Grill Island
Model CGI08ALP
NOTE: Complete Island Kit requires 3 boxes
FREE HELP
FROM THE GRILL EXPERTS
Do not return to the store. At Grand Hall we're
the experts on this product and trained to help
you with:
Ÿ
Assembly questions
Ÿ
Grill operation
Ÿ
Replacement of damaged or missing parts
www.grandhall.com
visit
1- 800-761-5456
Monday - Friday 8:00am-4:30pm CST
IMPORTANT:
Ÿ
NOTE TO ASSEMBLER / INSTALLER:
Leave this manual with the consumer.
Ÿ
NOTE TO CONSUMER:
Keep this manual for future reference.
Ÿ
RECORD YOUR SERIAL # __________________
(see silver CSA label on main body of grill)
Ÿ
Ÿ
Ÿ
or call:
Ÿ
Ÿ
Ÿ
Ÿ
OPERATOR'S MANUAL
WARNING
!
Failure to comply with these instructions could
result in a fire or explosion that could cause
serious bodily injury, death or property damage.
Whether this grill was assembled by you or
someone else, you must read this entire manual
before using your grill to ensure the grill is
properly assembled, installed and maintained.
Use your grill at least 3 feet away from any
wall or surface. Use your grill at least 3 feet
away from combustible objects that can melt or
catch fire such as vinyl or wood siding, fences
and overhangs or sources of ignition including
pilot lights on water heaters and live electrical
appliances.
THIS GAS APPLIANCE IS DESIGNED FOR OUT-
DOOR USE ONLY.
Never use your gas grill in a garage, porch,
shed, breezeway or any other enclosed area.
Never obstruct the flow of ventilation air
around your gas grill housing.
Never disconnect the gas regulator or any gas
fitting while your grill is lit. A lit grill can ignite
leaking gas and cause a fire or explosion which
could result in property damage, personal injury
or death.
Manual # P80170008B - Date:2007/12/04
!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CGI08ALP and is the answer not in the manual?

Questions and answers

Related Manuals for Grand Cafe CGI08ALP

Summary of Contents for Grand Cafe CGI08ALP

  • Page 1 OPERATOR'S MANUAL Grill Island Model CGI08ALP NOTE: Complete Island Kit requires 3 boxes FREE HELP WARNING FROM THE GRILL EXPERTS Ÿ Do not return to the store. At Grand Hall we're Failure to comply with these instructions could the experts on this product and trained to help result in a fire or explosion that could cause serious bodily injury, death or property damage.

  • Page 2: Table Of Contents

    Table of Contents WARNING Primary Safety Warnings ......1-3 Pre-Assembly Instructions ......3 Part Diagrams and Lists ......4-13 • LPG models must be used with Liquid Propane Gas and the regulator assembly Assembly Instructions......14-20 supplied. Natural Gas models must be used Use &...

