Pendo PENDOPAD 7” Quick Start Manual & User Manual
Hide thumbs
Also See for PENDOPAD 7”:
- Quick start manual & user manual (30 pages) ,
- Quick start manual & user manual (36 pages)
Related Manuals for Pendo PENDOPAD 7”
Summary of Contents for Pendo PENDOPAD 7”
- Page 1 PENDOPAD 7” QUICKSTAR T GUIDE & QUICKSTAR T GU USE R MANUAL > Please read carefully before us e...
-
Page 2: Table Of Contents
Û Table of Contents THANK YOU ........... 3 CONNECTING TO THE INTERNET ..... 19 Package Contents ............3 Requirements ..............19 Features................4 Connect to a Wi-Fi Network ........20 GETTING TO KNOW THE INTERNET TABLET BROWSING THE WEB ......... 22 OPTIONAL CONNECTIONS ......26 About the Touchscreen ..........8 Connecting to a Computer ........26 Protective Film ............8... -
Page 3: Thank You
Û Thank You Congratulations on your purchase of the Internet Tablet. This guide is provided to help you get started quickly with your tablet; please read it carefully and save it for future reference. To view PDF documents, download and install the free Adobe Acrobat reader from the Adobe website at www.adobe.com. -
Page 4: Features
Features Built-in camera Convenient front-facing and back-facing camera Browse the Web. Visit your favourite websites Automatic orientation detection Read any way you want; the display adjusts Check your e-mail automatically! Keep in touch with friends and family Requires optional HDMI cable (Type A-to-Type C). 1080p Watch YouTube™... -
Page 5: Getting To Know The Internet Tablet
Û Getting to Know the Internet Tablet Unit at a Glance Name Description Camera Front-facing camera HDMI Connect to a TV or other display USB 2.0 Output Connect a storage device to the tablet Page 5 Getting To Know The Internet Tablet... -
Page 6: Getting To Know The Internet Tablet
Name Description Headphone Audio output connection for jack head-phones. Reset Key Press to reset the tablet if it freezes or otherwise behaves abnormally. (Use a paperclip or other small object to gently press this key.) Power Turn the tablet on and off Volume Press to increase or decrease the volume level... - Page 7 Name Description Camera Back-facing camera Speaker Speaker output is automati- cally muted when using head- phone jack Page 7 Getting To Know The Internet Tablet...
-
Page 8: About The Touchscreen
About the Touchscreen buttons, menu items, the on-screen keyboard and other Your tablet comes equipped with an easy-to-use touch- items displayed on the screen. screen. You can perform the following actions on the touchscreen touch on the glass screen to activate tablet’s functions. Touch: To activate an on-screen item (e.g., application icons, buttons, menu... -
Page 9: About The Orientation Sensor
About the Orientation Sensor Swipe: Swipe up/down on the screen to scroll through a list. On some screens, The tablet contains a sensor that will automatically you may be able to swipe left/right to change the orientation of most screens as you rotate the change the view. -
Page 10: Charging The Tablet
Charging the Tablet Inserting a Memory Card The current battery status will be always displayed in the The tablet accepts microSD memory cards. Insert a lower right of the screen in the system information bar. memory card into the microSD card slot to: The battery icon will change in accordance with the battery status. -
Page 11: Resetting The Tablet
To release and remove a memory card: 2. Push the card further into the slot until you hear a click. The card will spring out of the slot. 1. UNMOUNT the memory card. 3. Grasp the card by its edge to remove it. a. -
Page 12: Getting Started
Û Getting Started Turning the Tablet on and off 2. Touch OK to turn off the tablet. To turn the tablet on: Press and hold the Power key until the LCD screen turns on. Wait until the Home screen appears; the tablet is now ready for use. -
Page 13: Turning The Screen On And Off (Standby)
Turning the Screen On and Off (Standby) Unlocking the Screen When the tablet is on, you can turn off the screen to When the screen turns off, you will have to unlock the conserve battery power. Simply press the Power key screen when you turn it back on. -
Page 14: Home Screen At A Glance
Home Screen at a Glance unlocking the screen. The Screen Unlock password can be set in the Security settings menu. The home screen is the starting point for all of the features of your tablet. WARNING: Please write down your password lock pattern/PIN/Password. -
Page 15: About Applications
About Applications Name Description G o o g l e Touch to search with Google To open an application, touch the application icon on the Search browser. home screen or in the Launcher. Widgets Widgets are small applications Launcher screen: that you can use directly from the home screen. - Page 16 Browse the web. tablet. View photos and videos, plus edit Display the calendar or record events photos. and appointments to manage your schedule. Perform simple mathematical Play music. operations. Take pictures or videos with the front- Access the Settings menu to adjust facing camera.
