- Page 1 Model: HD41-ARC Installation Guide...
-
Page 2: Table Of Contents
Contents Application Diagram ............3 Description ..............3 Features ................4 Installation ............... 4 Remote Control Guide ............ 6 RS232 Control Commands ..........7 USB Service Port.............9 Smart Scan ..............9 Customization..............10 1 RU Rackmount............11 Disabling / Enabling IR Remote Control Receiver..11 Warranty.................12 Disclaimers..............12 Specifications..............13... -
Page 3: Application Diagram
Application Diagram Description: The Octava 4x1 HDMI switch +ARC is a complete HD video and audio switch solution designed to work with HDTV's with ARC(audio return channel) and your existing audio receiver system with Optical Audio Inputs. The Octava 4x1 HDMI switch +ARC includes: 4 HDMI inputs, 4 Optical Audio inputs, 1 Optical Audio output, 1 HDMI output with ARC support. -
Page 4: Features
Features: Switch 4 HDMI sources to 1 output 3D support , 1080P 4 Optical Audio Inputs 1 Optical Audio Output Optical audio mode 1: convert HDMI audio to optical output Optical audio mode 2: convert HDMI ARC from HDTV to Optical Audio Format Optical audio mode 3: Switch directly from the 4 Optical inputs to the Optical Output... -
Page 5: Front View
LED Indicators Front View Infrared Detector Manual Select DC Power Optical Audio Back View Input Output RS232 Optical Audio HDMI Infrared Sources Sources Jack HDMI Output (To TV) USB/RS232 Select Toslink Audio Select HDMI Select Change Digital Audio Change HDMI input Output Source Port Examples... -
Page 6: Remote Control Guide
Press to directly switch optical input. 1-4 Switch Optical input 1-4 +/- Switch Optical input to next input Hint:Press OPT to synchronize the Optical Input Port to the HDMI port # selected. Turns ON/OFF the LED light. Turns ON/OFF the HD41-ARC... -
Page 7: Rs232 Control Commands
RS232 Control Commands: The Octava HD41-ARC can be easily integrated with 3 Party control systems via RS232 control. The following shows the control protocol: Set the switch to RS-232 side as shown. RS-232 protocol Baud Rate 9600 Data Bits Parity Check... - Page 8 Video Switching Commands Note: The commands are in HEX. No spaces between HEX codes. “0x” denotes HEX and not part of command Output A Switching Commands HEX CODE Select OUT A to Input port 1 0x02 0x32 0x31 0x03 Select OUT A to Input port 2 0x02 0x32 0x32...
-
Page 9: Usb Service Port
USB Service Port: The USB port is for service and updates if needed. Contact us if you need service. Set the switch to USB/Program side as shown. Smart Scan Smart Scan will automatically switch to the HDMI input source when the input source is turned on and detected. If no HDMI sources are detected, then the switch will go into standby mode. -
Page 10: Customization
Customization: The HD41-ARC MCU Program enables you to customize the behavior of HD41-ARC for your needs. HD41-ARC MCU Program is free and can be downloaded from: http://www.octavainc.com/support%20and%20updates.html Requires : Windows XP, 7... -
Page 11: Ru Rackmount
1 RU Rackmount : The Octava HD41-ARC can be installed in a 1 RU rack by simply installing the rack mounts included. Disabling /Enabling Front Panel IR Remote Receiver: To disable the front panel IR remote receiver-insert the plastic plug into the IR jack as shown. -
Page 12: Warranty
If Octava's equipment fails because of defects (1) year from the date of receipt, Octava will at its option, A) repair or replace the equipment, or B) request return of equipment for refund of the price paid for the product provided that the equipment has not been subjected to mechanical, electrical or other abuse or modifications. -
Page 13: Specifications
For Questions and support: Email: info@octavainc.com URL: www.octavainc.com Copyright© 2013 Octava Inc. All rights reserved. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LL.C All trademarks are the sole property of their respective companies Rev.E...
