Summary of Contents for Wheeltech TRAVELEASE
- Page 1 TRAVELEASE mini scooter mini scooter User Manual Page 1...
- Page 2 CONTENTS Parts Description Introduction QC Documentation Personal Safety Control Functions Description Transportation, Assembly and Disassembly Battery Charging Care and Maintenance Troubleshooting Service Record Specification Warranty Circuit breaker and main fuse Controller Seat Handlebar/ front tiller Seat stem Shopping basket Anti-tip Wheels Towing handle...
- Page 3 INSPECTED BY: PERSONAL SAFETY The Wheeltech Travelease must only be used by a single occupant of user mass up to 90kg (14 stone) for steel Travelease and 115kg (18 stone) for Aluminium Travelease. The Travelease is only suitable for users who experience difficulty or discomfort walking for prolonged periods, but have the use of both legs and the physical, visual and cognitive ability to operate the scooter safely.
- Page 4 Report all inceidents of unintended movement or brake release to the powered wheelchair / scooter manufacturer, and note whether there is a source of EMI nearby. ASSEMBLING THE TRAVELEASE (steel) Unscrew the knurled knob from the seat holder tube and remove the seat. Insert the seat into the holding tube and screw in the knurled knob to secure the seat in position.
- Page 5 When in the storage configuration, the Travelease can be freewheeled using the anti tip wheels at the rear. To do this, hold up the front end of the Travelease by the carry handle and drag, as shown in photograph 2 below.
- Page 6 Please refer to an authorised dealer for any problems with the main fuse. BATTERY CHARGING The Travelease comes complete with two 12V 8ah sealed lead acid batteries (installed) and a battery charger and mains lead. To charge the batteries: 1. Switch the scooter off with the ignition key 2.
- Page 7 The handbrake should be checked on a regular basis for braking force. The handbrake should be able to hold the user and Travelease on gradients up to 7 degrees (1 in 8) both in park mode and general braking mode whilst remaining easy to operate. The brake cable should be checked for wear.
- Page 8 SERVICE RECORD YEAR YEAR Service Dates Service Dates Controller Upholstery On/off switch Seat Joystick Back Braking Armrests Recharge point Electrics Batteries Connections condition Levels Lights Connections Test run Discharge test Forwards Wheel and Tyres Reverse Wear Emergency stop Pressure Left turn Bearings Right turn Wheel nut...
- Page 9 WARRANTY TRAVELEASE WARRANTY There is a comprehensive twelve month warranty from the date on which your new Travelease scooter is delivered. The warranty covers the scooter for repairs or replacement during this period. For more detail, please see the Warranty Conditions below.
