How to control a PTZ camera?

The PTZ control panel can be accessed from the Live Viewing screen by left-clicking
once on the channel screen of the corresponding PTZ camera, and then clicking the
icon on the channel toolbar.
Note for Remote Access and Mobile Device users:
The PTZ functions of the DVR and compatible cameras can be controlled remotely
via the SwannView Link software and mobile app.
Please note: due to the latency caused by streaming so much data over an Internet
connection, there will be a momentary pause between selecting a direction for the
camera to move and it actually moving.
Typically the delay will be less than one second; however periods of up to thirty
seconds are not uncommon on mobile, wireless or slow Internet connections.

PTZ Control Panel

Option
Arrows Move the camera in the direction selected.
Speed How fast the camera will move. The higher the number, the faster
the movement. Note that the actual speed of movement will
depend upon the capabilities of your particular PTZ device.
Zoom Increase or decrease the magnification of a varifocal lens. Not all
PTZ devices have varifocal lenses.
30
Description
Option
Focus Change the focal point of a PTZ device with a varifocal lens. Try
adjusting this control if your images seem "soft" or blurry. Not all
cameras support this function.
Iris Adjust how much light gets into the camera by opening and closing
the iris of the camera. Not all PTZ cameras have an adjustable iris.
Also called an "aperture". Not all cameras support this function.
Preset A Preset is a position that the camera is in which is saved to
memory to be retrieved later.
Patrol Initiate patrol mode (also sometimes called "cruise" mode). You'll
need to define a series of Preset points for the camera to patrol
between.
Exit Close the PTZ control panel.
PTZ Context Menu
After displaying the PTZ control panel, you can also right-click to access the PTZ
context menu.
Option
Camera No Switch quickly between cameras.
Call Preset Return the camera to a preset point.
Call Patrol Initiate a patrol of your choice.
Preset Define a preset point.
Patrol Initiate or stop a patrol.
PTZ Menu Toggle the appearance of the PTZ control panel on the screen.
While the PTZ control panel is hidden, the DVR will still be in PTZ
mode, and the context menu can still be opened via right-clicking
the interface.
PTZ Settings Display the "PTZ Options" screen in the Device menu, where you
can configure settings for the PTZ camera.
