Operating Manual
3.2 Ink Roll
Installation
8
Use the following instructions to install the INK ROLL.
(Refer to Figure 3.2.)
Figure 3.2 -- Ink Roll Installation
The FD 150 comes with one black INK ROLL.
Formax offers a tri-color INK ROLL. To order INK
ROLLS, call your Formax dealer.
Use care when handling the ink roll. The ink is
indelible and will not wash out of clothing.
1. Turn the EXECUTIVE KEY to the UNLOCKED
position and open the COVER.
2. Pull out the COTTER PIN.
3. Pull out the AXLE.
4. Put on the gloves shipped with the INK ROLL.
NOTE
NOTE
1/97