-
Page 17: Installing Applications
Installing Applications Removing Widgets You can also download and install additional applications Touch and hold the Widget until the Remove icon from the device’s applications marketplace, the web appears at the top side of the screen, then drag the browser, or other sources. Widget to the Remove icon to remove it. - Page 18 will launch. bottom right corner of the screen alert you when new messages arrive or alarms or other application events occur. Touch any other area of the screen except the Touch the Back icon. Touch the panel. Page 18 Getting Started...
-
Page 19: Connecting To The Internet
Û Connecting to the Internet Wireless Wi-Fi technology can provide Internet access at distances of over 300 feet; however, this distance can be affected by your surrounding environment and Wi-Fi router. Requirements Please refer to your wireless router’s documentation for help, or ask your network administrator for details. -
Page 20: Connect To A Wi-Fi Network
Connect to a Wi-Fi network tablet’s Wi-Fi status. Connected to a Wi-Fi network (waves indicate connection strength). There are no Wi-Fi networks in range, or [no icon] the Wi-Fi radio is off. 1. Turn on the Wi-Fi radio if it is not already on. To turn on Wi-Fi: a. - Page 21 If the network is open, the tablet will prompt you to When you have successfully connected to a Wi-Fi Connect to will show a Wi-Fi signal indicator. If the network is secured (as indicated by a Lock icon), the tablet will prompt you to enter a password or other credentials.
-
Page 22: Browsing The Web
Û Browsing the Web or enjoy video from YouTube™, the world’s most popular video-sharing community. To use Browser, the tablet must be connected to the Name Description Internet. Read the section “Connecting to the Internet” to New Window Creates a new browser win- learn how to connect to the Internet. - Page 23 Some common Browser actions are described below. To bookmark a webpage. Bookmark your favourite webpages in order to visit To go to a webpage. them quickly without entering a URL. 1. Go to the web- 1. Touch the Address page that you bar at the top of the want to bookmark Browser screen.
-
Page 24: Browser Menu
To go to a bookmarked webpage. 3. Touch “Delete bookmark“. 1. Touch the Goto Bookmark icon. 2. Touch a bookmark Browser menu tile to open it. While viewing a webpage, touch the icon(as shown on the right) to open the Browser Menu, the icon is located on the top right corner of the screen, the options are: Refresh: Refresh the current webpage. - Page 25 Request desktop site: internal memory, then you can read it when the internet connection is disabled. Page info: View information about the current page, including the URL. Page 25 Browsing The Web...
-
Page 26: Optional Connections
Û Optional Connections Connecting to a Computer panel. 1. Connect your tablet to the computer. With the included USB cable: Plug the small end of the cable into the USB 2.0 Hi- speed connector of the tablet. Plug the large end of the cable into an available USB 2.0 Hi-speed port on the computer. -
Page 27: Connecting Headphones
2. Mount the storage drive. Connecting Headphones Touch USB connected to mount the tablet’s built-in Connect a pair of headphones (or earphones) to the storage, then touch “Turn on USB storage” and “OK” tablet to enjoy media in private. Lower the volume level of the tablet before connecting headphones and then slowly raise the volume to a comfortable listening level. -
Page 28: Using The Usb Full-Size Adapter
Using the USB Full-Size Adapter The USB full-size adapter can be used to connect and You may also use this connection to add a use USB devices with the tablet. The adapter converts mouse to the tablet. the Micro USB port on the tablet into a USB On-the-Go The adapter supports one connection at a time. -
Page 29: Setting The System Options
Û Setting the System Options Open the system settings menu to adjust how the tablet looks and functions. to learn more. To open the Settings menu: 1. From the Home screen, touch the Launcher Tab. 2. Touch Settings to open the Settings menu. The settings are grouped by category. -
Page 30: Specifications
Û A31S Cotex-A7 Quad core Processor 1.0GHz brightness set to default. Actual playback results may vary. Storage microSD card slot (max. 32GB supported) 7” TFT LCD (1024 x 600), ca Display pacitive touchscreen Wi-Fi IEEE 802.11 b/g/n Networking Mini HDMI, type C (Up to 1080p) Video Output 3.5 mm headphone Audio Output... -
Page 31: Safety Notices
Û Safety Notices For Customer Use: Enter below the serial number that is located on the rear of the unit. Retain this information for future reference. Model No. Serial No. WARNING: To prevent fire or shock hazard, do not expose this device to rain or moisture. -
Page 32: Safety Notices
FCC Statement: This device complies with Part 15 of the FCC Rules. Operation is subject to the Use of shielded cable is required to comply with Class B limits in Subpart B of Part following two conditions: 15 of the FCC rules. (1) This device may not cause harmful interference, and Do not make any changes or modifications to the equipment unless otherwise specified in the manual. - Page 33 Important Safety Instructions tion is provided or the manufacturer instructions have been adhered to. 1. Read Instructions: All the safety and operating instruc- tions should be read before the product is operated. 9. Power Sources: This product should be operated only from the type of power source indicated on the rating 2.
- Page 34 the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions as improper adjustment of other controls may result in damage technician to restore the product to its normal operation; e) if the product has been dropped or damaged in any way;...
