Infinova V6812IR-H0065SA User Manual

Hd 1mp and 1.3mp ir ip minidome camera/ v6812ir-h00 & v6812ir-h01 series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
V6812IR-H0 Series
HD 1MP and 1.3MP IR IP Minidome Camera

User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V6812IR-H0065SA and is the answer not in the manual?

Questions and answers

Related Manuals for Infinova V6812IR-H0065SA

Summary of Contents for Infinova V6812IR-H0065SA

  • Page 1: User Manual

    V6812IR-H0 Series HD 1MP and 1.3MP IR IP Minidome Camera User Manual...
  • Page 2 Infinova. Infinova reserves the right to change this manual and the specifications without prior notice. The most recent product specifications and user documentation for all Infinova products are available on our web site www.infinova.com.
  • Page 3 Read this manual carefully before installation. This manual should be saved for future use. Important Safety Instructions and Warnings: Electronic devices must be kept away from water, fire or high magnetic  radiation. Clean with a dry cloth.  Provide adequate ventilation. ...

  • Page 4: Table Of Contents

    CONTENTS Chapter I System Introduction ................1 1.1 Product Description ................... 1 1.2 Product Features ..................1 1.3 System Requirement.................. 2 1.4 Product Model ................... 3 1.5 Specifications..................... 4 1.6 Precautions....................6 Chapter II Installation ..................7 Chapter III IE Browser Settings ..............10 3.1 Equipment Connection ................

  • Page 5: Chapter I System Introduction

    CHAPTER I SYSTEM INTRODUCTION 1.1 Product Description V6812IR-H00 & V6812IR-H01 series HD 1MP and 1.3 MP IR IP minidome camera features 1/3" progressive scan CMOS sensor and built-in 3.0 megapixel fixed lens (2.8mm/4mm/6mm/8mm/12mm optional). With H.264/M-JPEG compression format utilized, this camera can output HD full-frame videos with the resolution of 960P or 720P.

  • Page 6: System Requirement

    Support simultaneous access and parameter setting via Web Server from  multiple clients Compatible or able to integrate with Infinova V2216 and other digital video  surveillance software Standard SDK is provided for easy integration with other systems ...

  • Page 7: Product Model

    1.4 Product Model This manual is for the following models: V6812IR-H0065SA HD Megapixel IR IP minidome camera, Day/night, 1/3 inch CMOS sensor, H.264/M-JPEG, indoor, 1.0Mpx, 12VDC, Surface mount, 4mm fixed lens V6812IR-H0065SB HD Megapixel IR IP minidome camera, Day/night, 1/3 inch CMOS sensor, H.264/M-JPEG, indoor, 1.0Mpx,...

  • Page 8: Specifications

    1.5 Specifications V6812IR-H01 Series V6812IR-H00 Series Model 1/3" progressive scan CMOS Image Sensor 72.4dB Dynamic Range 50dB S/N Ratio F1.6, f=4mm, 6mm, 8mm, 12mm (For V6812IR-H00&-H01 series) Lens F1.8, f=2.8mm (For V6812IR-H00 series) Night Vision 20m (Max) Distance X (Panning): 0°~360°; Y (Tilting): -75°~75°; Camera Angle Z (Rotating): 0°~360°...
  • Page 9 1280×960@H.264/ 1280×720@H.264/ Maximum M-JPEG M-JPEG Resolution Major stream: Major stream: 1280×720; 1280×960, 1280×720; Minor stream: Optional Resolution Minor stream: 640×480, 320×240 640×480, 320×240 Maximum Frame 30fps@1280×960 30fps@1280×720 Rate Variable bit rate; Constant bit rate: Data Rate Major stream: 256Kbps~10000Kbps; Minor stream: 256Kbps~2000Kbps Up to 4 areas Motion Detection Up to 4 masks...

  • Page 10: Precautions

    Operating 14°F~122°F (-10°C~+50°C) Temperature Storage -4° F ~ 140° F (-20° C ~ 60° C) Temperature Operating 0%-90% RH (non-condensing) Humidity 3.34"×Φ4.71" (84.7mm×Φ119.5mm) Dimensions (H×Ø) Box Dimensions 6.65 "×6.65 "×5.79" (169mm×169mm×147mm) (L×W×H) 1.43lbs. (0.65kg) Unit Weight 1.83lbs. (0.83kg) Shipping Weight 1.6 Precautions 1.

  • Page 11: Chapter Ii Installation

    CHAPTER II INSTALLATION Step 1: Prepare mounting holes Attach the enclosed mounting schematic label on the desired position of wall or ceiling; drill holes according to the label’s instruction (4 mounting holes and 1 cable hole). Figure 2-1 Step 2: Install camera base Unscrew the base and take it off.
  • Page 12 Step 3: Pre-fasten minidome camera Install tightening ring, chuck ring and dome module to the base. Keep tightening ring loose, so that the dome module can turn freely. Tightening ring Chuck ring Dome module Figure 2-3 Step 4: Adjust dome module Turn the dome module to make it point to surveillance area.
  • Page 13 Dimensions (Unit: inch, in the parentheses is mm) Ø4.71(119.5) Figure 2-5...

