FIGURE 3-2. NL201 with CR800 (powered by datalogger)
3.2

Configuring the NL200/201

INSTALL THE DEVICE DRIVER BEFORE plugging the
NOTE
NL200/201 into your PC for the first time. You will need the
device driver properly installed before you can connect to the
NL200/201 via USB.
To install the device driver, download the latest version of
DevConfig from our website. Under Device Type, select Network
Peripheral | NL200 Series. Click the Install the device driver for
the device link and follow the prompts.
Ensure the NL200/201 is powered.
Connect the supplied USB cable between a USB port on your computer
and the USB port on the NL200/201.
Open DevConfig.
Under Device Type, select NL200.
Click the Browse button next to Communication Port.
Select the port labeled NL200.
Click OK.
Click Connect.
NL200/201 Network Link Interface
3
