Operating Instructions
for Hearing Instruments

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 06E123456L and is the answer not in the manual?

Questions and answers

Summary of Contents for Electone 06E123456L

  • Page 1 Operating Instructions for Hearing Instruments...
  • Page 2 Your hearing care provider has carefully prescribed an Electone hearing instrument designed to meet your individual hearing requirements. This booklet contains operating instructions for your specific hearing instrument as well as operating instructions for other hearing instrument models. Refer to the Table of Contents for instructions on using your particular instrument.
  • Page 3 Welcome to Better Hearing! Congratulations! You are about to enter a new world of better hearing. As you become familiar with your hearing instruments, you will be able to live a fuller life enjoying the sounds of your environment, your family and your friends.

  • Page 4: Table Of Contents

    Table of Contents Getting The Most From Your Hearing Instruments ..1 Binaural Amplification ............2 Custom In-the-Ear Hearing Instruments ......3 Getting Familiar With Your Custom In-the-Ear Instruments ..3 Inserting the Battery ............4 Inserting and Removing the Instruments ......5 Inserting and Removing the CIC Hearing Instrument ..
  • Page 5 Battery Compartment Safety Lock for BTE Hearing Instruments ................ 17 Open Fit Behind-the-Ear (BTE) Hearing Instruments ..17 Digitally Programmable Hearing Instruments ....18 Using the Optional Memory Selection Switch ....19 Reset Function ..............21 General Use ............... 21 Digital Hearing Instruments ........... 22 General Use ...............

  • Page 6: Getting The Most From Your Hearing Instruments

    Getting The Most From Your Hearing Instruments From the first fitting of your hearing instruments there are things that you can do to increase your listening satisfaction. Remember that there may be sounds, both wanted and unwanted, you may not have heard for a long time. Practice identifying and then ignoring sounds which at first may be disturbing to you.

  • Page 7: Binaural Amplification

    • Converse with only one person at a time initially until you feel comfortable using your instruments. Then move on to group listening situations. • When engaging in group conversations, request that one person speak at a time. • When in a church or theater, experiment with finding a place to sit where you can hear best.

  • Page 8: Custom In-The-Ear Hearing Instruments

    In-the-Ear In-the-Canal Microphone Battery Door Volume Control On-Off Switch Vent Laser-etched Laser-etched Serial Number Serial Number (on back side) (on back side) Manufacturer Size of instrument Electone FS 06E123456[L or R] Year of manufacture Serial number Left or Right instrument...

  • Page 9: Inserting The Battery

    Inserting the Battery To insert the battery, pull the tab on the battery door outward until the door swings all the way open (see figure 1). Remove the paper tab from the back of a proper size battery. Place the battery into the battery door (see figure 2). Observe the correct polarity.

  • Page 10: Inserting And Removing The Instruments

    Inserting and Removing the Instruments Hold the instrument between your thumb and index finger (see figure 3). Turn down the volume (if applicable) to reduce feedback (a whistling sound). (See note on page 6.) With the face of the instrument facing away from the ear, place the canal portion into your ear canal.

  • Page 11: Volume Controls

    press the CIC in place. If you experience irritation, inflammation, or pain when inserting your CIC hearing instrument, immediately contact your hearing care provider. To remove the CIC, simply grasp the removal cord with your thumb and index finger and gently pull the CIC out of your ear canal (see figure B).

  • Page 12: Manual Volume Controls

    type of volume controls your custom hearing instruments use, be sure to ask your hearing care provider. Manual Volume Controls The wheel shaped controls are rotated to select the most desirable listening position (louder or softer). Be sure volume controls are set at minimum before placing instruments in your ears.

  • Page 13: Screw Set Volume Controls

    Screw Set Volume Controls Your hearing care provider will adjust screw set volume controls. There is no on/off switch built into the screw set volume control. To turn off your instruments, you must leave the battery door open or remove the battery. An optional on/off toggle switch may be used if space is available.

  • Page 14: Using The Telephone

    Using the Telephone You may use the telephone in a normal manner. If you experience a whistling sound (feedback), tilt the phone receiver away from your ear and/ or reduce the volume until the whistling stops. By trying various positions of the telephone receiver, you will discover what works best for you.