  • Page 14: Chapter Iii Ie Browser Settings

    CHAPTER III IE BROWSER SETTINGS When view the video, the user need to adjust the IE browser of the monitor or other video devices, and set proper system function based on the following instructions: Support IE browser version: Internet Explorer 6.0 or above; ...
  • Page 15 successful login. Click the link to run, or store the exe file, then run it. Figure 3-1 If the installation fails, check whether there is video viewed through other IE window or page. You should close the video or the IE window directly. If it successes, click refresh, you can view the live video.
  • Page 16 Figure 3-4 Note: If InfiPlayerAX control installation falls, the live video won’t display. Then, you should change the IE security level. 1. Select “Tool” in the menu bar, and then select “Internet Options” from the drop-down menu. 2. Select “Security” in the pop-up Internet options. 3.

  • Page 17: Chapter Iv Basic Function Operation

    CHAPTER IV BASIC FUNCTION OPERATION This chapter mainly introduces the settings and operation of V6812IR-H0 series. 4.1 Live View Start IE browser after the server is powered on for about 90 seconds, and then enter IP address, such as http://192.168.1.100 (default), in the address field. Note: The default subnet mask is 255.255.255.0 and the default gateway IP address is 192.168.1.254.
  • Page 18 After login is successful, the following interface will display: Figure 4-2 Live view H.264 V6812IR-H0 series IP camera supports H.264 and M-JPEG video compression formats. After successful login, it enters H.264 major stream live video interface. Stream Type: Users can also select H.264 minor stream or MJPEG from the dropdown list of stream type.
  • Page 19 Figure 4-3 Click the button to snapshoot and to enter the storage path. Default: C:\InfiPlayerAX\Picture. V6812IR-H0 series supports local recording. Click the recording button to start recording; when the button changes to , click it to stop recording. During local recording, “REC” appears on the video screen. Click the button to enter the recording storage path.

  • Page 20: System

    Click the option tab “Setting” to enter the system setting interface. Figure 4-4 Settings Interface With the help of navigation menu on the left, Super user can perform the following operations: Basic Information View, Time Settings and Advanced Settings, Network Settings, Camera Settings (including Basic Set, Exposure Set, Effect Set, White Balance, IR set, Reset), Video Settings, Alarm Settings, Account Settings (Add/Delete User, Change Password), Log, etc.
  • Page 21 4.2.2 Time Settings Figure 4-5 “Time” Settings Time Zone Settings Time Zone: Select the desired time zone in the scroll box, and then click “Save” to save it. There are 33 time zones for your selection. If Daylight Saving Time is applied in your region, please enable daylight saving time.
  • Page 22 NTP Sync mode, the system will automatically adjust time to the same as that of NTP Server. 4.2.3 Advanced Settings Figure 4-6 “Advanced” Settings Software Update Free software update is provided for V6812IR-H0 series camera, and this update service can reduce system maintenance budget. Confirm the requirement submitted by user, we will provide the latest software for download, and help user to update the V6812IR-H0 series camera.
  • Page 23 Figure 4-7 Select update file, and press “Open” button. The selected update file will be displayed in the box before “Browse”. After that, click “Submit” button to update software, the following information will appear: Figure 4-8 Click “Yes” button, run the program to finish the update. The response time is due to the program type.
  • Page 24 After update successfully, it needs to reboot the system. There is time prompt in the web page during reboot. After reboot, it will skip to new web page to run new program. Note: Available only for the super user. Factory Settings V6812IR-H0 series camera provides online reset function, which greatly facilitates reset adjustment.
  • Page 25 2. Default IP address is 192.168.1.100, and default subnet mask is 255.255.255.0. 3. Do not power off during reset, or else the reset will fail. Online Reboot Click “Reboot” button, the dialog box “This operation will take 90 seconds, are Click “OK”...

