Telstra MF91 Getting To Know Manual

Telstra MF91 Getting To Know Manual

Telstra wi-fi 4g
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GETTING TO
KNOW YOUR
PRE-PAID
TELSTRA WI-FI 4G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MF91 and is the answer not in the manual?

Questions and answers

Related Manuals for Telstra MF91

Summary of Contents for Telstra MF91

  • Page 1 GETTING TO KNOW YOUR PRE-PAID TELSTRA WI-FI 4G...
  • Page 2 LET’S GET THIS SHOW ON THE ROAD You must be excited about your brand new Pre-Paid Telstra Wi-Fi 4G. This guide will help you get connected as quickly and as easily as possible. It’ll guide you through installation and run through all the handy extra features that are included.
  • Page 3 WHAT’S INSIDE Safety first Let’s get started Getting connected Extra features Wi-Fi home page Problem solving Extra bits you should know...

  • Page 4: Safety First

    SAFETY FIRST Please read all the safety notices before using this device. This device is designed to be used at least 20 cm from your body. Do not use the device near fuel or chemicals or in any prescribed area such as service stations, refineries, hospitals and aircraft.
  • Page 5 reduces when there is good quality reception. Maximum power is only used at the edge of network coverage so under most circumstances the power output is very low. Under poor network conditions the device transmits at a higher power, may get hot and have a significantly shorter battery life. DECLARATION OF CONFORMITY –...

  • Page 6: Rohs Declaration

    ROHS DECLARATION (RESTRICTION OF HAZARDOUS SUBSTANCES) ZTE declares that the Wireless device is free from hazardous materials and complies with EU directive 2002/95/EC (commonly known as the RoHS Directive) and the amendments.

  • Page 7: Let's Get Started

    LET’S GET STARTED YOUR PACKAGE CONTAINS THE FOLLOWING: • Pre-Paid Telstra Wi-Fi 4G device and battery • Telstra Pre-Paid Next G SIM card ® • AC charger and USB charging cable • This Getting Started Guide • Telstra Pre-Paid Welcome Guide • Manufacturer’s warranty card • Wi-Fi security card...

  • Page 8: Accessories Available For Purchase

    ACCESSORIES AVAILABLE FOR PURCHASE: • E xternal Memory Card, available at most consumer electronic stores. Your Pre-Paid Telstra Wi-Fi 4G supports microSDHC cards up to 32GB. By using this device your Pre- Paid Telstra Wi-Fi 4G can also act as an external storage drive when connected via USB. • E xternal Antenna (connector type TS5). IMPORTANT SECURITY SETTINGS: SSID AND WI-FI SECURITY KEY (WPA2 KEY) • T he default security settings are unique for your device and...

  • Page 9: Quick Reference Section

    • Y ou can change the SSID (Wi-Fi network name) and Security Key (Wi-Fi password) to your own preferences. • Y ou need this information to log on to the Pre-Paid Telstra Wi-Fi 4G. QUICK REFERENCE SECTION Wi-Fi home page http://telstra.wifi.4g Wi-Fi home password page password Default SSID Supplied on W-Fi security card. (Wi-Fi network name) Default Security Key 10 characters which are case sensitive.
  • Page 10 YOUR PRE-PAID TELSTRA WI-FI 4G LCD Display Power Key Power Key Simply press and hold the power key for three seconds to turn on your Pre-Paid Telstra Wi-Fi 4G.
  • Page 11 The device indicator panel shows you the status of your new Pre-Paid Telstra Wi-Fi 4G. Charger/USB Port microSDHC Memory Card Slot Charger/USB Port Connect to a USB port to charge your Pre-Paid Telstra Wi-Fi 4G and access the microSDHC Memory Card (if fitted). You can also connect to the AC charger supplied to charge and power your Pre-Paid Telstra Wi-Fi 4G.
  • Page 12 YOUR PRE-PAID TELSTRA WI-FI 4G Secondary Antenna Port WPS Quick Access button Primary Antenna Port Antenna Port You can connect an external antenna to boost your signal if required (sold separately). Use the primary port for single port antennas and use the secondary when additional ports are needed.
  • Page 13 Signal strength Number of devices connected Roaming Manual or Automatic connection 5 Battery level indicator...

  • Page 14: Getting Connected

    GETTING CONNECTED 1. INSERT SIM CARD • Y our SIM card should already be inside the device. Check to make sure. To remove back cover use thumb catch on the bottom of the device and gently lift off. • T o Insert the SIM card, slide in as shown with the gold chip facing down and the slanted edge on the right. Ensure it is pushed in entirely, so only part of the SIM is visible.

