The store where you made your purchase does not stock parts for this item. If you need parts, whether they are missing or damaged, call the Customer Service toll free Help Line.
- Page 3 Place (5) 1/4-20x2-1/4” machine screws into fire pan and base. Attach with (5) 1/4-20 flange nuts. Fire Pan Base Each corner post attaches with (2) #10-24x1/2” screws and (2) #10-24 flange nuts. Do not tighten flange nuts until the top is attached Corner Post 3 •...
- Page 4 Place hood on outside of corner posts. Secure each post with (2) #10-24x1/2” screws and (2) #10- 24 flange nuts. Tighten all flange nuts. Hood Corner Post Set hood cap onto hood. Hood Cap 02505755 • 4...
- Page 5 Place log rack on fire pan. Insert bottom of each screen into slots and rest against corner posts. Log Rack Screen 5 • 02505755...
-