  • Page 26: Network Settings

    4.3 Network Settings Click “Network” in the navigation bar, and the following interface will display: Figure 4-10 Network Settings 10 option tabs are available: Network, FTP, SMTP, HTTPS, 802.1X, QOS, IGMP, SIP, DDNS and UPnP. 4.3.1 Network Settings IP mode: support both IPv4 and IPv6 modes. Network parameters are slightly different under different IP modes.
  • Page 27 Figure 4-11 Network Settings Under IPv4 mode, users can enable or disable DHCP. When it is disabled, users can set Unit IP address, Subnet mask, Gateway and DNS server IP address manually. Note: The system indicator quickly flickers for 5s after the network settings completed.
  • Page 28 4.3.2 FTP Settings Figure 4-12 FTP Settings V6812IR-H0 series camera has the function of alarm associated with FTP upload (alarm triggered image snapshot). Configure server IP, user name and password in the FTP settings and activate FTP handling way in alarm settings, then alarm triggered images FTP upload can be achieved.
  • Page 29 Authentication: Enable or disable authentication function. This function  should be set according to authentication requirements of mail server. User name: Sender’s name, it can be set according user’s needs.  Password: Set sender’s password.  Note: there is no limit for Sender’s name and password settings. After setting, click “Set”...
  • Page 30 V6812IR-H0 series camera supports 802.1X protocol. You have to enable 802.1X authentication when needed. Then, select an EAP method and enter the user name and password. 4.3.6 QOS Settings Figure 4-16 QOS Settings There are 4 network Qos modes to be selected: (1) Normal Service (2) Max Reliability (3) Max Throughput...
  • Page 31 users can select the stream type and set the state, multicast IP address and RTP port. 4.3.8 SIP Settings Figure 4-18 SIP Settings SIP Server: to configure SIP server for device; SIP Server IP: the IP address of SIP server; Port: the port number of SIP server;...
  • Page 32 After configuration completed, click Save and the device sends a registration request to the server. Position Information: the mounting information or instruction for device. Longitude: the longitude of mounting position, as precise to two places of decimal; Latitude: the latitude of mounting position, as precise to two places of decimal. 4.3.9 DDNS Settings Figure 4-19 DDNS Settings Dynamic Domain Name System (DDNS) synchronizes the host name and...
  • Page 33 4.3.10 UPnP Settings Create mapping between private network and the Internet via UPNP protocol. Select UpnP option and enter the configuration page. The added mapping list appears on the page. Figure 4-20 UPnP Settings In “Operation” column, means to delete; means to edit user information.

  • Page 34: Camera Settings

    4.4 Camera Settings Click “Camera” in the navigation bar to enter the interface shown as below: Figure 4-22 Basic Settings 4.4.1 Basic Settings You can set the following parameters: Flicker frequency: 50Hz or 60Hz. CVBS: it automatically changes with the flicker frequency. Notes: The analog video is closed when the MJPEG video stream is enabled.
  • Page 35 4.4.2 Exposure Settings Figure 4-23 Exposure Settings Exposure set, scene, AGC, shutter speed and manual AGC can also be set in this interface. Exposure Set: Manual, Scene and Shutter priority. In the Scene mode, indoor or outdoor can be selected and AGC can be set (8X, 16X, 32X, 48X, 64X optional);...
  • Page 36 Figure 4-24 Effect Set - General Drag the slider to adjust the brightness, sharpness, hue, contrast, saturation and 3D denoise.
  • Page 37 Figure 4-25 Effect Set - Mode The camera supports 6 video effect modes. Users can set name for each mode. IR mode, brightness, Each mode matches with a group of parameters, such as sharpness, hue, contrast, saturation and 3D denoise. Users can set and save effect parameters for each mode.
  • Page 38 4.4.4 White Balance Settings Figure 4-26 White Balance Settings The camera has rich white balance modes, including Auto, Manual, Incandescent light, Cool white fluorescent light, Sun light, Cloudy and Natrium light. If set to manual mode, you can set the red gain and blue gain.
  • Page 39 4.4.5 IR Settings Figure 4-27 IR mode: set IR illuminators working mode. Options: Day, Night, Auto (turn on or off as per ambient light). Switch time: in auto mode, the response time for day/night switch. Power set: the adjusting mode of illuminators’ power consumption. Options: Auto, Manual.