  • Page 3: Pre-Assembly Instructions

    Pre-Assembly Instructions For Your Safety To expedite the assembly process follow these WARNING general guidelines: Tools Required for Assembly Failure to comply with these instructions may • Protective work gloves result in a hazardous situation which, if not • Phillips Head Screwdriver avoided, may result in injury.
  • Page 4 Hardware Pack Parts List for Model CGI08ALP PART # PART DESCRIPTION QTY PURPOSE OF PART P06024006A Hardware Pack For use in assembly (Grill and Range) S112G04061 Phillips Head Screw 1/4"x3/8" Install Cart Frames to Left / Right Bowl Panels Already packed in the Faucet Assembly Kit Box...
  • Page 5 Parts Diagram for Model CGI08ALP Grill...
  • Page 6 Parts Diagram for Model CGI08ALP Range...
  • Page 7 Parts Diagram for Model CGI08ALP Island...
  • Page 8 Parts List for Model CGI08ALP Grill DESCRIPTION PART# P00147063A Lid Assembly P00601071A Temperature Gauge P00205086B Lid Handle P06801022A Heat Insulating Spacer Protective Pad P05518011 I Cooking Rack/Secondary P01516004B Cooking Grid, 13" P01604013B Cooking Grid, 6.4" P01604031B Burner/Main P02008032A Infrared Burner Assembly...
  • Page 9 Parts List for Model CGI08ALP Grill DESCRIPTION PART # Cart Panel, Front P07621009D Cart Frame for Front Panel P03344010D Cart Frame, Front P00907012C Cart Panel, Rear/Left P07621010D Cart Panel, Rear/Right P07621011D Cart Frame for Rear Panel P03344012D P00907013C Cart Frame, Rear...
  • Page 10 Parts List for Model CGI08ALP Range DESCRIPTION PART # P0014605AY P05518011 I Protective Pad P0073943DC Bowl Panel, Top P0072075DC Bowl Panel, Left P0072575DC Bowl Panel, Rear Control Panel, Upper P02907971S P03328039C Control Panel Bracket, Left P00815013D Side Burner Pot Support...
  • Page 11 Parts List for Model CGI08ALP Range DESCRIPTION PART # Handle/Door P00206005B Door P04301041A Cart Basket P05203008G Cart Bottom Panel P01001063D Door Magnet Bracket P03301051D Door Magnet P05523005M Bowl Support Panel, B P03305059D Slide Set P05516132C Cart Frame, Right P01303017B Bowl Support Panel, A...
  • Page 12 Parts List for Model CGI08ALP Island DESCRIPTION PART # P07805001A Table Top Panel, Front P07621006D Frame for Panel Front/Rear P03344009D Panel, Left P07605031H Panel, Right P07606032H Panel, Rear P07702088G Frame, Front/Rear P00907011C P03303049D Decoration Panel A P04301039A Door Handle/Door P00216023B...
  • Page 13 Y0250122 Rotisserie Assembly Parts Diagram Y0250122 Rotisserie Assembly Parts List PART# DESCRIPTION P05508092A Rot. Bushing S196G04081 Rot. Thumbscrew 1/4"x1/2" P05508168A Rot. Collar P05508175A Rot. Spit P05508023A Rot. Holding Fork P05508174A Rot. Motor Bracket P07101042B Rot. Motor/AC S112G10121 Rot. Screw#10-24x3/4"UNC S411G03081 Rot.
  • Page 14 Assembly Instructions Install Cart Frame (For Range Model) Align the holes in the Cart Frame and the Range Right (Front/Rear) Cart Legs. Insert the 4 Phillips Head Screws 1/4"x3/8" and tighten securely. Phillips Head Screw 1/4"x3/8" Qty.4 Part # S112G04061 Install Cart Frame (For Grill Model) Align the holes in the Cart Frame and the Grill Left...
  • Page 15 Assembly Instructions Assemble Island for L-Shape Configuration Separate the Island from Range and Grill modules. See Fig. 1. Remove Island Left, Rear and Decoration Panels B. See Fig. 2. Reinstall Island Left Panel, Rear Panel and Decoration Panel A as shown in Fig.
  • Page 16 Install Regulator with Hose to Hose Holder (This assembly process requires 2 people) Move Island away from Grill and Range in order to get access to outside of the Island side panels. Remove Drawers of the Grill and Range. Pull the Plugs out of the Grill and Range. Insert the Plugs of the Grill and Range into the Holes of the Island.
  • Page 17 Install Gas Tank to Tank Tray Open Tank Tray Door. Turn your LP Gas Tank Valve clockwise to the closed or OFF positon. Unscrew the Wing Bolt from right bracket of tank holder. Place LP Gas tank into tank holder on the Tank Tray. Install the tank so the Tank Valve faces the rear right corner of cabinet.
  • Page 18 Install Faucet Assembly (This assembly process requires 2 people) Open the Cart Door, remove the Cart Basket then insert the Faucet.(See Fig.1). Apply pipe tape on the Faucet pipe inlet. Connet a 5/8" water supply hose, pipe or tube (not provided) to the Faucet Pipe Inet.(See Fig.1) CAUTION: Avoid breaking the copper pipe by using 2 wrenches to connect your water supply fitting to the Faucet Pipe Inlet.
  • Page 19 • Install Ignitor Battery Using an adjustable wrench, loosen the Inside Nut until the Gas Collector Box can Unscrew Ignitor Cap from Range and Grill be turned upward. Control Panels. • If the gap between the Spark Elec- Place supplied AA battery into the Ignitor trode Tip and Receiver is more than Slot with positive pole facing you.
  • Page 20 Install Pot Support and Griddle Place Side Burner Cap on top of side burner. Pot Support Place Pot Support on top of side burner body. Place Griddle on top of griddle frame with the grease drain in the front as shown. Side Burner Cap Griddle Adjust Island Assembly Set (on uneven surfaces only)
  • Page 21 USE AND CARE INSTRUCTIONS CORRECT LP GAS TANK USE Never allow children to operate your grill. Do LP Gas grill models are designed for use with a 20 not allow children or pets to play near your grill. Ib or 30 lb. Liquid Propane Gas (LP Gas) tank, not Use of alcohol, prescription or non-prescription included with the grill.
  • Page 22 USE AND CARE INSTRUCTIONS NOTE about LP Gas Tank Exchange Programs LP Gas Model only: Ÿ Secure a 20 lb or 30 lb LP Gas Tank to Many retailers that sell grills offer you the option of your Island replacing your empty LP Gas tank through an ex- change service.
  • Page 23 USE AND CARE INSTRUCTIONS Check all connections for LP Gas Leaks Check that the end of each Burner Tube is properly located over each Valve Orifice Never test for leaks with a flame. Prior to first use, 1. Open lid at the beginning of each season, or every time 2.

  • Page 24: Lighting Instructions

    USE AND CARE INSTRUCTIONS Burner Control Knobs on Control Panel Grill Lighting Instructions Before each use, check all hoses for cracks, nicks, cuts, Grill burns or abrasions. If a hose is damaged in any way, do not use your grill before replacing the hose with an authorized part from the Parts List.
  • Page 25 USE AND CARE INSTRUCTIONS Troubleshooting Manually Lighting Your Grill By Paper Match If the grill fails to light : To light your gas grill by match, insert a match into the Turn gas off at source and turn Control Knobs to OFF. Lighting Stick and follow steps 1 through 5 of the Grill Wait at least 5 minutes for gas to clear, then retry.
  • Page 26 USE AND CARE INSTRUCTIONS WARNING WARNING Keep any electrical supply cord and the fuel To protect against electrical shock, do not immerse electrical cord, plugs or motor in water or expose to supply hose away from any heated surface. rain. Protect electrical elements from burners, hot grill surfaces and grease.