  • Page 15: Insert The Battery

    2. INSERT THE BATTERY 3. SWITCH ON YOUR PRE-PAID TELSTRA WI-FI 4G • P ress and hold the power key for 3 seconds to switch the device on. 4. SWITCH ON YOUR COMPUTER OR WI-FI ENABLED DEVICE • C heck your computer or other device has Wi-Fi enabled and search for wireless networks. Refer to your Wi-Fi enabled device manual for further details on searching for wireless networks.
  • Page 16 For more information on the Wi-Fi home page see pages 19-20. 5. ACTIVATE YOUR SIM CARD There are 2 ways to activate your service: • A ctivate online via telstra.com.au/activate • C all 125 8887 and follow the prompts (from a Non Telstra phone call 13 2200 and say “Pre-Paid”)

  • Page 17: International Roaming

    Refer to the Telstra Pre-Paid Welcome Guide for further details . Your Pre-Paid Telstra Wi-Fi 4G is now connected and ready to use. 6. ENDING YOUR SESSION • S witch your device off, or disconnect via your Wi-Fi network icon status bar. 7. RECHARGING YOUR SIM • Go to telstra.com/myaccount and follow the prompts.

  • Page 18: Extra Features

    If you wish to use TS9 compatible antennae , please contact ZTE on 1300 789 475 during business hours EST or visit zte.com.au/telstra/MF91.htm for two free TS5 to TS9 adaptors. When conneting an antenna ensure to insert the connector carefully to avoid damage to your device.
  • Page 19 • Close the memory card slot cover. • C onnect the wireless device to your computer using the USB cable supplied and the memory card will display as an external drive.

  • Page 20: Home Page

    WI-FI HOME PAGE You can activate, check data usage and change the settings of your Pre-Paid Telstra Wi-Fi 4G through your Wi-Fi home page. The home page can only be accessed after connecting via Wi-Fi on your device. LOGIN TO YOUR WI-FI HOME PAGE • O pen a web browser and enter http://telstra.wifi.4g...
  • Page 21 CHECK DATA USAGE • To check your data usage click on ‘My Data Usage’ link on top right hand corner of your Wi-Fi home page. HOW TO CHANGE WI-FI HOME PAGE PASSWORD • Go to Settings Tab • Select Device Security, then select Admin password HOW TO CHANGE SECURITY KEY (WI-FI PASSWORD) • Go to Settings Tab • Select Wi-Fi Settings, then select Security Settings You can also enable or disable the security key (Wi-Fi password) from being displayed on your device screen by selecting Settings > Wi-Fi Security > Basic Settings.

  • Page 22: Problem Solving

    PROBLEM SOLVING Symptoms Possible Problems/ Solutions I cannot access Check the LCD display status. Make sure you the internet at all have network coverage in your area. Check that your SIM card is active and enabled with data services. Please wait 1–2 minutes for the device to initialize.

  • Page 23: Warranty And Support

    WARRANTY AND SUPPORT • A ll calls and support for PIN numbers, SIM card registration, account and billing information, network services and other general enquiries should be directed to Telstra. • S ee your warranty card for warranty and service information. • V iew Frequently Asked Questions online at http://www.zte.com.au/telstra...

  • Page 24: Technical Specifications

    TECHNICAL SPECIFICATIONS Network and LTE 1800/2600 MHz Frequency Band UMTS/HSPA+ 850/900/2100 MHz GPRS/EDGE 850/900/1800/1900 MHz Wi-Fi working range approx 25m radius in free space Wi-Fi Connections supports up to 5 users Dimensions (W×H×D) 100 x 58 x 16mm Weight 105g microSD™ or Up to 32GB microSDHC™...
  • Page 25 Operating Systems ® ® ® Windows 8, Windows RT, Windows Vista and XP. 32 and 64 bit. Mac OS 10.5.8 and above.

  • Page 26: Extra Bits You Should Know

    Visit telstra.com/mobilebbcoverage to check if you are covered. NETWORK LOCK • Your wireless device is locked to the Telstra network. • W hen you insert a non-Telstra SIM card you are presented with unlock instructions. • Contact Telstra to obtain your 16 digit unlock code. • An unlocking fee may apply. • 5 incorrect attempts will block the unlock process and the device will then only work with a Telstra SIM card. • Contact Telstra for more information.
  • Page 27 Windows is a trade mark of the Microsoft group of companies. ™ and are trade marks and registered trade ® marks o f Telstra Corporation Limited, ABN 33 051 775 556.
  • Page 28 FOR MORE INFORMATION CALL 125 8880 or FROM A NON-TELSTRA PHONE, CALL 13 2200 AND SAY “PRE-PAID” VISIT telstra.com/ppmbb VISIT A TELSTRA STORE OR PARTNER...
