Silver 100T
User Manual v 3.0.18
Please read carefully before using this product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Silver 100T and is the answer not in the manual?

Questions and answers

Related Manuals for Novus Silver 100T

Summary of Contents for Novus Silver 100T

  • Page 1 Silver 100T User Manual v 3.0.18 Please read carefully before using this product.

  • Page 2: Table Of Contents

    Contents Package Contents Page 4 Quick Start Guide - Installing the Camera Page 5 - Installing the Infrared Module Page 6 - Setting Up GPS Connection Page 7 - Installing the View-I PC Player Page 8 - PC Player Password Page 9 - Set Time and Date on the PC Player Page 10...
  • Page 3 Contents 15. PC Player and Camera Settings Page 26 16. Search List Screen Page 29 17. PC Player Search Engine Page 30 18. Google Maps Page 31 18. Speed and G-Sensor Reports Page 32 20. Screen Capture Page 33 21. ECO Driver Report Page 34 22.

  • Page 4: Package Contents

    1. Package Contents Please confirm below package list in the box * User Manual Silver 100T Camera Power Cable Wire Clip x 4 Cradle & Double Side Tape SD Card Optional Second Camera Key x 1 (Contains PC Player, User Manual, 64Gb formatting App ) * Product specification and package may change for product enhancement without any notification in advance.

  • Page 5: Quick Start Guide

    MUST be performed with the 4GB SD card supplied with your Novus product. If installing with a larger card, SD card must be formatted before use (see page 12) Ensure the camera has completely turned off during all movements of the SD Card.

  • Page 6: Installing The Infrared Module

    2.13 Plug the 2.5mm jack into the second camera and run the cabling along the roofline to the windscreen 2.14 Plug the 3.5mm Jack into the Camera input port on the upper side of the Silver 100T 2.15 Organise the cables using the cable clips provided.

  • Page 7: Setting Up Gps Connection

    Setting Up GPS Quick Start Guide Step 2 – Setting Up GPS Connection Important: For the initial GPS lock on, the camera must be powered for approx 20 minutes. The vehicle must be in an open clear area. Not inside a garage or an area where GPS connection will be affected.

  • Page 8: Installing The View-I Pc Player

    - Installing the PC Player Quick Start Guide Step 3 – Installing the Novus PC Player 2.20 Safely remove the 4GB SD card from the camera and insert the card into the SD card slot in a PC or laptop.

  • Page 9: Pc Player Password

    Installing the PC Player Quick Start Guide Continued... 2.25 Left click Next on the Wizard Setup. 2.26 Left click Next again. 2.27 Left click on box next to the Create a Desktop Icon if not already ticked, then left click Next. 2.28 Left click Install then Finish.

  • Page 10: Set Time And Date On The Pc Player

    Set Time and Date Quick Start Guide Step 4 – Set Time and Date on the PC Player 2.30 Left click on the Settings button, bottom right hand corner of player. 2.31 The Open box will appear. Double click on the SD card drive. 2.32 Double click on System folder.
  • Page 11 Set Time and Date Quick Start Guide Continued.. 2.36 To save the changes, left click Apply and repeat step.2.31 - 2.33 then click Save 2.37 Left click the red cross in top right hand corner of player to close the Player. 2.38 Safely remove the SD card from the SD card slot in the PC and insert the card into the camera.

  • Page 12: Formatting Sd Cards

    3. How To Format SD Cards Important: Ensure the PC player has been installed from the 4GB SD card to Desktop. Formatting SD cards will delete all data on the card. Data must be backed up onto another device if the data is to be used for future reference. Recommended - Format SD card at least once every 4 weeks for optimal performance.

  • Page 13: View Recordings From Sd Cards

    4. View Recordings Saved on SD Cards How to Watch Footage Saved on the SD Card Important: The Novus PC Player software must be installed to Desktop to watch any recorded data. If the PC Player has not been installed, see page 8, Installing the PC Player.
  • Page 14 4. View Recordings Saved on SD Cards Continued... 4.4 A list of recordings will appear. To play the recordings the list must be highlighted. Always tick the box in the top left hand side of the list, next to “No”, to highlight the recordings.