  • Page 40: Video Settings

    4.4.6 Reset In the interface, you can restore all the Camera Settings parameters to the factory default settings. 4.5 Video Settings Click the button “Video” in the navigation bar to display the following interface. Figure 4-28 Video Settings Video, OSD, Motion, Privacy, ROI, Shelter and Path can be set in this interface. Click the related option tab to enter the setting interface.
  • Page 41 For H.264 major stream, the resolution of V6812IR-H01 series comes to 1280×960 and 1280×720; while the resolution of V6812IR-H00 series comes to 1280×720. For H.264 minor stream, the resolution comes to 640×480, 320×240 and closed. For MJPEG stream, the resolution of V6812IR-H01 series comes to 1280×960, 1280×720, and closed;...
  • Page 42 reversely it occupies less bandwidth. When the setting goes with constant bit rate, then the image is transmitted under a constant bandwidth. Bit Rate: You have to set the upper limit of bit rate if “vbr” is selected; the stream size will be fixed if “cbr” is selected and the stream size is defined in the “Bit Rate”.
  • Page 43 4.5.2 OSD Figure 4-29 OSD settings include: Text OSD, Image OSD and Date OSD. Click the button “On” for text OSD; you can set the text content and the display position of text. Context: Enter the text content in the box of Context, which allows up to 42 characters (characters/lower/upper case letters and X-axis &Y-axis: The title axis location.
  • Page 44 The camera supports only one image uploaded on the video screen. Click the “Browse” button after the “Image”, select the image and click “Upload”. X-axis &Y-axis: The title axis location. Both X-axis and Y-axis can be any of whole numbers from 0 to 99. Drag the slider “Transparency”...
  • Page 45 4.5.3 Motion Detection Figure 4-30 Motion Detection Settings V6812IR-H0 series camera support motion detection. Users can easily set the motion detection areas (up to 4) with the mouse. Note: do turn on motion detection function in Live View interface before motion detection setting.
  • Page 46 To cancel a motion detection area, just cancel the box ticking. 4.5.4 Privacy Mask V6812IR-H0 series camera supports privacy mask function. If there is certain location within the surveillance area where operators are not allowed to see, and thus, Privacy Mask can be applied. System covers and shields the sensitive area via Privacy Mask setting, to avoid operators observing certain sensitive locations on monitor.
  • Page 47 4.5.5 ROI The camera supports four ROI encoding areas. Figure 4-32 ROI Settings ROI settings method: Tick off the serial number of the region for setting and click the button “Drag Box”. Then press the left button of the mouse on the video picture and drag it until a blue-line box appears.
  • Page 48 cancelled. Figure 4-33 Region 1 settings 4.5.6 Active video tampering The camera supports active video tampering.
  • Page 49 Figure 4-34 Active video tampering settings You can open or close this function on this page. When the function is open and active video tampering is detected, the alarm lamp on the top of the page turns red. 4.5.7 Storage Path You can set the photo saving path and recording saving path in the following interface.

  • Page 50: Alarm Settings

    Default video saving path: C:\InfiPlayerAX\ Video. Photo and video formats can also be set. The default photo format is .jpg and the format default video is .avi. To change the saving path, click the button “Browse” and select the path from the popup dialog box.

  • Page 51: Account Settings

    Alarm configuration Alarm Server IP: used to set the IP address of alarm server. If alarm occurs, it will inform the alarm server. Alarm out contact Users can set the relevant alarm response way for motion detection alarm. Options: Mail, FTP. After setting completed, click “Save” button to take effect. Note: when “FTP”...
  • Page 52 Figure 4-37 Account Settings 1. Add Users (1) Click “ ”, enter the interface of “Add a User”. Figure 4-38 Add a User (2) Enter the desired User Name and Password (Note: User name and password shall include letter, number and underline only. No special character is allowed. The string length of user name is legal between 1 and 30 characters and that of password is between 5 and 20 characters.) (3) Click “OK”...
  • Page 53 Figure 4-40 Click “OK” button, the selected user would be deleted and the account list would be automatically updated. 3. User Password Change Click button in the account list, the dialog box of Edit User Information will pop up: Figure 4-41 Input the old password, enter the desired new password for twice and then click “OK”...

  • Page 54: System Log

    4.8 System Log Click the “Log” option tab, the date, time and log information will appear on the right of the screen. Figure 4-43 It can display 30 logs on a page. The user can turn over the pages or skip to the desired page by clicking the below arrows.

  • Page 55: Appendix I Magnetic Ring Filter Instruction

    APPENDIX I MAGNETIC RING FILTER INSTRUCTION To reduce electromagnetic interference that power supply generates, it is necessary to install a magnetic ring filter with the power cable of Infinova front-end IP device. To install a magnetic ring filter with power supply: Step 1: Open the magnetic ring filter and lead the power cable through.

  • Page 56: Appendix Ii Questions & Solutions

    APPENDIX II QUESTIONS & SOLUTIONS The following table describes the symptoms causes and solutions for the problems. Symptoms Possible Causes Solutions Wrong power connection Reconnect power cable Repair or replace power Power supply failure supply PCB fuse damage Replace the fuse Immediate startup after Restart 10 seconds later The network...

  • Page 57: Appendix Iii Lightning & Surge Protection

    APPENDIX III LIGHTNING & SURGE PROTECTION The product adopts multi-level anti-lightning and anti-surge technology integrated with gas discharge tube, power resistor and TVS tube. The powerful lightning and surge protection barrier effectively avoids product damage caused by various pulse signals with power below 4kV, including instantaneous lightning, surge and static.
  • Page 58 Infinova 51 Stouts Lane, Monmouth Junction, NJ 08852, U.S.A. Tel: 1-888-685-2002 (USA only) 1-732-355-9100 Fax: 1-732-355-9101 sales@infinova.com V1.6 1410...
