Model CM-94444 Balun
To change settings,
remove four screws
from the cover.
Out
Antenna terminals
75 Ohm cable from amp to balun
In
75 Ohm cable from power inserter to TV
FM Switch
Indoor power supply
PREAMP
ANTENNA
POWER INSERTER
ATTIC
4-WAY SPLITTER
BEDROOM
BEDROOM
TV
TV
LIVING ROOM
DEN OR KITCHEN
FM STEREO
TV
TV
(Matching Outdoor Transformer)
U-bolt assembly
75 Ohm cable
from amp to indoor
power inserter
Cable tie
POWER INSERTER
PCT-MPI-1G
DC IN
Power inserter
75 Ohm cable
from power inserter to
indoor power supply
POWER SUPPLY
"O" dB WALL OUTLET
(TYPICAL)
TV OR FM
SPLITTER