  • Page 15: View Recordings Received By Email

    5.3 Locate the folder saved on Desktop. 5.4 Double click on the folder to open it and show the list of files. 5.5 Double click on the required clip and it will auto play in the Novus software window To apply for a copy of the PC Player, please log onto www.novuauto.com...

  • Page 16: Send A Copy Of An Incident By Email

    Clips will not be able to be replayed through other players, such as, Windows Media Player, Real Player.. Contact Novus to request your incident to be transferred to allow instant reply via Windows Media Player. This will help pass all evidence as shown on the player to the authority and allow immediate access to the evidence.
  • Page 17 6. Send Recordings by Email Continued... 6.6 Locate the required clips in the folders by the File Names. - Clips starting with EVT or EMG are saved in the Event folder. - Clips starting with INI are saved in the Normal folder. - First set of numbers represent the date the clips was recorded (American format) –...

  • Page 18: Camera Features

    Supports audio recording with on/off settings via PC Player Recording Internal GPS records time/speed/route information via Google Map GPS information can only be checked through the Novus PC Player. Sensor [NOTE] Camera needs to be connected to satellites for GPS data to be recorded.

  • Page 19: Camera Functions

    8. Camera Functions Name Description 1 Power Feed DC 12/24v 2 SD Lock Key lock 3 SD Cart Slot SD card slot 4 GPS Internal GPS Antenna 5 Front Camera 2 mega pixel CMOS lens 6 Rear Camera Input for optional second camera Manual User activated Event Recording Recording...

  • Page 20: Camera Button & Lights

    9. Camera Button & Lights Name Recording Mode Manually start Event recording if button is pressed, camera Manual Recording will make “tic-tic” sound and blue and orange LED will flash Button quickly. These clips will be saved as an Emergency file. Hold for 3 Seconds to power unit off.

  • Page 21: Software Features

    10. Software Features Features Description Software to view recordings. Novus PC View GPS data, generate reports can be done through the Player dedicated player. View driver’s route via Google Map through the PC Player. Google [NOTE] GPS needs to be connected to the satellites in order to Map Sync sync data with Google Maps.

  • Page 22: Pc Requirements

    11. PC Requirements System Requirement Novus software automatically encrypts recorded data. To view recorded data, the data must be replayed through the dedicated Novus PC player. Item Description Window XP, Windows Vista, Windows 7 & 8, Operating System (English version) Pentium 4 / 1.8Ghz Processor or above...

  • Page 23: Password Settings

    Password Settings In order to protect the recorded data being accessed by an unauthorised user, the NOVUS PC Player has a password protection function. To enter and change passwords, please follow the below. 12.1 When entering the NOVUS HD SCE 1.8 Player for the first time, leave the entry blank and click OK.

  • Page 24: Pc Player Playback Screen

    8. View-i PC Player Manual 13. Playback Screen PC Player Playback Screen Name Description Front Video Screen Front video play screen of designated video file Rear Video Screen Interior/Second Camera screen of selected video file File Information Displays file name, time and date, longitude and latitude. G-Sensor Graph G-sensor data of video screen for user analysis Displays current position of the video on Goggle Maps...

  • Page 25: Pc Player - Buttons Functions

    14. PC Player Button Functions Buttons Functions on PC Player Software Button Description Button Description Previous File Open 1 file Rewind Print Screen Play Settings Pause ECO-Drive Report Stop Event Report Fast-forward Volume Control : Video volume control with Next File mute function...

