Summary of Contents for YUNEEC GB200

  • Page 1: Table Of Contents

    9 ..... . . Mounting GoPro® on GB200™ 9 ..... . . Mounting GB200™ on Blade® 350QX2 13 .
  • Page 2: Warnings And Important Notes

    Adjusting or modifying the GB200™ in anyway is not recommended. Prior to using the GB200™, read and under- stand the quick start guide and instruction manual completely.
  • Page 3 YUNEEC™ and GB200™ are trademarks or registered trademarks of Yuneec International Co., Ltd.. This product and manual are copy- rights of YUNEEC™ with all rights reserved. No part of this product or manual shall be reproduced in any form without the prior written consent or authorization from YUNEEC™.
  • Page 4: Overview

    OVERVIEW Volt Universal Power Port Mode Control Port Universal for Angle or Velocity PWM Input Control Blade® 350QX Camera Pitch Control Port DIFFERENCE BETWEEN ANGLE OR VELOCITY MODE: Angle Mode allows the ‘pitch’ angle of the camera gimbal to be changed relative to the PWM control stick/knob/slider input.
  • Page 5 Software Yuneec™ Update Port Receiver Port Spektrum® Satellite Receiver Port Roll Axis CGO1™ Camera Gimbal Mount CGO1™ Mounting screw...
  • Page 6: How To Switch Camera Mounts

    Control Board GoPro® Camera Cover Mounting Sleeve Pitch Axis Gyro board GoPro® Camera Gimbal Mount HOW TO SWITCH CAMERA MOUNTS: CGO1™ to GoPro3/3+® (A) Step 1: Rotate the CGO1™ camera mount - as shown in illustration A - until the at spot inside the setscrew hole is facing up, and loosen the setscrew using the allen wrench.
  • Page 7: How To Switch Camera Mounts

    Step 4: Spin the gimbal motor shaft until the ‘ at spot’ is facing the setscrew hole. Insert and tighten the setscrew to secure the GoPro® mount to the GB200™. HOW TO SWITCH CAMERA MOUNTS: GoPro3/3+® to CGO1™ (B) Step 1: Rotate the GoPro® camera mount - as shown in illustration B - until the at spot inside the setscrew hole is facing up, and loosen the setscrew using the hex wrench.
  • Page 8 Illustration A: CGO1™ mount Illustration B: GoPro3/3+® mount...
  • Page 9: Mounting Cgo1™ On Gb200

    1. Install the GB200™ gimbal mounting plate on the 350QX using the (4) included screws. 2. Slide the GB200™ into place with the arm side toward the back of the model. 3. Connect the Blade® 350 QX2 control cable to the camera pitch control port on the GB200™...
  • Page 10 Illustration C: Mounting CGO1™ camera Illustration D: Mounting GoPro® camera...
  • Page 11 Illustration E: Installing the mounting plate to Blade® 350 QX2 Illustration F: Sliding GB200™ into the mounting plate...
  • Page 12 Illustration G: Connecting the Blade® 350 QX2 control cable Illustration H: Powering on the Blade® 350 QX2...
  • Page 13: Gb200™ Led Status

    TIP: The pitch axis neutral position can be changed by holding your desired pitch axis position within 5 seconds after the gimbal initializes. GB200™ LED STATUS ANGLE CONTROL MODE: LED COLOR RED 1. PWM Control Input (port 2): the red LED will ash once and become solid.
  • Page 14: Troubleshooting Guide

    ....Camera mount CGO1™: GB200™ ....Camera mount Go Pro Hero 3®: GB200™...
  • Page 15 Gimbal will not Gimbal control If using GB200™ with power on. harness may not be Blade® 350 QX2, be sure connected into the to connect the control correct port. harness to the camera pitch control port . If using with any other...
  • Page 16: Limited Warranty

    In the event of a defect, please contact YUNEEC customer Support (www.Yuneec.com) for assist- ance. YUNEEC’s sole obligation under this warranty will be, at its option, to repair or replace the product. This warranty does not apply to products damaged by misuse, accident, or normal wear and tear and water damage.