  • Page 27: Rotisserie Instruction

    Rotisserie Instructions 1. Remove all components from the carton. Attach the Motor Bracket on the outside of the right grill bowl panel. Align the two holes of the Bracket with the holes on the grill bowl. Tighten securely using two Screws #10-24x3/4" UNC, Plain Washers and Nuts provided.
  • Page 28 Install the AC (alternating current) Rotisserie Motor onto the Motor Bracket as shown below. Be sure the Motor attaches to the Bracket with the electrical cord down. This installation insures that once the Spit is inserted into the Motor it will also rest securely into the slot of your grill bowl. Rotisserie Motor Rotisserie Spit must rest securely in the slot of your grill bowl.

  • Page 29: Faucet Operation

    USE AND CARE INSTRUCTIONS Dual Function use Water supply and drainage system for Island Assembly Swivel and adjust the flexible faucet neck as needed to direct the spray head. Faucet neck Faucet Faucet holder head Remove the faucet neck from clamp holder for manual control and directional use.

  • Page 30: Refrigerator Instruction

    Refrigerator Instructions Operation CAUTION To avoid vibration, the cabinet must be set level. This appliance must be grounded. In the event To start the refrigerator, turn the temperature of an electrical short circuit grounding reduces control to the position corresponding to the the risk of electrical shock by providing an desired cooling.

  • Page 31: Cleaning And Maintenance

    Cleaning Exterior Stainless Steel Surfaces: CLEANING AND MAINTENANCE Routine care and maintenance is required to preserve the appearance and corrosion resistance of stainless steel. The Proper care and maintenance will keep your grill in top fact is stainless steel can corrode, rust and discolor under operating condition and prolong its life.
  • Page 32 CLEANING THE BURNER TUBES AND BURNER PORTS Regardless of which Burner cleaning procedure you To reduce the chance of FLASHBACK FIRE you must use, we recommend you also complete the following clean the Burner Tubes as follows at least once a month steps to help prolong Burner life.
  • Page 33 Cooking Instructions Indirect Cooking using Main Burners Burn-Off Before cooking on your gas grill for the first time, you The indirect cooking method can also be used with should "burn off" the grill to eliminate any odor or the supplied Cooking Grids. To cook indirectly, the foreign matter.
  • Page 34 Guide to Grilling using the Main Burners and Direct Cooking Method Approximate Cooking Times Grilling Steak and Ribs Cut of Meat Rare: 4-8 minutes Turn the grill Burners on HIGH, close the Lid and preheat T-bone steak Medium: 10-14 minutes your grill 3 to 5 minutes.
  • Page 35 Guide to Searing using the Infrared Cooking Zone • Important notes about using the Infrared Burner Once lit, leave the Infrared Burner on High and sear both sides of meat using the guidelines below. Whether you are a seasoned chef or a newcomer to gas •...
  • Page 36 Guide to Roasting and Baking Using the Main Burners Food preparation An Important Note About Heat Settings The suggested heat settings shown are approximate. Trim meat of excess fat. Truss meat and poultry with cooking string to retain shape if desired. Bacon strips can There are many factors such as outside temperature, wind conditions and grill location that affect your grill be used to cover the outside surface of lean meat and...
  • Page 37 Guide to Rotisserie Cooking Guide to Smoking Preparing to Smoke Slow Cooking with a Rotisserie Smoking gives food a distinctive, delicious flavor. You will Rotisserie cooking produces foods that are moist, find a variety of wood chips available for use in smoking flavorful and attractive.
  • Page 38 OPTIONAL GRILL ACCESSORIES Cast-Iron Cooking Pan with Lid This cast iron pan conducts heat wonderfully and cooks evenly, making this the ideal accessory for baking and roast- ing on your new grill. Prepare pizza, potatoes, stew, corn bread and desserts. Can be used in place of 1 grid and Flame Tamer or use on...
  • Page 39 Question: Question: Can I convert my grill from one fuel type to another in Sometimes I hear a humming sound coming from my other words from LPG to NG or vice versa? regulator. What causes this? And - My grill has a low flame and sometimes will not light.
  • Page 40 Question: After every use (after your grill has cooled down), wipe The Regulator and Hose supplied with my gas grill stainless surfaces with a soft, soapy cloth or sponge does not fit the older LP Gas tank I’ve used for then rinse with water.
  • Page 41 Grand Hall Limited Warranty Grand Hall Enterprise Co., Ltd. will warrant to the ORIGINAL PURCHASER of this gas grill that it will be free of defects in material and workmanship for set periods below from the date of purchase when used under normal outdoor use and correct assembly: Full Warranty on Grill - 1 year (except for paint loss, rusting and ignitor battery) Tube Burners - 3 years no rust through...
