SERVICE MANUAL
CD STEREO SYSTEM
SYSTEM
AMPLIFIER
XR-M98MK2
MX-LM98MK2
MX-LM99MK2 TX-LM99MK2
XR-M99MK2
• This Service Manual is the "Supplement" and replaces "Simple Manual"
(S/M Code No. 09-005-415-0T3).
• This Service Manual contains informations about the difference between
XR-M98MK2/99MK2 (EZ,K) and XR-M98/99 (EZ,K). If requiring the other information,
see Service Manual of XR-M98/99 (K,EZ). (S/M Code No. 09-999-415-0R2).
TUNER
CD PLAYER
TX-LM98MK2
DX-LM99MK2
S/M Code No. 09-005-415-0S1
XR-M98MK2
XR-M99MK2
BASIC CD MECHANISM: 3ZG-3 E3NC
MD
DECK
RECORDER
AM-LM99
FX-LM99
(OPTIONAL)
(OPTIONAL)
K
EZ
REMOTE
SPEAKERS
CONTROL
RC-ZAT04
SX-LM99MK2
Advertisement
Table of Contents
Related Manuals for Aiwa XR-M98MK2
Summary of Contents for Aiwa XR-M98MK2
- Page 1 • This Service Manual is the “Supplement” and replaces “Simple Manual” (S/M Code No. 09-005-415-0T3). • This Service Manual contains informations about the difference between XR-M98MK2/99MK2 (EZ,K) and XR-M98/99 (EZ,K). If requiring the other information, see Service Manual of XR-M98/99 (K,EZ). (S/M Code No. 09-999-415-0R2). S/M Code No. 09-005-415-0S1...
-
Page 2: Specifications
SPECIFICATIONS <STEREO CASSETTE DECK FX-LM99> <STEREO TUNER TX-LM98MK/99MK2> <Cassette deck section> <FM tuner section> Track format 4 tracks, 2 channels stereo Tuning range 87.5 MHz to 108 MHz Frequency response tape: 50 Hz to 16000 Hz Usable sensitivity (IHF) 13.2 dBf Normal tape: 50 Hz to 15000 Hz Antenna terminals 75 ohms (unbalanced) -
Page 3: Electrical Main Parts List
PLATE,JOG 24 87-A80-108-010 AC CORD ASSY,K BLK 3P<K> 3 8Z-CE3-008-010 REFLECTOR,JOG 25 87-085-185-010 BUSHING, AC CORD (E) 4 8Z-CC3-007-010 BADGE,AIWA 27.5 ABS SIL 26 81-664-202-010 HOLDER, PCB 5 8Z-CE3-022-010 CABI,FR AMP (EZ)<EZ> 27 8Z-CE3-006-010 FOOT,DIA40 H4 5 8Z-CE3-023-010 CABI,FR AMP (K)<K>... - Page 4 MECHANICAL EXPLODED VIEW 1 / 1 P.C.B HT-SYNK HT0-SYNK MAIN HT0-SYNK P.C.B P.C.B P.C.B P.C.B PT102 P.C.B 10 P.C.B CHAS,MAIN - 4 -...
- Page 5 DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 8Z-CF3-005-010 WINDOW,DISPLAY 15 88-908-151-110 FF-CABLE,8P 1.25-150MM 2 8Z-CC3-007-010 BADGE,AIWA 27.5 ABS SIL 16 8Z-CF3-002-010 PANEL,SIDE L LOW 3 8Z-CF3-009-010 CABI,FR TUNER (EZ)<EZ> 17 8Z-CF3-203-010 PLATE,TOP TUNER 3 8Z-CF3-001-010 CABI,FR TUNER<K> 18 8Z-CE3-005-110...
- Page 6 MECHANICAL EXPLODED VIEW 1 / 1 P.C.B P.C.B ZZA-1 P.C.B P.C.B P.C.B CHAS.MAIN FL701 P.C.B - 6 -...
- Page 7 MECHANICAL PARTS LIST 1 / 1 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 8Z-CC3-007-010 BADGE,AIWA 27.5 ABS SIL 16 8Z-CX3-204-010 HLDR,PWB CD 2 8Z-CX3-001-110 CABI,FR CD 17 8Z-CX3-016-010 PANEL,REAR CD MK2 YSM 3 8Z-CX3-005-010 KEY,PLAY CD 18 8Z-CX3-608-010 FF-CABLE, 16P 1.0 320MM...
- Page 8 MECHANICAL EXPLODED VIEW 1 / 1 3ZG-3 E3NC P.C.B P.C.B P.C.B P.C.B P.C.B P.C.B CHAS.MAN CD - 8 -...
- Page 9 SPEAKER PARTS LIST (SX-LM99MK2<YTL>) REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 8Z-CP3-010-010 CORD,SP 2 8Z-CP3-002-010 GRILLE,FRAME ASSY 3 8Z-CP3-007-010 HLDR,TW 4 8Z-CP3-013-010 PANEL,FR L 5 8Z-CP3-014-010 PANEL,FR R 6 8Z-CP3-006-010 PANEL,TW 7 8Z-CP3-005-010 PANEL,W 8 8Z-CP3-602-010 SPKR, W 9 88-NSV-601-010...
- Page 10 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 9820572 0251431 Printed in Singapore...