  • Page 26: Pc Player And Camera Settings

    Ensure the SD card is inserted into the camera after changes have been made and power the camera for at least 3 minutes. 15.1 Open the Novus PC Player. 15.2 Left click on the Settings button, bottom right hand corner of player.
  • Page 27 15. PC Player Settings - Express Express Settings Adjust camera and PC Player settings. Important: Any adjustments made must be saved on the SD card and camera. Click “Apply” button save Settings to the card. Re-insert SD Card into the camera to upload the changes Name Description...
  • Page 28 15. PC Player Settings - Expert Expert Settings Only use Expert setting if you are an advanced user. Click “Apply” button and re-insert SD Card to the device to save the changes Name Description Best: 2M@VGA 30fps / Good: 2M@VGA 25fps Video Quality Normal: 2M@VGA 15fps / Compact: 2M@QVGA10fps Brightness...

  • Page 29: Search List Screen

    16. PC Player – Search List Screen Search and Play List Screen The Search List screen is the main navigation screen. Upload data from SD cards, select files to view Name Description recordings. Open recorded clips on Folder Open SD card Play button for continual Chain Play...

  • Page 30: Pc Player Search Engine

    17. PC Player – Search Engine Create and Search Database The in-built search engine can catagorise the recorded data to allow users search specific criteria such as Speed, G-Senor etc, saving time filtering through hours of data. 17.1 Import data from the SD card to the Search List screen.

  • Page 31: Google Maps

    18. PC Player – Google Map Google Map Interface The PC Player supports Google Map interface. User must have internet connection to view Google map data. Number Description Adjust Map size: + : Zoom in - : Zoom out View Mode: Map View Mode: Satellite View Mode: Street Current Position...

  • Page 32: Speed And G-Sensor Reports

    19. PC Player – Speed / G-Sensor Speed and G-Sensor Reports Novus PC Player can generate detailed reports of recorded speed and G-Force impact data. These reports can be used for analysing the driver’s driving patterns. 19.1 Click on “Big Chart” button in the G sensor screen to display below screens.

  • Page 33: Screen Capture

    20. PC Player – Screen Capture Screen Capture Print/Save This function allows users to take screenshots of a incident or e.g. a number plate. The data can be easily be emailed as a detailed report along with location and G-Force data 20.1 Click on Screen Print to capture the picture.

  • Page 34: Eco Driver Report

    21. PC Player – ECO Driver Report ECO-Driver Report This report can provide information on the drivers driving behavior and bad habits. It can advise on how good or bad a driver is by scoring the recorded data. 21.1 Import data from the SD card to the Search List screen.

  • Page 35: Event Report

    22. PC Player – Event Report Create an Event Report This function allow users to take 4 screenshots of the build up to the incident. The data can be easily be emailed as a detailed report along with location and G-Force data. 22.1 Click on “Event Report”...

  • Page 36: Gps Data Report

    23. PC Player – GPS Data Report GPS and G-Sensor Data Export This function will export the recorded GPS and G-Sensor shock data into Excel format. 23.1 Import data from the SD card to the Search List screen. (See pages 13 & 14, 4.3 onward) 23.2 Click on “Create DB”.

  • Page 37: Road Track

    24. PC Player – Road Track Road Track™ Reports Road Track™ shows the recorded tracking data of the drivers journey. 24.1 Import data from the SD card to the Search List screen. (See page 17, 7.3 and 7.4) 24.2 Left click on Create Database. 24.3 Left click on Road Track.

  • Page 38: Buzzer/Led Alert Warning

    25. Buzzer/LED Alert Warnings Warning LED Alert Buzzer Alert Red LED : On Booting Status “beep, beep” sound Blue LED : Flash for apprx 10secs Orange LED : Flash for apprx 10secs Red LED : On If SD card is not SD Card Insert inserted: Constant Blue LED : Constant Flashing...

  • Page 39: Sd Card Recording Times

    26. SD Card Recording Times H = Hour / M = Minutes Best High Normal Compact QUALITY (Default) PIXELS 1280x720 1280x720 1280x720 1280x720 Frame Per Sec, Ext/Rear. 20fps/10fps 16.6fps/8.3fps 10fps/5fps 4.65fps/2.35fps 1H34M 1H49M 2H08M 5H54M 3H10M 3H39M 4H16M 11H49M Memory 16GB 6H21M 7H18M...

