Summary of Contents for Howden HJA8501
-
Page 1: Washing Machine
Integrated HJA8501 HJA8511 Washing Machine User & installation Guide... - Page 2 Built-In Appliances Dear Customer, Congratulations on your choice of washing machine which has been designed to give you excellent service. The user manual will help you use your machine quickly and safely. • Please read this user manual before installing and using the machine. •...
-
Page 3: Table Of Contents
User manual HJA8501 / HJA8511 Index 01 - Your washing machine Time display Overview Starting the Programme Technical specifi cations Progress of programme Changing the selections after 02 - Warnings & safety information the programme has started General Safety Switching the machine to standby mode... -
Page 4: Your Washing Machine
Top lid Control panel Filter cap Adjustable feet Door Detergent drawer Drain hose Technical specifi cation HJA8511 HJA8501 Maximum Dry Capacity (kg) Height (cm) Width (cm) Depth (cm) Net Weight (+/- 4Kg.) Electrical Input (V/Hz) 230V / 50Hz 230V / 50Hz... -
Page 5: Warnings & Safety Information
User manual HJA8501 / HJA8511 02 - Warnings & safety information Failure to read and follow these guidelines may Amperes, please have a qualifi ed electrician result in personal injury or damage to the machine install a 16 Ampere fuse or circuit breaker. -
Page 6: If There Are Children In Your House
Built-In Appliances • Never attempt to repair the machine yourself. Otherwise, you may be putting your and other’s lives in danger. • For malfunctions that cannot be solved by information in the operating manual turn off the machine, unplug it, turn off the water tap and contact an authorized service agent. -
Page 7: Installation
User manual HJA8501 / HJA8511 03 - Installation To make the product ready for use, review the information in the user manual and make sure that the electricity, tap water supply and water drainage systems are appropriate. If they are not, call a qualifi... -
Page 8: Connecting Water Supply
Built-In Appliances Do not use old or used water inlet hoses on the new product. It may cause stains on your laundry. Connect the special hose supplied with the product to the water inlet on the product. Attach the plastic covers supplied in the User Manual bag into the holes on the rear panel. -
Page 9: Connecting To The Drain
User manual HJA8501 / HJA8511 Connecting to the drain Adjusting the feet • The end of the drain hose must be directly In order to ensure that the product operates connected to the wastewater. silently and vibration-free, it must stand level and balanced on its feet. -
Page 10: Electrical Connection
Built-In Appliances Electrical connection Important Fitting a different plug Connect the product to an earthed outlet protected As the colours of the wires in the mains lead of this by a fuse complying with the values in the appliance may not correspond with the coloured “Technical specifi... -
Page 11: Removing The Transportation Locks
User manual HJA8501 / HJA8511 First use Transportation of the product Before starting to use the product, make sure Drain any remaining water in the product that all preparations are made in accordance completely; see, “Draining remaining water with the instructions in sections “Important safety and cleaning the pump fi... -
Page 12: Preparation
Built-In Appliances 04 - Preparation Things to be done for energy saving Wash with sensitive, Following information will help you use the product Washing water .short programmes temperature in an ecological and energy-effi cient manner. • Operate the product to the highest capacity allowed by the programme you have selected, but do not overload;... -
Page 13: Preparing Laundry For Washing
User manual HJA8501 / HJA8511 Preparing laundry for washing This will reduce piling. • Laundry that are subjected to materials such as fl our, lime dust, milk powder, etc. Intensely • Laundry items with metal attachments such must be shaken off before placing into the as, under-wired bras, belt buckles or metal machine. -
Page 14: Loading The Laundry
Built-In Appliances Loading the laundry Middle compartment with number “I” (pre- wash compartment for powder detergent, powder stain remover or liquid bleach - liquid • Open the door. bleach must be added either during the pre- • Place laundry items loosely into the machine. wash or during the fi... - Page 15 User manual HJA8501 / HJA8511 will reach the laundry without water and may cause Bleaches stains on the garments. In this case you will need to If you are going to use regular bleach in your refi ll the compartment. Do not pour the detergent...
