- Page 1 AUTOMATIC BLOOD PRESSURE MONITOR (Wrist Cuff Type) INSTRUCTION MANUAL Models: FT-B13W...
-
Page 2: Table Of Contents
English Instruction Guide Table of Contents IMPORTANT INFORMATION ………….………. (3) READING THE AVERAGE OF MEASUREMENTS (AUg).. . (11) PRECAUTION FOR USE………………..….…….(4) ACCESSING BLOOD PRESSURE FOR ADULTS. .(12) BEFORE YOU START….………………………(4)(5) CLASSIFICATION OF BLOOD PRESSURE….….. (12) MONITOR COMPONENTS…...…...……………..(5) SPECIFICATIONS…………………………………. .(13) DISPLAY OF LCD……………..……………….. . (6) TROUBLE SHOOTING……………………... -
Page 3: Important Information
. .(9) BLOOD PRESSURE RECORD.…………..…..…... (18) PROGRAM DATE, CLOCK AND LANGUAGES. (10) IRREGULAR HEARTBEAT INDICATOR…..(10) IMPORTANT INFORMATION Please read this instruction manual thoroughly so that you completely understand the operations, cautions, performance and limitations with this monitor. After reading this manual, please keep it for future reference. You should not use this blood pressure monitor for self-diagnosis, self- ... - Page 4 blood pressure measurements, you should consult your physician or other health care professional. This device is contained high-precision parts; therefore, avoid exposing it to extreme temperature or humidity or to direct sunlight, shock and dust. Pharma Supply guarantees the accuracy of this monitor only when it is stored and used properly.
-
Page 5: Precaution For Use
Remove and replace the batteries if the monitor is not used for more than 6 months. Alkaline batteries recommended. PRECAUTION FOR USE The Wrist Automatic Blood Pressure Monitor is designed to be operated by anyone who is eighteen years and older or by medical professionals to monitor blood pressure (systolic and diastolic) and pulse rate. -
Page 6: Battery Loading
Battery Loading ■ ★ Remove the battery compartment cover by gently pushing down on arrow and sliding cover forward. ★ Place batteries with positive “+” and negative “-“ terminals into compartment and make sure they match the indicated terminals in the compartment. -
Page 7: Monitor Components
★ When the LCD display shows “Low Battery” signal ,the batteries must be replaced for accurate readings. ★ Do not use rechargeable batteries (voltage 1.2V). They are not suitable for this product, can damage the monitor and will caused inaccurate readings to be obtained. -
Page 9: Display Of Lcd
DISPLAY OF LCD Mode for LCD display: (1) Date: Month - Day (2) Time: Hour - Minute (3) Systolic Blood Pressure (unit: mmHg) (4) Diastolic Blood Pressure (unit: mmHg) (5) Pulse (unit: beat/minute) (6) WHO BP Classification Indicator (7) Inflation / Deflation Indicator (8) Blood Pressure Measurement Unit (9) Low Battery Indicator (10) Irregular heartbeat Indicator... -
Page 10: Tips For Blood Pressure Monitoring
TIPS FOR BLOOD PRESSURE MONITORING ★ Relax for about 5 minutes before measurement. ★ Do not smoke or ingest caffeine at least 30 minutes prior to measurement. ★ Remove any constricting clothing and place the cuff on a bare wrist. ★... - Page 11 HOW TO PLACE/WRAP THE ★ Place the cuff around your bare wrist ½” - ¾” above the CUFF ON YOUR WRIST? wrist joint on the opened-hand (inside) side of the wrist. ★ Keep the cuff at approximately the same level as your heart.
- Page 12 TAKING YOUR BLOOD PRESSURE After you are in a comfortable position, press the “ON/OFF” button. The device will perform a self verification/check. During this verification/check the LCD will display all “8’s”. At the conclusion of the verification/check the LCD will display “00”. PROGRAM DATE, CLOCK AND LANGUAGE ★...
- Page 13 the “SET” buttons for about 5 seconds, the number of the YEAR signal will begin to blink on the LCD display. Press the “M” (for memory) button to change the YEAR. Each time when you press the “M” button, it will change one YEAR forward.
- Page 14 ★ REPEAT THIS PROCESS FOR SETTING THE TIME. Use the “SET” button to change (Hours/Minutes) and the “M” button will change the numbers forward. ★After you have set the YEAR, MONTH, DAY, HOUR and MINUTE press the “SET” button. The “SP” in the lower left corner of the LCD display will begin to blink.