  • Page 40: Liability

    27. Liability Please read the follow liability information: 27.1 This product is offered for use on the provision that all guidelines, advice and recommendations are followed, and the device is used for its intended Purpose only. 27.2 You may not modify, reproduce, create derivative works from, transfer or sell , any information, software, products or services without the express permission of the manufacturer.

  • Page 41: Camera Precautions

    28. Camera Precautions Please read the camera precaution information below: 28.1 Do not open/fix/alter this device. Any customer alterations will void the warranty. 28.2 Do not use any accessories other than those provided with the product. The use of any additional accessories will void the product warranty. 28.3 Do not connect the device directly to car’s battery.
  • Page 42 28. Camera Precautions Continued... 28.8 Check the product regularly to ensure that the camera lens angle is properly adjusted. Always check when replacing the camera into the bracket. After violent force is applied to the vehicle or product, the camera angle may be altered resulting in poor picture quality.

  • Page 43: Sd Card Precautions

    29. SD Card Precautions IMPORTANT: Format the SD card at least once every 2-4 weeks for optimal performance. ( See page 12 for How to Format a SD Card) 29.1 Check SD card’s data regularly to ensure the camera is recording correctly. 29.2 Backup the data regularly if any data needs to be saved for future reference or as evidence.

  • Page 44: Trouble Shooting

    30. Trouble Shooting Problem Solution - Check the power cable connection to the camera. - Check the power cable fuse. - Check the power cable connection to vehicle power source. Camera has - If all power connections are correct then remove SD Card, re-insert and No Power turn the ignition on.
  • Page 45 30. Trouble Shooting Problem Solution - Check the correct and latest PC Player version is being used. - Open a single clip by File Open button instead of Folder Open button. - If videos are too dark, please raise the brightness in the setting configuration Recorded - Back up any data required, format the SD card and continue to record.
  • Page 46 30. Trouble Shooting Problem Solution - Check event recording settings in the Novus PC Player setting menu. Sensitivity might be to low. Event recordings will not be triggered by small or minor impact. Press Manual button to trigger a Event recording.

  • Page 47: Specification

    Forward: MPEG4 - 2M Pixel 30fps at 1280x720 (HD) resolution Audio Internal Mic (ON/OFF) Storage SD Card (Max 64GB, Class 10 only) PC Viewer Novus Windows PC Player (Win XP,Vista,7,8) Firmware Update via SD Card Voltage 12V~24V Consumption 230mA @ 12v, 300mA with second camera Backup Internal Super Cap –...

  • Page 48: Accreditations

    32. Accreditations List Description KCC / FCC / CE / RoHS SSL Ruby/Silver, Ruby 100 & Silver 100T Transport For London (TFL), Fleet Operator Recognition Scheme (FORS), Certifications Freight Transport Association (FTA), VOSA compliant. See Novus website for more accreditations and approvals.

  • Page 49: Warranty

    Dealer Date Guarantee Attention: Novus will not be liable in any way in respect of: 1. The failure by the user of the device to drive safely and in accordance with all road traffic laws and regulations. 2. The failure by the user to maintain and level of maintenance of the camera or SD card.
  • Page 50 INJURY CAUSED BY OUR NEGLIGENCE OR FRAUDULENT MISREPRESENTATION. NOVUS WILL NOT BE HELD LIABLE FOR ANY INDIRECT OR CONSEQUENTIAL LOSS OR DAMAGE (WHETHER FOR LOSS OR BUSINESS OR OTHERWISE) COSTS, EXPENSES OR OTHER CLAIMS, WHICH ARISE OUT OF OR IN CONNECTION WITH THE USE OF THE DEVICE.
  • Page 51 www.novusauto.com...

This manual is also suitable for:

Silver 150t
