Clarion DRX9255EXL Service Manual

■

SPECIFICATIONS

FM tuner section
Frequency range: 87.9MHz to 107.9MHz
Usable sensitivity: 9dBf
50dB quieting sensitivity:
15dBf
Alternate channel selectivity:
75dB
Stereo separation: 35dB(1kHz)
Frequency response: 30Hz to 15kHz(
AM tuner section
Frequency range: 530kHz to 1710kHz
Usable sensitivity: 20
CD player section
System: Compact disc audio system
Usable discs: Compact disc
Frequency response: 5Hz to 20kHz(
Signal to noise ratio: 110dB(1kHz) IHF-A
Dynamic range: 100dB(1kHz)
Audio section
Bass control action: ±
Treble control action: ±
Line output: 4V(CD)
General
Power supply voltage: DC14.4V(10.8V to 15.6V)
Negative ground
Current consumption: Less than 3A
Dimensions(mm): Source unit
178(W)
DC/DC converter
156(W)
Clarion Co., Ltd.
Export Division - 22-3, Shibuya 2-chome, Shibuyaku, Tokyo, 150-8335 Japan
Service Dept.- 50 kamitoda,Toda-shi,Saitama,335-8511 Japan Tel: 048-443-1111 FAX:048-433-6996
± 3dB)
μ V
± 1dB)
12dB(50Hz)
12dB(10kHz)
× 50(H) × 153(D)
× 28(H) × 71(D)
Tel: 03-3400-1121
Service Manual
AM/FM Stereo CD Player
With CD Changer Control
Model
(PE-2221K)
Weight:
※ Specifications and design are subject to change without
notice for further improvement.
COMPONENTS
■
PE-2221K-A
Main unit
DC/DC converter
Mounting bracket(strap)
Mounting bracket(universal)
Extension lead
Parts bag
Hook plate
Clip
Tap screw(5 ×
Screw(M5 8)
×
Plate nut
Parts bag
Escutcheon
■ NOTE
We cannot supply PWB with component parts in principle.
When a circuit on PWB has failure, please repair it by compo-
nent parts base. Parts which are not mentioned in service
manual are not supplied.
- 1 -
Published by Service Dept.
298-5890-00 Jan.2001 B
Printed in Japan
Source unit
1.8kg
DC/DC converter
0.3kg
−−−−−
−−−−−
300-4976-00
300-9035-01
854-4121-00
−−−−−
330-8216-03
335-3744-00
16) 700-5016-80
716-0496-01
725-0216-00
−−−−−
370-5115-00