- Page 15 ★ WHEN EVERYTHING IS SET-UP COMPLETELY, THE MONITOR WILL AUTOMATICALLY SWITCH OFF. BUT, WHEN YOU PRESS “ON/OFF” BUTTON AGAIN, THE MONITOR WILL ACTIVATE. NOTE: When batteries are replaced, the time and date must be reset. NOTE: Time is maintained using a 24 HOUR clock. AM/PM is not displayed. IRREGULAR HEARTBEAT INDICATOR: If an irregular heartbeat is detected, the IRREGULAR HEARTBEAT symbol...
- Page 16 READING THE AVERAGE OF THE LAST THREE MEASUREMENTS (Aug): ★ Each time, when you press and release the “M” button during the monitor’s being turned off condition, the LCD will display “AUg” symbol on the left upper corner of the LCD screen to show the average of the last three measurements record;...
- Page 17 and release the “M” button the next oldest result will be displayed. If the “TALKING” function is turned ON, each result will be verbally announced DELETING MEASUREMENT FROM THE MEMORY: ★ Press and hold the “MEMORY” button until all the numbers change to ‘ZERO’.
- Page 18 ACCESSING BLOOD PRESSURE FOR ADULTS The following standards for assessing high blood pressure (without regard to age or gender) have been established as a guide according to WHO (World Health Organization). Please note that other risk factors (e.g. diabetes, obesity, smoking, etc.) need to be taken into consideration and may affect these figures.
- Page 19 WHO CLASSIFICATION OF BLOOD PRESSURE SPECIFICATIONS...
- Page 20 Model No.: FT-B13W (Voice) Operation Environment: Temperature: 5~40°C Humidity: < 85%RH ------------------------------------- ---------------------------------------- Type: Oscillometric; Automatic air Storage Environment: Temperature: -20~60°C inflation by air pump and Humidity: < 95%RH automatic deflation Classification: Class II, type B ------------------------------------- ---------------------------------------- Measurement Pressure: 40~280mmHg...
- Page 21 Approx. 250 times (180mmHg, 26.9mm (10.6inch) -------(H) Battery Life: once /day, 22°C) ---------------------------------------- 238g (0.52 LB) Weight:...
- Page 22 TROUBLE SHOOTING (1) Abnormality Probable Reason Corrective action Batteries are low. Install new batteries. shows Low Batter symbol The unit does not Pneumatic system blocked or cuff Make certain the cuff is wrapped around measure. Readings are is too tightly wrapped. your wrist correctly and re-measure.
- Page 23 your physician or other health care professional.. Voice processor Unclear announcement by voice Batteries may be low. Please install new processor batteries and then take a measurement again, Incorrect operation Some interference in inflation or Refer to the inflation step in “Taking blood wrong operation during measuring pressure”...
- Page 24 LCD shows “Er U” Insufficient inflation Wait for 5 minutes and re-measure. operation still abnormal, contact LCD shows “Er H” Inflation over 305 mmHg manufacture or agent (see the last page) LCD shows “Er 1” Undetectable the pulse LCD shows “Er 2” Radiation interference Move away the radiation source LCD shows “Er 3”...
- Page 25 Pharma Supply guarantees that the Digital Blood Pressure Monitor will be free manufacturing defects under normal use for two years the original purchase. This warranty covers only normal use, and does not apply to use in clinical or commercial applications. This warranty does not cover batteries or other power sources that may be provided with or used with the Digital Blood Pressure Monitor.
- Page 26 Write your RA number on the return label that will be created at the time you call to receive RA number. Enclose your sales receipt (or photocopy) in the shipping carton. Mail your product back to Pharma Supply by any carrier you wish (USPC, UPS, Fed Ex, etc.), but please make sure the package has the proper amount of postage.
- Page 27 ANY IMPLIED WARRANTIES WHICH THE PURCHASER MAY HAVE ARE LIMITED IN DURATION TO THE TIME THAT THE ORIGINAL CONSUMER PURCHASER OWNS THE PRODUCT. Some states do not allow limitations or how long an implied warranty lasts, so the above limitation may not apply to you. This warranty constitutes the warrantor’s only responsibility and obligation to repair and/or replace materials or components, without refund the purchase price.
- Page 28 Manufacturer Distributed By: Pharma Supply, Inc. Diabetic Supply of Suncoast, Inc. 999 Stinson Way, HC 3 Box 7017 West Palm Beach, FL 33411 Dorado, PR 00646 Toll Free: (888) 469-3579 Toll Free: (866) 373-2834 info@pharmasupply.com www.pharmasupply.com Manual Version: V1.0 BLOOD PRESSURE RECORD REGISTRO DE LA PRESION ARTERIAL Name: Age:...
- Page 29 Note: By monitoring and controlling high blood pressure, you can lower your risk of stroke, heart attack, heart failure and kidney disease...