  • Page 15: Behind-The-Ear Hearing Instruments

    For Digitally Programmable Instrument Users If your custom in-the-ear hearing instruments are digitally programmable, refer to page 18 for additional information. Behind-The-Ear Hearing Instruments Getting Familiar With Your Behind-the-Ear Instruments Your behind-the-ear instrument is designed for comfort, performance and durability. The instrument fits comfortably behind your ear and is attached to a custom-made earmold.

  • Page 16: Inserting The Battery

    Inserting the Battery To insert the battery, pull the tab on the battery door outward until the door swings all the way open. Remove the paper tab from the back of a proper size battery. Place the battery into the battery door.

  • Page 17: How To Put On The Instruments

    How To Put On the Instruments Hold the earmold between your thumb and index finger (see figure 9). Turn down the volume (if applicable) to reduce feedback. Place the earmold into your ear canal. Gently work the earmold into its proper position by slightly twisting until it is firmly seated in your ear.

  • Page 18: Bte Volume Controls

    BTE Volume Controls Behind-the-ear hearing instruments are equipped with either a wheel or rocker volume control. A wheel volume control has four levels of volume, with 1 (I) being the lowest sound level and 4 (IV) being the highest sound level (see figure 11).

  • Page 19: Using The Telephone

    Using the Telephone To use the telephone, place the receiver of the telephone above your ear and on the hearing instrument, then try tilting the phone receiver. You will discover what works best for you. Microphone-Telecoil Controls Your behind the ear instruments may be equipped with either a Microphone-Telecoil push button or a Microphone-Telecoil-Off switch.
  • Page 20 The Microphone-Telecoil-Off switch features three program positions (see figure 12A). During normal use the M-T-O switch is worn in the microphone (M) position. Moving the switch to the telecoil (T) position changes the Figure 12A program to telecoil. In the telecoil position for both the Microphone- Telecoil push button and Microphone-Telecoil- Off switch, your instruments are compatible with the electro-magnetic field of the telephone...

  • Page 21: Audio Input

    Audio Input Your hearing instruments may be equipped with an audio input device. This allows the output signal from a Radio Microphone (FM) System or another auxiliary product to be fed directly into the hearing instrument amplifier using a standard Europlug lead or MicroLink MLX receiver and an adaptive shoe that fits onto the base of the instrument (see figure 13).

  • Page 22: Battery Compartment Safety Lock For Bte Hearing Instruments

    Battery Compartment Safety Lock for BTE Hearing Instruments Your hearing instrument may be equipped with a battery door lock. This feature will prevent access to the battery when there are safety concerns. Your hearing instrument provider will inform you if this feature is present and provide instruction regarding its use.

  • Page 23: Digitally Programmable Hearing Instruments

    Digitally Programmable Hearing Instruments Your hearing care provider has programmed certain sound features in your instruments using a micro-processor-controlled programmer or computer. These sound features are designed to more accurately fit your individual hearing needs and give you distinct, high- quality amplification.

  • Page 24: Using The Optional Memory Selection Switch

    Using the Optional Memory Selection Switch If fitted with a memory selection switch, Electone programmable hearing instruments provide selectable multiple memories. These memories store preprogrammed settings for you to choose at any time depending on your listening requirements. A push button on the faceplate of the instrument controls this multi-memory feature (see page 20).
  • Page 25 Some non-programmable behind-the-ear instruments may feature a push button that toggles between two listening programs, and may include a “beep” to indicate a program change. Memory Button Memory Button Memory Switch In-the-Ear Behind-the-Ear Hearing Instruments Hearing Instruments...

  • Page 26: Reset Function

    Reset Function If the instrument is turned off or the battery is removed, the instrument automatically resets to Memory Number 1 the next time it is turned on. Your hearing care provider has instructed you regarding your memory selections and their appropriate listening environments.

  • Page 27: Digital Hearing Instruments

    Digital Hearing Instruments The term digital hearing instrument describes the manner in which sound is processed inside of the hearing instrument. This is similar to digital TV or CDs. This is different from digitally programmable which is the method that your hearing care provider uses to adjust your hearing instrument.