-
Page 16: Tips For Effi Cient Washing
Built-In Appliances Tips for effi cient washing CLOTHES Dedicates/ Light Colours And Whites Colours Dark Colours Woollens/Silks Recommended (Recommended (Recommended (Recommended temperature temperature range based temperature range based temperature range based range based on soiling level: on soiling level: on soiling level: on soiling level: 40-90C) cold-30C) cold-40C) -
Page 17: Selecting A Programme Operating Your Machine
User manual HJA8501 / HJA8511 05 - Selecting a Programme & Operating Your Machine Control panel Spin Speed Adjustment Button Display Temperature Adjustment Button Programme Selection Knob On/Off Button Time Delaying Button (+/-) Auxiliary Buttons Start/Pause/Cancel Button Selecting a Programme & Operating Your Machine... -
Page 18: Display Symbols
Built-In Appliances Display symbols Main programmes Depending on the type of textile, the following main c d e programmes are available: Each of these main programmes comprise of a complete washing process, including washing, rinsing and, if required, spin cycles. When selecting the programme you are going to use, always consider type of fabric, colour, degree of soiling and permissible water temperature. -
Page 19: Additional Programmes
User manual HJA8501 / HJA8511 Additional programmes woollen shampoo with this programme. • Mixed Fabrics For special cases, there are also extra programmes You can use this programme to wash cottons and available: synthetics together. There is no need to sort them. -
Page 20: Special Programmes
Built-In Appliances Special programmes Economy symbol For specifi c applications, select any of the following Shows energy saving programmes and temperature programmes: selections. As “Intensive” and “Hygiene” programmes are long • Rinse programmes with higher temperature selections This programme is used when you want to rinse or to ensure hygiene, “... -
Page 21: Programme And Consumption Table
User manual HJA8501 / HJA8511 Programme & consumption table Auxiliary functions Programme (º C) Cottons 2.30 1600 • • • • • 90-Cold Cottons 1.50 1600 • • • • • 90-Cold Cottons 0.85 1600 • • • • •... -
Page 22: Auxiliary Functions
Built-In Appliances Auxiliary functions water, detergent and time. • Pre-wash without detergent is recommended for lace and curtains. Auxiliary Function Selection Buttons • Quicker Wash With this function (b), the wash time is shortened. “F2” symbol lights up on the display. Use this function for smaller amounts or slightly soiled laundry. -
Page 23: Time Display
User manual HJA8501 / HJA8511 Time display symbol will fl ash. The Start Symbol will fade. Press “Time delaying” buttons “+” or “-” to set your desired time delay. The display shows the time remaining for the Press “Start/Pause/Cancel” button. The Time programme to complete while a programme is delaying symbol will light up. -
Page 24: Standby Mode
Built-In Appliances Switching the machine to Pre-wash When “prewash” auxiliary function is selected, standby mode prewash symbol will light up to indicate the beginning of prewash step. The machine is switched to standby mode Main wash by pressing “Start/Pause/Cancel” button Main wash symbol will light up to indicate that the momentarily. -
Page 25: Child-Proof Lock
User manual HJA8501 / HJA8511 Child-proof lock Ending the programme through cancelling Protect the appliance from being tampered with by children by means of the child-proof lock. In “Start/Pause/Cancel” button is pressed for 3 this case, no change can be made in the running seconds to cancel the programme. -
Page 26: Maintenance & Cleaning
Built-In Appliances 06 - Maintenance and cleaning Detergent Drawer Remove any powder residue buildup in the drawer. To do this; • Open the hole in the bellow with the aid of a toothpick if it is clogged. Foreign metal substances in your machine can You can remove the detergent drawer by cause rust stains. -
Page 27: Inlet Water Fi Lters
User manual HJA8501 / HJA8511 Inlet water fi lters to clean it every 2 years or whenever it is blocked. Water must be drained off to clean the pump fi lter. There is a fi lter at the end of the water intake valve... -
Page 28: Troubleshooting
Built-In Appliances 07 - Troubleshooting TROUBLESHOOTING GUIDE Symptoms Possible Cause Solutions Programme cannot be • Washing machine has switched to Press and hold Start / Pause / Cancel button for 3 started or selected. self protection mode due to a supply seconds to reset the machine to factory settings. - Page 29 User manual HJA8501 / HJA8511 TROUBLESHOOTING GUIDE Symptoms Possible Cause Solutions Door cannot be opened. • Door lock is activated because of the Drain the water by running the Pump or Spin programme. water level in the machine. • Machine is heating up the water or it Wait until the programme completes.
- Page 30 Built-In Appliances TROUBLESHOOTING GUIDE Symptoms Possible Cause Solutions Machine does not switch to • There might be an imbalance of Automatic unbalanced load detection system might spinning step. laundry in the machine. be activated due to the unbalanced distribution of the laundry in the drum.
- Page 31 User manual HJA8501 / HJA8511 TROUBLESHOOTING GUIDE Symptoms Possible Cause Solutions Colour of the clothes is • Excessive laundry was loaded in. Do not load the machine in excess. fading. • Detergent in use is damp. Keep detergents closed in an environment free of humidity and do not expose them to excessive temperatures.
- Page 32 Built-In Appliances TROUBLESHOOTING GUIDE Symptoms Possible Cause Solutions Detergent residue in the • Detergent is put in wet drawer. Dry the detergent drawer before putting in detergent. detergent drawer. • Detergent has gotten damp. Keep detergents closed in an environment free of humidity and do not expose them to excessive temperatures.
- Page 33 User manual HJA8501 / HJA8511 TROUBLESHOOTING GUIDE Symptoms Possible Cause Solutions Foam is overfl owing from the • Too much detergent is used Mix 1 tablespoonful softener and ½ l water and pour into detergent drawer. the main wash compartment of the detergent drawer.
-
Page 34: Built-In Installation
Built-In Appliances 08 - Built-in Installation 541mm 591mm 580 min 820mm 20-842mm 51mm 151mm 11mm Standard Height Door & False Drawer Adjustable Feet Fasten the drawer front to the door with 2x steel The feet are adjustable to give an appliance height jointing plates (supplied separately). - Page 35 User manual HJA8501 / HJA8511 Fittings 2) Attach Door Fittings S1 (x8) S2 (x6) A (X2) 3) Connect Brackets B (x2) C (x2) 1) Prepare the door 4) Connect Brackets _ 35 Built-in Installation...
-
Page 36: Guarantee
Built-In Appliances 09 - Your guarantee Product Guarantee Details (UK only) Your appliance has the benefi t of a comprehensive manufacturer’s guarantee which covers the cost of breakdown repairs. (Details of which are shown on your Proof of Purchase Document). •... - Page 37 User manual HJA8501 / HJA8511 _ 37...
- Page 38 Built-In Appliances Notes...
- Page 39 User manual HJA8501 / HJA8511 Notes _ 39...
- Page 40 ISSUE v1-170712 If supplied, please stick your self adhesive product rating plate here, or make a note of the product serial number below in the box below for future reference. Serial Number : ................... 2820523066_EN...