  • Page 28: Maintenance & Daily Care

    Maintenance & Daily Care You can ensure the best possible performance by following these simple instructions daily: In-the-Ear Hearing Instruments: • Remove wax build-up on the surface of the hearing instrument with a soft tissue. Use only the special cleaning tool provided by your hearing care professional to remove any wax accumulation from the receiver and microphone ports.
  • Page 29 in the ear canal. See your doctor periodically for removal of wax from the ear canal. • Inspect plastic tubing frequently. Ask your hearing care provider to replace clogged, cracked or hardened tubing. Open Fit Behind-the-Ear Hearing Instruments: It is important that you inspect and maintain your instrument daily.
  • Page 30 • Insert the Cleaning Wire into the Open Tube as shown in figure 14, all the way through until it appears at the Open Tip side. • Wipe away any wax or debris. • You may wash the Open Tube and Tip with warm water and gentle soap as needed.
  • Page 31 Open tips can be a choking hazard. • The cleaning tool should not be used for purposes other than cleaning the Open Tube. Only use the cleaning tool provided by your professional to clean your Open Tube and Tip. • Never remove the Open Tip from the Open Tube.

  • Page 32: Health Considerations

    • Always store your hearing instruments inside the case or carrying pouch provided. • When storing the hearing instruments for an extended period of time, always remove the battery to prevent damage from corrosion. Store the instruments in a dry area, preferably at room temperature.
  • Page 33 medical evaluation for religious or personal beliefs that preclude consultation with a physician. The exercise of such a waiver is not in your best health interest and its use is strongly discouraged. According to law, your hearing care provider must advise all prospective hearing instrument users to consult promptly with a licensed physician (preferably an otolaryngologist or ear specialist) before dispensing an instrument if he...

  • Page 34: Hearing Instrument Warranty

    A Hearing Professional: • Is trained, licensed, and experienced in hearing problems. • Is experienced in fitting, programming and adjusting hearing instruments. • Invites you for regular progress check-ups and instrument cleaning. • Provides batteries and accessories for hearing needs. •...
  • Page 35 our expense within the limits of the warranty. This warranty does not apply to any instrument which has been tampered with or altered in any way, or which has the serial number altered, effaced or removed, or to which any unauthorized repairs have been made.

  • Page 36: Replacement Opportunity

    If a replacement instrument is issued for a lost device, and the original instrument is recovered, the original instrument is not eligible for repair or service and is the property of Electone. To Return Your Hearing Instruments for Service If your hearing instrument requires service, you should return it to the hearing care provider from whom it was purchased.

  • Page 37: Warranty Information

    Warranty Information For your records, information about your hearing instruments may be recorded below. Warranty Register To: Warranty Expiration: Model Description: Serial Number: Battery Size: Hearing Care Provider: Hearing Care Provider Telephone No.:...

  • Page 38: Battery Tips

    Battery Tips For optimum performance, use only the correct size hearing aid batteries. See page 35 for battery size recommendations. To ensure longer battery life, each battery door should be left open at the end of each day. This prevents possible damage from the expansion or leakage of the battery, as well as current discharge if the instrument is not fully turned off.
  • Page 39 Caution! Batteries can be harmful if swallowed. Keep batteries out of reach of small children or pets. In the event a battery is accidentally swallowed, seek prompt medical attention at the nearest emergency center, or call collect: The National Battery Registry at (202) 625-3333 Always dispose of your batteries responsibly.

  • Page 40: Battery Sizes For Hearing Instruments

    Battery Sizes for Hearing Instruments Typical Battery Universal Package Instrument Size Size Tab Color Full Shell (FS) # 13 or 312 Orange/Brown Half Shell (HS) # 312 Brown # 312 or Canal (CA) Brown/Yellow Mini Canal (MC) # 10A Yellow Completely-in-the- # 10A Yellow...

  • Page 41: Troubleshooting Hearing Instruments

    Troubleshooting Hearing Instruments Problem Cause Solution Battery polarity Reinsert battery reversed Battery low or Replace battery dead Instrument has Rotate volume no sound or Instrument off control sound is weak Clogged microphone or Clear wax guard receiver Volume setting Turn up volume set too low Not placed in ear Reposition...
  • Page 42 Your Hearing Care Provider: P .O. Box 521727 Longwood, FL 32752-1727 © 2006 Electone, Inc. www.electoneonline.com 7130-0276-6 11/2006...
